OUTSIDE COVER INSIDE COVER

01.25.10

T-Mo bile

cab 3" x 5"

CLIENT SIGNATURE INDICATES THAT THE CLIENT HAS PROOFREAD COPY AND CLOSELY EXAMINED ART FOR FINAL APPROVAL OF THIS MECHANICAL FILE TO PROCEED TO THE PRINTER. PHILIPPEBECKER IS NOT RESPONCIBLE FOR PROOFREADING

COPY OF OTHER MATERIALS SUPPLIED. S PELLING, PUN CTUATION, GR AMMAR , AN D CONTECT ARE THE SOLE RESPONSIBILIT Y OF THE CLIENT. THIS MECHANICAL FILE CONTAINS PROPRIETARY INFORMATION AND IS CONFIDENTIAL.

CONFIDENTIAL

THIS PROOF

IS NOT FOR

COLOR MATCH

CYAN MAGENTA YELLOW BLACK

OVERVIEW

This guide provides you with everything you

need to get started. If you need additional

information on features and services,

please select one of these helpful options:

nOn the Home screen, swipe

your nger to the right to view

the rst panel to the left and

then tap Tips and Tricks,

nOn the Home screen, swipe

your nger to the right to view

the rst panel to the left and

then tap Getting Started,

nOn your phone, tap the Application

tab and then tap My Account,

nVisit www.t-mobile.com and

www.motorola.com/mycliqxt

to view the user guide, video,

and online tutorials.

nMotorola Android support for North

America and Canada, 800-734-5870.

TABLE OF CONTENTS

Introducing Your Phone...........................1

Service Activation ....................................3

SIM Card..................................................4

Battery......................................................5

Power .......................................................6

Typing Tips ............................................. 7

MOTOBLUR™ Account.........................10

Call Functions........................................13

Home Screen.........................................17

Personalize Home Screen.....................25

Social Networking..................................29

Contacts ................................................32

Bluetooth®Setup ...................................39

Battery Life .............................................41

E-mail .....................................................45

Text Messaging .....................................51

Picture Messaging.................................53

Instant Messaging .................................55

FM Radio .............................................56

Music Player ........................................58

Market ..................................................60

Web Browsing .....................................62

Location ...............................................64

YouTube®.............................................71

Security ................................................72

Emergency Dialing ..............................75

Caring for Your Phone .........................76

Tips for Safety......................................78

Accessories for Your Phone................80

Additional Information .........................81

INTRODUCING YOUR PHONE

With the MOTOROLA CLIQ XT™ with

MOTOBLUR™, you can:

nSynchronize, view, and share

contacts, messages, feeds,

and updates from the most

popular social Web sites

on your phone (Facebook®

MySpace®

, Twitter®

, and more).

nBrowse the Web using high-

speed 3G and Wi-Fi networks.

nSend text messages, e-mails,

and wall posts using the

virtual QWERTY keyboard.

nVirtual keyboard, with

Swype™technology.

nSnap photos with the 5 megapixel

camera and post them to favorite

sites, such as Facebook®

, MySpace®

Picasa®

, Photobucket®

, and more.

nFM Radio.

nAnd much more!

Home key

Back key

Camera key

Power /

Lock key

Press and

hold to power

on/off.

Quick press

to lock the

phone and

turn off the

display.

Navigation touch pad

Headset jack

Volume

keys

Charging /

Data port

Menu key

Search key

SIM CARD

Your Subscriber Identity Module (SIM) card

identies you to the wireless network. Your

phone will not work without the SIM card.

To insert the SIM card and battery:

1. Detach your SIM card.

2. Press the cover release button on the

bottom of the phone while pulling the

the back cover away from the phone.

SERVICE ACTIVATION

If you are a new T-Mobile customer and your

service has not been activated, simply call

Customer Care at 1-800-937-8997 from your

landline phone and a T-Mobile Activations

representative will assist you.

You will need the following information when

activating service:

nService Agreement and agent

code on your Agreement

nYour name, home address, home

phone, and billing address

Note: For business and government accounts, please

provide the name of your company or government

agency, address, and tax ID.

nYour Social Security number, current

driver’s license number, and date

of birth for credit check purposes

nYour choice of T-Mobile rate plan and

services (see www.t-mobile.com for

latest plan information)

nSIM serial number and IMEI number

(located on the box bar code label)

By activating service, you acknowledge that you have read,

understand, and agree to be bound by each of T-Mobile’s

Terms and Conditions and your Service Agreement.

Charge using a charger cable

Connect the small end of the charger

cable to the micro-USB port on the left side

of your phone. Plug the other end of the

charger into a wall outlet.

Charge using a USB cable

Connect the small end of the USB cable to

the micro-USB port on the left side of your

phone. Plug the other end of the USB cable

to the USB port of your computer.

Note: For tips on conserving battery power, turn to the

Battery Life section (page 41).

POWER

Press and hold the Power/Lock key on the

right side of the phone to turn on or off.

3. Lift the slot guard. Slide the SIM

card into the SIM card slot with the

gold contacts facing down and the

notched corner aligned as shown.

4. Align the gold contacts on the battery

with the contacts in the battery

compartment. Snap the battery into

place and replace the battery cover.

BATTERY

You can charge your phone using the

charger cable connected to a wall power

outlet or by using the USB cable connected

to your computer.

nTo enter a symbol, tap and

then tap the symbol. To view

more symbols, tap ALT.

nTo turn on Caps lock, tap the Up

Arrow/CAPS key twice (until you

see a green circle on the key).

