Mitsubishi Electric MELSEC-A0J2H Series Bedienungsanleitung

Transition from MELSEC-A0J2H Series

to Q Series Handbook

Sep. 2018 Edition

A- 1

SAFETY PRECAUTIONS

(Read these precautions before using this product.)

Before using this product, please read this handbook and the relevant manuals introduced in this handbook

carefully and pay full attention to safety to handle the product correctly.

In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".

Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to

serious consequences.

Observe the precautions of both levels because they are important for personal and system safety.

Make sure that the end users read this handbook and then keep the handbook in a safe place for future

reference.

WARNING

CAUTION

Indicates that incorrect handling may cause hazardous conditions,

resulting in death or severe injury.

Indicates that incorrect handling may cause hazardous conditions,

resulting in minor or moderate injury or property damage.

A- 2

[Design Precautions]

WARNING

●Configure safety circuits external to the programmable controller to ensure that the entire system

operates safely even when a fault occurs in the external power supply or the programmable

controller. Failure to do so may result in an accident due to an incorrect output or malfunction.

(1) Configure external safety circuits, such as an emergency stop circuit, protection circuit, and

protective interlock circuit for forward/reverse operation or upper/lower limit positioning.

(2) When the programmable controller detects an abnormal condition, it stops the operation and all

outputs are:

All outputs may turn on when an error occurs in the part, such as I/O control part, where the CPU

module cannot detect any error. To ensure safety operation in such a case, provide a safety

mechanism or a fail-safe circuit external to the programmable controller. For a fail-safe circuit

example, refer to the QCPU User's Manual (Hardware Design, Maintenance and Inspection).

(3) Outputs may remain on or off due to a failure of an output module relay or transistor. Configure

an external circuit for monitoring output signals that could cause a serious accident.

●In an output module, when a load current exceeding the rated current or an overcurrent caused by a

load short-circuit flows for a long time, it may cause smoke and fire. To prevent this, configure an

external safety circuit, such as a fuse.

●Configure a circuit so that the programmable controller is turned on first and then the external power

supply.

If the external power supply is turned on first, an accident may occur due to an incorrect output or

malfunction.

●For the operating status of each station after a communication failure, refer to relevant manuals for

the network.

Incorrect output or malfunction due to a communication failure may result in an accident.

Q series module

All outputs are turned off

All outputs are held or turned off

according to the parameter setting.

A series module

All outputs are turned off

Overcurrent or overvoltage protection of the power supply

module is activated.

The CPU module detects an error such as a watchdog

timer error by the self-diagnostic function.

A- 3

[Design Precautions]

WARNING

●When changing data of the running programmable controller from a peripheral connected to the

CPU module or from a personal computer connected to an intelligent function module/special

function module, configure an interlock circuit in the sequence program to ensure that the entire

system will always operate safely.

For other forms of control (such as program modification or operating status change) of a running

programmable controller, read the relevant manuals carefully and ensure that the operation is safe

before proceeding.

Especially, in the case of a control from an external device to a remote programmable controller,

immediate action cannot be taken for a problem on the programmable controller due to a

communication failure.

To prevent this, configure an interlock circuit in the sequence program, and determine corrective

actions to be taken between the external device and CPU module in case of a communication

failure.

CAUTION

●Do not install the control lines or communication cables together with the main circuit lines or power

cables.

Keep a distance of 100mm or more between them.

Failure to do so may result in malfunction due to noise.

●When a device such as a lamp, heater, or solenoid valve is controlled through an output module, a

large current (approximately ten times greater than normal) may flow when the output is turned from

off to on.

Take measures such as replacing the module with one having a sufficient current rating.

●After the CPU module is powered on or is reset, the time taken to enter the RUN status varies

depending on the system configuration, parameter settings, and/or program size. Design circuits so

that the entire system will always operate safely, regardless of the time.

A- 4

[Installation Precautions]

CAUTION

●Use the programmable controller in an environment that meets the general specifications in the

QCPU User's Manual (Hardware Design, Maintenance and Inspection).

Failure to do so may result in electric shock, fire, malfunction, or damage to or deterioration of the

product.

●To mount the module, while pressing the module mounting lever located in the lower part of the

module, fully insert the module fixing projection(s) into the hole(s) in the base unit and press the

module until it snaps into place.

Incorrect mounting may cause malfunction, failure or drop of the module.

When using the programmable controller in an environment of frequent vibrations, fix the module

with a screw.

