Mistral MWM710FL Bedienungsanleitung
Thank you.
Thank you for choosing a quality Mistral appliance. Mistral prides itself on‘affordable living making sure there is nocompromise in your favourite room.... The Kitchen. This product comes with a 2 Year in home warranty,be sure to retain your user manual and receipt. For all warranty and technical queries please phone: 1300 373 199 AUST0800 764 912 NZGSM Retail Australia Pty Ltd ABN: 53 007 582 475 For Warranty and technical queries: 1300 373 199 Aust Or 0800 764 912 NZModel: MWM710FL
Contents
Safety instructions & warnings....................... 4-5Parts & Features .......................................... 6Installation ................................................ 7-9Operation................................................... 10-12How to Use ................................................ 13-15Maintenance & Cleaning................................ 1 6Troubleshooting .......................................... 1 7Parameters ................................................ 1 8Electric Diagram ......................................... 1 9Warranty ......... ......................................... 20-21GSM Retail Australia Pty Ltd ABN: 53 007 582 475 For Warranty and technical queries: 1300 373 199 Aust Or 0800 764 912 NZModel: MWM710FL
Safety InstructionsYour safety is of the utmost importance to our company. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Consumer service support hotline.4
Read and understand thoroughly these safety instructions before use. The items indicated here are very important safety precautions, which must be followed. We cannot be held liable for damage caused by non-compliance with the warning and safety instructions or resulting from incorrect use or operation. Cleaning and user maintenance shall not be made by children without supervision. Children of less than 3 years should be kept away unless continuously supervised. The new hose-sets supplied with the appliance are to be used and the old hose-sets should not be reused. WARNINGThis appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. This appliance can be used by children aged from 8 years and above and persons with reduced physical,sensory or mental capabilities or lack of knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and under stand the hazards involved.Children shall not play with the appliance.Cleaning and user maintenance shall not be made by children without supervision.This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices and other working environments;-farm houses;-by clients in hotels, motels and other residential type environments;-bed and breakfasts type environments;-areas for communal use in blocks of flats or in launderettes.For washing machines having ventilation openings on the base, the washing machines cannot be washing on the carpet. Before setting the washing machine, check it for any externally visible damage. Do not install or use a damaged washing machine. Before connceting the washing machine, ensure that the connection data on the plate(voltage and current)match the electricity supply. If in any doubt, consult a qualifiled electrician. The electrical safety of this washing machine can only be guaranteed when continuity is complete between it and an effective earthing system which complies with current local and national safety regulations. It is most important that this basic safety requirement is present and regularly tested, and where there is any doubt the household wiring system should be inspected by a qualified electrician. The manufacturer cannot be held liable for the consequences of an inadequate earthing system. Do not connect the washing machine to the mains electricity supply by an extension lead. Extension leads do not guarantee the required safety of the appliance.Unauthorized repairs could result in unforeseen dangers for the user, for which manufacturer can not accept liability. Repairs should only be undertaken by an approved service technician.Ensure current is not supplied to the machine until after maintenance of repair work has been carried out.
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust
www.belliniappliances.com.au Model: BPI1200 Fineline Aus Portable Induction Cooker
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust
www.belliniappliances.com.au Model: BPI1200 Fineline Aus Portable Induction Cooker
5
If the connection cable is damaged or broken, it must only be replaced by an approved service technician to protect the user from danger. Faulty components must only be replaced by genuine manufacturer original spare parts. Only when these parts are fitted the safety standards of the machine can be guaranteed.THIS WASHING MACHINE MUST BE EARTHED.•To avoid the risk of personal injury or damage to the washingmachine, do not install it in place where it is damp and whereit suffers from rainfall.• Do not install the washing machine in place where it suffersfrom the sun directly, in which plastic or components will bedamaged. It will be shortened the life of your washing machine.• Do not install the washing machine in place where temperaturesbelow freezing may occur. Frozen hoses may burst or split. Thereliability of the electronic control unit may be impaired attemperatures below freezing point.• Do not shoot the washing machine with water when you clean it.• Keep the washing machine away from fire or heat sources.• Before using the washing machine for the first time, make sure that the transit bolts at the rear of themachine have been removed. During spinning, transit bolts which is still in place may result in damage to both the machine and adjacent furniture or appliances.• Turn off the tap if the machine is to be left for any length of time (e.g. holiday), especially if there is nofloor drain (gully) in the immediate vicinity.• Take care to ensure that foreign objects (e.g. nails, pins, coins, paper clips) do not find their way into themachine with the laundry. These may damage components of the machine (e.g. drum), which in turn can result in damage to the laundry.• Do not wash water-repellent things(e.g. raincoats) with washing machine.• Only remove laundry from the washing machine once the drum has stopped turning. Reaching into amoving drum is extremely dangerous and could result in injury.Correct useSafety with children• Keep children away from the washing machine at all times. To avoid therisk of injury do not allow children to play on or near it or toplay with its controls. Supervise children whilst you are using it. • Older children may only use the washing machine if its operation hasbeen clearly explained to them and they are able to use it safely, recognising the dangers of misuse.• For machines with a 'porthole' door, remember that the porthole glasswill be hot when washing at very high temperatures. Do not let children touch it.
