Use & Care Guide

Tumble Dryer

MAYTAG

MDE 9701

MDE 9801

CONTENTS

READ FIRST Page

1 Before tumble drying for the first time 3

2 Safety instructions 4

General,Installation,Safety,Interruptinga

programme, Transport/Winter storage,

Packing materials, Disposal

3 Child safety 5

General, Child lock on Start button

4 Parts of the tumble dryer 6

5 Panel 7

6 Option buttons 7

INSTALLATION

See Installation Instructions

TUMBLE DRYING

7 Before tumble drying 8-10

Spin-dried? Recommended washing mar-

king,Sortingfabrics,programmes,Options,

Temperature, Drying time

8 Tumble dry 11-14

Tumble dry – step-by-step

9 Consumption values 15

CARE Page

10 Care and cleaning 16-18

Cleaning the lint filter, Draining the con-

densation water container, Cleaning the

outside of the machine, Cleaning the fan,

Cleaning the condenser

PROBLEMS?

11 Trouble shooting 20-21

Machine will not start, Overheating pro-

tection, Drying takes too long, Fault indi-

cation on the display, Normal indications

on the display

MISCELLANEOUS

12 Technical information 23

Technical data, Standard tests

13 Service and guarantee 25

14 Quick guide 26

15 Index 27

1BEFORETUMBLEDRYINGTHEFIRSTTIME

READ THE OPERATING INSTRUCTIONS

Please read through this Use and Care Guide

before attempting to use the machine, particu-

larly Chapter 2, Safety instructions, and 3,

Children’s safety.

DO NOT TUMBLE-DRY

Some fabrics are sensitive to tumble drying.

Check the Recommended washing marking on

the items concerned, and study Chapter 7, Be-

fore tumble drying.

NOTE.

When you start the tumble dryer the first time,

or after a long period when it has not been in

use,youmayhearalightrumblingnoise.Thisis

quitenormalandthesound will disappear after

a few drying operations.

For brief operating instructions; see Chapter 14, Quick guide.

2SAFETYINSTRUCTIONS

GENERAL

• Study and save this Use and Care Guide for

future reference.

• Electrical installation, if required, must be

carried out by an authorized electrician.

• The machine may only be used for tumble

drying in accordance with this Use and Care

Guide.

• Repairs and maintenance which affect safety

or performance must be carried out by an aut-

horized specialist.

• Damaged mains cables must only be repla-

ced by an authorised professional.

• Sufficient ventilation is required to prevent

smoke from open fires or fumes from equip-

ment burning other fuels being sucked into the

room.

INSTALLATION

Seetheaccompanyinginstallationinstructions.

SAFETY

Thismachinemaynotbeusedfordryingfabrics

that have been dry-cleaned at home, or which

canbesuspectedofcontainingresiduesofflam-

mablefluids.

The tumble dryer is fitted with an overhea-

tingprotectiondevice,whichswitchesthemach-

ine off in the event of excessive temperature.

A float valve switches the machine off if the

condensation water hose becomes clogged, or if

there is danger of water flowing over from the

container.

INTERRUPTING THE PROGRAMME

You can interrupt a drying programme by ope-

ning the door, causing the drum to stop auto-

matically. The machine will then “remember”

the point in the drying programme at which it

was interrupted. Restarting: close the door and

press the button.The machine will rest-

art automatically from the point at which the

programme was interrupted.

You can also interrupt a programme by pres-

singthe button for three seconds. If you

interrupt a programme with this button, the

machine will forget where it was in the pro-

gramme, and you will have to select a new pro-

gramme to restart.

TRANSPORT/WINTER STORAGE

If the machine is to be transported or stored

during the winter, on unheated premises, ensu-

re that the water container is drained.

PACKING MATERIAL

Sort the packing material for recycling according

to recommendations by the local authorities.

DISPOSAL

When the machine is no longer useful and is to

be scrapped it should be made unusable.

Get in touch with the refuse collection servi-

ce or your local authorities for advice on how to

scrap the machine in a proper manner.

Themachineismade and markedtofacilitate

recycling.

CAUTION!

Duringtheprogramme, the back of thetumble

dryer will get very hot. Leave the machine to

cool completely before touching the back.

GENERAL

Do not allow children to play with the tumble

dryer.

The tumble dryer is fitted with a magnetic

catch, which allows the door to be opened from

the inside. The door is equipped with a switch,

whichautomaticallystopsthetumbledryerwhen

the door is opened. The machine will not start

automatically on closing the door (eg, if a child

should close the door from the inside).

CHILD LOCK ON BUTTON

You can prevent a child from starting the tum-

bledryerbymistake.You candothisbylocking

the button, as follows.

Child lock On/Off:

Set the programme selector knob to the posi-

tion in which it points directly upwards.

Turn off the main power switch and

then turn it on again so that the machine is in

stand-by mode.

Press the button five times, and then

pressthe buttonfivetimes.Thesetenpres-

ses must be completed within 15 seconds.

Within three seconds after pressing the

button for the last time, you must then use the

button to select Child lock On (the figure

3 appears in the display) or Off (the figure 0

appears in the display).

Start a programme with the button

locked:

To start the machine, you must hold the

button down for three seconds.

3CHILDREN’SSAFETY

1. FLUFF-FILTER HOLDER

2. DATA PLATE

3. CONDENSATION WATER CONTAINER

4. PANEL

5. OUTER DOOR

4PARTSOFTHETUMBLEDRYER

6. FAN (BEHIND THE LOWER COVER)

7. CONDENSER (BEHIND THE LOWER

COVER)

8. LINT FILTER

Start/Stop

5PANEL

1. INDICATOR LAMP ON/OFF

2. MAIN POWER SWITCH

3. PROGRAMME SELECTOR KNOB

THE PROGRAMMES ARE DESCRIBED IN

CHAPTER 7, BEFORE TUMBLE DRYING.

4. DISPLAY

5. START BUTTON WITH LED TO INDICATE

STARTED PROGRAMME

6. SETTING AND OPTION BUTTONS

7. STOP BUTTON WITH LED TO INDICATE

THAT THE PROGRAM IS COMPLETED

1 4

235

6OPTIONBUTTONS

4 5 6

1 2 3 1. TIME ADJUSTMENT BUTTON FOR TIMED

DRY AND AIR FLUFF PROGRAMME

2. ANTI-CREASE PROGRAMME BUTTON

3. DELAYED START BUTTON

4. LOW TEMPERATURE BUTTON

5. BUZZER BUTTON

6. QUICK COOLING BUTTON

The LEDs indicate that the associated choice

has been activated.

Air fluff

Timed dry

Iron dry

Normal dry

Dry

Extra dry

Start

Stop

MDE 9701. CONDENSER SENSOR DRY

7BEFORETUMBLEDRYING

Before you start tumble drying, here is some

advice that can be useful.

SPIN-DRIED?

Items that are to be tumble dried should first

bespin-dried,preferably at800revsper minute

or more. Better spin drying saves both energy

anddryingtime.

RECOMMENDED WASHING MARKING

Material suitable for tumble drying

The symbol above indicates that the material

can be tumble-dried. Cotton fabrics, towelling

and synthetic fibres are best suited to tumble

drying. Clothes and fabrics become softer and

fluffier when tumble-dried than when dried on

a line.

NOTE

Wear and tear of fabrics in a tumble dryer is

minimal. The lint caught in the lint filter con-

sists of dust and fibre residue that has been for-

med when wearing the garments.

Material which should not be tumble-

dried

Thissymbolindicatesthat the material will not

withstandtumble-drying.

Certain materials will melt or become dan-

gerously flammable if heated, while others will

loose their shape or shrink.

Do not tumble-dry...

• Materials that are marked “Do not dry close

to heat”.

• Items that have been dry-cleaned at home.

• Foam plastic.

• Glass-fibre materials

• Woollen items, because of the risk of felting.

SORTING FABRICS

Best results are obtained if all articles are of the

same material.

Close zip-fasteners, button up garments, tie

belts, and sort the fabrics and adapt the load

and the temperature as shown in the table be-

low.

TYPE OF FABFIC LOAD TEMPERATURE

White, coloured Cotton and 1/1 (6.0 kg) Normal

and synthetic linen

Polyester/ 1/2 (3.0 kg) Normal

cotton

Delicate and Acrylic, rayon, 1/2 (3.0 kg) Low

mild acetate etc.

Sort a suitable amount and type of fabric.

PROGRAMMES

Yourchoiceofprogrammewilldependonwhat

you wish to do with the fabrics after tumble

drying.TheavailableprogrammesareExtradry,

Dry,Normaldry,Irondry,Timeddryprogram-

meandAirfluff.

Extra dry

Thisprogrammeis designed for washing thatis

extremely difficult to dry, eg, jeans with very

thick seams.

NOTE

Knittedfabricsinparticularareliabletoshrink.

Use the Dry, Normal dry or Iron dry program-

meforthesematerials.Always stretch garments

out directly after drying.

Dry, Normal dry

These programmes turn off the heat when the

washing is dry, but not bone-dry.

The Dry programme turns off the heat a litt-

lelater than Normal dry. Choose what youpre-

fer by trial and error. Use these programmes

when you want dry fabrics.

Iron dry

This programme turns off the heat when the

washingisjustdampenoughforironingormang-

ling.

Timed dry

The programme length that you should choose

depends on what you wish to do with the fa-

brics after tumble drying. Dry different times

for different materials to find the right combi-

nation.

When using a timed dry programme with

mixed washing it may happen that some of the

items will not be sufficiently dried. Such items

cansuitablyby driedbyrunningthetimedpro-

gramme for a further 10 minutes or so.

Timed dry programmes automatically opera-

tes at temperature Low, but you can change it

yourself to Normal.

NOTE

Whenusingatimedprogrammeitispossibleto

over-dry fabrics if you set too long a time.This

can cause fabrics to shrink or crease and feel

rough.Syntheticmaterialscanalsobecomechar-

ged with static electricity. Set a shorter time if

you tumble dry at temperature Normal.

Air fluff

Use the air fluff programme just to shake dust

out of garments, air them or soften them up.

ToselectTimeddryprogrammeorAirfluffpro-

gramme, see Chapter 10, Making own drying

programmes.

OPTIONS

To choose these options, see Chapter 10, Ma-

kingowndryingprogrammes.

Cooling

You can choose between Normal cooling and

Quick cooling . Normal cooling lasts 20

minutes and Quick cooling lasts 5 minutes.

Buzzer

The machine offers you the possibility of hea-

ring when the cooling period ends. Set the op-

tion Buzzer on and it will sound for three

seconds when the programme is completed.

Anti-crease

You can select the anti-crease option to

prevent the fabrics from lying still and beco-

ming creased at the end of tumble drying.This

is a helpful option if you are unable to take out

the fabrics promptly at the end of the tumbling

phase.

Youcanchooseaprogrammedurationof1,2

or 3 hours. The drum will then continue to

rotate intermittently, i.e., three seconds every

minute for the number of hours chosen.

IfyouchooseBuzzerON, a signal willsound

each time the drum rotates.

TEMPERATURE

You can select Low temperature for the

Extra dry, Dry, Normal dry and Iron dry pro-

grammes.

DRYING TIME

Thedryingtimemaybeinfluencedbyanumber

of factors, such as the size of the load, the pro-

gramselected,the moisturecontentoftheload,

the materials being washed, connection capaci-

ty and the ambient temperature and humidity.

Dryingtimeremainingiscalculatedwithinfour

minutesofthe startofthe drying program.The

estimated time is shown in the bottom right-

hand corner of the display, together with the –

symbol.

If the actual drying time is less than that calcu-

lated, the time display may jump ahead, e.g.

from 50 to 20 minutes, at the end of the pro-

gram.

If the actual drying time is longer than that

calculated, the countdown will stop at the end

of the progam until the load is dry.

Please note that times include a cooling period.

The remaining drying time is estimated ap-

proximately(withinfour minutesofthestartof

the drying programme) and is shown on the

display in intervals of five minutes.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Maytag Trockner Handbücher

Maytag

Maytag EPIC MGD9700S Bedienungsanleitung

Maytag

Maytag MDG17CSBGW Bedienungsanleitung

Maytag

Maytag MLE24PDAZW0 Bedienungsanleitung

Maytag

Maytag MGDE500VW - Performance Series Front Load Steam Gas... Bedienungsanleitung

Maytag

Maytag MDE22PN Bedienungsanleitung

Maytag

Maytag MGD5600TQ1 Bedienungsanleitung

Maytag

Maytag MEDZ400TQ1 Bedienungsanleitung

Maytag

Maytag MED5600TQ - Electric Dryer Bedienungs- und Montageanleitung

Maytag

Maytag 3RMED4905TW0 Bedienungsanleitung

Maytag

Maytag Neptune MDE5500AYQ Bedienungsanleitung

Maytag

Maytag Epic W10150638A Bedienungsanleitung

Maytag

Maytag MED9700SQ - 27" Front-Load Electric Dryer Bedienungsanleitung

Maytag

Maytag MGDC300BW Bedienungsanleitung

Maytag

Maytag MDE2440 Bedienungsanleitung

Maytag

Maytag NEPTUNE WASHER Bedienungsanleitung

Maytag

Maytag MEDC500VW - Centennial Series 29 Inch Electric... Bedienungsanleitung

Maytag

Maytag W10562334A Bedienungsanleitung

Maytag

Maytag MED6400TQ0 Bedienungsanleitung

Maytag

Maytag W10385090A Bedienungsanleitung

Maytag

Maytag MGDE251YG Bedienungsanleitung

Maytag

Maytag D-8 Bedienungsanleitung

Maytag

Maytag BRAVOS MGD6600TQ0 Bedienungsanleitung

Maytag

Maytag LDE8706ADE Bedienungsanleitung

Maytag

Maytag 4KMEDX505BW0 Bedienungsanleitung

Beliebte Trockner Handbücher anderer Marken

Bosch

Bosch WTA79200GB Bedienungsanleitung

Amana

Amana W10233410A Bedienungsanleitung

Miele

Miele TWH 780 WP Bedienungsanleitung

Asko

Asko T760 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Bedienungsanleitung

Bosch

Bosch Logixx 10 WTB76556GB Technisches Datenblatt

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Bedienungsanleitung

Electrolux

Electrolux EW2H328R2 Bedienungsanleitung

Beko

Beko DS8433RX1M Bedienungsanleitung

Dawlance

Dawlance Spinner DS 6000 C Bedienungsanleitung

Electrolux

Electrolux TP5080TW Bedienungsanleitung

AEG

AEG TR838P4OB Bedienungsanleitung

Indesit

Indesit IDV 75 Bedienungsanleitung

Infiniton

Infiniton SD-DG85C Bedienungsanleitung

BOMANN

BOMANN WT 5019 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Bedienungsanleitung

Asko

Asko T793C Bedienungsanleitung

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Bedienungsanleitung
