Maytag 661S/W Bedienungsanleitung

Use & Care Guide

Dishwasher

MAYTAG MSE 661

1. Loading the baskets

Remove large food particles and debris. There is no need to rinse thanks to the Super

Cleaning System™.

2. Dispensing dishwasher detergent

The detergent compartment has a small compartment for pre-wash and one for main wash.

3. Ensure that the spray arms can rotate freely

4. Switch on the main switch

5. Close the door

6. Select program and press start

For washing normally soiled mixed loads use the Normal wash program with

normal temperature and normal drying .

To save more water and energy use economy temperature and economy drying.

Mini Program Guide

Quick Guide

70°C

65°C

70°C

30°C

Program

Press

Program

Options

How the

machine

works

Temperature

Main wash

Final rinse

Heavy

soil

Normal

wash

Quick

wash

Rinse &

Hold

Contents

Page

Contents 3-4

Before doing your first wash 5

Read through the directions for use

Take care with certain materials

Check the door

Check water hardness level

Machines with water softener

Safety 6

General

Winter storage/Transport

Overfill protection

Cleaning

Packaging materials

Scrapping

Child safety 7

Child-safe dishwashing

Protect your children! Dishwasher

detergent is corrosive

Parts of the dishwasher 8

Technical information 8

Baskets 9

Control panel 10

Dispenser 10

Basic Course 11-12

Load the baskets correctly

Dispense dishwasher detergent

Select program

Options 13

Temperature

Drying

Press start

Changing options

Do you want to load more dishes?

If the machine is switched off with

the main switch

After dishwashing

Eco-dishwashing 14

Only perform washes with a full machine

Do not rinse before dishwashing

Choose environmentally-friendly

dishwasher detergent

Fragile dishes 15

Fragile decoration

Crystal/glass

Silver

Cutlery with glued handles

Wood

Aluminium

Plastic

Protect plastic goods

Standard program 16-17

Cleaning 18-19

Coarse filter

Fine filter

Drain pump

Spray arms

Door

Rinse aid 20

Pour in rinse aid

Select dosage

Salt 21

Pour in salt

Settings 22

Setting water hardness

Fault indications 23

Troubleshooting 24-26

The dishes are not clean

Stains or a film on the china

The china has a whitish-blue sticky film

Stains on stainless steel or silver

Stains which remain after dishwashing

Rattling sounds during dishwashing

The machine will not start

Water remains in the machine

Overfilling/ leakage

Bad odour in the machine

Performance information 27

Installation 28-32

Suggestions on positioning the dishwasher

A. Built-in

B. Freestanding

C. Semi-freestanding

Connection to water supply

Connection to electricity

Drainage connection

Positioning the machine

A. Adjusting machines with six feet

(freestanding dishwasher)

B. Adjusting machines with three

or four feet

C. Adjusting dish washers with

adjustable foot

Installing the plinth

(Only with kick-plate as accessory)

Screw the dishwasher into place

Fitting strip seal (on floor plinth

covering plate)

NB! Not all models

Setting water hardness

Service & guarantee 33

Own comments 34

Search words 35

Before doing your first wash

Read through the directions for use

Read through the directions for use before

starting to use your machine, especially the

Safety, Child Safety and Basic Course

sections.

Take care with certain materials

Read the section ‘Fragile dishes’ before

washing china with unglazed decoration or

other household goods made of plastic,

wood or crystal requiring careful treatment.

Check the door

Check that the door of the dishwasher fits

properly: open the door a little and let it go.

Does it stay exactly where you released it?

If not, you should check the installation

instructions or consult the installer.

Check water hardness level

Phone your local Water Board to check the

water hardness in your area. This is important

when dispensing dishwasher detergent and

rinse aid.

Machine with water softener

Once you know the water hardness, you

can set the water softener, see Settings.

Before you start dishwashing, you must

also fill with salt, see Salt.

Safety

General

• Read and keep the directions for use!

• Installation of water, drainage and electricity

must be carried out by a qualified professional.

• Do not use the dishwasher for any pur-

poses other than those stated in these

directions for use.

• Do not load the dishwasher door or the

dishwasher baskets with anything other

than dishes.

• Only use dishwasher detergent!

• Place knives and other sharp objects so

that they cannot cause injury to people or

damage the dishwasher.

Never put dishes containing solvent residue

in the machine due to risk of explosion.

Neither may dishes containing ashes, wax

or lubricating grease be washed in the

dishwasher.

Winter storage/Transport

Store the machine away from frost.

Avoid long journeys in extreme cold. Trans-

port the machine in an upright position or

lying on its back.

Overfill protection

The overfill protector starts pumping out

water and closes off the water intake if the

machine’s water level exceeds the normal

level. If the overfill protector starts up, shut

off the water supply and phone for service.

See also ‘Troubleshooting’ on pages 23-25.

Cleaning

Only use a slightly damp cloth for cleaning

around the edge of the door. Do not use a

spray bottle! Water can penetrate into the

lock and come into contact with the elec-

trical components.

Packaging materials

Sort at source in accordance with the re-

commendations of your local authority.

Scrapping

When the time comes for the machine to be

scrapped, it should immediately be ren-

dered unusable. Remove the plug and cut

off the lead as short as possible.

Contact the refuse collection department or

your local authority for information on the

correct way to dispose of the dishwasher!

The dishwasher is manufactured and la-

belled for recycling.

Child-safe dishwashing

• Always close the door and start the pro-

gram immediately once dishwasher deter-

gent has been added.

• Keep children away from the dishwasher

when it is open. There might be the remains

of dishwasher detergent present!

• Do not allow children to use or play with

the dishwasher. Always take particular care

when the door is open.

Protect your children!

- Dishwasher detergent is corrosive!

Store dishwasher detergent and rinse aid

out of the reach of children! Should dish-

washer detergent be swallowed, immedi-

ately drink one or two glasses of milk or

water. Do not attempt to induce vomiting.

Contact a doctor! Should dishwasher deter-

gent come into contact with the eyes, rinse

(for at least 15 minutes) with copious

amounts of water.

Child safety!

Parts of the dishwasher*

Technical information

Height

Width

Depth

Weight

Capacity**

Water pressure

Connection

Max output

Accessories

* Details may differ depending on model and

market!

**In accordance with standard, EN 50242.

***See type plate.

****Without fitted wooden door.

820-870 mm

596 mm

550 mm****

48 kg/51 kg with water softener*

12 place settings

0.03-1.0 MPa (0.3–10 kp/cm2)

1-phase, 200V/ 230 V, 50Hz/60Hz

10/10A***

1550W/ 1900 W***

Work surface, Side panels, Anti-tilt

1. Knife basket

2. Upper basket

3. Spray arms

4. Lower basket

5. Cutlery basket

6. Rinse aid dispenser

7. Dishwasher detergent compartment

8. Main switch

9. Program panel

10. Filter

11. Type plate

* Details may differ

depending on model and market!

Baskets*

*Details may differ depending on the model

and market!

Cutlery basket

Upper basket

Lower basket

1. Wine glass shelf

2. Cup rack

3. Knife stop

4. Cutlery basket with door and folding

handle

1. Program selector

2. Heavy soil

3. Normal wash

4. Quick wash

Control panel

Dispenser

1. Compartment for main wash dishwasher

detergent

2. Compartment for pre-wash detergent

3. Refill indicator rinse aid (not all models)

4. Rinse aid cover

5. Detergent compartment cover

5. Rinse & Hold

6.Temperature

7. Drying

8. Start/stop
