Motorola P8088 Bedienungsanleitung

P8088

Level 1and 2

Service Manual

Ver 1.0

of 48 European Customer Services

P8088

CONTENTS

Page Number

SECTION 1: GENERAL

1.1 Introduction v

1.2 Motorola service policy for P8088 in warranty vi

1.3 General Safety Information vii

SECTION 2: P8088 DESCRIPTION

2.1 Specifications of P8088 2

2.2 P8088 Overview 3

2.3 Connector Pinout 5

2.4 Talk time, Weight and Volume Matrix 5

SECTION 3: FEATURE LIST

3.1 List of Features available 7

3.2 Phone Book 7

3.3 Call Related Features 8

3.4 Messages 9

3.5 Phone Set Up 10

3.6 Network selection 11

3.7 Call Meters 11

3.9 Accesory Set up 12

SECTION 4: DISASSEMBLY & PARTS

4.1 Dissasembly Introduction 14

4.2 Recommended Tools 14

4.3 Disassembly Procedure 14

4.4 Assembly procedure 14

4.5 Exploded Parts diagram 19

4.6 Replacement parts 20

SECTION 5: SIM CARDS AND SECURITY

5.1 Manual test mode 22

5.2 Live Sim Card 22

5.3 Personality Transfer 22

5.4 GSM Test Command 23

5.5 Identity and Security 24

SECTION 6: REPAIR & TEST PROCEDURES

6.1 Repair introduction 26

of 48 European Customer Services

iii

P8088

6.2 Mechanical repairs 26

6.3 Basic modular troubleshooting 26

6.4 Repair Chart 27

6.5 Software Upgrade 29

6.6 Flexing 29

6.7 Testing on HP8922 30

SECTION 7: ACCESSORIES

7.1 Introduction 32

SECTION 8: SALES MODELS

8.1 List of available sales models by country 34

SECTION 9: GLOSSARY OF TERMS

9.1 List of Abbreviations 36

of 48 European Customer Services

P8088

SECTION 1: GENERAL

of 48 European Customer Services

P8088

1.1 Introduction

This manual is intended for use by technicians familiar with similar types of equipment. It contains all

service information required for the equipment described and is current as of the printing date.

The scope of this document is to provide the reader with basic information relating to the P8088, and

also to provide procedures and processes for repairing the units up to and including Level 2 repair.

Level 1 and 2 repairs involve the following activities to be carried out: -

•Unit swap out

•Repairing of mechanical faults

•Basic modular troubleshooting

•Testing and verification of unit functionality

•Upgrading software

•Flexing units

•Initiate warranty claims and send faulty modules to Level 3 or 4 repair centres.

Computer Software Copyrights

The Motorola products described in this instruction manual may include copyrighted Motorola

computer programs stored in semi-conductor memories or other media. Laws in the United States and

other countries preserve for Motorola certain exclusive rights for copyrighted computer programs,

including the exclusive right to copy or reproduce in any form the copyrighted computer program.

Accordingly, any copyrighted Motorola computer programs contained in the Motorola products

described in this instruction manual may not be copied or reproduced in any manner without the

express written permission of Motorola. Furthermore, the purchase of Motorola products shall not be

deemed to grant either directly or by implication, estoppel, or otherwise, any license under the

copyrights, patents or patent applications of Motorola, except for the normal non-exclusive, royalty

free license to use that arises by operation of law in the sale of a product.

of 48 European Customer Services

P8088

1.2 Motorola Service Policy for P8088 in warranty

1.2.1 Warranty:

Product will be sold with the standard 12 months warranty terms and conditions. Accidental damage

misuse, retailers extended warranties will not be supported under warranty. Non warranty repairs will

be available at agreed fixed repair prices.

Proof of purchase will be required to validate warranty claims.

1.2.2 Out of Box Failure Policy

The standard OOB failure criteria will apply. Customer units that fail very early on, after date of sale,

are to be returned to Manufacturing for root cause analysis, to guard against epidemic criteria.

Manufacturing to bear the costs of early life failure.

1.2.3 Product Support

Customers original units will be repaired but not refurbished as standard. Appointed Motorola Service

Hubs will perform warranty and non-warranty field service for level 2 (assemblies) and level 3 (limited

PCB component). The Motorola HTC centres will perform level 4 (full component) repairs.

1.2.4 Customer Support:

This will be available through dedicated Call Centres and In Country Help Desks.

Product Service training should be arranged through the local Motorola Support Centre.

1.2.5 Replacement Parts Ordering

Only centres authorized to carry out repairs will be able to purchase spare parts. Orders for spare parts

from Hub’s and Hi-Tech Centres should be placed with the regional Motorola Parts Distribution

Centre.

of 48 European Customer Services

vii

P8088

1.3 General Safety Information

1.3.1 Portable Operation

•DO NOT hold the radio so that the antenna is very close to, or touching, exposed parts of the body,

especially the face or eyes whilst transmitting. The radio will perform best if it is held in the same

manner as you would hold a ‘land’ telephone handset, with the antenna angled up and over your

shoulder.

