PART Ⅱ: Special Version

WQP12-5201

Please read this manual carefully

before using the dishwasher and

Keep this manual for future reference.

CONTENTS

ERROR CODES

NOTE:

If you cannot solve the problems by yourself, please ask for help from a

professional technician.

The manufacturer, following a policy of constant development and updating of

the product, may make modifications without giving prior notice.

If lost or out-of-date, you can receive a new user manual from the manufacturer

or responsible vendor.

PROGRAMMING THE DISHWASHER

Wash Cycle Table

Starting A Cycle Wash

Changing The Program Mid-cycle

Forget To Add A Dish?

USING YOUR DISHWASHER

Control Panel

Water Softener

Preparing And Loading Dishes

Function Of The Rinse Aid And Detergent

Filling The Rinse Aid Reservoir

Filling The Detergent Dispenser

TECHNICAL INFORMATION

QUICK USER GUIDE

Please read the corresponding content on the instruction manual for detailed

operating method.

2Removing the larger residue on the

cutlery

3Loading the baskets

4Filling the dispenser Selecting a program and running

the dishwasher

Inside Outside

1Install the dishwasher

(Please check the section 5 “INSTALLATION INSTRUCTION ”

of PART Ⅰ: Generic Version.)

USING YOUR DISHWASHER

Control Panel

Operation (Button)

Power

Child lock

Half-load

Press this button to turn on your dishwasher, the screen lights up.

This option allows you to lock the buttons on the control panel -

except the Power button - so children cannot accidently start the

dishwasher by pressing the buttons on the panel. To lock or

unlock the buttons on the control panel, press and hold the Delay

button + Half-load button for 3 seconds simultaneously.

When pressing this button, corresponding indicator will be lit.

When you have about or less than 6 place setting dishware to

wash, you can choose this function to save energy and water.(It

can only be used with Intensive, Normal, ECO, Glass and 90 mins.)

Rapid

A shorter wash for lightly soiled loads that do not

need drying.

90 mins

For normally soiled loads that need quick wash.

Display

Warning

indicator Salt

Rinse Aid

Program

indicator

Glass

For lightly soiled crockery and glass.

Intensive

For heaviest soiled crockery, and normally soiled pots,

pans, dishes etc. With dried-on food.

Normal

For normally soiled loads, such as pots, plates, glasses

and lightly soiled pans.

ECO

This is standard program, it is suitable to clean normally

soiled tableware and it is the most efficient program

in terms of its combined energy and water consumption

for that type of tableware.

To start the selected washing program or pause it when the

dishwasher is working.

Start / Pause6

If the “ ” indicator is lit, it means the dishwasher is low

on dishwasher rinse aid and requires a refill.

If the “ ” indicator is lit, it means the dishwasher is low

on dishwasher salt and needs to be refilled.

Delay time

9To show the delay time(3h/6h/9h).

Water Softener

The water softener must be set manually, using the water hardness dial.

The water softener is designed to remove minerals and salts from the water, which

would have a detrimental or adverse effect on the operation of the appliance.

The more minerals there are, the harder your water is.

The softener should be adjusted according to the hardness of the water in your area.

Your local Water Authority can advise you on the hardness of the water in your area.

Adjusting salt consumption

The dishwasher is designed to allow for adjustment in the amount of salt consumed

based on the hardness of the water used. This is intended to optimise and customise

the level of salt consumption.

1. Switch on the appliance;

2. Press the Start/Pause button for more than 5 seconds to start the water softener set

model within 60 seconds after the appliance was switched on;

3. Press the Start/Pause button to select the proper set according to your local

environment, the sets will change in the following sequence:

H1->H2->H3->H4->H5->H6;

4. Press the Start/Pause button to end the set up model.

Please follow the steps below for adjustment in salt consumption.

dH=1.25 Clarke=1.78 fH=0.178mmol/l

°°

The manufactory setting: H3

Contact your local water board for information on the hardness of your water supply.

