Midea MRQ23P4AST Bedienungsanleitung
en
French-Door
Bottom Mount
Refrigerator
Power supply: 115 V~
Frequency: 60 Hz
Capacity: 22.5 cu. ft.
Warning:
Before using this product,
please read this manual carefully
and keep it for future reference.
The design and specifications
are subject to change without
prior notice for product
improvement. Consult with your
dealer or manufacturer for
details.
version A - 07 - 2021 MODEL NUMBER MRQ23P4AST
www.midea.com
Free 3 months
extension of the
original limited warranty
period!*Simply text a
picture of your proof of
purchase to:
1-844-224-1614
*The warranty extension is for the
three months immediately following
the completion of the product’s
original warranty period.
Dear user
THANK YOU and CONGRATULATIONS on your purchase of this
high-quality Midea product. Your Midea refrigerator is designed
for reliable, trouble-free performance. Please take a moment to
register your new refrigerator.
Register your new refrigerator at www.midea.com under the
Support tab.
For future reference, record your product model and serial
numbers located on the back of the refrigerator above the
compressor compartment.
Model Number________________________________________
Serial Number_________________________________________
REFRIGERATOR SAFETY .................................................................3
OPERATION REQUIREMENTS .........................................................7
Location Requirements..........................................................................7
Electrical Requirements.........................................................................8
Water Supply Requirements ................................................................9
PARTS AND FEATURES ..................................................................10
INSTALLATION..................................................................................11
Unpack.........................................................................................................11
Door Removal (only if needed)..........................................................11
Installing the Water Line.......................................................................13
Move to Final Location .........................................................................14
Align Doors (if needed) ........................................................................15
Level Refrigerator....................................................................................16
BEFORE USE ....................................................................................16
Waiting Period........................................................................................ 16
Cleaning .................................................................................................... 16
REFRIGERATOR USE...................................................................... 17
General ...................................................................................................... 17
Controls..................................................................................................... 18
3
Refrigerator
Safety
Operating
Requirements
Parts and
Features Installation Refrigerator
Use
Refrigerator
Care
Troubleshooting
Before
Use
REFRIGERATOR CARE....................................................................20
Cleaning .................................................................................................... 20
Moving ....................................................................................................... 21
Storage ...................................................................................................... 21
Replacing Lights .................................................................................... 21
TROUBLESHOOTING ..................................................................... 22
General ...................................................................................................... 22
Error Codes..............................................................................................24
WARRANTY..................................................................................... 25
REFRIGERATOR SAFETY
YOUR SAFETY AND THE SAFETY OF OTHERS ARE VERY
IMPORTANT
To prevent injury to the user or other people and property damage, the
instructions shown here must be followed. Incorrect operation due to
ignoring of instructions may cause harm or damage, including death.
The level of risk is shown by the following indications.
CAUTION
WARNINGWARNING
WARNING
This symbol indicates the possibility of dangerous voltage
constituting a risk of electrical shock is present that could
result in death or serious injury.
This symbol indicates the possibility of injury or damage to
property.
This symbol indicates the possibility of death or serious
injury.
4
Refrigerator
Safety
Operating
Requirements
Parts and
Features Installation Refrigerator
Use
Refrigerator
Care
Troubleshooting
Before
Use
IMPORTANT SAFETY INSTRUCTIONS
WARNING
GENERAL APPLIANCE SAFETY
• Read all safety warnings, instructions, illustrations and specifications
provided with this appliance. Failure to follow all instructions listed
below may result in electric shock, fire and/or serious injury.
• Save all warnings and instructions for future reference.
ELECTRICAL SAFETY
• Plug into a grounded 3 prong outlet.
• Do not remove ground prong.
• Do not use an adapter.
• Unplug the power cord by holding the plug, never by pulling the
cord.
• Do not turn the appliance on or off by plugging in or unplugging the
power cord.
• Do not use an extension cord.
• Unplug the refrigerator before cleaning or defrosting.
NOTE: Power to the refrigerator cannot be disconnected by pressing
a control on the control panel.
Grounding requirement
• This refrigerator must be grounded. This refrigerator is equipped with
a grounding plug. The plug must be inserted into an outlet that is
properly installed and grounded.
