•SAFETY PRECAUTIONS •

(Always read these instructions before using this equipment.)

Before using this product, please read this manual and the relevant manuals introduced in this manual

carefully and pay full attention to safety to handle the product correctly.

The instructions given in this manual are concerned with this product. For the safety instructions of the

programmable controller system, please read the CPU module user's manual.

In this manual, the safety precautions are ranked as "DANGER" and "CAUTION".

!DANGER

CAUTION

Indicates that incorrect handling may cause hazardous conditions,

resulting in death or severe injury.

Indicates that incorrect handling may cause hazardous conditions,

resulting in medium or slight personal injury or physical damage.

Note that the !CAUTION level may lead to a serious consequence according to the circumstances.

Always follow the instructions of both levels because they are important to personal safety.

Please save this manual to make it accessible when required and always forward it to the end user.

[Disposal Precautions]

!DANGER

•Please refer to the manual for each station concerning the operating status of each station when

communications errors occur in the station. There is danger of accidents due to wrong outputs

or wrong operations.

•When connecting a peripheral device to the CPU module or performing control of a

programmable controller which is being run through a BASIC program, configure an interlock

circuit in the sequence program so that the system overall is operating on the safe side at all

times. Also before exercising other control (program change, operating status change (status

control)) on the running programmable controller, read the manual carefully and fully confirm

safety. Especially for the above control on the remote programmable controller from, an

immediate action may not be taken for programmable controller trouble due to a data

communication fault. In addition to configuring up the interlock circuit in the sequence program,

corrective and other actions to be taken as a system for the occurrence of a data

communication fault should be predetermined between and programmable controller CPU.

•Do not write data to the "System Area" in the intelligent function module's buffer memory.

Also, do not turn ON the "Use Prohibited" output signals among the output signals from the

programmable controller CPU to the intelligent function module.

If data are written to the "System Area" or output in response to "Use Prohibited" signals, there

is danger that the programmable controller system will malfunction.

A - 2 A - 2

[Disposal Precautions]

!CAUTION

•Do not bunch the control wires or communication cables with the main circuit or power wires, or

install them close to each other. They should be installed 100mm (3.94 in.) or more away from

each other.

Not doing so could result in noise that would cause erroneous operation.

•If a BASIC program is registered in the flash ROM in the module, do not power OFF or reset the

programmable controller CPU at the station where the module is installed during registration.

If it is performed during registration, the data contents in the flash ROM will be erratic and it will

be necessary to reset the setting values, etc. in the buffer memory and register them again in

the flash ROM. It could also cause the module to break down or malfunction.

[Installation Precautions]

!CAUTION

•Use the programmable controller in an environment that meets the general specifications

contained in the user's manual of the CPU module to use.

Using this programmable controller in an environment outside the range of the general

specifications could result in electric shock, fire, erroneous operation, and damage to or

deterioration of the product.

•While pressing the installation lever located at the bottom of module, insert the module fixing tab

into the fixing hole in the base unit until it stops. Then, securely mount the module with the fixing

hole as a supporting point.

Incorrect loading of the module can cause a malfunction, failure or drop.

When using the programmable controller in the environment of much vibration, tighten the

module with a screw.

•Tighten the screw in the specified torque range.

Undertightening can cause a drop, short circuit or malfunction.

Overtightening can cause a drop, short circuit or malfunction due to damage to the screw or

module.

•Completely turn off the externally supplied power used in the system before mounting or

removing the module.

Not doing so could result in damage to the product.

•Do not directly touch the conductive area or electronic components of the module.

Doing so may cause malfunction or failure in the module.

A - 3 A - 3

[Wiring Precautions]

!CAUTION

•When turning on the power supply or operating the module after installation or wiring work, be

sure that the module's terminal covers are correctly attached. Not attaching the terminal cover

could result in electric shock.

•External connections shall be crimped or pressure welded with the specified tools, or correctly

soldered.

Imperfect connections could result in short circuit, fires, or erroneous operation.