0 - 5

6 - 11

12 - 17

18 - 22

23 - 34

35 - 55

German

Salt consumption

(gram/cycle)

Salt consumption

(gram/cycle)

0 - 9

10 - 20

21 - 30

31 - 40

41 - 60

61 - 98

0 - 6

7 - 14

15 - 21

22 - 28

29 - 42

43 - 69

0 - 0.94

1.0 - 2.0

2.1 - 3.0

3.1 - 4.0

4.1 - 6.0

6.1 - 9.8

H1-> indicators flicker

H2-> 90 Min indicators flicker

H3-> 90 Min, Rapid indicators flicker

H4-> Glass indicators flicker

H5-> Glass, Rapid indicators flicker

H6-> Glass, 90 Min indicators flicker

Rapid 0

French

fH Mmol/lMmol/l

Water softener levelWater softener level

British

Clarke

British

Clarke

WATER HARDNESS

NOTE:

If your model does not have any water softener, you may skip this section.

Water Softener

The hardness of the water varies from place to place. If hard water is used in the

dishwasher, deposits will form on the dishes and utensils.

The appliance is equipped with a special softener that uses a salt container

specifically designed to eliminate lime and minerals from the water.

Preparing And Loading Dishes

Consider buying utensils which are identified as dishwasher-proof.

For particular items, select a program with the lowest possible temperature.

To prevent damage, do not take glass and cutlery out of the dishwasher

immediately after the program has ended.

Cutlery with wooden, horn china or mother-of-pearl handles

Plastic items that are not heat resistant

Older cutlery with glued parts that are not temperature resistant

Bonded cutlery items or dishes

Pewter or cooper items

Crystal glass

Steel items subject to rusting

Wooden platters

Items made from synthetic fibres

Some types of glasses can become dull after a large number of washes

Silver and aluminum parts have a tendency to discolour during washing

Glazed patterns may fade if machine washed frequently

For washing the following cutlery/dishes

Are not suitable

Are of limited suitability

Please check the section 3 “Loading The Salt Into The Softener”

of PART Generic Version, If your dishwasher lacks salt.Ⅰ:

Please check the section 3 “Loading The Salt Into The Softener”

of PART Ⅰ: Generic Version, If your dishwasher lacks salt.

Items such as cups, glasses, pots/pans, etc. are faced downwards.

Curved items, or ones with recesses, should be loaded aslant so that water can run

off.

All utensils are stacked securely and can not tip over.

All utensils are placed in the way that the spray arms can rotate freely during

washing.

Load hollow items such as cups, glasses, pans etc. With the opening facing

downwards so that water cannot collect in the container or a deep base.

Dishes and items of cutlery must not lie inside one another, or cover each other.

To avoid damage, glasses should not touch one another.

The upper basket is designed to hold more delicate and lighter dishware such as

glasses, coffee and tea cups.

Long bladed knives stored in an upright position are a potential hazard!

Long and / or sharp items of cutlery such as carving knives must be positioned

horizontally in the upper basket.

Please do not overload your dishwasher. This is important for good results and for

reasonable consumption of energy.

NOTE:

Very small items should not be washed in the dishwasher as they could easily fall

out of the basket.

To prevent water dripping from the upper basket into the lower basket, we

recommend that you empty the lower basket first, followed by the upper basket.

Removing the dishes

WARNING

Items will be hot! To prevent damage, do not take glass and

cutlery out of the dishwasher for around 15 minutes after the

program has ended.

Recommendations for loading the dishwasher

Scrape off any large amounts of leftover food. Soften remnants of burnt food in

pans. It is not necessary to rinse the dishes under running water.

For best performance of the dishwasher, follow these loading guidelines.

(Features and appearance of baskets and cutlery baskets may vary from

your model.)

Place objects in the dishwasher in following way:

Loading the upper basket

The upper basket is designed to hold more delicate and

lighter dishware such as glasses, coffee and tea cups

and saucers, as well as plates, small bowls and shallow

pans (as long as they are not too dirty). Position the

dishes and cookware so that they will not get moved by

the spray of water.

WARNING

Do not let any item extend through

the bottom.

Always load sharp utensils with the

sharp point down!

Loading the cutlery basket

Cutlery should be placed in the cutlery rack separately from each other in the

appropriate positions, and do make sure the utensils do not nest together, this may

cause bad performance.

For the best washing effect, please load the baskets refer to standard

loading options on last section of PART Generic VersionⅠ:

For the best washing effect, please load the baskets refer to standard

loading options on last section of PART Ⅰ: Generic Version

Loading the lower basket

We suggest that you place large items and the most

difficult to clean items are to be placed into the lower

basket: such as pots, pans, lids, serving dishes and bowls,

as shown in the figure below. It is preferable to place

serving dishes and lids on the side of the racks in order to

avoid blocking the rotation of the top spray arm.