• Improper use of the grounding plug can result in a risk of electric
shock. Consult a qualified electrician or service person if the
grounding instructions are not completely understood or if doubt
exists as to whether the refrigerator is properly grounded.
LOCATION SAFETY
• This refrigerator is intended to be used in household and similar
environments.
• Install in accordance with the manufacturer’s instructions.
• This refrigerator should not be recessed or built-in an enclosed
cabinet. It is designed for freestanding installation only.
WARNING - Keep ventilation openings, in the refrigerator, clear of
obstruction.
• When moving the refrigerator, do not roll over or damage the power
supply cord.
• Do not install near any heat sources, such as radiators, heat registers,
stoves, other cooking appliances or in direct sunlight.
• Keep flammable materials and vapors, such as gasoline, away from
refrigerator.
5
Refrigerator
Safety
Operating
Requirements
Parts and
Features Installation Refrigerator
Use
Refrigerator
Care
Troubleshooting
Before
Use
USE AND CARE SAFETY
• Flammable refrigerant used. Follow handling instructions carefully.
Risk of fire or explosion due to puncture of refrigerant tubing.
• Flammable refrigerant used. Do not use mechanical devices to
defrost freezer. Do not puncture refrigerant tubing.
• Do not store or use gasoline or any flammable liquids inside or in the
vicinity of this refrigerator.
• Use two or more people to move and install refrigerator.
• Connect refrigerator to a potable water supply only for ice maker
and dispenser use.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do not play with
the appliance.
• Keep fingers out of the “pinch point” areas; clearances between the
doors and between the doors and cabinet are necessarily small. Be
careful closing doors when children are in the area.
• Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
• Do not touch the interior of the freezer with wet hands. This could
result in frostbite.
• Use nonflammable cleaner. Clean only with a damp cloth.
• In refrigerators with automatic icemakers, avoid contact with the
moving parts of the ejector mechanism, or with the heating element
that releases the cubes. Do not place fingers or hands on the
automatic ice making mechanism while the refrigerator is plugged in.
• Do not use electrical appliances on the top of the refrigerator, unless
they are of the type recommended by the manufacturer.
• Do not place heavy objects on the top of the refrigerator considering
that objects may fall when doors are opened and closed.
• Do not store beer, beverages or other fluid contained in bottles or
enclosed containers in the freezer. The bottles or containers may
crack due to freezing.
SERVICE SAFETY
• Disconnect power before servicing.
• Flammable refrigerant used. To be repaired only by trained service
personnel. Do not puncture refrigerant tubing.
6
Refrigerator
Safety
Operating
Requirements
Parts and
Features Installation Refrigerator
Use
Refrigerator
Care
Troubleshooting
Before
Use
• Refer all servicing to qualified service personnel. Do not repair or
replace any part of this appliance unless specifically recommended
in this manual. Servicing is required when the appliance has been
damaged in any way, such as the power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the
appliance, the appliance has been exposed to rain or moisture, does
not operate normally, or has been dropped.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent, or similarly qualified person, in order
to avoid a hazard.
• If component part is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
• Replace all parts and panels before operating.
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY
State of California Proposition 65 Warnings:
WARNING: Cancer and Reproductive Harm
-www.P65Warnings.ca.gov.
PROPER DISPOSAL
WARNING
Suffocation Hazard
Before you throw away your old refrigerator:
• Remove the doors and drawers so that children cannot hide or get
trapped inside your old appliance.
• Leave any shelves in place so that children may not easily climb
inside.
• Failure to follow these instructions can result in death or brain
damage.
IMPORTANT: Refrigerant and cyclopentane foaming material used
for the appliance are flammable. It is the consumer’s responsibility
to comply with Federal and Local regulations when disposing of this
product. Refrigerants must be evacuated by a licensed, EPA certified
refrigerant technician in accordance with established procedures.
OPERATING REQUIREMENTS
8
Refrigerator
Safety
Operating
Requirements
Parts and
Features Installation Refrigerator
Use
Refrigerator
Care
Troubleshooting
Before
Use
ELECTRICAL REQUIREMENTS
WARNING
Electrical Shock Hazard
• Plug into a grounded 3 prong outlet.
• Do not remove the ground prong from the power cord plug.
• Do not use an adapter.
• Do not use an extension cord.
• Failure to do so can result in death, fire or electrical shock.
IMPORTANT: A 115 Volt, 60 Hz., AC only, 15-amp fused, grounded electrical
supply is required.
• Use an electrical outlet that accepts the grounding prong.
NOTE: The power cord is equipped with a 3-prong (grounding) plug
which mates with a standard 3-prong (grounding) electrical outlet.
• We recommend that the refrigerator be plugged into an electrical
circuit serving ONLY this appliance.
• Use an electrical outlet that cannot be turned off with a switch or pull-
chain.
• DO NOT use an extension cord.
a
b
c
a 3-prong plug
b 3-prong receptacle
c Receptacle box cover
9
Refrigerator
Safety
Operating
Requirements
Parts and
Features Installation Refrigerator
Use
Refrigerator
Care
Troubleshooting
Before
Use
WATER SUPPLY REQUIREMENTS
A cold water supply with water pressure between 30 and 100 psi (207 and
689 kPa) is required to operate the water dispenser and ice maker. If
you have questions about your water pressure, call a licensed, qualified
plumber.
IMPORTANT: Operation outside the water pressure range may cause
malfunction and severe, damaging water leaks.
NOTE: If the water pressure is less than what is required, the flow of water
from the water dispenser could decrease or ice cubes could be hollow or
irregularly shaped.
Reverse Osmosis Water Supply (if applicable)
IMPORTANT: The pressure of the water supply coming out of a reverse
osmosis system going to the water inlet valve of the refrigerator needs to
be between 30 and 100 psi (207 and 689 kPa).
If water pressure is too low:
Check to see whether the sediment filter in the reverse osmosis system is
blocked. Replace the filter if necessary.
Allow the storage tank on the reverse osmosis system to refill after
heavy use. The tank capacity could be too small to keep up with the
requirements of the refrigerator.
If your refrigerator has a water filter, it may further reduce the water
pressure when used in conjunction with a reverse osmosis system.
Remove the water filter.
10
Refrigerator
Safety
Operating
Requirements
Parts and
Features Installation Refrigerator
Use
Refrigerator
Care
Troubleshooting
Before
Use
PARTS AND FEATURES
LED lighting
Dairy Bin
Door tray
Crisper drawer Lowerfreezerdrawer
light switch
Control and display panel
Shelf
Big drawer
Upper freezer drawer
Inhaltsverzeichnis
Sprachen:
Andere Midea Kühlschrank Handbücher
Midea
Midea TMF Series Bedienungsanleitung
Midea
Midea MRF29D3ABB Bedienungsanleitung
Midea
Midea SO-BCD595WM-UT Bedienungsanleitung
Midea
Midea COMBI Series Bedienungsanleitung
Midea
Midea UR-BC96CM-ST Bedienungsanleitung
Midea
Midea MDRF692MIE Bedienungsanleitung
Midea
Midea CE-BCD87CM-SQ Bedienungsanleitung
Midea
Midea MDRS791MIE Bedienungsanleitung
Midea
Midea MDRB470MGD28 Series Bedienungsanleitung
Midea
Midea HD-468RWEN Bedienungsanleitung
Midea
Midea HD-423FWWD Bedienungsanleitung
Midea
Midea MRT14B3AWW Bedienungsanleitung
Midea
Midea HS-121LN Bedienungsanleitung
Midea
Midea TMF No Frost Series Bedienungsanleitung
Midea
Midea HD-332RWEN Bedienungsanleitung
Midea
Midea SBS Series Bedienungsanleitung
Midea
Midea HD-113FN Series Bedienungsanleitung
Midea
Midea MDRS723MYF28 Bedienungsanleitung
Midea
Midea MDRE353FGF Series Bedienungsanleitung
Midea
Midea FP-20RWC096LMNV-T1 Series Bedienungsanleitung
Beliebte Kühlschrank Handbücher anderer Marken
Bonnet Neve
Bonnet Neve SKYVIEW PLUS Bedienungsanleitung
Zanussi Electrolux
Zanussi Electrolux ZERB 8441 Bedienungsanleitung
Sharp
Sharp SJ-BA31IEXW2-EU Bedienungsanleitung
CORBERO
CORBERO CC2300MCW Bedienungsanleitung
KitchenAid
KitchenAid 2205264 Bedienungsanleitung
Stengel
Stengel KU 1101 A++ Bedienungsanleitung
