FEVERTRACK - Ear and Forehead

Thermometer

Model No.: 70116

Instruction Manual

Please read this instruction manual completely before operating.

Package Contents

Quantity

1pc

2pc

1pc

Parts

FEVERTRACK Thermometer

1.5V (AAA) batteries

User Manual

Thermometer Specification

Power Supply:

Body Measuring Range:

Ear and Forehead Measure Accuracy:

Object Measuring Range:

Object Measure Accuracy:

Dimention:

Weight:

Forehead operating Condition:

Ear and Object operating Condition:

Atmosphere pressure:

Service life:

Service life of the battery:

DC 3V (2 x AAA)

89.6°F –109.3°F (32.0°C –42.9°C)

Within range of 95.0°F –107.6°F (35.0°C- 42.0°C):

Accuracy = ±0.4°F (±0.2°C)

Outside of stated range:

Accuracy = ±0.5°F (±0.3°C)

41.0°F –139.8°F (5.0°C - 59.9°C)

±2.0°F (1.0°C)

150.0(L)x40.5(W)x 50.0(H)mm(±2mm)

61.0g (without batteries)

59.0°F –104.0°F (15.0°C –40.0°C)

With a relative humidity of 20% –85%

50.0°F –104.0°F (10.0°C –40.0°C)

With a relative humidity of 20% –85%

700hPa –1060hPa

2 years

6 months based on the use frequency at 5 times/day

Product Specification

1. Forehead Temperature Symbol

2. Ear Temperature Symbol

3. Object Temperature Symbol

4. Low Battery Symbol

5. Temperature Display

6. Celsius/Fahrenheit Symbol

7. Health Check

8. Cleaning Symbol

9. Memory Symbol

10. Temperature Trending Indication

Note: When the device is powered on all icons are temporarily displayed on screen, this is not an

indicator of battery power. Battery indicator will display constantly when battery level is low.

1. Infrared Sensor

2. LCD Display

3. Power & Scan Button

4. Probe Cap

5. MEM/SET Button

6. Temperature Mode Selection

7. Battery Cover

Installing/Replacing Battery

•Remove the battery cover by sliding it toward the bottom of the thermometer.

•Insert or replace 2 x 1.5 AAA batteries into the battery compartment, ensuring to match the

indicating polarity symbols (always use new batteries).

•Replace the battery cover on to the thermometer ensuring it snaps closed.

Temperature Indicators

Temperature Trend Indication Arrows: This indicator helps to easily identify whether the temperature

measurement result is higher or lower than the previous temperature taken. If the temperature rises, the

indicators will light upwards in sequence; if the temperature drops the indicator will light downwards in

sequence, as shown below.

Temperature LED Indication: There are two color LED temperature indicators in this unit. When a

temperature is taken the corresponding light will illuminate around the ‘POWER/SCAN’ button.

Green LED: 34.0°C (93.2°F) - 37.9°C (100.3°F)

Red LED: 38.0°C (100.4°F) - 43.0°C (109.4°F)

Celsius and Fahrenheit Setting

•When thermometer is turned on press and hold the ‘MEM/SET’ button until you hear a beep, to

switch between Celsius and Fahrenheit.

Measurement Preparation For Best Results

•For more accurate measurements always store the device in same environment it is being used, for

at least 30 minutes prior. An unexpected fluctuation of ambient temperature is likely to lower

measuring accuracy.

•External factors may influence ear and forehead temperatures, particularly when the individual has

been:

oLying on the ear to be measured or has it covered.

oExposed to very hot or cold temperatures.

oSwimming or bathing causing the ear canal to be wet.

oRecently exercising, bathing or other physical exertion as this increase’s temperature.

•Do not talk or move body during measurement.

•Make sure to dry forehead or keep ear canal clean. Unclean ear canal or excessive hair may cause

inaccurate reading.

•The infrared sensor must be kept clean, dry and undamaged to ensure accurate results. Please wait

5-15 minutes before taking measurement again.

•Replace battery when low battery indicator is “ON”.

•Use of this device is not intended as a substitution for consultation with your physician.

Measurement results are for reference only. Contact your physician if you have or suspect and

health concerns.

•For individuals using hearing aids or ear plugs remove any such device and wait 30 minutes before

taking an ear temperature.

Thermometer Operating Guide

Ear temperature measurement:

•Press the ‘SCAN/POWER’ button to turn the thermometer ‘On’.

•To measure temperature via ear, remove the forehead probe cover from the unit.