•Securely insatll the connector to the module.

•Be sure to fix communication cables leading from the module by placing them in the duct or

clamping them.

Cables not placed in the duct or without clamping may hang or shift, allowing them to be

accidentally pulled, which may cause a module malfunction and cable damage.

•When connecting cables, be sure to do so correctly after confirming the type of interface you are

connecting to. If connection is made to a different interface or if wiring is faulty, it could cause

the module or external device to break down.

•Tighten the terminal screws with the specified torque.

If the terminal screws are loose, it could result in short circuits, fire, or erroneous operation.

Tightening the terminal screws too far may cause damages to the screws and/or the module,

resulting in fallout, short circuits, or malfunction.

•When disconnecting the communications cable or power cable that is connected to the module,

do not disconnect it by grasping the cable with your hand and pulling it.

Disconnect cables with connectors attached by taking hold of the connector at the connection

with the module and pulling the connector. For cables connected to a terminal block, remove the

cable after loosening the terminal block screws.

If the cable is pulled while it is connected to the module, it could cause malfunction or damage

the module or the cable.

•Be sure there are no foreign substances such as sawdust or wiring debris inside the module.

Such debris could cause fires, damage, or erroneous operation.

•The module has an ingress prevention label on its top to prevent foreign matter, such as wire

offcuts, from entering the module during wiring.

Do not peel this label during wiring.

Before starting system operation, be sure to peel this label because of heat dissipation.

A - 4 A - 4

[Startup and Maintenance precautions]

!CAUTION

•Do not disassemble or modify the modules.

Doing so could cause trouble, erroneous operation, injury, or fire.

•Completely turn off the externally supplied power used in the system before mounting or

removing the module. Not doing so could result in damage to the product.

•Do not install/remove the module to/from the base unit, or the terminal block to/from the module

more than 50 times after the first use of the product. (IEC 61131-2 compliant)

Failure to do so may cause malfunction.

•Do not touch the terminals while power is on.

Doing so could cause shock or erroneous operation.

•Switch off all phases of the externally supplied power used in the system when cleaning the

module or retightening the terminal or module fixing screws.

Not doing so could result in electric shock.

Undertightening of terminal screws can cause a short circuit or malfunction.

Overtightening of screws can cause damages to the screws and/or the module, resulting in

fallout, short circuits, or malfunction.

•Before touching the module, always touch grounded metal, etc. to discharge static electricity

from human body, etc.

Not doing so can cause the module to fail or malfunction.

[Operating Precautions]

!CAUTION

•When performing control (in particular, changing data, changing a program or changing the

operation status (status control)) of the programmable controller during operation using a BASIC

program, do so only after reading the user's manual thoroughly and taking adequate safety

precautions.

If there are errors when changing data, changing a program or in status control, it could result in

system malfunction, or cause mechanical damage or accidents.

[Disposal Precautions]

!CAUTION

•When disposing of this product, treat it as industrial waste.

A - 5 A - 5

REVISIONS

The manual number is given on the bottom left of the back cover.

