MicroNet Dual Maxi Bedienungsanleitung

Dual Maxi Display
User Guide

Dual Maxi Display
Important
Suitability
Due to the wireless communication systems used in Micronet
instruments they are only recommended for use on boats up to 18
metres (60 ft.) Before installing to a boat of aluminium, steel or
Carbon Fibre construction, please consult www.tacktick.com.
Aid to Navigation
Like any other electronic instruments your Micronet system is designed
to serve only as an aid to navigation and it remains the skippers
responsibility to maintain a permanent watch and be aware of
developing situations.
Dismantling the product
Any attempt to take a Micronet product apart will invalidate the warranty.
The battery may only be replaced by a person trained and approved for
this purpose.
Safety and Disposal
Your Maxi Display contains Manganese Lithium Dioxide batteries which
should be disposed of correctly. Do not dispose of any instrument in
domestic waste. Refer to regulations in force in your country.
If in doubt return the instrument to Tacktick Ltd. for correct disposal.
EMC Conformance
All Tacktick equipment is designed to the best industry standards for use
in the recreational marine environment. The design and manufacture of
Tacktick equipment conforms to the appropriate Electromagnetic
Compatibility (EMC) standards. Correct installation is required to ensure
that performance is not compromised.

Contents
1
1 Key Features 2
2 System Overview 3
2.1 Display Features - 3
2.2 Remote Control - 3
2.3 Switching the System On and Off - 4
2.4 Chapter and Page operation - 4
2.5 Power Management and Battery Life - 4
2.6 Backlighting - 5
2.7 Sleep Mode - 6
3 Performance Functions 7
3.1 Automatic Pages - 7
3.2 Optimising your start with the Maxi Display - 8
3.3 During the Race - 10
4 Operation 13
4.1 Data Chapters and Pages - 13
4.2 Audible Signals and Alarms - 14
4.3 Page Hiding - 15
4.4 Operating the Dual Maxi Display using the control button - 16
5 Setup and Calibration 18
5.1 Setup and Calibration Organisation - 18
5.2 Setup and calibration Operation - 19
5.3 Editing Setup Data - 19
5.4 Setup Page Descriptions - 20
6 Seatrial and Calibration 25
7 Installation 26
7.1 Bracket mounting - 26
7.2 Bulkhead mounting - 27
8 Maintenance and Fault Finding 29
8.1 Care and Maintenance - 29
8.2 Fault Finding - 29
Specifications 32
Warranty Information 33

1 Key Features
Simple to Install
Solar Powered: your Dual Maxi Display is powered for life by the Sun.
The innovative technology uses so little current and the power supply is
so efficient, that the display is independent from your boat's batteries.
Wireless: your Tactick displays communicate by wireless, they can be
sited anywhere on your boat without disruption or cables.
Dedicated to Performance
Optimise your start: the Dual Maxi Display's powerful functions for
Distance and Speed-Trim to the line, Line Bias and Race Timer help you
get the best possible start.
Enhance your performance with the built-in functions for Wind Shift,
Velocity Made Good and Tack Course
Simplify your tidal navigation with the Dual Maxi Display's Set, Drift,
Turn and Course to Steer functions.
Easy to Manage
Automatic data selection: the innovative Auto Leg function allows the
display to automatically show the information you need for each leg of
the course.
Page Hiding means you can avoid data duplication on different
displays, minimising the time to select the pages you really need.
Wireless Remote control: your Dual Maxi display can
be controlled and configured from anywhere in the boat
using a Tacktick Remote display.
Excellent visibility
The large, high contrast LCD gives the Dual Maxi Display a wide angle
of view and ensures excellent visibility from anywhere on your boat.
Two panes with 35mm digits maximise the information available.
The black background minimises disturbance to your night vision, and
the red/amber option allows you to choose the backlight colour of your
display at night.
Dual Maxi Display
2www.tacktick.com

System Overview
3
2 System Overview
Important: Ensure that the "Auto Network" procedure described on the
yellow instruction sheet and full Setup and Calibration has been
performed correctly before attempting to use your Micronet system.
2.1 Display Features
2.2 Remote Control
Your Dual Maxi Display is designed to be controlled and configured
using a Tacktick Remote Display. See the user guide supplied with the
Remote Display for details of using the Remote Display in remote control
mode. All references in this user guide to the , , or
buttons refer to the appropriate button on the Remote Display.
Upper and Lower Panes
The upper and lower panes of the Dual Maxi Display function
independently; each pane acts as a separate display and can be
configured separately.
When a Dual Maxi Display is selected using the button of the
Remote Display, the upper pane of the Dual Maxi will flash, indicating
that it is selected for remote control. A further press of the button
will cause the lower pane of the Dual Maxi to flash, indicating that this
pane is now selected for remote control.
Note: If a Remote Display is not available, the single control button
provides a limited control capability, see page 16 for details.
Note: for configuration of the Dual Maxi Display a Remote Display is
required.
See page 18 for details of configuring your Dual Maxi Display.

