MITSUBISHI

ELECTRIC

PRESENTATION PRODUCTS

Leading the evoLution of

HIGH-DEFINITION

digital signage

Slim eye-catching bezel design•

Advanced high-definition digital signage display•

Full 1920 x 1080 native resolution•

Optional CAT5 transmitter and receiver•

Front and rear ambient light sensors•

www.mitsubishi-presentations.com

888.307.0349

MDT421S

42” LCD Monitor

CLASS 42” (Diagonal) LCD Monitor

VIEWABLE IMAGE SIZE 36.6” x 20.6”

ORIENTATION Landscape / Portrait

BRIGHTNESS/LUMENS 700 cd/m2

PIXEL PITCH 0.485 mm

CONTRAST RATIO 1100:1

DIMENSIONS

(W x H x D in.)

38.0” x 22.0” x 4.6”

WEIGHT

(WITHOUT STAND

AND SPEAKERS)

52 lbs. (Net)

BEZEL WIDTH 0.63”

RESPONSE TIME 9 ms (gray to gray)

VIEWING ANGLE Horizontal and vertical: 178O

VIDEO/AUDIO

INPUTS AND OUTPUTS

mini D-Sub 15 pin In/Out, HDMI, DVI-D,

CAT5 In/Out (optional DP-1CA5),

DisplayPort, BNC (R,G,B,H,V), S-Video,

Composite (RCA, BNC), Audio LR (RCA),

Audio Stereo mini jack

SPEAKER OUTPUT External speaker jack

CONTROL INPUT/OUTPUT RS232C (mini D-Sub 9 In/Out)

POWER CONSUMPTION

(WITHOUT SPEAKERS)

214 W

ESTIMATED BACKLIGHT LIFE Up to 50,000 hours*

AUDIO SPEAKER Optional - SP-421S

TABLE STAND Optional - ST-421S

WALL MOUNT

COMPATABILITY

Optional - CTM-VESA

WARRANTY 3-years parts and labor, Express

Replacement Assistance, toll-free 24x7

technical support

*Results may vary depending on usage and operating environment

MITSUBISHI

ELECTRIC

PRESENTATION PRODUCTS

MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.

Presentation Products Division

Toll Free: 888.307.0349

Email: [email protected]

www.mitsubishi-presentations.com

Canada

Mitsubishi Electric Sales Canada Inc.

Information Technologies Group

Phone: 905.475.7728

www.mitsubishielectric.ca

LITMDT421S

Optional Stand:

ST-421S

MDT421S

42” LCD Monitor

multiple standard input and output connectors

Slot for optional CAT5

input/output connectors

(modular connector 8pin)

EXTERNAL CONTROL

(mini D-Sub 9 pin)

VIDEO IN/OUT

VIDEO IN CONNECTOR (BNC and RCA)

VIDEO OUT CONNECTOR (BNC)

S-VIDEO IN CONNECTOR (Mini DIN 4 pin)

RGB 4 IN/ DVD/HD IN (BNC)

AC IN connector

EXTERNAL SPEAKER TERMINAL

AUDIO OUT

AUDIO IN 1,2,3

RGB 1 IN (HDMI)

RGB 2 in (DVI-D)

RGB 3 IN (mini D-Sub 15 pin)

RGB out (mini D-Sub 15 pin)

RGB 6 IN (DisplayPort)

Side Connector

Panel

Rear Connector

Panel

Out OutIn In In In
