HTP-1
16 Channel Home Theater Processor
User Manual P/N 37887
Updated October 14, 2020
© 2019, 2020 Monoprice Inc. All rights reserved.
HTP-1 Installation and User Guide Release 1.8.1
(This page left blank)
HTP-1 User Manual Page 2 V1.8.1
HTP-1 Installation and User Guide Release 1.8.1
Table of Contents
Table of Contents 3
Safety Warnings and Guidelines 8
Licenses 9
Introduction 9
Customer Service 9
Package Contents 10
Requirements 10
Product Overview 11
Front Panel 11
Rear Panel 12
Front Panel LCD Display 14
Remote Control 16
Web GUI Home Page 18
Basic Setup 20
System Requirements 20
Step by Step 20
Initial WiFi Setup 22
Update the Firmware 22
Interface Description 23
Speaker Configurations 24
Speaker Location Diagrams 26
5.1 vs 7.1 Surround Speakers 28
Top Middle vs High Side 28
Valid Speaker Configurations 29
HTP-1 User Manual Page 3 V1.8.1
HTP-1 Installation and User Guide Release 1.8.1
Multiple Subwoofers and Dirac Live Bass Control™31
Mapping Channels to Speakers 31
Speaker Setup 32
Setting Speaker Size 33
Enabling Speakers 34
Dolby® Enabled Speakers 35
Example Speaker Setups 36
Back Panel Mapping Display 37
Example 7.1.4h Speaker Configuration (Upper Level On the Wall) 38
Example 7.2.6 Speaker Configuration (Upper Level On the Ceiling) 39
Example 9.3.4 Speaker Configuration (Upper Level On the Ceiling) 40
Example 9.1.6 Speaker Configuration (Upper Level On the Ceiling) 41
Configure the Bass Manager 42
Calibration 44
Volume Range and Maximum Output Voltage 45
Recommendations on setting the Maximum Output Level 46
Lipsync Delay 46
Dirac Calibration 47
Calibration Steps 48
Dirac Bypass 53
Dirac On 53
Dirac Bypass 53
Dirac Off 54
Tips for a Successful Dirac Calibration 54
Manual Calibration 55
Calibrating for Higher Sample Rates 55
Dirac Live Bass Control 55
HTP-1 User Manual Page 4 V1.8.1
HTP-1 Installation and User Guide Release 1.8.1
A DLBC Tour 57
Signal Generation Page 59
“THX like” band limited noise 60
Louder reference noise 61
Polarity Pulse 61
Left signal as input / Right signal as input 61
Sine Wave 62
EQ Page 63
Using PEQ with Dirac ™64
Inputs Page 65
Naming the Audio/Video Sources 66
Watch Video with Other Audio 67
Partial Reset by Changing Inputs 67
PCM Detect Sensitivity 68
USB Audio Input 68
Sound Enhancement Page 69
Using Surround Modes 69
Wide Synth 70
Bass Enhancement (AKA Bass Reinforcement) 71
Audio Features 72
Night Mode 72
Dialog Enhancement 72
Loudness 72
For Highest Quality Audio 74
Connectivity 75
Setting up ARC/eARC and CEC 75
Connecting HTP-1 to TV for ARC/eARC 76
HTP-1 User Manual Page 5 V1.8.1
HTP-1 Installation and User Guide Release 1.8.1
CEC Settings 76
CEC Control Options 77
Alternate TV Input 77
TV Audio Priority 77
System Audio 77
Using Wi-Fi 79
Choosing DHCP or Static IP Address Assignment 79
Bluetooth 80
System Page 81
Support Features 84
Video Features 85
UHD Support 85
EDID Management 85
Dolby Vision 86
Triggers 86
Using Roon 86
Firmware Updates 87
Feedback 88
Alexa 89
Specifications 90
Signal Processing Flow 91
IR Code Table 92
IR Code Over HTTP Remote Control 93
Third Party Applications 93
Privacy Disclosure 93
Regulatory Compliance 94
Notice for FCC 94
HTP-1 User Manual Page 6 V1.8.1
HTP-1 Installation and User Guide Release 1.8.1
Safety Warnings and Guidelines
Please read this entire manual before using this device, paying extra attention to these safety warnings
and guidelines. Please keep this manual in a safe place for future reference.
●This device is intended for indoor use only.
●Do not expose this device to water or moisture of any kind. Do not place drinks or other
containers with moisture on or near the device. If moisture does get in or on the device,
immediately unplug it from the power outlet and allow it to fully dry before reapplying power.
●Do not touch the device, the power cord, or any other connected cables with wet hands.
●Do not install this device on an unstable surface where it could fall and cause either personal
injury or damage to the device and/or other equipment.
●Do not subject the product to extreme force, shock, or fluctuations in temperature or humidity.
