Midea 360471 Bedienungsanleitung

MODEL:

360471

Read all instructions and explanations for

the installation before use. Follow the

instructions carefully. Keep the operation

instructions handy for later use. If the

appliance is sold or passed on, ensure

that the new owner always receives this operation instructions.

delete installation before use. Follow the

instructions carefully. Keep the operation

instructions handy for later use. If the

product is sold or passed on then ensure

that the new owner always receives this

manual.

MODEL:

Safety Instructions

Safety Instructions ..................................................

Installation

Product Description ................................................

Installation ...........................................................

Operations

Quick Start .............................................................

Before Each Washing ..............................................

Detergent Dispenser ...............................................

Control Panel .........................................................

Option....................................................................

Other Functions ......................................................

Programmes ..........................................................

Washing Programmes Table .....................................

Maintenances

Cleaning And Care .................................................

Trouble Shooting ....................................................

Technical Specifications .........................................

Testing methods .....................................................

CONTENTS

For your safety,the information in this manual must be followed

to minimize the risk of fire or explosion, electric shock, or to

prevent property damage, personal injury or loss of life.

Explanation of the symbols:

manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

• If the supply cord is damaged, it must be replaced by the

The electric shock!

This combination of symbol and signal word indicates

a potentially dangerous situation which may result in

death or serious injuries unless it’s avoided.

Warning!

！

This combination of symbol and signal word indicates

a potentially dangerous situation which may result in

slight or minor injuries.

Note!

This combination of symbol and signal word indicates

a potentially dangerous situation which may result in

slight or minor injuries or damage to property and the

environment.

Caution!

SAFETY INSTRUCTIONS

Safety Instructions

Warning!

！

• The new hose-sets supplied with the appliance are to be

used and that old hose-sets should not be reused.

• Before any maintenance the device, unplug the

appliance from the mains.

• Always unplug the machine and turn off the water

supply after use. The max. inlet water pressure, in

pascals. The min. inlet water pressure, in pascals.

• To ensure your safety, power plug must be inserted into

an earthed three-pole socket. Check carefully and make

sure that your socket is properly and reliably earthed.

• Make sure that the water and electrical devices must

be connected by a qualified technician in accordance

with the manufacturer's instructions and local safety

regulations.

Risk to children!

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capabilities or lack of experience and knowledge

unless they have been given supervision or instruction

concerning use of the appliance by a person responsible

for their safety.

• Children of less than 3years should be supervised to

ensure that they do not play with appliance.

• Animals and children may climb into the machine. Check

the machine before every operation.

• Kids should be supervised that they do not play with

the appliance.

SAFETY INSTRUCTIONS

• Remove all packages and transport bolts before using

the appliance. Otherwise, serious damage may result.

• Glass door may be very hot during the operation. Keep

kids and pets far away from the machine during the

operation very wet rooms as well as in the rooms with

explosive or caustic gas.

• Plug must be accessible after installation.

Risk of explosion!

•

Do not wash or dry articles that have been cleaned in, washed

in, soaked in, or dabbed with combustible or explosive

substances( such as wax, oil, paint, gasoline, degreasers,

dry-cleaning solvents, kerosene, etc.) This may result in

fire or explosion.

Before hand thoroughly rinse items of washing by hand.

• This washing machine is for indoor use only.

• It isn't intended to be built-in using.

• The openings must not be obstructed by a carpet.

• Washing machine shall not be installed in bath room or

very wet rooms as well as in the rooms with explosive

or caustic gases.

• The washing machine with single inlet valve only can be

connected to the cold water supply. The product with

double inlet valves should be correctly connected to the

hot water and cold water supply.

• Plug must be accessible after installation.

Installing the product!

SAFETY INSTRUCTIONS

Caution!

• Remove all packages and transport bolts before using

the appliance. Otherwise, serious damage may result.

Risk of damaging appliance!

• Your product is only for home use and is only designed

for the textiles suitable for machine washing.

• Do not climb up and sit on top cover of the machine.

• Do not lean against machine door.

• Cautions during Handling Machine:

1.Transport bolts shall be reinstalled to the machine by

a specialized person.

2.The accumulated water shall be drained out of the

machine.

3.Handle the machine carefully. Never hold each protruded

part on the machine while lifting. Machine door can

not be used as the handle during the conveyance.

4.This appliance is heavy. Transport with care.

• Please do not close the door with excessive forces. If it

is found difficult to close the door, please check if the

clothes are put in or distributed well.

• It is forbidden to wash carpets.

Operating the appliance!

• Before washing the clothes at first time, the product

shall be operated in one round of the whole procedures

without the clothes inside.

• Flammable and explosive or toxic solvents are forbidden.

Gasoline and alcohol etc.Shall not be used as detergents.

Please only select the detergents suitable for machine

washing, especially for drum.

SAFETY INSTRUCTIONS

• Make sure that all pockets are emptied. Sharp and rigid

items such as coin,brooch,nail,screw or stone etc. may

cause serious damages to this machine.

• Please check whether the water inside the drum has

been drained before opening its door.Please do not open

the door if there is any water visible.

• Be careful of burning when the product drains hot

washing water.

• Never refill the water by hand during washing.

• After the program is completed, Please wait for two

minutes to open the door.

