MD-HPBT01

Bluetooth Stereo Headset

Before using your new product, please read these instructions to prevent any damage.

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 1 Tuesday, July 8, 2014 10:25 AM

Modal MD-HPBT01 Bluetooth

Stereo Headset

Contents

Introduction ...................................................................... 2

Features............................................................................... 3

Setting up your stereo headphones......................... 6

Using your stereo headphones .................................. 6

Maintaining .....................................................................15

Troubleshooting ............................................................15

Specifications..................................................................18

Legal notices ...................................................................19

One-Year Limited Warranty........................................21

Introduction

Congratulations on your purchase of a high-quality Modal product.

Your MD-HPBT01 represents the state of the art in Bluetooth stereo

headset design and is designed for reliable and trouble-free

performance.

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 2 Tuesday, July 8, 2014 10:25 AM

3MD-HPBT01

Features

Package contents

• Bluetooth stereo headset

•ACwalladapter

• USB charging cable

•Replacementearpads

• Quick Setup Guide

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 3 Tuesday, July 8, 2014 10:25 AM

Side view

#Item Description

Logo with

indicator LED

Indicator LED show current status of the headphones. See the LED

Indicators table on page 5.

Volume Up/Down Press + or – to increase or decrease the volume.

(power/talk)

button

Press to turn on your stereo headphones. If you receive a phone

call, press to talk. Press to turn off your stereo headphones.

(play/pause)

button

Press to begin playback. During playback, press to pause

playback. Press again to resume playback.

Micro USB connector Plug the micro USB connector from the AC adapter into this port

to charge your headphones.

(rewind)

• Press once to return to the beginning of a track.

• Press twice to go to the previous track.

• Press and hold to rewind.

(fast forward) • Press once to skip to the next track.

• Press and hold to fast-forward.

Microphone Allows you to talk on the telephone.

Reflective strip An attractive feature and provides extra safety in low-light

conditions.

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 4 Tuesday, July 8, 2014 10:25 AM

5MD-HPBT01

LED indicators

Headphones status LED status

Power on Blue LED flashes

Turning off Red LED dims and disappears

Low battery Red LED blinks continuously

Recharging Red LED stays on

Recharging complete Blue LED stays on

Pairing mode Blue and red LEDs flash rapidly

Connection complete Blue LED blinks every five seconds

Receiving a call Blue LED flashes rapidly

Talking on the phone Blue LED brightens and dims repeatedly

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 5 Tuesday, July 8, 2014 10:25 AM

Setting up your stereo headphones

Charging your stereo headphones

When your stereo headphone’s battery is low, the red LED blinks.

To charge your stereo headphones:

• Connect the charging cable from the AC adapter to your Bluetooth

stereo headphones and plug the AC adapter into a wall outlet. The red

LED stays on while your stereo headphones are charging and turns blue

when they are fully charged.

Using your stereo headphones

Turning your stereo headphones on and off

To turn your stereo headphones on and off:

• Press and hold the

(power/talk) button for two seconds. The LED

blinks blue (when turned on) or red (when turned off), and the voice

prompt says “Hello”, or “Bye.”

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 6 Tuesday, July 8, 2014 10:25 AM

7MD-HPBT01

Pairing your stereo headphones with a Bluetooth device

Your stereo headphones can store pairing information for up to 8

Bluetooth devices, such as phones and tablets.

Notes: Your stereo headphones:

- Range is 33 feet (10 meters).

- Support easy pairing.

- Prompt you by saying “Connected,” when connected.

- Support a battery indicator icon on an iOS device.

Make sure that your Bluetooth device supports the Bluetooth V 3.0

protocol and is not paired with another device. To determine what

Bluetooth protocol your device supports, see the documentation that

came with your device.

With the headphones turned off, press and hold

(power/talk) for four

seconds. The LED blinks blue and red rapidly, then pairing mode is

activated

Make sure that your Bluetooth device is within 33 feet of your stereo

headphones.

Turn on your Bluetooth device, turn on Bluetooth, then set your device

to pairing mode. For more information, see the documentation that

came with your Bluetooth device.

On your Bluetooth device, select “MD-HPBT01”, then enter the password

0000 (four zeros), if required, to pair your headphones. Your stereo

headphones pair with the Bluetooth device and the LED on your stereo

headphones blinks blue every two seconds.

For more information on pairing Bluetooth devices to your cell phone or

MP3 player, see the device's documentation.

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 7 Tuesday, July 8, 2014 10:25 AM

Reconnecting to a paired device

When your stereo headphones are not paired to a device, the Blue

and red LEDs flash rapidly.

• After the headphones have been successfully paired with the cell phone

or MP3 player, the headphones will automatically reconnect to the

phone or MP3 player. If a device does not automatically reconnect, you

may need to reselect MD-HPBT01 on your Bluetooth device.

Pairing with a computer running Windows

Note: Before you pair the headphones with the computer, make sure that the

computer is equipped with Bluetooth. Refer to the computer's documentation or

contact the computer manufacturer for more information. If your computer is not

Bluetooth compatible, install a Bluetooth USB adapter (dongle).

Turn on Bluetooth on the computer. For instructions, see the computer's

documentation or contact the computer manufacturer.

Double-click the Bluetooth icon in the system tray, then click Add a

device (Add Wireless Device using Windows Vista).

-OR-

If you’re using Windows XP, click Add a New Bluetooth Device. When

the Add Bluetooth Device Wizard opens, click Next.

With the headphones turned off, press and hold

(power/talk) for four

seconds. The LED blinks blue and red rapidly, then pairing mode is

activated.

Your stereo headphones will lose the

Bluetooth connection if you:

To reconnect:

Turn them off. Turn on your stereo headphones. Your stereo

headphones search for the last connected

Bluetooth device and reconnect automatically.