Print Date Manual Number Revision

Apr., 2000 SH(NA)-080089-A First printing

Sep., 2000 SH(NA)-080089-B Addition

Section 1.3, Section 2.3, 2.3.1, 2.3.2, 2.4

Dec., 2003 SH(NA)-080089-C Correction

Section 2.1, 6.2

Correction

SAFETY PRECAUTIONS, About Manuals, Conformation to the EMC

Directive and Low Voltage Instruction, About the Generic Terms and

Abbreviations, Chapter 1, Section 2.1, 2.3, 2.4, 2.5, Section 3.1, 3.2.1,

3.3.2(2), 3.8.1, Section5.1, 5.5.1

Term change

Before change After change

GPPW GX Developer

MELSECNET/10H MELSECNET/H

Oct., 2004 SH(NA)-080089-D

Feb., 2006 SH(NA)-080089-E Correction

SAFETY PRECAUTIONS, About Manuals, Conformation to the EMC

Directive and Low Voltage Instruction, How to read this manual, and

Configuration, Section 1.1 to 1.3, Section 2.1, 2.5, Section 3.1, 3.2.1,

3.3.1, 3.3.3, 3.4, 3.5, 3.5.1 to 3.5.7, 3.6 to 3.8, 3.8.1, 3.8.2, 3.9, 3.10,

3.10.1 to 3.10.3, 3.11, 3.11.1 to 3.11.4, 3.12.1, 3.13.1, 3.13.2,

Section 4.1, 4.2, 4.2.1, 4.2.2, 4.3, 4.3.2, 4.4.1, 4.4.5, 4.5, 4.5.3, 4.5.4,

4.8.2, Section 5.2 to 5.5, 5.5.2, 5.6.1, 5.6.2, Section 6.1, 6.2,

Appendix-1, Appendix-2, Appendix-2.1, Appendix-3

Deletion

Appendix-2.2 (incorporated into Appendix-2.1)

Oct.,2006 SH(NA)-080089-F Correction

SAFETY PRECAUTIONS, Section 2.1

Aug.,2008 SH(NA)-080089-G

Change of a term

"PLC" was changed to "programmable controller".

Correction

SAFETY PRECAUTIONS, Compliance with the EMC and Low Voltage

Directives, About The Generic Terms and Abbreviations, Section 1.2,

2.1, 2.3, 2.4, 2.6, 3.1 to 3.3, 5.1, 5.3 to 5.5, 5.6.2, 5.7, 6.2, Appendix-3

Japanese Manual Version SH-080092-H

This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent

licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property

rights which may occur as a result of using the contents noted in this manual.

A - 6 A - 6

INTRODUCTION

Thank you for purchasing the MELSEC-Q series programmable controller.

Before using the equipment, please read this manual carefully to develop full familiarity with the functions

and performance of the Q series programmable controller you have purchased, so as to ensure correct use.

CONTENTS

SAFETY PRECAUTIONS..............................................................................................................................A- 1

REVISIONS ....................................................................................................................................................A- 5

CONTENTS....................................................................................................................................................A- 6

About Manuals ...............................................................................................................................................A- 9

Conformation to the EMC Directive and Low Voltage Instruction ................................................................A- 9

How to read this manual, and Configuration .................................................................................................A-10

About The Generic Terms and Abbreviations...............................................................................................A-11

Meaning of Terms and Their Contents..........................................................................................................A-13

Product Configuration ....................................................................................................................................A-13

1 OVERVIEW 1- 1 to 1- 9

1.1 Operation Overview for QD51 (-R24)..................................................................................................... 1- 2

1.2 Features of QD51 (-R24) ........................................................................................................................ 1- 4

1.3 About the Function Added/Changed to the Function Version B ........................................................... 1- 9

2 SYSTEM CONFIGURATION AND USABLE FUNCTIONS 2- 1 to 2-11

2.1 Application Systems................................................................................................................................ 2- 1

2.2 Combining the Opposite Party's Device and the Programmable controller CPU................................. 2- 4

2.3 For Use in Multiple CPU System ............................................................................................................ 2- 6

2.4 For Use with Redundant CPUs .............................................................................................................. 2- 7

2.5 For Use at MELSECNET/H Remote I/O Station.................................................................................... 2- 8

2.6 How to confirm the function version ....................................................................................................... 2-10

3 SPECIFICATIONS 3- 1 to 3-66

3.1 Performance Specifications .................................................................................................................... 3- 1

3.2 RS-232 Interface Specifications ............................................................................................................. 3- 3

3.2.1 RS-232 connector specifications ..................................................................................................... 3- 3

3.2.2 RS-232 cable specifications............................................................................................................. 3- 4

3.3 RS-422/485 Interface Specifications ...................................................................................................... 3- 5

3.3.1 RS-422/485 terminal block specifications ....................................................................................... 3- 5

3.3.2 RS-422/485 cable specifications ..................................................................................................... 3- 6

