1Congratulations

Congratulations

MOTOROLA i1

The MOTOROLA i1 brings the convenience of

walkie-talkie calls together with a premium browsing

and messaging experience, all in a touchscreen device.

• Walkie-Talkie Calls. Stay in touch with your family,

friends and colleagues with the simple touch of a

button.

• Organization. Check your email, calendar, and

contacts wherever you are.

•Browsing.Get more from the Web with a huge

screen for an improved browser experience. Search,

browse, everything you want to do, all made easier.

• Maps and more. The latest technology and apps.

Google Maps™ to find your way. Easy access to

Google™ and thousands of Android applications to

expand your world.

• Tough and durable. Built to military specification to

survive the harshest environments.

Caution: Before assembling, charging or using your

phone for the first time, please read the important

legal and safety information packaged with your

phone.

More information

On your computer—Go to

www.motorola.com/support/.

So, whether you want to read, watch, or play, we can

help.

2Contents

Your phone

the important keys & connectors

Note: Your phone might look a little different.

6:50 PM

Browser

MessagingCall log Contacts

Press & hold

to turn on/off.

2.5mm

Headset Jack

Home Key

Back Key

Microphone

Menu Key

Micro USB

Connector

Charge or

connect to PC.

WT Button

To u chscreen

Camera

Key

Speaker

Key

Volume Keys

Talk Key

End/Power

Key

Screen Lock Key

Navigation

Key

OK Key OK

Contents

Your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Walkie-Talkie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Google Maps™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Latitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Manage your life . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Photos & videos. . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . . 39

Wi-Fi® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

USB & memory card . . . . . . . . . . . . . . . . . . . . . . . . 42

Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Safety, Regulatory & Legal. . . . . . . . . . . . . . . . . . . . 46

3Let’s go

Let’s go

let’s get you up and running

Assemble & charge

1Remove cover 2SIM in

3MicroSD in 4Battery in

5Cover on 6Charge up

Caution: Please read “Battery Use & Safety” on

page 46.

Note: To ensure your phone survives exposure to the

elements, make sure the battery cover is secured

correctly, and all connector covers are tightly sealed.

Set up & go

The first time you turn on your phone, a setup wizard

guides you through:

•Setting up your Wi-Fi® connection.

•Signing in to your existing Google™ account.

Note: If you don’t have a Google account, you can

create one using the wizard.

Tip: Remember to write down your user name and

password, and keep them in a safe place.

•Setting up additional email accounts, such as POP3,

IMAP, or Microsoft™ Exchange.

•Loading contacts from your SIM card.

•Loading apps from your microSD card.

•Selecting your keyboard type.

Note: This phone supports data-intensive apps and

services. It is strongly recommended that you

purchase a data plan that meets your needs. Contact

your service provider for details.

4Touchscreen & keys

Turn it on & off

To turn on your phone, press and

hold End/Power .

To turn off your phone, press and

hold End/Power , then touch

Power off.

Wi-Fi connect

If you want to use a Wi-Fi computer network for even

faster Internet access, touch > Settings >

Wireless controls > Wi-Fi settings.

Cool content & more

Browse and download thousands of the coolest apps

on the planet from Android Market™. See “Apps for

all” on page 20.

Note: It’s strongly recommended you use a Wi-Fi

connection when downloading apps from Android

Market.

Your phone comes with a microSD memory card

slot—you can load it up with photos, videos, and

music from your computer using “USB drag & drop”

on page 42.

End/Power

Key

Touchscreen & keys

a few essentials

Touch tips

Here are some tips on how to navigate around your

phone.

To u ch

To choose an icon or option, touch

it.

Touch & hold

To open special options, touch

and hold an icon or other item.

Try it: In the home screen,

touch Contacts, then

touch and hold a contact to

open options.

To use MySign, touch the

screen twice with two fingers.

See “MySign” on page 5.

Email Messaging BrowserCall log

All contacts

Ashley Grover Home

PTT

Dialer Call log Contacts Favorites

Dialer

Call

Favorites

1:22 PM

Push to Talk

Ashley Grover

View contact

Call Mobilr

Send SMS/MMS

5Touchscreen & keys

Drag

To scroll through a list or

move slowly, drag up or

down the touchscreen. Try

it: In the home screen,

touch Contacts,

then drag your Contacts

list up or down.

Tip: When you drag or flick

a list, a scroll bar appears

on the right. Drag the

scroll bar to move the list

to a letter A - Z.

Flick

To scroll through a list or move quickly, flick across the

touchscreen (drag quickly and release).

Tip: When you flick a long list, touch the screen to stop

it from scrolling.

All contacts

Ashley Grover

Bomi Kim

Book Club

Chris Boomer

Mobile

PTT

Chris Hunter

Work

PTT

Home

PTT

3 Members

Dialer Call log Contacts Favorites

Dialer

Call

Favorites

1:22 PM

Zoom

In maps, touch or at the

bottom of the screen to zoom

in or out. When viewing Web

pages, touch the screen once

to zoom in. To zoom out touch

the screen twice, or touch

at the bottom of the screen.

MySign

Draw on your screen to get to

your favorite apps. To open

MySign, touch >

MySign.

Draw the sign for the action you

want. For example, draw a “V”

to go to voicemail.

To see which actions are already

assigned to gestures, press

Menu > List Gestures.

You’ll also see several gestures

that are unassigned.