TYPING TIPS

You can enter text using your on-screen

keyboard in either prole or landscape view.

nTo open the on-screen keyboard,

tap a text entry eld.

nTo close the on-screen keyboard,

press the Back key.

nTo enter a number, tap and

then tap the number.

nTo enter :, /, @, ‘, “, ?, or !while

on the text screen touch and

hold and then tap the

desired punctuation mark.

MOTOBLUR ACCOUNT

Before using your phone, you must

rst create a MOTOBLUR account.

MOTOBLUR syncs contacts, posts,

feeds, messages, e-mails, photos

and much more—from sources like

Facebook, Twitter, MySpace, Gmail®

your work e-mail, Picasa, Photobucket.

Once created, you can also log into

this account from a computer to upload

contacts, reset your password, get help,

or even locate your phone:

www.motorola.com/mymotoblur.

For help managing your accounts, see

the Social Networking section in this

guide.

To highlight, copy, and place text:

1. Place the cursor before the text you

want to highlight.

2. Touch and hold the screen until the

Edit text menu displays.

3. Tap Select text.

4. Touch and drag your nger to

highlight the desired text.

5. Touch and hold the highlighted text

until the Edit text menu displays.

6. Tap Cut or Copy.

7. Place the cursor where you want to

paste the text.

8. Touch and hold the screen until the

Edit text menu displays.

9. Tap Paste.

Change keyboard mode

1. Touch and hold within a text eld until

the Edit text menu displays.

2. Tap Input Method.

3. Tap Swype.

Note: For more information about Swype,

see http://www.swypeinc.com.

13. Tap Next.

14. Verify the information is correct and

tap Conrm.

15. When account creation is complete,

tap Next.

16. Tap the icon for a service you use.

17. Enter your login information for that

service.

18. Tap Next.

19. Repeat steps 16–18 for all of

your accounts.

20. Tap Done adding accounts.

21. Under Picture source, tap the

Down Arrow icon and then tap the

social networking site you want to

use as the picture source for your

contacts’ picture IDs.

22. Read about Google’s location service

and tap Next.

23. Tap Done.

Congratulations on creating your new

MOTOBLUR account! Now you are ready to

make calls or continue on with this guide to

learn more about your phone.

Create a MOTOBLUR account

1. Select the language.

2. Tap Start.

3. Tap Register a new account.

4. Tap Next.

5. Read the MOTOBLUR Terms of

Service.

6. Tap the check mark next to I agree.

7. Tap Next.

8. Tap the Your name eld to open the

on-screen keyboard.

9. Enter your name.

10. Tap Next or tap the MOTOBLUR ID

eld and enter the e-mail address

where MOTOBLUR can send

account information.

Note: When entering in landscape view, tap Next to

move to the next eld or press the Back key to close

the on-screen keyboard and return to the Create

MOTOBLUR account screen.

11. Enter a new MOTOBLUR account

password.

12. Re-enter the password and tap

Done.

Adjust call volume

While on an active call, press the Volume

key up or down.

Adjust ringer volume

On the Home screen, press the Volume

key up or down to adjust ringer volume or

to select Vibrate or Silent mode.

Adjust media volume

1. At the Home screen, press the Menu

key.

2. Tap Settings.

3. Tap Sound & ringtones.

4. Tap Media volume.

5. Touch and slide the slider to the

desired volume setting.

6. Tap OK.

CALL FUNCTIONS

Make and end calls

1. On the Home screen, tap the green

Phone icon.

2. Tap the Dialer tab, if necessary.

3. Enter the number and tap Call.

4. To end the call, tap End call.

Answer calls

Tap Answer. When the screen is locked,

touch Slide to Answer and slide your

nger to the right.

Use Mute and

Speakerphone

To mute a call or turn on

speakerphone, tap Mute.

or Speakerphone. When

active you will see a green

bar on the button.

Tap again to turn off.

Andere Handbücher für CLIQ XT

Inhaltsverzeichnis

Andere Motorola Handy Handbücher

Motorola

Motorola Q Bedienungsanleitung

Motorola

Motorola V361 Bedienungsanleitung

Motorola

Motorola DROID X Technisches Handbuch

Motorola

Motorola V535 Bedienungsanleitung

Motorola

Motorola moto g PRO Bedienungsanleitung

Motorola

Motorola i897 Bedienungs- und Wartungshandbuch

Motorola

Motorola SLVR L7C - VERIZON Bedienungsanleitung

Motorola

Motorola V3682 Bedienungsanleitung

Motorola

Motorola MOTO G XT1039 Bedienungsanleitung

Motorola

Motorola RAZR Bedienungsanleitung

Motorola

Motorola DROID RAZR HD Bedienungsanleitung

Motorola

Motorola MOTORAZR2 V8 Bedienungsanleitung

Motorola

Motorola edge 30 fusion Bedienungsanleitung

Motorola

Motorola V180 Bedienungsanleitung

Motorola

Motorola iDEN i88s Bedienungsanleitung

Motorola

Motorola V170 Bedienungsanleitung

Motorola

Motorola V975 Bedienungsanleitung

Motorola

Motorola SYN5383 - G-520/M3090/Populous Ultra Saver... Bedienungsanleitung

Motorola

Motorola EX124G Bedienungsanleitung

Motorola

Motorola digital cellular phone Bedienungsanleitung

Motorola

Motorola DROID PRO Bedienungsanleitung

Motorola

Motorola I80s Bedienungsanleitung

Motorola

Motorola MOTORAZR2 V9 Bedienungsanleitung

Motorola

Motorola ATRIX HD Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
