MULTIMEDIA DATA/VIDEO PROJECTORS

Functional Performance at its best

3000 ANSI lumens of outstanding brightness

2000:1 rich contrast ratio

Center lens design for easy symmetrical installation

Splash screen and wall screen support

Audio and video inputs for

computers and video sources

BrilliantColorTM Technology is Texas Instruments’ latest innovation for richer colors

and better imaging for vibrant displays

. At MitsubishiElectric, we developed a 6-

segment

color wheel that includes RGBWYC. Apart from the typical red, green, blue

and white, we added yellow and cyan segments to display a wider color spectrum.

In addition, we coded our color algorithms to emphasize brightness or color modes,

designed to match the environment where the EX52U is used.

Together with selective lamp powered modulation techniques, the EX52U with

BrilliantColorTM technology acts intelligently to boost colors to improve the intensity

and vibrancy of an entire display. For instance, when projecting an already-bright

screen image, the lamp is programmed to provide brighter, more vivid colors. In

contrast, if the image shows genuine color reproduction, the algorithm delivers just

the right colors with the appropriate radiance for maximum visual impact.

Original

BrilliantColor

Conventional

DLP projector's

color area

BrilliantColor

mode

Non-BrilliantColor

Color Gammut

BrilliantColor is a trademark of Texas Instruments.

BrilliantColorTM Technology and MitsubishiElectric’s Engineering

Yields Superior Color Performance

Splash screen

Lower Cost of Ownership for a Better Investment

Top-access lamp cover for easy lamp replacement

Filter-free design

Enhanced security features

with reinforced anti-theft bar

and password protection

Time-saving instant shut down feature

Top Access Lamp Cover

NEW

EX52U

Mobile XGA

The clarity to create smooth presentations.

L-188-8-B8073-A KYO 0806 Printed in Japan(MDOC)

New publication, effective Jun. 2008

Specifications subject to change without notice.

EX52U other projectors,

Screen size and Projection distance

Input and Output Terminals

*All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.

Audio speaker

Fan noise

Dimentions(WxHxD)

Weight

Power supply

Optional lamp

Video compatibility

Computer compatibility

Source lamp

Model

Display technology

Resolution

Brightness

Contrast

Picture Size

The above numbers are approximate, and may be slightly different from the actual measurements.

Screen size chart

Communication terminals

Output terminals

Input terminals

As seen from the side

Unit:mm

Dimensions

69.8

165.6

331.2

245.2

71.0128.3

14.6

57.9 58.6 198.7

300.0

19.0

24.3

87.0

101.7

Front

Side(Left)

Side(Right)

Top Bottom

Specifications

0.55”1-Chip DMD

1024 x 768 (total 786,432 pixels)

3000lm

2000:1

40”~300”

2W mono

332 x 102 x 250 mm / 13.1 x 4.0 x 9.8 inch (excluding height adjustment)

3.2kg / 7.0lbs

AC100-240V, 50/60Hz

NTSC / NTSC4.43 / PAL (including PAL-M, N) / SECAM/PAL-60

Component Video : 480i/p (525i/p), 576i/p (625i/p), 720p (750p), 1080i (1125i 60Hz), 1080i (1125i 50Hz)

230W (Shut Off Time 3000Hrs) with Low Mode, 280W (Shut Off Time 2000Hrs) with Standard Mode

640 x 480 ~ 1280 x 1024 True: 1024 x 768, Sync on green available

RS-232C (D-sub 9pin) x 1, USB terminal for Page Up/Down x 1

RGB : mini D-sub15pin x 2, Video : RCA x 1+ S-video x 1

Audio : stereo mini jack ( 3.5mm) x 1, RCA jack (L/R) x 1

RGB : mini D-sub15pin x 1, Audio : stereo mini jack ( 3.5mm) x 1

EX52U

VLT-XD520LP

34dBA (Low Mode)

Screen (4:3 aspect ratio)

Diagonal size Width (W)Shortest LongestHeight (H)

inch

Distance from screen (L)

Height projected

image (Hd)

inch cm inch cm cm inch

1.3

2.0

2.6

3.3

4.9

6.6

8.3

9.9

inch

1.6

2.4

3.2

4.0

6.0

8.0

10.0

–

inch cm

1.8

2.7

3.6

4.5

6.8

9.0

11.3

13.5

125

157

236

315

394

–

103

129

195

260

326

391

122

152

229

305

381

457

120

150

180

122

163

203

305

406

508

610

120

160

200

240

102

152

203

254

381

508

635

762

100

150

200

250

300

Screen (16:9 aspect ratio)

Diagonal size Width (W)Shortest LongestHeight (H)

inch

Distance from screen (L)

Height projected

image (Hd)

inch cm inch cm cm inch inch inch cm

1.4

2.1

2.9

3.6

5.4

7.2

9.0

10.8

1.7

2.6

3.5

4.4

6.5

8.7

10.9

–

5.2

7.9

10.5

13.1

19.6

26.2

32.7

39.3

100

102

137

171

258

344

430

–

113

141

213

284

356

427

100

125

187

249

311

374

19.6

29.4

39.2

49.0

73.5

98.1

122.6

147.1

133

177

221

332

443

553

664

34.9

52.3

69.7

87.2

130.7

174.3

217.9

261.5

102

152

203

254

381

508

635

762

100

150

200

250

300

NEW EX52U

Mobile XGA

EX52U

Height

Projection Distance(L)

PC / Component Video output

S-Video / RCA

Audio input [RCA jack (L/R)]

Audio input (stereo mini jack)

Audio output

Serial RS-232C

USB terminal for Page Up/Down

PC / Component Video input

(mini D-sub 15pin)

1 2 3 4 5 6 7 8
