Motorola HS805 Bedienungsanleitung

Wireless Headset

User Guide

Manuel HS805 Nexus 02/09/2004 09:41 Page 2

Figure 1

Figure 2

Manuel HS805 Nexus 02/09/2004 09:41 Page 4

040067o

90°

Figure 3

Figure 4

Manuel HS805 Nexus 02/09/2004 09:41 Page 5

English

Welcome

Welcome to Motorola’s “connected” world of Bluetooth®personal area wireless

networking.

The headset provides hands-free convenience and freedom from cables and

wires. You can place a call directly from your Bluetooth Wireless Headset by

using your Bluetooth capable phone and your phone’s activation feature.

Bluetooth wireless technology makes all connections quickly and without

cables.

All Motorola wireless products are designed and manufactured to meet

Motorola’s rigorous specifications and world-class quality standards. During

development, our testing team took the Motorola Bluetooth Wireless Headset

through rigorous durability tests including temperature, humidity, shock, dust,

vibration, and drop tests.

Thank you for choosing a Motorola product equipped with Bluetooth®

technology!

Manuel HS805 Nexus 02/09/2004 09:41 Page 6

English

Safety and General information

Users are not permitted to make changes or modify the device in any way.

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Electromagnetic Interference/Compatibility

Nearly every electronic device is susceptible to electromagnetic interference

(EMI) if inadequately shielded, designed, or otherwise configured for

electromagnetic compatibility.

Turn off your device in any facility where posted notices instruct you to do so.

These facilities may include hospitals or health care facilities that may be

using equipment that is sensitive to external RF energy.

European Union Directives Conformance Statement

Hereby, Motorola declares that this product (“HS805”) is in compliance with

• The essential requirements of European Union Directive 1999/5/EC

You can view your product's Declaration of Conformity (DoC) to Directive

1999/5/EC (the R&TTE Directive) at www.motorola.com/rtte.

Manuel HS805 Nexus 02/09/2004 09:41 Page 7

English

Introduction

What Is Bluetooth wireless technology?

Bluetooth wireless technology propels you into a new dimension in

connectivity. Bluetooth devices communicate without wires, using built-in

radio transceivers that operate on a globally available radio frequency to

ensure worldwide compatibility. Your Bluetooth Wireless Headset can

communicate with other Bluetooth devices within a range of approximately

10 meters (33 feet).

How can I use my wireless headset?

Your Wireless Headset equipped with Bluetooth wireless technology lets you

connect with other similarly equipped devices :

• Use your phone hands-free.

• Handle incoming and outgoing calls with the headset multifunction

control button

• Use voice activation to make calls.

Headset Features

Please refer to figure 1 on page 1.

1. Headset Indicator LED Provides visual cue about headset status.

2. Volume Control Buttons Adjust speaker volume up and down.

3. Multifunction Button Controls several headset functions.

4. Microphone Picks up your voice input.

5. Earhook Attaches headset to ear.

6. Speaker Plays the sound you receive on the call.

7. Battery door Allows you to change the battery.

Manuel HS805 Nexus 02/09/2004 09:41 Page 8

English

Using your headset

Replacing your headset battery

Please refer to figure 2 on page 1.

- Open the battery door on the back of the headset.

- Insert a new battery following the + and - markings in the battery compartment.

- Close the battery door.

For best performance, use AAA alkaline batteries. A fresh battery will provide

up to 22 hours talk time and 20 days standby time (based on performance

using Energizer ® e2 AAA batteries).

Turning your headset on and off

To turn the headset on or off, press the multifunction button until the indicator

flashes.

Wearing your headset

Placing the headset on your ear: refer to figure 3 on page 2.

Changing for wear on the left ear: refer to figure 4 on page 2.

Adjusting volume

To adjust volume, press either one of the bottom and top volume buttons

repeatedly until you reach the desired volume level.

Volume Orientation technology - To change the volume button orientation

from left or right rear: with the headset off, press the multifunction button and

desired volume button to assign a “volume up” until the LED flashes 2 times

and the headset powers up.

Pairing your headset and phone

You must pair your headset and phone before you can make a call.

“Pairing” creates a link between devices equipped with Bluetooth wireless

technology and allows the phone to remember the headset’s unique ID. Once

your headset and phone are paired, your headset automatically connects to

your phone.

Manuel HS805 Nexus 02/09/2004 09:41 Page 9

English

Pairing

With the headset and phone in close proximity:

Step 1: When the headset is off, press and hold the multifunction button

until the headset indicator turns on permanently.

Step 2: Perform a device discovery (or scan) from the phone. For details

about device discovery consult your phone’s user guide.

Step 3: Select the Motorola HS805 in the list of discovered devices and confirm

by following the on-screen prompts.

Step 4: When requested by the phone, enter the passkey 0000 and confirm.

The device ID is now stored in the phone’s memory. Pairing is successful

when the headset indicator flashes rapidly.

Paired link to additional devices

Your headset can store pairing information for up to 8 different devices equipped

with Bluetooth wireless technology. Devices are stored in a “Paired Device

List” in memory in chronological order. When an attempt to pair to more than

8 devices is made, the oldest paired device is removed from the list.

The headset will automatically initiate a connection with the last device it

was connected to either by powering up the headset or by pressing the

multifunction button. If you want to connect the headset to another device in

the paired device list, you must initiate the connection from that device.

Whichever of the 8 devices initiates a connection to the headset

afterwards, that device then becomes the “last connected” device.

Placing and receiving calls

You can use the phone as usual to dial a number.

Your headset supports both Hands Free and Headset Profiles. Accessing call

functions depend on which profile your phone supports.

Note: some phones do not support all features listed. See your phone user'

guide.

Manuel HS805 Nexus 02/09/2004 09:41 Page 10

English

You can activate call functions for the hands-free profile according to the

following table:

Function Phone Status Action (Hands-free profile)

Receive a call ON - phone rings Short press n

Make a voice dial call ON - idle Short press n, speak name

Redial a number ON - voice dialing Long press n

turned on or off

End a call ON - in call Short press n

Transfer call ON - in call Short press n

from phone to headset

Toggle between ON - in call, another Long press n

two calls call is coming in

ON - in call, another

call is on hold

Reject a call ON - phone rings Long press n

Note: if the link abnormally disconnects (for example, out of range), the

headset tries to reestablish the link.

Using your headset indicators

Headset indicator (LED)

Headset indicator Headset

OFF Power off

ON (steady) Pairing mode

10 rapid flashes Pairing successful

Flashes at a 3-second interval Standby (not on a call)

Flashes at a 8-second interval Connected (on a call)

Note: When the wireless headset is paired to the phone and there is no activity

for 5 minutes, the green flashing LED turns off. Any button press on the headset

will reawaken the headset and the flashing resumes. If you press the up and

down volume buttons simultaneously, the flashing LED turns off.

If you press the up and down volume buttons simultaneously, during a call, the

flashing LED turns off.

Manuel HS805 Nexus 02/09/2004 09:41 Page 11

English

Audio tones

Audio Tone Headset status

Single high tone when pressing Volume maximum or minimum reached

volume button

Five rapid high tones, repeated Low battery

every 60 seconds

No audio indications; Out of range

deteriorating audio quality

Series of 4 tones, low to high ON

Ring tone Incoming call

Single high tone Pairing confirmation

Single low tone Initiate voice activation

Dual high/low tone voice Voice tag not recognized

Single high tone End call

Series of 4 tones, high to low OFF

If you have additional questions, please call your local hotline or visit us at

www.hellomoto.com

Manuel HS805 Nexus 02/09/2004 09:41 Page 12
