Microchip Technology PD-9501-5GCO/DC Fehlerbehebungshandbuch

PD-9501-5GCO/DC

PD-9501-5GCO/DC PoE User Installation Guide

Introduction

Microchip’s family of Power over Ethernet (PoE) Midspans PD-9501-5GCO/DC is a single-port high-power PoE

outdoor solution that offers a cost-effective IEEE® 802.3bt compliant solution and pre-BT support for IEEE 802.3af/at

standard guaranteeing 60W of power and ensures safe and reliable operation in outdoor environments for standard

PoE data terminal. The PD-9501-5GCO/DC supports emerging wireless 5 Gbps devices such as wireless IEEE

802.11ac access points.

PoE Midspan powers devices that are PoE enabled or equipped to receive PoE. These devices are called PDs.

PoE Midspans offer the following key features:

• Outdoor rated: IP66 and IP67

• Extended temperature range –40 °C to 65°C

• Supports 10/100/1000 Mbps and 2.5/5 Gbps data rates

• Standards compliant: IEEE 802.3bt and IEEE802.3af/at

• Plug and play installation (installer does not have to open unit)

• Includes integrated surge protection

and its subsidiaries

User Guide DS00004336A-page 1

Table of Contents

Introduction.....................................................................................................................................................1

1. Standards and Safety Guidelines............................................................................................................3

1.1. Part Number Definition.................................................................................................................3

1.2. Electrical Compatibility Approvals................................................................................................ 3

1.3. Safety Standard Approvals...........................................................................................................3

1.4. CE Marking...................................................................................................................................3

1.5. GS Compliance............................................................................................................................ 3

1.6. Surge/Lightening Protection.........................................................................................................3

1.7. Safety Information........................................................................................................................ 4

2. Information en Matière de Sécurité......................................................................................................... 5

2.1. Directives Générales....................................................................................................................5

2.2. Mises en Garde............................................................................................................................5

3. PoE Midspan Installation (Outdoor Model)............................................................................................. 6

3.1. Installation Overview.................................................................................................................... 6

4. Troubleshooting.....................................................................................................................................15

4.1. Preliminary Steps....................................................................................................................... 15

4.2. Troubleshooting Steps................................................................................................................15

5. Specifications........................................................................................................................................ 16

5.1. Environmental Specifications..................................................................................................... 16

5.2. Electrical Specifications..............................................................................................................16

5.3. Interface..................................................................................................................................... 16

6. Contacting Technical Support............................................................................................................... 17

7. Revision History.................................................................................................................................... 18

The Microchip Website.................................................................................................................................19

Product Change Notification Service............................................................................................................19

Customer Support........................................................................................................................................ 19

Microchip Devices Code Protection Feature................................................................................................19

Legal Notice................................................................................................................................................. 19

Trademarks.................................................................................................................................................. 20

Quality Management System....................................................................................................................... 21

Worldwide Sales and Service.......................................................................................................................22

PD-9501-5GCO/DC

and its subsidiaries

User Guide DS00004336A-page 2

1. Standards and Safety Guidelines

The following sections describes the standard and safety guidelines for the product.

1.1 Part Number Definition

PD-9501-5GCO/DC: 4–pairs DC input family.

Table 1-1. Part Number Definition

Symbol Description

DC Midspan has DC input.

1.2 Electrical Compatibility Approvals

Microchip’s PD-9501-5GCO/DC series complies with the following standards:

• EN55035

• EN55032: Class B

• FCC Part 15: Class B

• VCCI

1.3 Safety Standard Approvals

Microchip meets the following safety standards. Consult Microchip for a complete list of safety certifications.

• UL/IEC/EN62368-1

• UL/IEC/EN60950-22

• GS Compliance

1.4 CE Marking

CE marking on this product indicates that this product complies with the Electromagnetic Compatibility (EMC)

Directive.

1.5 GS Compliance

GS marking on this product indicates that the product complies with the German Product Safety Act.