The maximum diameter advised for plates in front of the

detergent dispenser is of 19 cm, this not to hamper the

opening of it.

The rinse aid is released during the final rinse to prevent water from forming droplets

on your dishes, which can leave spots and streaks. It also improves drying by allowing

water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.

WARNING

Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser

with any other substances (e.g. Dishwasher cleaning agent, liquid detergent).

This would damage the appliance.

Function Of The Rinse Aid And Detergent

When to refill the rinse aid dispenser

Unless the rinse-aid warning light ( ) on the control

panel is on, you can always estimate the amount from the

color of the optical level indicator located next to the cap.

When the rinse-aid container is full, the indicator will be

fully dark. The size of the dark dot decreases as the rinse-

aid diminishes. You should never let the rinse aid level be

less than 1/4 full.

Full 3/4 full 1/2 full 1/4 full Empty

Function of detergent

The chemical ingredients that compose the detergent are necessary to remove, crush and

dispense all dirt out of the dishwasher. Most of the commercial quality detergents are

suitable for this purpose.

WARNING

Proper Use of Detergent

Use only detergent specifically made for dishwashers use. Keep your detergent

fresh and dry.

Don't put powdered detergent into the dispenser until you are ready to wash

dishes.

Dishwasher detergent is corrosive! Keep dishwasher

detergent out of the reach of children.

Rinse aid level indicator

As the rinse aid diminishes, the size of the black dot on the rinse aid level indicator

changes, as illustrated below.

Inhaltsverzeichnis

Andere Midea Spülmaschine Handbücher

Midea

Midea MDW45FSS Bedienungsanleitung

Midea

Midea MFD45S200W.2-ES Bedienungsanleitung

Midea

Midea 340457 Bedienungsanleitung

Midea

Midea WQP6-3206B Anleitung zur Verwendung

Midea

Midea MFD60S200W.2-ES Bedienungsanleitung

Midea

Midea MDWMINIPLUS Bedienungsanleitung

Midea

Midea MDWB1W Bedienungsanleitung

Midea

Midea MDT24H3AST Bedienungsanleitung

Midea

Midea MID45S201-HR Bedienungsanleitung

Midea

Midea WQP6-3602F Bedienungsanleitung

Midea

Midea MDP18B10AWWC Bedienungsanleitung

Midea

Midea M18DB9339WW3A Bedienungsanleitung

Midea

Midea WQP12-7605V Bedienungsanleitung

Midea

Midea MDT24H2AST Bedienungsanleitung

Midea

Midea TORRINO Bedienungsanleitung

Midea

Midea WQP8-9339L-US Betriebsanleitung

Midea

Midea MDT24P4AST Bedienungsanleitung

Midea

Midea MDF24P1BST Bedienungsanleitung

Midea

Midea WQP6-3603A Anleitung zur Verwendung

Midea

Midea MDW12RBS Bedienungsanleitung

Midea

Midea SB 80-9373 Bedienungsanleitung

Midea

Midea ST 3.6F wi Bedienungsanleitung

Midea

Midea WQP6-3209 Anleitung zur Verwendung

Midea

Midea WQP12-5203 Bedienungsanleitung

Beliebte Spülmaschine Handbücher anderer Marken

Electrolux

Electrolux ESI5211LOX Bedienungsanleitung

KitchenAid

KitchenAid KUDB230B Bedienungsanleitung

Brandt

Brandt BDJ424DB Bedienungsanleitung

Asko

Asko DSD767UXXL.AU Bedienungsanleitung

Beko

Beko DFN26210W Bedienungsanleitung

NEFF

NEFF S153ITX00E Technisches Datenblatt

LG LDF7932 Bedienungsanleitung

Gorenje

Gorenje GV63214 Bedienungsanleitung

Hotpoint

Hotpoint HDA1100ZWH Service-Handbuch

Blomberg

Blomberg LDFN2240W Bedienungsanleitung

AEG

AEG FFB83836PM Bedienungsanleitung

Cylinda

Cylinda DM3220RFD Bedienungsanleitung

Atag

Atag DW8214MB Bedienungsanleitung

GE GLD8000 Series Bedienungsanleitung

Siemens

Siemens SN23HI02KE Technisches Datenblatt

Omega

Omega ODW717X Bedienungsanleitung

BORETTI

BORETTI BVW-683 Bedienungsanleitung

Siemens

Siemens SN 56N591 Bedienungsanleitung