6
Parts and FeaturesCordTransit boltsBack coverwater inlet valveDoor glassTop Cover Control Panel CabinetGasketDrain Hose Adjustable Feet Drain pump filter Door Drawer(for detergent or fabric softener)Drain pump cover The drawing of machine in the manual is only used for instruction. It may be vary from the mode you buy.Unscrew the drain pump filter to let water run out when the machine is not used for a long time.Before Use
7
Installation:Backout packing• Remove all the packing(including the foam base) orthe vibration and noise may occur.• Dispose all the wrappage safety and keep them out ofthe reach of children. Danger of suffocation!• It is normal that water drops appear on the packingplastic bag and the door glass, which are resulted from the water left in the tub for checking out.AccessoriesMake sure that you have received all of the items shown below.AccessoriesNameQty.AccessoriesNameQty.Inlet hosetransit bolts caps14“U” piece1Manual1Removing transit bolts• Remove all the transit bolts at the back of the machine with tools.• Plug the holes with the transit bolts caps supplied.• Keep the transit bolts for future transportation. Whenever the machine is transported, the transit boltsmust be refitted.Transit bolts Strong vibration, noise or failures may occur if the transit bolts are not removed.Before Use
8
Installation:Installation place requirement•A concrete floor is the most suitable installation surface for awashing machine, being far less prone to vibration during the spin cycle than wooden floorboards or carpeted surface.•The machine must be level and securely positioned. Thedistance between the machine and wall must be more than 10 cm .•To avoid vibrations during spinning. the machine should notbe installed on soft floor coverings.Level adjustmentThe machine must stand perfectly level on all four feet to ensure safe and proper operation. Incorrect installation may cause vibrationsand noise and may cause the machine to move about.To do these when the machine is not level: •Using the spanner turn locknut in a clockwisedirection. Then turn locknuts together with adjust feet to unscrew.•Hold adjust feet securely with a pipe wrench. Turnlocknut again using the spanner until it sits firmly up against the housing.Vibration and noise may occur if the locknuts do not sit firmly up against the houses.Drain hose connection1.Direct into a sinkIf the outlet spigot has not been used before, remove any blanking plug that maybe in place.Push the drain hose onto the spigot and secure with a clip if required, ensure aloop is formed in the drain hose to prevent waste from the sink entering thewashing machine.If required,the drain hose can be extended to a length of 4 m.LocknutsAdjustable feet Use process
9
Installation:2.Connected securely to a standpipeFirstly form a hook in the end of the drain hose using the “U” piece supplied.Place the drain hose into your standpipe, which should have an internal diameter of approximately 30mmthus ensuring there is an air break between the drain hose and standpipe.When discharging into a standpipe ensure that the top fo the standpipe is no more than 90cm and no lessthan 60cm above floor level.Water inlet connectionConnect the inlet hose supplied with the machine to a tap with a 3/4" thread.Do not use previously employed hoses.Installation should comply with local water authority and building regulations ‘ requirements.When there is a inlet valve at the back of the machine, it must be connected to a cold water supply. If there are two inlet valve, one is connected to a cold water supply and the otheris connected to a hot water supply. Follow the indication of the picture below to complete the connection.inlet valve for cold waterinlet hose for cold water with a white nutUse process
10
Use process
Control PanelTempMixedEco 40-60SyntheticsDelicates/silkDrum CleanSpinRinse+Spin20℃Super QuickDelayRinse+Press for 3"to reloadAnti-AllergyProgramSpeed
12131
Programmes: Page 9Display: Page 7
2
Buttons: Page 8
3
Digital display: This icon shows the time, speed, rinse times, Error codes. DisplayThe display shows the current settings, options or relevant information.The digital display can show:Delay time: the light under this icon will be lighting once the display shows the delay time.Child lock: the light under this icon will be lighting once child lock function is selected.Washing phase: the light above this icon will flicker during the washing phase.Spin and drain phase: the light above this icon will flicker during the spin and drain phase.Door lock: the light under this icon will be lighting when door lock is working.Rinse phase: the light above this icon will flicker during the rinse phase.Programme duration (e.g.1:20)Speed (e.g.1:20, on behalf of 1200 rpm)Temp (e.g.20,on behalf of 20℃)Rinse times (e.g. 2) Delay time (e.g.12h)Error codes (e.g. E01)