Dual Maxi Display
4www.tacktick.com
2.3 Switching the System On and Off
To switch your Micronet system on or off select any display and
press the button for 2 seconds. (See page 16 for use of the
Dual Maxi Display control button)
2.4 Chapter and Page operation
Data is shown on the panes of the Dual Maxi Display in Chapters,
each containing several pages of related data. The diagram on
page 13 shows the full set of chapters and data pages available.
For a detailed description of individual data items supported on the
Micronet network, see the Micronet Data user guide on your
product CD or on the Tacktick web site.
Selecting Chapters and Pages:
Use to scroll through the chapters and and to move
between the pages within a chapter.
Pressing at any time will move on to the next Chapter and on
scrolling through the Chapters the page last selected in that
Chapter will be displayed. Both Chapter and Page selection will
scroll back to the first page once a cycle has been completed.
Pages for which no data is available are displayed as dashes (- - -)
2.5 Power Management and Battery Life
What makes your Dual Maxi display possible is Tacktick's
revolutionary approach to power management. By reducing the
amount of power being used by the electronics and dual
Maximizing the potential of the sun to provide power, the Dual Maxi
display becomes a virtually perpetual device.
Power status is indicated by two icons on the display:
Battery Level and Charge Rate
Used together these icons will show the condition of the power
supply.
Note: If the internal battery is fully charged then it does not matter
how much the display is subjected to bright sunlight no further
charging is required and the Charge Rate Indicator will remain low.

If the displays are to be stored for a long period of time before next use
(Over Winter) ensure that the batteries are fully charged before storage.
If necessary connect to a 9 to 30V DC power supply for 24 hrs prior to
storage, using the external power leads.
Warning: Artificial light WILL NOT recharge the battery. Placing your
Dual Maxi Display close to an artificial light will seriously damage the
display. Only recharge in natural daylight.
2.6 Backlighting
At any stage of the display's operation press and hold for two
seconds to access the lighting control.
Pressing and will scroll through setting OFF, 1, 2
and 3 whilst changing the backlighting.
If using the displays at night, power usage can be reduced
dramatically by switching the Backlighting to level 1 or 2. To save power, it
is recommended that backlighting Level 3 is used only in dusk conditions.
The Dual Maxi Display can be configured to use either red or amber
backlighting (see page 23). Tacktick recommend that red backlighting is
used whenever possible as this uses less battery power.
Backlighting is automatically switched off in daylight as part of the
display's power saving feature and will not operate in daylight.
System Overview
5
www.tacktick.com

2.7 Sleep Mode
If there is no boat speed or change in heading registered on the system
for a period of 12 hours your Dual Maxi display will switch off to conserve
power. A "POWER SAVE" alarm will sound before the system switches
off. Pressing any button within 10 seconds of the alarm sounding will
allow the system to remain switched on.
Dual Maxi Display
6www.tacktick.com

Performance Functions
7
3 Performance Functions
3.1 Automatic Pages
You probably want different pages shown on your Dual Maxi Display for
each leg of the course.
The Dual Maxi display makes this easy by providing a special page: the
AUTO LEG page. Using this feature, you can programme your Dual Maxi
to show exactly the information you require for each leg of the course
without the need to manually change pages at each mark rounding.
For example, consider a boat with two Dual Maxi Displays on a mast
bracket. It may be decided that during the start the data required is Boat
Speed,Depart, Line Bias and Race Timer; for the windward leg Boat
Speed, Heading, VMG to Windward and Wind Shift; and downwind
Boat Speed, Heading, VMG to Waypoint and True Wind Direction.
Programming these pages into the Autoleg Page prior to the race would
automatically show these pages for the appropriate leg of the course;
leaving the tactician free to concentrate on the race, not on configuring
his instruments.
The legs and the pages displayed can be configured in setup to meet
your specific needs, see page 20.
Similarly, using the Page Hiding function to eliminate duplicate pages
across the three displays reduces the time and key presses required if
a manual reconfiguration of the data displayed becomes necessary.
Note: It is a good idea to programme the remote control display list of
your Remote Display to show your displays in the same order as their
physical location on the boat. See the Remote Display user guide.
www.tacktick.com

Dual Maxi Display
8www.tacktick.com
3.2 Optimising your start
The Dual Maxi display has three functions to help you get a great start:
The Depart page shows your distance from the start line and how
much faster (or slower) you must sail to hit the line at the start signal.
The Race Timer gives you a visual and audible count down.
The Line Bias page helps you choose the best position on the line.
Using the Depart page
Approaching the start, it is vital to know your distance from
the line and whether you will arrive before or after the signal.
The large digits show your distance from the nearest point
on the line in distance units or boat-lengths (see page 23).
Note: A negative distance shows that the boat is to windward of the start
line, not that the boat is on the course side of the line; i.e. for a downwind
start, a negative distance shows you are approaching the line correctly.
The small digits show the change in speed required for you to arrive at
the line at the signal; a negative value means that you must decrease
your speed to avoid arriving early.
Warning: These calculations rely on GPS data, so they are subject to
error, particularly as the distance from the line becomes small. Do not rely
on this information to determine if you are over the line at the start. Rather,
you should use the data to help optimise your approach to the line.
Note: Before using the Depart function, you must configure the Boat
Length and GPS Bow parameters in setup; see page 22.
Initialising the Depart page
With the depart page displayed, approach one end of the start line as if
starting; press when the bow touches the line. A popup page shows
that the first line position has been captured. Repeat at the other end of
the line. The popup shows the second line position has been captured.
Inhaltsverzeichnis
Andere MicroNet Monitor Handbücher
