Mercury 1st Mate Technisches Datenblatt
Operation and Installation
Manual
© 2021 Mercury Marine 1ST MATE
8M0159020 920 eng
eng
Declaration of Conformity
Mercury Marine declares that under our sole responsibility the following
products to which this declaration relates are in conformity with the
requirements of the following EU Directives:
Directives
2014/35/EU The Low Voltage Directive
2014/53/EU Radio Equipment Directive (RED)
2011/65/EU RoHS Directive
Equipment ‑ MOB Link Safety HUB
Marketed as 1st Mate HUB
Model number F3501
FCC ID 2AFOZF3501
IC 2AFOZ‑F3501
Equipment ‑ MOB Safety FOB
Marketed as 1st Mate FOB
Model number F3502
FCC ID 2AFOZF3502
IC 2AFOZ‑F3502
The following harmonized standards and normative documents are those
to which the products conformance is declared, and by specific reference
to the essential requirements of the referenced directives.
eng i
EU / EMEA
Health & Safety (Article 3.1(a)
of the RED)
EN 60950‑1:2006 + A11:2009 + A1:2010+
A12:2011 + A2:2013
EN 62368‑1: 2014/A11:2017
EN 62311: 2008
EMC (Article 3.1(b) of the
RED)
EN 301 489‑1 v2.2.0
EN 301 489‑17 v3.2.0
EN 55032:2015 + AC:2016
EN 55024:2010
EN 61000‑3‑2:2014
EN 61000‑3‑3:2013
Spectrum (Article 3.2 of the
RED)
EN 300 328 v2.1.1
EN 301 893 v2.1.1
Equipment within Certain Categories or Classes
(Article 3.3 of the RED)
N/A
RoHS Directive, 2011/65/EU EN 50581:2012
United States / Canada
FCC Rules and Regulations Part 15 Subpart C Section 15.247
ANSI C63.10: 2013
RSS‑247 Issue 2: February 2017
RSS‑Gen Issue 5 April 2018
American Boat and Yacht Council (ABYC) A‑33
Authorized Representative in the EU:
Name of authorized representative: Brunswick Marine in EMEA Inc.
Address: Parc Industriel de Petit‑Rechain
Town: Verviers Post Code: B‑4800 Country: Belgium
I, the undersigned, hereby declare that the equipment specified above
conforms to the above Directive and standards for CE Marking for sale in the
European Community.
ii eng
Name / function:
Christopher D. Drees, President,
Mercury Marine
Date and place of issue:
June 03, 2020
Fond du Lac, Wisconsin, USA
Welcome
You have selected one of the finest marine accessories available. It
incorporates numerous design features to ensure operating ease and durability.
This manual contains specific instructions for using and maintaining your
product.
Thank you for purchasing one of our products. We sincerely hope your boating
will be pleasant!
Mercury Marine
Fond du Lac, Wisconsin, U.S.A.
Read This Manual Thoroughly
IMPORTANT: If you do not understand any portion of this manual, contact the
1st Mate support team using the link provided in the Help section of this
manual.
Copyright and Trademark Information
© MERCURY MARINE. All rights reserved. Reproduction in whole or in
part without permission is prohibited.
Alpha, Axius, Bravo One, Bravo Two, Bravo Three, Circle M with Waves Logo,
K‑planes, Mariner, MerCathode, MerCruiser, Mercury, Mercury with Waves
Logo, Mercury Marine, Mercury Precision Parts, Mercury Propellers, Mercury
Racing, MotorGuide, OptiMax, Quicksilver, SeaCore, Skyhook, SmartCraft,
Sport‑Jet, Verado, VesselView, Zero Effort, Zeus, #1 On the Water and We're
Driven to Win are registered trademarks of Brunswick Corporation. Pro XS is a
trademark of Brunswick Corporation. Mercury Product Protection is a registered
service mark of Brunswick Corporation.
eng iii
eng iv
Components
The 1st Mate Hub............................................................................................... 1
Indicator Lights................................................................................................... 1
Hub Indicator Light Table.................................................................................... 2
1st Mate Antenna................................................................................................2
NFC Chip and RFID Sensor............................................................................... 2
Reset button....................................................................................................... 3
Fobs.................................................................................................................... 3
Insert Battery in FOB/S....................................................................................... 4
Wearables...........................................................................................................4
Important Safety Information.............................................................................. 5
App Download.................................................................................................... 5
Setup
Register New Account........................................................................................ 6
Vessel Setup.......................................................................................................6
Pair Devices........................................................................................................ 6
System Test........................................................................................................ 7
Optional Distress Messaging.............................................................................. 7
Optional Theft‑Deterrent System........................................................................ 7
Features and Operation
Connecting..........................................................................................................9
Operation.......................................................................................................... 10
Man Overboard (MOB)..................................................................................... 10
App Menu......................................................................................................... 13
Fob Light and Hub Horn Tables
Fob Light and Hub Horn Tables........................................................................ 15
Important Information
Help.................................................................................................................. 20
Technical Specifications................................................................................... 20
For Products Sold in the US/CAN..................................................................... 21
eng v
eng vi
The 1st Mate Hub
The 1st Mate hub is mounted in the vessel's console or in an interior
compartment that is protected from the elements. NMEA network, power, and
remote antenna connections are located on the hub. The 1st Mate hub is
powered by battery power from the vessel's key switch circuit. A NMEA
network is not required for operation. The hub uses a dedicated marine
wireless protocol to communicate with wearable devices (fobs) that are worn by
the driver and each passenger.
a - NFC chip
b - RFID sensor
c - Reset button
d - Hub indicator lights
Indicator Lights
Hub lights provide a visual indication of the 1st Mate system status. A flashing
red light on any of the five systems indicates that there is a fault in the
corresponding system.
TDS ‑ If the vessel is equipped with an enabled security system. The TDS light
will be green when the system is unlocked and blue when the system is locked.
Fob ‑ When fobs are paired with the hub, the fob light will be green. The fob
light will turn solid red and the warning horn will beep if a MOB incident occurs.
NMEA ‑ If the vessel is equipped with a connected National Marine Electronics
Association (NMEA) network the NMEA light will be green.
SmartCraft ‑ If the vessel is equipped with a connected Mercury SmartCraft
network the SmartCraft light will be green.
71012
c
ad
b
COMPONENTS
eng 1
Wireless ‑ A green light indicates that the 1st Mate wireless network is
enabled. A flashing green light indicates that the wireless network is waiting to
pair with a fob.
Hub Indicator Light Table
Indicator
Light
Off/No
Data Waiting On Status Change Fault
TDS > > > > > > >
Fob > > > > > > >
NMEA > > > > > > > > > >
SmartCraft > > > > > > > > > >
Wireless > > > > >
1st Mate Antenna
The 1st Mate system is equipped with a small antenna for wireless
communication with 1st Mate devices. The antenna is connected to the 1st
Mate hub and is usually located in an interior compartment or console. In some
cases it may be necessary to reorient or relocate the antenna to improve
performance. Refer to IMPORTANT INFORMATION and the 1st Mate Kit
installation instructions for more information about antenna installations.
71234
1st Mate antenna
NFC Chip and RFID Sensor
Tap the radio‑frequency identification (RFID) sensor with the near‑field
communication (NFC) chip to unlock the theft‑deterrent system (TDS) if an
active fob or the app is not available. The NFC chip is used for anti‑theft
authentication and system override functions.
COMPONENTS
2 eng