Tighten the screw within the specified torque range.

Undertightening can cause drop of the screw, short circuit or malfunction.

Overtightening can damage the screw and/or module, resulting in drop, short circuit, or malfunction.

●When using an extension cable, connect it to the extension cable connector of the base unit securely.

Check the connection for looseness.

Poor contact may cause incorrect input or output.

●When using a memory card, fully insert it into the memory card slot.

Check that it is inserted completely.

Poor contact may cause malfunction.

●When using an SD memory card, fully insert it into the SD memory card slot. Check that it is inserted

completely. Poor contact may cause malfunction.

●Securely insert an extended SRAM cassette into the cassette connector of a CPU module. After

insertion, close the cassette cover to prevent the cassette from coming off. Poor contact may cause

malfunction.

●Shut off the external power supply for the system in all phases before mounting or removing the

module. Failure to do so may result in damage to the product.

A module can be replaced online (while power is on) on any MELSECNET/H remote I/O station or in

the system where a CPU module supporting the online module change function is used.

Note that there are restrictions on the modules that can be replaced online, and each module has its

predetermined replacement procedure.

For details, refer to the relevant sections in the QCPU User's Manual (Hardware Design,

Maintenance and Inspection) and in the manual for the corresponding module.

●Do not directly touch any conductive parts and electronic components of the module, memory card,

SD memory card, or extended SRAM cassette. Doing so can cause malfunction or failure of the

module.

●When using a Motion CPU module and modules designed for motion control, check that the

combinations of these modules are correct before applying power. The modules may be damaged if

the combination is incorrect. For details, refer to the user's manual for the Motion CPU module.

A- 5

[Wiring Precautions]

WARNING

●Shut off the external power supply for the system in all phases before wiring.

Failure to do so may result in electric shock or damage to the product.

●After wiring, attach the included terminal cover to the module before turning it on for operation.

Failure to do so may result in electric shock.

CAUTION

●Ground the FG and LG terminals to the protective ground conductor dedicated to the programmable

controller.

Failure to do so may result in electric shock or malfunction.

●Use applicable solderless terminals and tighten them within the specified torque range. If any spade

solderless terminal is used, it may be disconnected when the terminal screw comes loose, resulting

in failure.

●Check the rated voltage and terminal layout before wiring to the module, and connect the cables

correctly.

Connecting a power supply with a different voltage rating or incorrect wiring may cause a fire or

failure.

●Connectors for external connection must be crimped or pressed with the tool specified by the

manufacturer, or must be correctly soldered.

Incomplete connections could result in short circuit, fire, or malfunction.

●Securely connect the connector to the module. Poor contact may cause malfunction.

●Do not install the control lines or communication cables together with the main circuit lines or power

cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction

due to noise.

●Place the cables in a duct or clamp them. If not, dangling cable may swing or inadvertently be pulled,

resulting in damage to the module or cables or malfunction due to poor contact.

●Check the interface type and correctly connect the cable. Incorrect wiring (connecting the cable to an

incorrect interface) may cause failure of the module and external device.

●Tighten the terminal screw within the specified torque range.

Undertightening can cause short circuit, fire, or malfunction.

Overtightening can damage the screw and/or module, resulting in drop, short circuit, or malfunction.

●Prevent foreign matter such as dust or wire chips from entering the module.

Such foreign matter can cause a fire, failure, or malfunction.

●A protective film is attached to the top of the module to prevent foreign matter, such as wire chips,

from entering the module during wiring.

Do not remove the film during wiring.

Remove it for heat dissipation before system operation.

●When disconnecting the cable from the module, do not pull the cable by the cable part. For the cable

with connector, hold the connector part of the cable. For the cable connected to the terminal block,

loosen the terminal screw. Pulling the cable connected to the module may result in malfunction or

damage to the module or cable.

A- 6

[Wiring Precautions]

[Startup and Maintenance Precautions]

CAUTION

●Mitsubishi programmable controllers must be installed in control panels.

Connect the main power supply to the power supply module in the control panel through a relay

terminal block.

Wiring and replacement of a power supply module must be performed by maintenance personnel

who is familiar with protection against electric shock. (For wiring methods, refer to the QCPU User's

Manual (Hardware Design, Maintenance and Inspection)).

WARNING

●Do not touch any terminal while power is on.

Doing so will cause electric shock or malfunction.

●Correctly connect the battery connector.