●Do not expose this device to excessively high temperatures. Do not place it in, on, or near a heat
source, such as a fireplace, stove, radiator, etc. Do not leave it in direct sunlight.
●This device ventilates excessive heat through the slots and openings in the case. Do not block or
cover these openings. Ensure that the device is in an open area where it can get sufficient
airflow to keep from overheating.
●Do not place or install this device in an area where it can be exposed to excessive amounts of
dust, humidity, oil, smoke, or combustible vapors.
●Use only in a well-ventilated area. Do not use in close, confined spaces. Ensure that there is at
least 3" of space around and above the device.
●Prior to operation, check the unit and power cord for physical damage. Do not use it if physical
damage has occurred.
●Before plugging the unit into a power outlet, ensure that the outlet provides the same type and
level of power required by the device.
●This device uses a grounded power cord and requires a ground connection for safe operation.
Ensure that the power source has a proper ground connection. Do not modify the plug or use a
"cheater" plug to bypass the ground connection.
●Disconnect the unit from the power source when replacing the fuse. Replace the fuse only with
the same type. Never bypass the fuse.
●Unplug this device from the power source when not in use.
●Take care to prevent damage to the power cord. Do not allow it to become crimped, pinched,
walked on, or become tangled with other cords. Ensure that the power cord does not present a
tripping hazard.
●Never unplug the unit by pulling on the power cord. Always grasp the connector head or adapter
body.
●Ensure that power is turned off and disconnected before making any electrical connections.
●Remove the batteries from the controller if it will go unused for a lengthy period of time.
●Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or detergents. For
stubborn deposits, moisten the cloth with warm water.
●This device has no user serviceable parts. Do not attempt to open, service, or modify this device.
HTP-1 User Manual Page 8 V1.8.1
HTP-1 Installation and User Guide Release 1.8.1
Licenses
This product uses features licensed from several suppliers:
●Manufactured under license from Dolby Laboratories
●Manufactured under license from Xperi / DTS
●Manufactured under license from Auro Technologies
●Manufactured under license from Momentum Data Systems
●Manufactured under license from Dirac Research
Introduction
The Monolith™ HTP-1 is an "AVP" or "Audio Video Pre-Processor" designed for use in home theaters. It
supports Dolby Atmos®, DTS:X®, Auro-3D®, and Dirac Live®. It features eight HDMI® Ultra High Definition
(4K UHD) inputs and two HDMI 4K UHD outputs. It has seven digital audio inputs, two stereo analog
inputs, one secondary stereo analog output, and sixteen balanced XLR analog outputs. It has a built-in
web GUI, which allows you to configure it using a computer, smartphone, or tablet, as well as an
infrared remote control for adjusting volume, changing the upmix, and selecting inputs. It is designed for
easy software updates using an Ethernet connection.
This User Guide describes version 1.7 of the HTP-1 software. As a software product, the HTP-1 may be
updated and this user guide may also be updated. Please check for updates on the info page of the
HTP-1 web interface. Do also read the release notes found on the info page. The release note gives the
latest information about what has changed in the software.
Each page of the Web GUI includes a help button.
These bring up brief descriptions of the current page. This User Guide gives more detailed information.
The latest version of the user guide can always be retrieved from the help screens.
Customer Service
The Monoprice Customer Service department is dedicated to ensuring that your ordering, purchasing,
and delivery experience is second to none. If you have any problem with your order, please give us an
opportunity to make it right. You can contact a Monoprice Customer Service representative through the
Live Chat link on our website www.monoprice.com or via email at [email protected]. Check the
website for support times and links.
HTP-1 User Manual Page 9 V1.8.1
HTP-1 Installation and User Guide Release 1.8.1
Package Contents
Please take an inventory of the package contents to ensure you have all the items listed below. If
anything is missing or damaged, please contact Monoprice Customer Service for a replacement.
1x HTP-1 Home Theater Pre-Processor
1x IR Remote Control
1x Bluetooth®/Wi-Fi® Antenna
1x AC Power Cord
Requirements
●The HTP-1 must be connected to an existing Ethernet wired or wireless network for initial
configuration. Computers or mobile devices connected to the network can be used to control
and configure the HTP-1. The HTP-1 can be operated with no network connection if no more
configuration is required.
●A separate power amplifier or powered speakers are required.
●A laptop or desktop computer with a web browser. Mac’s and PC’s are supported by the Dirac
Live® calibration system.
○A phone can easily access the Web GUI once initial setup is complete, but a bigger
screen is very helpful for setup.
●A USB connected calibrated
microphone (not included) is required to perform a Dirac®
calibration. A smartphone or tablet cannot be used to perform a Dirac calibration. The Dirac web
page (https://www.dirac.com/recommended-microphones) discusses microphones.
HTP-1 User Manual Page 10 V1.8.1