•Press the ‘MODE’ button to switch to ear temperature mode, “ ” symbol will be displayed on

screen.

•Insert the ear probe tip slightly into the ear opening, then press & release the ‘SCAN’ button to

measure the body temperature.

•Once you hear a short beep the body temperature will be displayed. Please allow 6 seconds before

the next reading. The “ ” icon will stop flashing in the display.

Forehead temperature measurement:

•To measure temperature via the forehead, ensure forehead probe cover is attached.

•Press the ‘MODE’ button to switch to forehead temperature mode “ ” symbol will be displayed on

screen.

•Gently touch the entire tip of the probe to the center of the forehead, midway between the

eyebrows and the hairline. Ensure no hair is obstructing the unit, then press the ‘SCAN’ button, you

will hear a short beep and the temperature will be displayed.

Note: Results shown from 89.6

F to 109.4

F (32.0

C to 43

C). ‘HI’is displayed for all results above

109.4

F (43

C), and ‘LO’displayed for result below 89.6

F (32.0

C).

Object temperature measurement:

•Remove the forehead cap.

•Press the ‘MODE’ button to switch to ‘object’ mode. “ ” will show up on the display.

•Hold the thermometer approximately 1cm away from the object surface, press and release the

‘SCAN’ button aiming the measurement sensor at the object.

•Once you hear the short beep the object temperature will be displayed.

Note: If display shows HI/LOW please make sure thermometer is in ‘object’ mode.

Care and Maintenance

Lens / Measurement Sensor

•Gently clean with an alcohol swab. Do not use water to wash the thermometer lens directly.

Thermometer

•Clean with a soft, dry cloth. Do not use water to rinse the device.

Note: The thermometer is programmed to remind the user to clean the device, ‘ ’ will flash on screen.

Press any button to exit this notification, and please clean the unit.

Health Check

•Press buttons ‘MEM/SET’and ‘MODE’together for 2 seconds to enter the countdown. Use the

‘MODE’button to toggle between 15 minutes, 30 minutes or 45 minutes or OFF.

•Press the ‘MEM/SET’button when the desired time is on screen to start counting down. When the

countdown is active and running in the background the “ ” sign will flash on screen.

•When the countdown begins, the user can press ‘MEM/SET’ and ‘MODE’ button together for 2

seconds to display the remaining time, then press ‘SCAN’ button to return to waiting mode or press

‘MEM/SET’ button to cancel the countdown.

•When the countdown is zero. Health check “ ” symbol will display on LCD and the unit will ‘BEEP’ to

remind the user. To stop the notification’s and return to the home menu press any button.

Memory Function

•This unit can recall up to 9 prior measurements stored in memory.

•Turn on thermometer, press the ‘MEM’button once, then press it again to show the last

measurement.

•The symbols for ‘EAR’ or ‘FOREHEAD’ will appear with each measurement stored in memory to

indicate whether a person’s forehead or ear temperature was taken.

•Each press of the same button recalls a previous measurement.

Troubleshooting

Problem

Checklist

Countermeasure

No response/automatic reset

when pulling out plastic insulator

tab.

Batteries are low or dead

Batteries installed in wrong

polarity?

Poor battery contact?

Change to new batteries

Remove batteries and reinsert

batteries correctly

Measured temperature is lower

than 89.6°F/32.0°F or higher than

109°F/42.9°C

Follow steps in user manual for

correct measurements.

Check the device is in the correct

operating mode.

These Error messages indicate a

problem with the hardware.

Contact Mobi Technologies, Inc.

via contactin information at the

end of this manual.

Operating Temperature is out of

the range

Use the thermometer in the range

of operating conditions

The sensor temperature has not

been stabilised

Wait 10 seconds and take a

measurement again.

The measurement is not accurate

or there is doubt of measurement

results.

Check to see if the infrared sensor

is clean or not.

Clean the infrared senosr with

cotton swab according to the user

manual.

Determine whether your

measuring method is correct or

not.

Please review the user manual

and ensure you are operating the

thermometer correctly.

Assess whether or not you hae

allowed the thermeter and the

patient to become stabilized in the

room for 30 minutes.

Please ensure the thermometer

and patient remain in the location

for at least 30 minutes before

recording a temperature.

Are you using the thermometer

indoors or outdoors.

Always do the measurements

indoors.

Determine if you might have held

the thermometer in your hand too

long which may affect its accuracy.

Place the thermometer in the

room where the measurement is

due to be taken, let it stabilize for

30 minutes before use.

Check to see if the Low Battery

icon is showing on the LCD screen.

