Motorola A630 Bedienungsanleitung

START HERE >

A630

GSM

Welcome

Welcome to the world of Motorola digital wireless

communications! We are pleased that you have chosen

the Motorola A630 GSM wireless phone.

Note:

There are some functions that can be done with the

A630 flip open or closed. In those cases, we will show you

both key press options in parentheses.

Power & End Key

Turn phone on/off,

end calls, exit

menu system.

Right Soft Key

Perform functions identified

by right display prompt.

Menu Key

Left Soft Key

Perform functions

identified by left

display prompt.

Send Key

Make & answer calls, view

recently dialed calls list.

5-Way

Navigation Key

Scroll through

menus & lists, set

feature values.

Space Key

Shift Key

Enter Key

Game

Keys

Game

Keys

Alt Key

Enter

symbols

in text

messages.

Home

Screen

Internal

Keyboard

Check It Out!

Camera Lens

Take photos to

send to others &

use on your phone.

External Display

View call & menu

information.

Camera Button

Turn camera on &

take photos. Press

& hold to record

voice memos.

External Keys

For closed flip

operation.

Handsfree Speaker

(on back of phone)

Volume Keys

Adjust earpiece,

ringer volume, &

ring style. Zoom in

& out when taking

a photo.

Headset Jack

Insert headset

accessory for

handsfree use.

OK and Send Key

Move forward in

menus, make &

answer calls, &

view recent calls

list.

Back, End, &

Power Key

Go back in menus,

end calls, & turn the

phone On or Off.

Menu &

Up & Down Keys

Access the menu

and scroll up and

down.

Accessory

Connector Port

Insert charger &

phone accessories.

Antenna

(on back of phone;

internal antenna)

External

Keypad

Feature Description

Take Photo

with Flip

Open 90

Degrees

Press the external Camera button. Rotate

handset to view image properly (see page

21 of this user guide for more details). Point

lens at subject and press the camera

button to take a photo.

Send Photo

Send the photo to a phone number or email

address: Use the external Volume Down

button to scroll to

. Press the external

camera button to select. Select message

typeType message below photo and press

. Scroll to select Send To number or

address and press

Add

Done

, and then

Send

Set Photo as


Caller ID

Assign a photo to a phonebook entry to

enable picture caller ID:

Multimedia

Pictures

> photo

Apply As

Phonebook Entry

SendPicture

Message

Send a picture message with

pictures, animations, sounds:

Messages

Create Message

New Picture Msg

Wireless

Connection

Set up a Bluetooth

wireless connection to a

headset accessory, car kit, or external device.

Make sure the Bluetooth device is powered

on and is in discover mode:

Settings

Connection

Bluetooth Link

Handsfree

[Look For Devices]

Play Games

Play a game:

Games & IM

> game

Motorola, Inc.

Consumer Advocacy Office

1307 East Algonquin Road

Schaumburg, IL 60196

www.motorola.com

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States for hearing impaired)

1-800-461-4575 (Canada)

MOTOROLA and the Stylized M Logo are registered in the US Patent &

Trademark Office. The Bluetooth trademarks are owned by their proprietor and

used by Motorola, Inc. under license. Java and all other Java-based marks are

trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and

other countries. All other product or service names are the property of their

respective owners.

Caution:

Changes or modifications made in the radio phone, not

expressly approved by Motorola, will void the user’s authority to operate

the equipment.

The information contained in Motorola’s user’s guides is believed to be

correct at the time of printing. Motorola reserves the right to change or

modify any information or specifications without notice. The contents of

Motorola’s user manuals are provided “as is.” Except as required by

applicable by law, no warranties of any kind, either expressed or implied,

including, but not limited to, the implied warranties of merchantability and

fitness for a particular purpose, are made in relation to the accuracy,

reliability or contents of this guide.

Manual number: 6809490A44-A

Contents

Getting Started

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Installing the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Charging the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Battery Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Turning Your Phone On. . . . . . . . . . . . . . . . . . . . . . . . . . 13

Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Answering a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . . 15

Activate/Deactivate Keylock . . . . . . . . . . . . . . . . . . . . . . 15

Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . . 16

Highlight Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Taking and Sending a Photo. . . . . . . . . . . . . . . . . . . . . . 18

Using Email. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Using Instant Messaging . . . . . . . . . . . . . . . . . . . . . . . . 25

Sending a Picture Message . . . . . . . . . . . . . . . . . . . . . . 25

Receiving a Picture Message . . . . . . . . . . . . . . . . . . . . . 27

Using a Bluetooth

Wireless Connection . . . . . . . . . . . . 28

Playing Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Learning to Use Your Phone

. . . . . . . . . . . . . . . . . . . . . . 30

Using the External Display . . . . . . . . . . . . . . . . . . . . . . . 30

Using the Internal Display. . . . . . . . . . . . . . . . . . . . . . . . 35

Using the 5-Way Navigation Key

on the Internal Keyboard. . . . . . . . . . . . . . . . . . . . . . . . 39

Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Using the Camera Button . . . . . . . . . . . . . . . . . . . . . . . 47

Changing a Code, PIN, or Password. . . . . . . . . . . . . . . 48

Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 49

If You Forget a Code, PIN, or Password . . . . . . . . . . . . 50

Using the Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Setting Up Your Phone

. . . . . . . . . . . . . . . . . . . . . . . . . . 53

Storing Your Name and Phone Number . . . . . . . . . . . . 53

Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . 53

Setting a Ring Style. . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Setting Answer Options. . . . . . . . . . . . . . . . . . . . . . . . . 54

Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . 55

Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . 56

Setting Display Color. . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . 57

Calling Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . 59

Calling an Emergency Number . . . . . . . . . . . . . . . . . . . 59

Dialing International Numbers. . . . . . . . . . . . . . . . . . . . 60

Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . 62

Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Attaching a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . 63

Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Putting a Call On Hold . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Phone Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Feature Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . 68

Specific Absorption Rate Data

. . . . . . . . . . . . . . . . . . . . 81

Index

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Getting Started

About This Guide

This guide describes the basic features of your Motorola

wireless phone.

Optional Features

This label identifies an optional network, SIM

card, or subscription-dependent feature that

may not be offered by all service providers in all

geographical areas. Contact your service

provider for more information.

Optional Accessories

This label identifies a feature that requires an

optional Motorola Original™ accessory.

CAUTION:

Before using the phone for the

first time, read the

Important Safety and

Legal Information

included in the

gray-edged pages at the back of this guide.

032259o
