Microtek MS4 Bedienungsanleitung

—

CHECK PACKING LIST

Congratulations on your purchase! Be

sure to check the following items are

included with your projector.

Main Parts Description

1. Projector

2. Remote with battery

3. Carrying case

4. Computer cable (DVI-DB15)

5. S-video cable

6. Audio cable (mini jack-to-RCA x 2)

7. CD-ROM(User’smanual)

8. Power cord

9USB cable

Contact your dealer immediately if any

parts are missing or damaged.

IDENTIFY PROJECTOR PARTS

Main Parts Description

1. Turn lens to focus

2. IR receiver

3. Connect input/output devices

4. Socket for power cable

5. Side foot—adjusts level of projector

6. Kensingtonsecuritylock

7. Height adjuster—adjusts level of

projector

8. Height adjuster button—push to

adjust height

Caution:

Overheating can damage the projector.

Do not block any of the air vents

around the unit.

IDENTIFY REMOTE PARTS

Remote Buttons Description

1. Laser

2. IR transmitter

3. Status LED

4. Auto

5. Blank

6. Enter

7. Up cursor

8. Right cursor

9. Cursor pad

10. Keystone top

11. Keystone bottom

12. Mute

13. Right mouse

14. Left mouse

15. Volume down

16.Volume up

17. Down cursor

18. Left cursor

19. Menu

20. Freeze

21. Source

22. Power

INSERT REMOTE BATTERY

1. Remove the battery

compartment cover by

sliding the cover in the

direction of the arrow.

2. Insert the supplied

batteries taking note

of the polarity (+/-) as

shown here.

3. Replace the cover.

—

MAKE CONNECTIONS

Warning:

As a safety precaution, disconnect all

power to the projector and connecting

devices before making connections.

Label Description

Audio-in Connect an audio cable

(not supplied) from the

computer’s audio-out

connector.

Connect the supplied

audio cable (mini jack-

to-RCA x 2) from a

video device.

RS-232 Reserved service port

for firmware upgrades.

DVI-IConnect the supplied

DVI cable from a com-

puter.

Video Connect a composite

video cable (not sup-

plied) from a video

device.

S-video Connect the supplied

S-video cable from a

video device.

USB Connect the USB cable

(supplied) from a com-

puter

SETLANGUAGE

1. Connect the power cord to the

projector (A). Connect the

other end to a wall outlet.

The Power LED and Lamp-

ready LED turn on.

2.Turn on the connected de-

vices.

3.Ensure the Lamp-ready LED is

orange (not flashing) and then

press the Power button to turn

on the projector (B).

The projector splash screen

displays and connected

devices are detected.

4.Press the Menu button and

then press the cursor

button until Language is

highlighted (C).

5.Press the cursor button

until the language you want is

highlighted (D).

6.Press the cursor or

button to select the language.

7.Press the Menu button twice to

close the OSD.

8.To finish your presentation,

turn off the projector.

—

ADJUST PROJECTOR LEVEL

1. To raise the level of the

projector, lift the projector (A)

and press the height adjuster

button (B).

The height adjuster drops

down (C).

2. To make minor adjustments,

rotate the side foot (D).

3. To lower the level of the

projector, press the height

adjuster button [B] and push

down [A] on the top of the

projector.

ADJUST IMAGE

1. Use the Image-focus control

(on the projector only) to

sharpen the projected image

(A).

2. Use the Image-zoom control

(on the projector only) to resize

the projected image and

screen size (B).

3. Use the Keystone buttons to

correct image-trapezoid (wider

top or bottom) effect (C).

NEED MORE INFORMATION?

The CD-ROM that shipped with your

projector features a detailed user’s

manual in a printer-friendly format. The

user’s manual includes detailed hard-

ware, operation, and maintenance

descriptions. You will also find trouble-

shooting procedures and instructions

on securing the projector by means of

the Kensington security lock.

The projector has an On-Screen Dis-

play (OSD) that lets you make image

adjustments and change various set-

tings. To open the OSD, press the

Menu button on the remote control.

Use the remote Cursor buttons to navi-

gate and make changes to the projector

settings.

Refer to the “On-Screen Display Set-

tings” section of the CD-ROM user’s

manual for more information.