1.6 Surge/Lightening Protection

Microchip’s PD-9501-5GCO/DC is designed according to the following EMC requirements.

• ITU-T K.21 (6 kV enhanced surge) — Port and DC Main

• EN61000-4-5 (6 kV) — Port and DC Main

• GR-1089-CORE Issue 6 — Port Only

PD-9501-5GCO/DC

Standards and Safety Guidelines

and its subsidiaries

User Guide DS00004336A-page 3

1.7 Safety Information

Read the safety information before using the PoE Midspan unit.

1.7.1 General Guidelines

Read the following safety information before carrying out any installation, removal, or maintenance procedure on the

PoE Midspan. Warnings contain directions to be followed for the safety of personal and product.

1.7.2 Warnings

• Read installation instructions in 3. PoE Midspan Installation (Outdoor Model) before connecting Midspan to its

power source.

• Follow basic electricity safety measures when connecting the PoE Midspan to its power source.

• Only trained and qualified personnel must be allowed to install, replace, and service this equipment.

• A voltage mismatch can damage the equipment and can pose a fire hazard. If voltage indicated on the label is

different from the power outlet voltage, do not connect Midspan to this outlet.

• All wiring and connections must comply with NFPA 70 (NEC) and state and local regulatory requirements.

• Power supply cord must not be attached to the building surface or run through walls, ceilings, floors, and similar

openings in the building structure.

• Measures must be taken to prevent physical damage to the power supply cord, including proper routing.

• Data and Data and Power ports of the Midspan are shielded RJ45 data sockets. They cannot be used as Plain

Old Telephone Service (POTS) sockets. Only connect RJ45 data connectors to these sockets.

• When disposing this product, follow all local laws and regulations.

PD-9501-5GCO/DC

Standards and Safety Guidelines

and its subsidiaries

User Guide DS00004336A-page 4

2. Information en Matière de Sécurité

Lire les informations suivantes en matière de sécurité avant d'utiliser d'activer l'alimentation sur votre appareil

Ethernet Midspan.

2.1 Directives Générales

Lire les informations suivantes en matière de sécurité avant d'installer ou enlever quoi que ce soit, ou procéder à

l'entretien de l'alimentation de votre appareil Ethernet Midspan. Les mises en garde contiennent des instructions qui

doivent être suivies pour la sécurité des personnes et du produit. Suivre les instructions soigneusement.

2.2 Mises en Garde

• Lire les instructions d'installation dans 3. PoE Midspan Installation (Outdoor Model) avant de connecter le

Midspan à une source d'alimentation.

• Suivre les mesures de sécurité électrique de base lors de la connexion de l'injecteur PoE à sa source

d'alimentation.

• Seul du personnel formé et qualifié doit être autorisé à installer, remplacer et entretenir cet équipement.

• Une disparité de voltage peut endommager l'équipement et constituer un risque d'incendie. Si le voltage indiqué

sur l'étiquette est différent du voltage de la source d'alimentation, ne pas connecter le Midspan à cette prise.

• Tous les câblages et connexions doivent être conformes à la norme NFPA 70 (NEC) et aux exigences

réglementaires locales et nationales.

• Le cordon d'alimentation ne doit pas être fixé à la surface du bâtiment ni passer à travers les murs, les plafonds,

les planchers et les ouvertures similaires de la structure du bâtiment.

• Des mesures doivent être prises pour éviter tout dommage physique au cordon d'alimentation, y compris son

acheminement correct.

• Les ports Data et Data et Power du PoE Midspan sont des prises de données blindées RJ45. Elles ne peuvent

pas être utilisées comme prises de service téléphonique traditionnel. Connecter seulement des connecteurs de

données RJ45 à ces prises. Le câblage Ethernet connexe doit être limité à l'intérieur de l'immeuble.

• Pour disposer/jeter ce produit, suivre les lois et règlements locaux.