To assign an action to a gesture,

press Menu > List

Gestures, touch an unassigned

gesture, then touch an app from

the list.

1:22 PM

Call Voicemail

1-555-555-5555

6Touchscreen & keys

To create a new gesture, press Menu > New

Gesture, select an action from the list, and draw a

gesture to assign to the action.

Key tips

Front keys

•Home – Press to return to the home screen.

Press and hold to see recently used apps.

•Menu – Open menu options.

•Talk – Press to start a call.

•Navigation Key – Navigate through menus, apps,

and Web pages.

•OK – Select menu options.

•End/Power – Press to end a call or press and

hold to turn phone on/off.

Home

Key

Back Key

Key

Speaker Key

Talk Key

End/Power

Key

Navigation

Key

OK Key

•Speaker – Press to turn walkie-talkie speaker

on/off. Press during a phone call to turn speaker

on/off.

•Back – Go back to the previous screen.

Sleep & wake up

To save your battery, prevent

accidental touches, or when you

want to wipe smudges off your

touchscreen, put the touchscreen to

sleep by pressing Screen Lock .

To wake up the touchscreen, just

press Screen Lock again.

To change how long your phone waits before the

screen goes to sleep automatically, touch >

Settings > Sound & display > Screen timeout.

Tip: To make the screen lock when it goes to sleep,

use “Screen lock” on page 43.

Power key menu

Press and hold End/Power to open the power key

menu, where you can turn off the phone (Power off),

or turn Airplane mode or Silent mode on or off.

Screen Lock Key

7Home screen

Adjust volume

Press the volume keys to change

the ring volume (in the home

screen), or the earpiece volume

(during a call).

Rotate the screen

The touchscreen can rotate 90 degrees to stay

right-side up when you rotate your phone:

Find it: > Settings > Sound & display >

Orientation

Note: Not all applications are designed to rotate.

Volume

Keys

Home screen

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information

in one place. It’s what you see when you turn on the

phone or press Home . It’s basically like this:

Note: Your home screen might look a little different.

Contacts

Launch PTT

Email Messaging BrowserCall log

1:22 PM

Notifications Bar

Touch & drag this bar down

to check notifications.

Status Indicators

Shortcuts

Touch to open.

Drag up to see

all your apps.

Applications Tab

Widgets

Touch to open, or touch &

hold to move or delete.

Flick left or right to open

more panels.

8Home screen

The home screen extends beyond what you see on

the screen to give you more room for adding

shortcuts, widgets, and more. Flick the home screen

left and right to see more panels or to add widgets or

shortcuts.

Widgets

Add a widget, such as a clock, music player, or a

calendar that shows upcoming appointments.

To open a widget, touch it. To add widgets,

press Menu > Add > Widgets.

Note: If you install apps from Android Market that

have widgets, touch and hold the home screen, then

select a widget to add to the home screen.

1:22 PM

Email Messaging BrowserCall log

1:22 PM

Google search

1:22 PM

Shortcuts

To add shortcuts to the home screen, open the

Applications tab, then touch and hold the shortcut you

want. It will be added to the home screen. Or, press

Menu > Add > Shortcuts.

Apps

Your phone comes with some apps already, and you

can download and install more. To open an app, touch

it.

Applications tab

All the apps on your phone,

including the apps that came

with your phone, and the ones

you download and install, are

listed in alphabetical order in

your Applications menu.

Touch the app tab, , in the home screen to open

the app menu.

Running multiple apps

No need to close an app before opening another one.

Your phone runs multiple apps, all at once.

You can open a new app while already running another.

Press Home to return to the home screen. Open

the Applications tab, and touch the app you want. To

E-mail Voice Mail Camera Calculator

Alarm Clock Browser Settings Video Player

Andere Handbücher für i1

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Motorola Handy Handbücher

Motorola

Motorola 3200 Bedienungsanleitung

Motorola

Motorola moto g71 Bedienungsanleitung

Motorola

Motorola Moto X Pure Edition Bedienungsanleitung

Motorola

Motorola MILESTONE - Bedienungsanleitung

Motorola

Motorola MOTO 68000201890-A Bedienungsanleitung

Motorola

Motorola DROID RAZR HD Bedienungsanleitung

Motorola

Motorola CLIQ XT Bedienungsanleitung

Motorola

Motorola V235 Bedienungsanleitung

Motorola

Motorola MOTO W388 Renew+ Bedienungsanleitung

Motorola

Motorola i425 Bedienungsanleitung

Motorola

Motorola TEAM Badge (EWB100) Kurzanleitung

Motorola

Motorola M800 BAG PHONE Bedienungsanleitung

Motorola

Motorola Adventure V750 Bedienungsanleitung

Motorola

Motorola i856 H74XAN6JR7AN Bedienungsanleitung

Motorola

Motorola XT2075-2 Merkblatt

Motorola

Motorola E380 Bedienungsanleitung

Motorola

Motorola Milestone X Bedienungsanleitung

Motorola

Motorola MOTO Q 6802935J48 Bedienungsanleitung

Motorola

Motorola MOTO EM330 Bedienungsanleitung

Motorola

Motorola V555 Bedienungsanleitung

Motorola

Motorola MOTORIZR Z6TV Bedienungsanleitung

Motorola

Motorola iDEN i99cl Bedienungsanleitung

Motorola

Motorola CLIQ XT Technisches Handbuch

Motorola

Motorola V171 Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung

Motorola i1 Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken
