Genio 350 Evaluation Kit
Quick Start Guide
Genio 350 EVK
Genio 350 Evaluation Kit Quick Start Guide
MediaTek Proprietary and Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document,
in whole or in part, is strictly prohibited.
Page 2 of 12
Version History
Version
Date
Author
Description
1.0
2022-04-12
MTK
First Release
Genio 350 EVK
Genio 350 Evaluation Kit Quick Start Guide
MediaTek Proprietary and Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document,
in whole or in part, is strictly prohibited.
Page 3 of 12
Table of Contents
1Packing list ............................................................................................. 4
2Genio 350-EVK System Setup.................................................................. 5
3Genio 350-EVK Board overview.............................................................. 6
4Camera board installation ...................................................................... 7
5DC Jack installation................................................................................. 8
6LCM/Touch Panel installation (1/2) ........................................................ 9
7LCM/Touch panel installation (2/2).......................................................10
8Bracing frame installation .....................................................................11
9How to Power Up The System ...............................................................12
Genio 350 EVK
Genio 350 Evaluation Kit Quick Start Guide
MediaTek Proprietary and Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document,
in whole or in part, is strictly prohibited.
Page 4 of 12
1Packing list
In box items
Qt'y
Note
1
Genio 350 EVK main board
1
2
AP1302 ISP board
2
Camera Board
3
AR0430 IAS sensor module
2
Camera Module
4
Mini-SAS cable
2
Camera Cable
5
TFT LCM MODULE 7 LCM+TP
1
6
FPC SSBE5 i350EVK
1
LCM FPC Cable
7
12V AC adaptor
1
8
AC cable
1
9
Plastic Pillars
4
10
Screw
4
Genio 350 EVK Document
http://download.mediatek.com/aiot/G350QSG
Genio 350 EVK
Genio 350 Evaluation Kit Quick Start Guide
MediaTek Proprietary and Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document,
in whole or in part, is strictly prohibited.
Page 5 of 12
2Genio 350-EVK System Setup
Please refer below pictures for entire assembled Genio 350 EVK, the entire peripherals include:
1: LCM Module with Touch Panel * 1 sets
2: Camera double board * 2 sets
3: Connectivity module with 2 antennas * 1 sets
4: Power Adapter * 1 sets
Genio 350 EVK
Genio 350 Evaluation Kit Quick Start Guide
MediaTek Proprietary and Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document,
in whole or in part, is strictly prohibited.
Page 6 of 12
3Genio 350-EVK Board overview
Please refer below picture for IO function overview of EVK.
Genio 350 EVK
Genio 350 Evaluation Kit Quick Start Guide
MediaTek Proprietary and Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document,
in whole or in part, is strictly prohibited.
Page 7 of 12
4Camera board installation
Install procedure:
Insert Mini-SAS Cable into Genio 350 EVK mainboard and Camera board corresponded connector.
Connector locations can be referred to the marks in the picture as below.
Mini-SAS cable is tightened down well, you should hear “click" sound.
Genio 350 EVK
Genio 350 Evaluation Kit Quick Start Guide
MediaTek Proprietary and Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document,
in whole or in part, is strictly prohibited.
Page 8 of 12
5DC Jack installation
Install procedure:
Plug Adapter into DC Jack connector.
After the EVK power is turned on, pay attention to the LED indicator is lighted on.
In normal condition, there are total 4 LED indicators will light, please refer the
marks of above picture.
Genio 350 EVK
Genio 350 Evaluation Kit Quick Start Guide
MediaTek Proprietary and Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document,
in whole or in part, is strictly prohibited.
Page 9 of 12
6LCM/Touch Panel installation (1/2)
Install procedure:
Step1: Remove paper tape of the LCM/Touch Panel to release 2 FPC cables, as picture 1.
[picture 1]
Step2: Insert the LCM FPC cable one terminal into the FPC connector of the LCM/Touch Panel, as
picture 2. After cable inserted, the FPC connector must be pressed down firmly.
[picture 2]
Genio 350 EVK
Genio 350 Evaluation Kit Quick Start Guide
MediaTek Proprietary and Confidential
© 2022 MediaTek Inc. All rights reserved.
Unauthorized reproduction or disclosure of this document,
in whole or in part, is strictly prohibited.
Page 10 of 12
7LCM/Touch panel installation (2/2)
Step3: Insert Touch Panel cable and LCM FPC cable into the FPC connector of the mainboard,
please refer picture 3 for cable position and direction. After cable inserted, the FPC connector must
be pressed down firmly.
[picture 3]