PD-9501-5GCO/DC

Information en Matière de Sécurité

and its subsidiaries

User Guide DS00004336A-page 5

3. PoE Midspan Installation (Outdoor Model)

The following sections describe the procedures for the installation of the Midspans unit.

Note: Do not use cross-over cable between the PoE Midspan output port and load device.

Warnings:

1. Take extra care when connecting the DC power inlet terminals, so that the +ve and –ve terminals are

connected to the proper polarity.

2. Ensure the DC power is within the allowed range.

3. Earth ground screw must be connected to earth ground in all types of installations.

3.1 Installation Overview

Figure 3-1. Product Overview

PD-9501-5GCO/DC

PoE Midspan Installation (Outdoor Model)

and its subsidiaries

User Guide DS00004336A-page 6

Before mounting the midspan to a fixed location, note the following:

• To ensure weather-proof connection in order to meet IEC60529 level IP67. PoE Midspan DC power plug needs

to be connected to a weather-proof DC power source box.

• Do not cover the midspan or block the airflow to the PoE with any foreign objects.

• Keep the midspan away from excessive heat and free from vibration.

• Ensure that the cable length from the Ethernet network source to the terminal does not exceed 100 meters (333

feet). The midspan is not a repeater and does not amplify the Ethernet data signal.

• The midspan has no ON-OFF switch, simply plug the midspan into an DC power source.

• PoE Midspan DC power lines should be connected to the socket-outlet that shall be installed near the

equipment and be easily accessible.

Installation Options

There are two options available for the installation of PD-9501-5GCO/DC:

1. Wall installation – PoE Midspan unit can be mounted on a wall/bench (all kind of flat surfaces such as wood,

brick, concrete etc.) using the mounting holes.

Note: Use only on solid walls to install the midspan, do not install on drywall or plasterboard walls.

2. Pole installation – Using optional mount kit.

Note: The mounting kit is not provided with the kit.

PD-9501-5GCO/DC

PoE Midspan Installation (Outdoor Model)

and its subsidiaries

User Guide DS00004336A-page 7

3.1.1 Parts List

The following table lists the parts included in the kit:

Quantity Component

1 60 W midspan, outdoor model

1 DC female connector

1 Quick installation guide

3.1.2 Additional Parts

The following table lists additional parts recommended to install the midspan:

Quantity Part

1 Screwdriver

1 Wire stripper

1 Solid Wrench No. 30 or Adjustable Wrench

3.1.3 Connect the Midspan to Ground

Note: Connect the midspan to ground only if replacing pre-assembled ground cable.

1. Connect the chassis bolt to the earth ground point on the rear of the midspan.

2. Connect the other end of the ground wire to earth ground at your installation point.

3. Tighten the screw to 1.7 Nm.

PD-9501-5GCO/DC

PoE Midspan Installation (Outdoor Model)

and its subsidiaries

User Guide DS00004336A-page 8

3.1.4 Install the Midspan Directly to a Wall

1. Using the screw holes of the midspan as a template, put marks on the mounting surface (a wall of wood, brick

or concrete) to mark drill points and drill four holes.

2. Insert four mounting screws into the screw holes. For bricks or concrete wall use anchor with screw (5 mm x

40 mm. minimum) and for wooden wall use screws for wood 5 mm x 40 mm.

Note: The screws are not provided with the kit.

3. Tighten each screw until the midspan is attached safely to the mounting surface.

3.1.5 Install the Midspan to a Pole Mount Adapter

Before installing the midspan, ensure that all the following parts listed in the parts list are included. If any items are

missing, notify your Sales or Customer Service Representative from Microchip.

1. Install the midspan onto the mounting bracket of the pole mount adapter, using four pan head screws.

PD-9501-5GCO/DC

PoE Midspan Installation (Outdoor Model)

and its subsidiaries

User Guide DS00004336A-page 9

2. Install the mounting bracket onto the pole. Use the appropriate components depending on the diameter of the

pole.

a. Pole of small diameter: The following parts list identifies the components required to install the metal

bracket on a pole with a diameter of 25 mm to 76 mm (1 in. to 3 in.).

b. Pole of large diameter: The following parts list identifies the components required to install the metal

bracket on a pole with a diameter of 76 mm to 203 mm (3 in. to 8 in.).

