MULTIMEDIA DATA/VIDEO PROJECTORS

Feature Packed,

Budget Friendly

EX240U

NEW Mobile XGA Projector

BBB

XGA

1024x768

LUMENS

2500

2000:1

CONTRAST RATIO

CLOSED

CAPTION

SUPPORT

4000hr

Estimated Lamp Life*

29dBA

Noise Level*

5.3lbs

Ultra Portable

S.R.D. LAMP

TOP LOADING

USER REPLACEABLE

A New Definition of Value

Maximize your budget with the new Mitsubishi EX240U—a low

cost XGA projector that offers features you’d expect in higher

priced models. High-end features on the EX240U include an

HDMI connection as well as a 6-segment color wheel for a rich

and vivid spectrum. With the EX240U, your technology won’t

be limited by your budget

DLP Technology

DLP projectors have long been a classroom’s best choice. With

filter-free design comes reduced maintenance, saving both

time and costs—lowering the overall lifetime operating cost of

the unit while maintaining better longevity and durability.

Light & Bright

The EX240U weighs only 5.3lbs offering excellent portability or

easy light-weight installations while showing an impressive

brightness of 2500lm. From meeting rooms to classrooms,

clear images are displayed even with ambient light. With an

estimated lamp life of up to 4000 hours (in low mode), you’ll be

shining for quite a while.

3D-Ready—Enjoy the Future Today

Future-proof your installation with the 3D-Ready Mitsubishi

EX240U! Immersive, interactive 3D presentations are the

future of instructional education, and with the EX240U—you’ll

be ready. The 3D video content must be designed in field

sequential format, played in a 3D capable computer and active

shutter glasses are required.

Crestron RoomView™

The EX240U is equipped with a RJ-45 terminal for LAN

connectivity and remote operation when connected to a

network. Compatibility with Crestron®RoomView™software

enables integrated control of up to 250 projectors including

power on/off control, message display on multiple projectors

and confirmation of lamp service hours. RoomView automates

and streamlines several management and technical support

functions so you can work more efficiently and provide the best

possible support.

BrilliantColorTM •Filter-Free •Wall Screen •Password Lock •Direct Power Off •Long-life Lamp •LAN (RJ-45)

*low mode

EX240U

Monitor output

PC/Component video input

HDMI

Serial RS-232C

LAN (RJ-45)

4 5 6 7321

Audio input

Audio output

S-Video

Video

Input and Output Terminals

NEW

Screen size and Projection distance

As seen from the side

EX240U

Height

Projection Distance (L)

EX240U

0.55" 1-Chip DMD

1024 x 768 (Total 786,432 pixels)

2500lm

2000 : 1

40" - 300"

1.9 - 2.1

Model

Display Technology

Resolution

Brightness

Contrast Ratio

Picture Size*1

Throw Ratio*1

Specifications

PC Compatibility 640 x 480 - 1600 x 1200,

True: 1024 x 768, Sync on Green available

Video Compatibility

4000 hours*3(Low Mode),

3000 hours*3(Standard Mode)

Estimated Lamp Life

RGB: mini D-sub 15pin x 2

Video: RCA x 1 + S-VIDEO x 1

Digital: HDMI (Ver1.2) x 1

Audio: Stereo mini jack (ø3.5mm) x 1

RGB: mini D-sub 15pin x 1

Audio: Stereo mini jack (ø3.5mm) x 1

Input Terminals

Output Terminals

Communication Terminal

Speaker Output

Dimensions (W x H x D)

Weight

Power Requirements

Optional Accessories

Included Accessories

Warranty

RS-232C: D-Sub 9pin x 1 LAN: RJ-45 x 1

2W Mono

2.4kg / 5.3lbs

AC 100-240V, 50/60Hz

Replacement Lamp (VLT-EX240LP),

Ceiling mount

(PROJ-UCM-PRO2), Hard shell case (DKT1-ATAC)

Soft carrying bag, Remote control (With 2 batteries), Power cable,

VGA(D-sub) cable, User-Manual (CD-ROM), Safety manual, Lens Cap

3-Years of Parts/Labor, 3-Years of Express Replacement Assistance

(ERA), 1-year or 500 hours lamp warranty (whichever comes first)

Screen

Diagonal Size Width (W)Shortest

(Wide)Longest

(Tel e)Height (H)

inch

120

150

180

Distance from screen (L) Height

projected

image (Hd)

inch

100

150

200

250

300

102

152

203

254

381

508

635

762

inch

120

160

200

240

122

163

203

305

406

508

610

122

152

229

305

381

457

inch

120

150

225

300

375

450

1.5

2.3

3.0

3.8

5.7

7.6

9.5

11.4

inch

132

165

247

330

412

–

1.7

2.5

3.4

4.2

6.3

8.4

10.5

–

inch

Screen size chart (4:3 aspect ratio)

The above numbers are approximate, and may be slightly different from the actual measurements.

Screen

Diagonal Size Width (W)Shortest

(Wide)Longest

(Tel e)Height (H)

inch

123

135

Distance from screen (L)Height

projected

image (Hd)

inch

100

150

200

250

275

102

152

203

254

381

508

635

699

inch

131

174

218

240

133

177

221

332

443

553

609

100

125

187

249

311

342

inch

132

166

248

331

414

455

1.7

2.5

3.4

4.2

6.3

8.4

10.5

11.6

inch

109

146

182

273

364

455

–

1.9

2.8

3.7

4.6

6.9

9.3

11.6

–

inch

103

The above numbers are approximate, and may be slightly different from the actual measurements.

Screen size chart (16:9 aspect ratio)

NTSC / NTSC 4.43 / PAL (including PAL-M, N) / SECAM / PAL-60

Component Video: 480i/p (525i/p), 576i/p (625i/p),

720p (750p), 1080i/p (1125i/p 60Hz), 1080i/p (1125i/p 50Hz)

Unit:mm

Top View Bottom View

Front View Side View

Mobile XGA Projector

• Compliance with ISO21118-2005

• All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.

*1: Value may vary a few percent from that listed in the chart.

*2: The above numbers are approximate, and may be slightly different from the actual measurements.

*3: Lamp life specification is an estimate based on information provided by the lamp manufacturer and is not the duration

of the warranty. Lamp will shut-off automatically when usage reaches the specified estimated maximum lamp hours.

282

229 94

11.1” x 3.7” x 9.0” (Not including protrusion)

LITEX240U

New publication, effective May 2010.

Specifications subject to change without notice.

MITSUBISHI DIGITAL ELECTRONICS

AMERICA, INC.

Presentation Products Division

Phone: 888.307.0349

www.mitsubishi-presentations.com

MITSUBISHI ELECTRIC SALES

CANADA, INC.

Display & Imaging Solutions Division

Phone: 905.475.7728

www.mitsubishielectric.ca

Dimensions