3.3.3 Cautions during data communications with a RS-422/485 line...................................................... 3- 7

3.4 List of Commands and Functions in AD51H-BASIC.............................................................................. 3-10

3.5 QD51 (-R24) Internal Memory ................................................................................................................ 3-16

3.5.1 Program area.................................................................................................................................... 3-18

3.5.2 Buffer memory.................................................................................................................................. 3-20

3.5.3 Common memory............................................................................................................................. 3-23

3.5.4 Expansion register (ED0 to ED1023) .............................................................................................. 3-26

A - 7 A - 7

3.5.5 Special register (ED9000 to ED9127) ............................................................................................. 3-31

3.5.6 Expansion relay (EM0 to EM1023).................................................................................................. 3-35

3.5.7 Special relay (EM9000 to EM9127)................................................................................................. 3-38

3.6 Receive Buffer......................................................................................................................................... 3-41

3.7 List of GX Developer Setting Items for the QD51 (-R24)....................................................................... 3-42

3.8 List of Input/Output Signals From/To the Programmable controller CPU............................................. 3-43

3.8.1 Input (X) detailed explanation .......................................................................................................... 3-45

3.8.2 Output (Y) detailed explanation ....................................................................................................... 3-49

3.9 Relationship between the QD51 (-R24) Start Condition and the Flash ROM Execution

Program Area.......................................................................................................................................... 3-53

3.10 QD51 (-R24) Operation when the Power is Turned On ...................................................................... 3-54

3.10.1 In the case of the programming mode........................................................................................... 3-54

3.10.2 In the case of the multitask debug mode ...................................................................................... 3-55

3.10.3 In the case of the run mode ........................................................................................................... 3-56

3.11 Running a Task (a created program) ................................................................................................... 3-57

3.11.1 Conditions for permitting running of a task and start conditions................................................... 3-57

3.11.2 Starting by turning the power on or by reset (start condition: START) ........................................ 3-58

3.11.3 Starting by an interrupt from the programmable controller CPU (Start Condition: IT)................. 3-60

3.11.4 Starting by a start request from another task (Start condition: BOOT, ON)................................. 3-61

3.12 Running a BASIC Program by Multitask Processing........................................................................... 3-63

3.12.1 Multitask processing....................................................................................................................... 3-63

3.13 BASIC Program Priority Order (Priority)............................................................................................... 3-64

3.13.1 Synchronizing execution between BASIC programs (Event control) ........................................... 3-65

3.13.2 Sharing equipment (Resources) by multitasking .......................................................................... 3-66

4 ABOUT QD51 (-R24) FUNCTIONS 4- 1 to 4-24

4.1 List of Functions ...................................................................................................................................... 4- 1

4.2 Communications with a Console / Terminal........................................................................................... 4- 2

4.2.1 Communications with a console ...................................................................................................... 4- 3

4.2.2 Communications with a terminal...................................................................................................... 4- 6

4.3 Printing by a Printer................................................................................................................................. 4-10

4.3.1 Printing from a printer connected to an interface that is not set in the console ............................. 4-11

4.3.2 Printing from a printer connected to the console ............................................................................ 4-13

4.4 Communications with the External Device............................................................................................. 4-14

4.4.1 If data are being sent ....................................................................................................................... 4-14

4.4.2 If data are received........................................................................................................................... 4-15

4.5 Communications with the Programmable controller CPU ..................................................................... 4-16

4.5.1 ON/OFF data communications by general output (X/Y)................................................................. 4-17

4.5.2 Reading and writing data from/to buffer memory............................................................................ 4-18

4.5.3 Reading and writing data from/to the programmable controller CPU ............................................ 4-19

4.5.4 Reading and writing data from/to the programmable controller CPU's expansion file register..... 4-20

4.6 Reading and Writing Data from/to the Buffer Memory of Another Intelligent Function Module/

Special Function Module ........................................................................................................................ 4-21

4.7 Reading and Writing Clock Data ............................................................................................................ 4-22

4.8 Data Communications Between Tasks .................................................................................................. 4-23

4.8.1 ON/OFF data communications by expansion relay (EM) ............................................................... 4-23

4.8.2 Data communications by expansion register (ED).......................................................................... 4-24

A - 8 A - 8

4.8.3 Data communications by common memory.................................................................................... 4-24

5 SETTINGS AND PROCEDURES UP UNTIL OPERATION 5- 1 to 5-17

5.1 Handling Precautions.............................................................................................................................. 5- 1

5.2 Settings and Procedures Up Until Operation ......................................................................................... 5- 2

5.3 Names of Parts and Functions ............................................................................................................... 5- 3

5.4 Connection with a Console, Debugger................................................................................................... 5- 4

5.5 Connection with the External Device...................................................................................................... 5- 5

5.5.1 Connecting to the RS-232 interface ................................................................................................ 5- 6

5.5.2 Connecting to the RS-422/485 interface ......................................................................................... 5- 8

5.6 Setting from the GX Developer............................................................................................................... 5-11

5.6.1 I/O assignment settings.................................................................................................................... 5-11

5.6.2 Switch setting for I/O and intelligent function module ..................................................................... 5-12

5.6.3 Intelligent function module interrupt point settings .......................................................................... 5-16

5.7 Maintenance, Checks ............................................................................................................................. 5-17

6 EXCLUSIVE COMMANDS 6- 1 to 6- 2

6.1 Exclusive Command List and Available Devices ................................................................................... 6- 1

6.2 Z(P). YCHECK ........................................................................................................................................ 6- 2

7 TROUBLESHOOTING 7- 1 to 7- 3

7.1 About QD51 (-R24) Status Checks ........................................................................................................ 7- 1

7.1.1 Checking the LED lighting status, communications error status and QD51 (-R24) switch

setting status .................................................................................................................................... 7- 1

7.1.2 Errors that occur in BASIC............................................................................................................... 7- 3

APPENDIX App- 1 to App- 7

Appendix-1 Comparison of Functions with Previous Modules ................................................................App- 1

Appendix-2 About Use of Programs from Previous Modules ..................................................................App- 2

Appendix 2.1 About use of A1SD51S, AD51H-S3 programs ..............................................................App- 2

Appendix-3 External Dimensions .............................................................................................................App- 6

INDEX Index- 1 to Index- 2

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Mitsubishi Controller Handbücher

Mitsubishi

Mitsubishi FX2NC-16EX Anleitungen und Rezepte

Mitsubishi

Mitsubishi Q2ACPU Bedienungsanleitung

Mitsubishi

Mitsubishi MELDAS TRS50 Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC Q Series Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC-F FX1N-40MT-001 Bedienungsanleitung

Mitsubishi

Mitsubishi FX3U-64CCL Bedienungsanleitung

Mitsubishi

Mitsubishi q64rd Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC-F GRAPHIC FX DU Bedienungsanleitung

Mitsubishi

Mitsubishi FX2N-2LC Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC QS Series Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC-Q/L Betriebsanleitung

Mitsubishi

Mitsubishi MELSEC-QnA Series Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC Q Series Bedienungsanleitung

Mitsubishi

Mitsubishi FX3UC Series Bedienungsanleitung

Mitsubishi

Mitsubishi A-Melsec A1FXCPU Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC FX3U-4DA Bedienungsanleitung

Mitsubishi

Mitsubishi FX2N-4AD-PT Bedienungsanleitung

Mitsubishi

Mitsubishi JY992D74401C Bedienungsanleitung

Mitsubishi

Mitsubishi FX3U-32DP Bedienungsanleitung

Mitsubishi

Mitsubishi AJ65SBT2B-64RD3 Bedienungsanleitung

Mitsubishi

Mitsubishi 00JCPU Bedienungsanleitung

Mitsubishi

Mitsubishi Q00JCPU Bedienungsanleitung

Mitsubishi

Mitsubishi FX-16NP-S3 Bedienungsanleitung

Mitsubishi

Mitsubishi FX3UC Series Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