PD-9501-5GCO/DC

PoE Midspan Installation (Outdoor Model)

and its subsidiaries

User Guide DS00004336A-page 10

Inhaltsverzeichnis

Andere Microchip Technology Mikrocontroller Handbücher

Microchip Technology

Microchip Technology RN1810 Bedienungsanleitung

Microchip Technology

Microchip Technology SAM Series Bedienungsanleitung

Microchip Technology

Microchip Technology STK600 Bedienungsanleitung

Microchip Technology

Microchip Technology PD-95-10GC Series Bedienungsanleitung

Microchip Technology

Microchip Technology PIC16F87X Bedienungsanleitung

Microchip Technology

Microchip Technology dsPIC33E/PIC24E Series Bedienungsanleitung

Microchip Technology

Microchip Technology MCP2120 Bedienungsanleitung

Microchip Technology

Microchip Technology DSPICDEM MCHV Bedienungsanleitung

Microchip Technology

Microchip Technology PIC16F87X Bedienungsanleitung

Microchip Technology

Microchip Technology ATWINC3400 Bedienungsanleitung

Microchip Technology

Microchip Technology PIC16F18076 Bedienungsanleitung

Microchip Technology

Microchip Technology MCP1630 NiMH Bedienungsanleitung

Microchip Technology

Microchip Technology SAMR34 Xplained PRO Bedienungsanleitung

Microchip Technology

Microchip Technology DM164120-1 Bedienungsanleitung

Microchip Technology

Microchip Technology Protouch2 Bedienungsanleitung

Microchip Technology

Microchip Technology PIC16C62B Bedienungsanleitung

Microchip Technology

Microchip Technology megaAVR 0 Series Bedienungsanleitung

Microchip Technology

Microchip Technology PIC18C 8 Series Bedienungsanleitung

Microchip Technology

Microchip Technology SAM E54 Xplained Pro Bedienungsanleitung

Microchip Technology

Microchip Technology Digital Power Starter Kit Bedienungsanleitung

Microchip Technology

Microchip Technology PIC16C62B/72A Bedienungsanleitung

Microchip Technology

Microchip Technology SAMA5D27 Bedienungsanleitung

Microchip Technology

Microchip Technology PIC12F1501 Bedienungsanleitung

Microchip Technology

Microchip Technology ATmega328PB Xplained Mini Bedienungsanleitung

Beliebte Mikrocontroller Handbücher anderer Marken

AMS

AMS AS7261 Demo Kit Bedienungsanleitung

Novatek

Novatek NT6861 Bedienungsanleitung

Espressif Systems

Espressif Systems ESP8266 SDK Einrichtungshandbuch

Nuvoton

Nuvoton ISD61S00 ChipCorder Leitfaden

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Bedienungsanleitung

Texas Instruments

Texas Instruments Chipcon CC2420DK Bedienungsanleitung

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Bedienungsanleitung

NEC

NEC 78GK0S/K 1+ Series Montage- und Bedienungsanleitung

Mikroe

Mikroe SEMITECH N-PLC Click Montage- und Bedienungsanleitung

Intel

Intel Agilex Bedienungsanleitung

Cypress

Cypress CY4607 HX2VL Bedienungsanleitung

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Bedienungsanleitung

Texas Instruments

Texas Instruments TMS320F2837 D Series Bedienungsanleitung

CYPRES

CYPRES CY14NVSRAMKIT-001 Bedienungsanleitung

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Bedienungsanleitung

Espressif Systems

Espressif Systems ESP8266EX Betriebsanleitung

Abov

Abov AC33M8128L Bedienungsanleitung

Laird

Laird BL654PA Bedienungsanleitung