Immediately replace the batteries

with new ones.

Product Safety & Warnings

WARNING:

This product was designed to measure human body temperature on the forehead, do not

use this for any other purpose.

Do not use this thermometer if it has been malfunctioning or it has been broken or

damaged.

This product is not waterproof. Do not use this product under any wet conditions and do

not immerse in any liquid or water.

This product should not be left alone with children or pets with not in use by an adult.

Do not store the thermometer in extreme temperatures below (-4°F / -20°C) or over

(131°F/ 55°C).

Do not use the product in a wet ear canal after swimming or bathing. It is possible to

damage the ear canal.

Equipment Symbols

Warning

Compliance with WEEE Standard

Non Sterile Packaging

DO NO THROW AWAY intended for

multiple use

Refer to Operating Instructions

Operating atmospheric pressure

Operating Temperature

Serial number

Operating Humidity

Recyclable

Manufacturer

This device compiles with Part 15

of FCC (federal commuinications

Commission) Rules.

IP22: The first number 2: Protected against solid foreign objects to 12.5mm Φ and greater.

The second number: Protected against vertically falling water drops, when enclosure titled

up to 15°.

Limited Product Warranty

MOBI® warrants its products to be free from defects in material and workmanship for period of (1 Year) from

the date of purchase. Should the product prove to be defective at any time during the warranty period, we

would either replace or repair the product at our option without charge. After the warranty period, a service

charge will apply for replacement of parts and labor costs. To obtain warranty service, you must return the

product complete with its original parts & accessories along with a copy of the original purchase, gift or

registry receipt to us. This warranty does not cover damage caused by any tampering, accident, misuse, abuse,

improper maintenance, unauthorized modification, or connection to an improper power supply. There will be

a charge for repair caused for such damage. This warranty excludes all incidental or consequential damages

and any liability other than stated above.

Questions?

Please visit: www.getmobi.com

Email: [email protected]

Note: For Detailed Instructional Manual please follow this link: http://www.getmobi.com/users-manuals

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Mobi Technologies Thermometer Handbücher

Mobi Technologies

Mobi Technologies HEALTH CHECK Bedienungsanleitung

Mobi Technologies

Mobi Technologies 70113 Bedienungsanleitung

Mobi Technologies

Mobi Technologies HTD8813C Bedienungsanleitung

Mobi Technologies

Mobi Technologies 70118 Bedienungsanleitung

Mobi Technologies

Mobi Technologies 70125 Bedienungsanleitung

Mobi Technologies

Mobi Technologies DualScan Prime 3 Bedienungsanleitung

Mobi Technologies

Mobi Technologies tempTalk Bedienungsanleitung

Mobi Technologies

Mobi Technologies 700026 Bedienungsanleitung

Mobi Technologies

Mobi Technologies 70117 Bedienungsanleitung

Mobi Technologies

Mobi Technologies DualScan Bedienungsanleitung

Mobi Technologies

Mobi Technologies 70119 Bedienungsanleitung

Mobi Technologies

Mobi Technologies PRIME Bedienungsanleitung

Mobi Technologies

Mobi Technologies PRIME Bedienungsanleitung

Mobi Technologies

Mobi Technologies BT-A13 Bedienungsanleitung

Mobi Technologies

Mobi Technologies DualScan prime Bedienungsanleitung

Beliebte Thermometer Handbücher anderer Marken

Delton

Delton 981A Bedienungsanleitung

Baker

Baker MM2P Bedienungsanleitung

Tarmo

Tarmo 320281 Bedienungsanleitung

Citizen

Citizen CTD 504 Bedienungsanleitung

TFA

TFA 14.1500 Bedienungsanleitung

Vive

Vive DMD1010 Bedienungsanleitung

Gotemp

Gotemp THB4002 Bedienungsanleitung

GREISINGER

GREISINGER G 1202 Bedienungsanleitung

Amprobe

Amprobe TMD-53W Bedienungsanleitung

Trotec

Trotec BP10 Bedienungsanleitung

Radiance instruments

Radiance instruments RT616 Series Bedienungsanleitung

Eurolec

Eurolec IR151 Bedienungsanleitung

Scaneo

Scaneo TS42B Bedienungsanleitung

Sper scientific

Sper scientific 800043 Bedienungsanleitung

Microlife

Microlife NC 200 Bedienungsanleitung

Motorola

Motorola MBP69SN Konfigurationshandbuch

The MeatStick

The MeatStick The MeatStick Bedienungsanleitung

Hama

Hama TH35-A Bedienungsanleitung