Do not charge, disassemble, heat, short-circuit, solder, or throw the battery into the fire. Also, do not

expose it to liquid or strong shock. Doing so will cause the battery to produce heat, explode, ignite, or

leak, resulting in injury and fire.

●Shut off the external power supply for the system in all phases before cleaning the module or

retightening the terminal screws or module fixing screws.

Failure to do so may result in electric shock.

CAUTION

●Before performing online operations (especially, program modification, forced output, and operation

status change) for the running CPU module from the peripheral connected, read relevant manuals

carefully and ensure the safety.

Improper operation may damage machines or cause accidents.

●Do not disassemble or modify the modules.

Doing so may cause failure, malfunction, injury, or a fire.

●Use any radio communication device such as a cellular phone or PHS (Personal Handy-phone

System) more than 25cm away in all directions from the programmable controller.

Failure to do so may cause malfunction.

●Shut off the external power supply for the system in all phases before mounting or removing the

module. Failure to do so may cause the module to fail or malfunction.

A module can be replaced online (while power is on) on any MELSECNET/H remote I/O station or in

the system where a CPU module supporting the online module change function is used.

Note that there are restrictions on the modules that can be replaced online, and each module has its

predetermined replacement procedure.

For details, refer to the relevant sections in the QCPU User's Manual (Hardware Design,

Maintenance and Inspection) and in the manual for the corresponding module.

A- 7

[Startup and Maintenance Precautions]

[Disposal Precautions]

[Transportation Precautions]

CAUTION

●After the first use of the product, do not mount/remove the module to/from the base unit, and the

terminal block to/from the module, and do not insert/remove the extended SRAM cassette to/from

the CPU module more than 50 times (IEC 61131-2 compliant) respectively. Exceeding the limit may

cause malfunction.

●After the first use of the SD memory card, do not insert/remove the memory card more than 500

times. Exceeding the limit may cause malfunction.

●Do not drop or apply shock to the battery to be installed in the module.

Doing so may damage the battery, causing the battery fluid to leak inside the battery.

If the battery is dropped or any shock is applied to it, dispose of it without using.

●Before handling the module, touch a grounded metal object to discharge the static electricity from

the human body.

Failure to do so may cause the module to fail or malfunction.

CAUTION

●When disposing of this product, treat it as industrial waste.

When disposing of batteries, separate them from other wastes according to the local regulations.

(For details of the battery directive in EU member states, refer to the QCPU User's Manual

(Hardware Design, Maintenance and Inspection).)

CAUTION

●When transporting lithium batteries, follow the transportation regulations.

For details on the regulated models, refer to the MELSEC-L CPU Module User's Manual (Hardware

Design, Maintenance and Inspection).

A- 8

CONDITIONS OF USE FOR THE PRODUCT

(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions;

i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident;

and

ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the

case of any problem, fault or failure occurring in the PRODUCT.

(2) The PRODUCT has been designed and manufactured for the purpose of being used in general industries.

MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED TO ANY AND ALL

RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY

INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE

OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR

WARNING CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL

BULLETINS AND GUIDELINES FOR the PRODUCT.

("Prohibited Application")

Prohibited Applications include, but not limited to, the use of the PRODUCT in;

• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the

public could be affected if any problem or fault occurs in the PRODUCT.

• Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality

assurance system is required by the Purchaser or End User.

• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator,

Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for Recreation and Amusement, and

Safety devices, handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling, and/or other

applications where there is a significant risk of injury to the public or property.

Notwithstanding the above restrictions, Mitsubishi may in its sole discretion, authorize use of the PRODUCT in one or

more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific

applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or

other safety features which exceed the general specifications of the PRODUCTs are required. For details, please

contact the Mitsubishi representative in your region.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Mitsubishi Electric Controller Handbücher

Mitsubishi Electric

Mitsubishi Electric MELSEC FX3U-232ADP Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC Q Series Betriebsanleitung

Mitsubishi Electric

Mitsubishi Electric TC-24B Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q172DCPU Betriebsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric PAC-WHS01HC-E Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC FX0N-8EX-UA1/UL Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MR-J5W-G Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric FX2N-20GM Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC-Q QnPHCPU Betriebsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSERVO J5 Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric NZ2GN2B1-32D Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric FX3G SERIES Gebrauchsanweisung

Mitsubishi Electric

Mitsubishi Electric MELSEC Q Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric NZ2GN2S-D41P01 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric FX3S-30MT/ES-2AD Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC FX2N-32DP-IF Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric FX3U-4AD Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