•DO NOT operate the portable phone in an aircraft. Switch off your telephone. The use of a cellular

telephone in an aircraft may be dangerous to the operation of the aircraft, disruption of the Cellular

Network may occur, and is illegal. Failure to observe this instruction may lead to a suspension or

denial of Cellular Telephone Service to the offender, or legal action, or both.

1.3.2 Mobile/Portable Operation - Telephone use in Vehicles:

•All equipment must be properly grounded according to installation instructions for safe operation.

•Users are advised to turn off their equipment when at a refueling point.

•Safety is every driver’s responsibility. Cellular telephones should only be used in situations in

which the driver considers it safe to do so.

1.3.3 General

•DO NOT allow children to play with any radio equipment containing a transmitter.

•DO NOT operate this equipment near electrical blasting caps or in an explosive atmosphere.

Mobile Telephones are, under certain conditions, capable of interfering with blasting operations.

When you are in the vicinity of such work, look out for and observe signs cautioning against

mobile radio transmission. If transmission is prohibited, you must turn off your mobile telephone

to prevent any transmission.

In standby mode the mobile telephone will automatically transmit to acknowledge a call if it is not

turned off.

•Refer to the appropriate section of the product user manual for additional pertinent safety

information

•All equipment should be serviced only by a Motorola qualified technician.

of 48 European Customer Services

P8088

SECTION 2:

P8088

DESCRIPTION

of 48 European Customer Services

P8088

2.1 Specifications of P8088

General

Function Specification

Frequency Range GSM

Frequency Range DCS

880-915 MHz TX (with EGSM)

925-960 MHz RX

1710-1785 MHz Tx

1805-1880 MHz Rx

Channel Spacing 200 kHz

Channels 174 GSM/374 DCS carriers with 8 channels per carrier

Modulation GMSK at BT = 0.3

Transmitter Phase Accuracy 5 Degrees RMS, 20 Degrees peak

Duplex Spacing 45 MHz GSM 95MHz DCS

Frequency Stability +0.10 ppm of the downlink frequency (Rx)

Operating Voltage Full Rate PSU = 4.4V +/- 5%

(During Charging = VBatt +/-5% 6.63V

Mid Rate Charger = 5.9V +/- 0.3V

CLA Supply = 4.4V

Battery Operating Voltage = 2.85V(Radio Shut Down voltage in

standby) To 4.2V Max

Transmit Current Typically 250 ma avg, 1.0A peak

Stand-by Current Typically 7.0 ma (DRX2)

Dimensions 130mm x 46mm x 24.5mm

Size (Volume) 105cc with LSQ6 / with LSQ8

Weight 106g with Batt

Temperature Range -10C to +55C

Transmitter

Function Specification

RF Power Output 33 dBm +2dB GSM/ 30 dBm + 2 dB DCS

Output Impedance 50 ohms (nominal)

Spurious Emissions -36 dBm from 0.1 to 1 Ghz

-30 dBm from 1 to 4 Ghz

Receiver

Function Specification

RF Level -102 dBm GSM, -100dBm DCS

RX bit error rate (100 k bits) < 2%

Channel Hop Time 500 microseconds

Time to Camp Approximately 5-10 seconds

Speech Coding

Function Specification

Speech Coding Type Regular Pulse Excitation / Linear Predictive Coding with Long

Term Prediction. (RPE LPC with LTP).

Bit Rate 13.0 k bps

Frame Duration 20 ms

Block Length 260 bits

Classes Class 1 bits = 182 bits. Class 2 bits = 78 bits

Bit Rate with FEC Encoding 22.8 k bps

of 48 European Customer Services

P8088

2.2 P8088 Overview

The Timport P8088 is based around the StaTAC 160 (StarTAC X), but is supported by the StarTAC

210 1.8V. Hardware and is being launched as a Startac 160 refresh product. P8088 is a dual band

cellular handset with a 96 x 32 graphics display, and uses the 3V only, 5V only or the 3 / 5V mini SIM

cards.

Supports HR / FR / EFR and EGSM. There will only be a manual band select option for Asia

Unit will support both simple and complex CKE and there will be new keypads for these.

Launched under the Timeport branding logo, this product is aimed at Time Managers / Career builders.

The wakeup text will support any Co-branding.

Launched initially in Platinum Silver, the P8088 will be different to the existing StarTAC 160 (X) in

the following ways:

•There are now no Aux Battery contacts, however all the mechanical features will still exist for

attachment of accessories.

•New Main batteries

•No Planned Li-Ion Battery

•Whitecap hardware – 1.8V technology

•New Mechanical parts – housings

•New Branding and Lens

•Not Compatible with existing hang up cups for DHFA or Desktop charger.

•Same Key layout, but different graphics on the keys.