This marking indicates that this product should not be

disposed with other household wastes throughout the

EU.To prevent possible harm to the environment or

human health from uncontrolled waste disposal,recycle

it responsibly to promote the sustainable reuse of

material resources.To return your used device, please use

the collection systems or contact the retailer where the

product was purchased. They return and can take this

product for environmental safe recycling.

Packaging/Old appliance

SAFETY INSTRUCTIONS

Accessories

Product Description

• The product line chart is for reference only, please refer to real product as

standard.

Note!

Drum

Power supply cord

Control panel

Detergent dispenser

Service filter

Door

Water supply hose

Top cover

Drain hose

INSTALLATION

4 x Cover caps 1 x Supply hose

cold water

1 x Owner’s manual Acoustic

sponge

(Optional)

Installation

Before installing the machine, the location characterized

follows shall be selected:

1.Rigid, dry, and level surface

2.Avoid direct sunlight

3.Sufficient ventilation

4.Room temperature is above 0℃

5.Keep far away from the heat resources such as coal or gas.

Unpacking the washing machine

1. Remove the cardboard box and styrofoam packing.

2. Lift the washing machine and remove the base packing.

3. Remove the tape securing the power supply cord and drain hose.

4. Remove the inlet hose from the drum.

Make sure the small triangle

foam is removed with the bottom one together. If not, lay the unit down with side

surface, then remove the small foam from the unit bottom manually.

•

Stability is important to prevent the product from

wandering!

Make sure that the product should not stand on

the power cord.

Warning!

！

•

Packaging material (e.g. Films, Styrofoam) can be

dangerous for children.

There is a risk of suffocation ! Keep all packaging

well away from children.

Warning!

！

INSTALLATION

W> 20mm

Installation area

INSTALLATION

Remove transport bolts

• You must remove the transport bolts from the backside before using the product.

Warning!

！

Loosen the 4 transport

bolts with a spanner.

Remove the bolts

including the rubber parts

and keep them for future

use.

Close the holes using the

cover caps.

Levelling the washing machine

• The lock nuts on all four feet must be screwed tightly against the housing.

Warning!

！

1. Loosen the lock nut.

2. Turn the foot until it reaches the floor.

3. Adjust the legs and lock the nuts with a

spanner. Make sure the machine is level and

steady.

Connect the water supply hose

To prevent leakage or water damage, follow the instructions in this chapter

• Do not kink, crush or modify water inlet hose.

Warning!

！

Connect the water supply hose

to the water inlet valve and a

water tap with cold water as

indicated.

• Connect manually, do not use tools. Check if the connections are tight.

Note!

Inhaltsverzeichnis

Andere Midea Waschmaschine Handbücher

Midea

Midea 360462 Bedienungsanleitung

Midea

Midea MA500W21/W Bedienungsanleitung

Midea

Midea MFWG7514 Bedienungsanleitung

Midea

Midea MF10EW70B Bedienungsanleitung

Midea

Midea LUNAR 01 Bedienungsanleitung

Midea

Midea MAD160-A2801GPS Bedienungsanleitung

Midea

Midea FP-92LFC100GMTH-W2 Bedienungsanleitung

Midea

Midea MA500W210 Series Bedienungsanleitung

Midea

Midea MFC80-JS1403B/C14E-AU Bedienungsanleitung

Midea

Midea MAC160-S2802TPS/FM Bedienungsanleitung

Midea

Midea MA100W75 Bedienungsanleitung

Midea

Midea MTW70 Bedienungsanleitung

Midea

Midea 360215 Bedienungsanleitung

Midea

Midea KL15TTGIW Bedienungsanleitung

Midea

Midea MLTW44A4BWW Handbuch

Midea

Midea MFW-1250MV2 Bedienungsanleitung

Midea

Midea MFW-1255CV Bedienungsanleitung

Midea

Midea 360484 Bedienungsanleitung

Midea

Midea MJ70N68P Bedienungsanleitung

Midea

Midea MLH27N5AWWC Handbuch

Midea

Midea MFW-701S Bedienungsanleitung

Midea

Midea A1 4.5kg Bedienungsanleitung

Midea

Midea MAE180-2404TPS/01FM Bedienungsanleitung

Midea

Midea MA200W130 Series Bedienungsanleitung

Beliebte Waschmaschine Handbücher anderer Marken

Tricity Bendix

Tricity Bendix AW 1000 W Produkthandbuch

Panasonic

Panasonic NA-F60L5WRB Bedienungsanleitung

GE WSLP1500 Handbuch

Electrolux

Electrolux EWF1284EDW Bedienungsanleitung

Bosch

Bosch WAN2829BSN Bedienungsanleitung

LG TV2516DV3B Bedienungsanleitung

LG TH2517DSAV Bedienungsanleitung

VESTEL

VESTEL CMH-XL 7510 TE Bedienungsanleitung

AEG

AEG 74335 Bedienungsanleitung

Johnson

Johnson JWF721A Bedienungsanleitung

Beko

Beko WTE7604XLW0 Bedienungsanleitung

Danby

Danby DTT100A1WDB Montageanleitung

Amica

Amica WA 14 Ex Bedienungsanleitung

Daewoo

Daewoo DWD-F1222 Bedienungsanleitung

Bosch

Bosch WAS28461AU Bedienungsanleitung

Miele

Miele PW 6080 Vario Bedienungsanleitung

Finlux

Finlux FLX108CF220 Bedienungsanleitung

Whirlpool

Whirlpool 3LBR5132AN0 Bedienungsanleitung