Move the Bluetooth device out of range. Make sure that your Bluetooth device is within 33

feet of your stereo headphones.

Turn off the Bluetooth device. Turn on the Bluetooth device, then make sure that

Bluetooth is turned on.

Turn off Bluetooth on your Bluetooth

device.

Turn on Bluetooth on your Bluetooth device.

Connect your Bluetooth device to

another Bluetooth device.

Disconnect your Bluetooth device from the other

device, then set your device to pairing mode. Select

MD-HPBT01 on the Bluetooth device.

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 8 Tuesday, July 8, 2014 10:25 AM

9MD-HPBT01

Double-click the MD-HPBT01 icon on the computer or highlight the

icon and click Next.

Note: If you are unable to locate the MD-HPBT01 icon, click the Search Again

button.

If required, enter 0000 (four zeros) in the Bluetooth security code field,

then click Next.

After the headphones have been paired, click Close. If you are using

Windows XP, continue with steps 7 through 9.

Select one of the Bluetooth hands-free types shown on the Add a

Bluetooth Device Wizard screen, then click Next.

Select the services shown on the wizard screen to use with your

Bluetooth headphones, then click Finish.

To connect the device, double-click the MD-HPBT01 Hands-Free Unit

icon or the MD-HPBT01 Stereo Audio icon.

Note: The headphones should be automatically selected as the default playback

device (Windows Vista, Windows 7, or Windows 8), or the default recording and

playback device (Windows XP). To make those settings manually, see the following

sections.

Setting the headphones as the default playback device

using Windows Vista, Windows 7, or Windows 8

Click Start, then click Control Panel.

Click Hardware and Sound, then under Sound, click Manage audio

devices.

On the Recording tab, select Headset Microphone Bluetooth

Hands-free Audio, then click Set Default.

On the Playback tab, select Speakers Bluetooth Hands-free Audio,

then click Set Default.

Click OK to finish.

Setting the headphones as the default recording and

playback device using Windows XP

Click Start, then click Control Panel.

Click Sounds, Speech, and Audio Devices, then click the Sounds and

Audio Devices icon.

On the Audio tab, select Bluetooth Hands-free Audio or Bluetooth

Stereo Audio in the Sound recording list, then select Bluetooth

Hands-free Audio in the Sound playback list, if it is an option.

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 9 Tuesday, July 8, 2014 10:25 AM

Pairing with a Mac computer

Note: Before you pair the headphones with the computer, make sure that the

computer is Bluetooth compatible. Refer to the computer's documentation or

contact the computer manufacturer for more information. If your computer is not

Bluetooth compatible, install a Bluetooth USB adapter (dongle).

Turn on Bluetooth on the computer. For instructions, see the computer's

documentation or contact the computer manufacturer.

Click the Bluetooth status menu.

Click Set up Bluetooth Device. The Bluetooth Setup Assistant opens.

Click Continue.

Select Headset as the device type, then click Continue.

With the headphones turned off, press and hold

(power/talk) for four

seconds. The LED blinks blue and red rapidly, then pairing mode is

activated.

Select MD-HPBT01, then click Continue. The computer gathers

information.

Click Continue.

Enter 0000 (four zeros) into the Passkey field, then click Continue.

Click Quit to finish.

Note: To use the headphones, they must be selected as the default input and output

device on the computer.

Click System Preferences, then click Sound.

Under Input, select MD-HPBT01, then under Output, select

MD-HPBT01.

Using your stereo headphones with Skype

Note: Before you pair the headphones with the computer, make sure that the

computer is Bluetooth compatible. Refer to the computer's documentation or

contact the computer manufacturer for more information. If your computer is not

Bluetooth compatible, install a Bluetooth USB adapter (dongle).

Turn on your Bluetooth headphones, then right-click the Bluetooth icon

at the bottom left- hand side of your computer screen. The Bluetooth

icon appears there. Right-click the icon and click Add Device.

Find your Bluetooth headphones on the list and double-click it. The

computer and Bluetooth headphones will now sync.

Open the Skype program. On the top menu bar, click the Tools tab, then

click Options.

MD-HPBT01_14-0244_MAN_V1_ENG.fm Page 10 Tuesday, July 8, 2014 10:25 AM

Andere Handbücher für MD-HPBT01

Inhaltsverzeichnis

Andere Modal Headset Handbücher

Modal

Modal MD-HPBT01 Bedienungsanleitung

Beliebte Headset Handbücher anderer Marken

Sena

Sena SMH10 Bedienungsanleitung

IASUS

IASUS Stealth IA-NT4-BASIC-BT Bedienungsanleitung

Sennheiser

Sennheiser EPOS ADAPT 230 Bedienungsanleitung

Doro

Doro Flexus HS2005 Bedienungsanleitung

GE 98971 Bedienungsanleitung

Hama

Hama 00184070 Bedienungsanleitung

Plantronics

Plantronics Blackwire 3200 Series Bedienungsanleitung

Blue Tiger

Blue Tiger Advantage PLUS Bedienungsanleitung

Jawbone

Jawbone Icon Bedienungsanleitung

Jabra

Jabra FR 20 Bedienungsanleitung

Roxcore

Roxcore Flow A+ Bedienungsanleitung

Turtle Beach

Turtle Beach XP 510 Bedienungsanleitung

Philips

Philips SHB6101 Bedienungsanleitung

Jabra

Jabra PRO 9460 Duo Bedienungsanleitung

HyperX

HyperX HyperX Cloud Flight Bedienungsanleitung

Bose

Bose MIE2 Mobile Bedienungsanleitung

Jabra

Jabra Steel Bedienungsanleitung

HyperX

HyperX cloud ii Bedienungsanleitung
