MINOLTA-QMS SC-210 Bedienungsanleitung
SC-210
User's Manual
(D/N: 250-0278-E Rev. 1.0 )
Minolta-QMS, Inc
-ii
Trademarks
Microsoft isa U.S. registered trademark of Microsoft Corporation.
Windows and MS-DOS are trademarks of Microsoft Corporation.
IBM, PC, AT, XT are registered trademarks of International Business
Machines Corp.
Other brands and product names herein are trademarks or registered
trademarks of their respective holders.
Copyright
All rights reserved. No part of this publication may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any
language or computer language, in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, manual, or otherwise, without the
prior written permission of the manufacturer.
Material scanned by this product may be protected by governmental laws
and other regulations, such as copyright laws, the customer is solely
responsible for complying with all such laws and regulations.
Warranty
The information contained in this document is subject to change without
notice.
The manufacturer makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of fitness for a particular
purpose.
The manufacturer shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the furnishing,
performance, or use of this material.
iii
FCC Radio Frequency Interference
Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communication. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
* Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION: To assure continued compliance,(example- use only
shielded interface cables when connecting to computer or peripheral
devices). Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Responsible
Party: MINOLTA-QMS INC.
1 Magnum Pass
Telephone No.:
Mobile, AL 36618
USA
+1 (334) 633-4300
-iv
Table of Contents
1. INTRODUCTION..........................................................................................1-1
2. SC-210 INSTALLATION...........................................................................2-1
2.1 PRECAUTIONS............................................................................................2-1
2.2 UNLOCKING THE SC-210..........................................................................2-2
2.3 CONNECTING THE CABLE.......................................................................2-3
2.3.1 connecting SC-210 to a printer to work as a copier.........2-3
2.3.2 connecting SC-210 to a Windows workstation to work as a
Scanner..........................................................................................................2-4
2.4 DOCUMENT PLACEMENT........................................................................2-5
3. USING SC-210 AS A COPIER................................................................3-1
THE CONTROL PANEL...................................................................................3-2
3.2 BEFORE MAKING COPIES..........................................................................3-4
3.3 MAKING SIMPLE COPIES.........................................................................3-5
3.4 MAKING COPIES WITH COPY FEATURES.............................................3-6
3.4.1 Mirror function................................................................................3-6
3.4.2 Enlarging or Reducing your Original.......................................3-7
3.4.3 Auto Zooming your Original.......................................................3-8
3.4.4 Changing your Copy Density.....................................................3-9
3.4.5 Changing Color intensity............................................................3-9
3.4.6 Choosing your Copy Quantity.................................................3-10
3.4.7 Enhancing your Copy Quality..................................................3-11
3.4.8 Original Content..........................................................................3-12
auto/text/photo copies.............................................................................3-12
3.4.9 Making Copies of a 3D object................................................3-13
3.4.10 Automatic Power Saving.....................................................3-14
4. USING SC-210 AS A SCANNER..........................................................4-15
4.1 INSTALLATION PROCEDURE.................................................................4-15
4.2 DOWNLOADING PRINTER COLOR TABLE...........................................4-17
4.3 TO CUSTOMIZE COLOR TABLES ON SC-210,......................................4-21
4.4 UNINSTALL THE SC-210 DRIVER..........................................................4-24
5. SCANNER OPERATION & DOCUMENT PRINTING.......................5-1
v
5.1 IMAGE TYPE...............................................................................................5-3
5.2 SCANNING PARAMETERS & IMAGE CONTROL.....................................5-4
5.3 SCANNING...................................................................................................5-9
5.4 PRINTING..................................................................................................5-10
6. MAINTENANCE............................................................................................6-1
7. TROUBLESHOOTING...............................................................................7-1
7.1 QUESTIONS AND ANSWERS.....................................................................7-1
7.2 TECHNICAL SERVICE................................................................................7-3
8. SPECIFICATIONS ......................................................................................8-4
9. SC-210 AUTOMATIC DOCUMENT FEEDER (ADF) USER’S
GUIDE.......................................................................................................................9-1
9.1 INSTALLING THE ADF.............................................................................9-1
9.1.1 Unpack the ADF...........................................................................9-1
9.1.2 Installing the ADF........................................................................9-2
9.1.3 Unlocking the SC-210.................................................................9-5
9.1.4 Connecting the Cables...............................................................9-6
9.2 USING THE ADF........................................................................................9-8
9.2.1 fanning paper Before usage......................................................9-8
9.2.2 Loading the Paper........................................................................9-9
9.2.3 Starting Your First Copy.............................................................9-9
9.3 MAINTAINING THE ADF.......................................................................9-13
9.3.1 Cleaning the ADF.......................................................................9-13
9.3.2 Replacing the ADF Snap-in Pad Module.............................9-15
9.4 HOW TO CLEAR THE PAPER JAM.........................................................9-18
1-1
1. INTRODUCTION
Congratulations on your purchase of the Minolta-QMS
SC-210.
The SC-210 produces better printing quality and is
free from maintenance, compared with traditional
copy machines. Its high copy/scan quality,
maintenance-free operation and affordability make
SC-210 the best convenience copier solution for
office.
The following sections introduce the unpacking,
hardware and software installation, the operation, and
maintenance information to you. Please spend a few
minutes reading through them to keepquality
scanning result possible.
Figure 1-1 shows how the SC-210 is packed.
Please check all the items against Figure 1-1. If
there is any missing or damaged, please contact your
nearest dealer immediately for the replacement.
-1-2
1. Utilities & Documentation CD
2. Power Adapter
3. Parallel Cable for Computer Connection
4. Parallel Cable for Printer Connection
5. Quick Installation Guide
6. SC-210
Figure 1-1 SC-210 Packing
1
2
3
5
6
4
2-1
2. SC-210 INSTALLATION
2.1 PRECAUTIONS
ŸKeep the SC-210 out of direct sunlight. Direct
exposure to the sun or excessive heat may cause
damage to the unit.
ŸDo not install the SC-210 in a humid or dusty
place.
ŸBe sure to use the proper AC power source.
ŸPlace the SC-210 securely on an even, flat
surface. Tilted or uneven surfaces may cause
mechanical or paper-feeding problems.
ŸRetain the SC-210 box and packing materials for
shipping purposes.
-2-2
2.2 UNLOCKING THE SC-210
To protect the scanning head from damage during
shipment, the SC-210 is designed with a lock switch
beneath the main unit. Therefore, before using the
SC-210, it is required to unlock SC-210 by moving
the lock switch to theUse position.(See Figure 2-1)
1. “Shipping” Position 2. “Use” Position
Figure 2-1 Unlocking the SC-210
1
2
2-3
2.3 CONNECTING THE CABLE
2.3.1 CONNECTING SC-210 TO A PRINTER TO WORK
AS A COPIER
Connect the power cable and signal cable as shown
below.
Figure 2-2 Connecting SC-210 to a printer
To Printer To Power Outlet
Power Cable
Printer Cable
