EM400™

Mobile Radio User Guide

English

RADIO OVERVIEW

LED INDICATORS

Indicates power up, transmit, receive, scan,

monitor status, channel busy, Call Alert™

receive/transmit, and Selective Call receive/

transmit.

DISPLAY

The top row displays menu and radio status

information:

LED State/Color Indication

Radio Call

Red Transmitting

Flashing Red Receiving

Flashing Red Channel Busy

Scan

Flashing Green Scanning for activity

Call Alert

Flashing Yellow Indicates receiving a Call Alert

Yellow Indicates sending a Call Alert

Selective Call

Flashing Yellow Indicates receiving a Selective

Call

Ye l l o w Indicates sending a Selective

Call

Sticky Monitor/Open Squelch

Yellow While monitoring

Symbol Indication

Signal Strength

The more bars, the stronger

the signal being received by

your radio.

Power Level

Low Power “R” or High Power

“S” is activated.

Monitor

The selected channel is being

monitored.

Phone

Phone mode is selected.

Scan

Indicates that the Scan

feature has been activated.

PERS4

English

RADIO OVERVIEW

OPTIONAL ENHANCED KEYPAD

MICROPHONE (RMN5029)

Your radio may be ordered with an optional

DTMF (Dual-Tone Multi-Frequency)

microphone that has a direct entry keypad.

This keypad microphone has three

programmable buttons (A, B, C) below the

keypad that can be programmed to

conveniently activate select radio features.

Priority 1 Scan

(•flashing)

Indicates scan has stopped

and landed on an active

Priority 1 channel.

Priority 2 Scan

(• steady)

Indicates scan has stopped

and landed on an active

Priority 2 channel.

Talkaround

You are not transmitting

through a repeater

Call Received

A Selective Call or Call Alert

has been received.

Emergency

An Emergency Alarm is being

sent.

Option Board

An Option Board has been

activated.

Symbol Indication

Microphone

ush-to-Talk

TT)button

DTMF

Keypad

Programma-

bleButtons (

B, C)

English

RADIO OVERVIEW

The keypad is used for:

• Dialing a phone number.

• Entering information when programming

phone lists.

• Directly accessing preprogrammed features

(see page 13).

Each key can generate several different

characters. For example, to enter the

character “C,” press the 2button three

times. (Refer to the Entering Characters

Using the DTMF Microphone Keypad table.)

Entering Characters Using the DTMF

Microphone Keypad

Number of Times Button is Pressed

Button 1 2 3 4 5

11/ \

2ABC2

3DEF3

4GH I 4

5JKL5

6MNO6

7PQRS7

8TUV8

9WX YZ9

**<>

##+ -_

English

RADIO OVERVIEW

INDICATOR TONES

High pitched tone Low pitched tone

Some programmable buttons use tones to

indicate one of two modes:

Self Test Pass Tone

S e l f Te s t Fa i l To n e

Positive Indicator Tone

Negative Indicator Tone

Good Key Press

Bad Key Press

Programmable

Buttons

Positive

Indicator Tone

Negative

Indicator Tone

Scan Start Stop

Power Level High Low

Squelch Tight Normal

Repeater/

Talkaround

Does not use

repeater

Uses repeater

VOX Enabled Disabled

Local/Distance Local Distance

Sticky Monitor/

Open Squelch

—Enabled

Home Revert

Memory

Channel (1&2)

—Enabled

Story Memory

Channel (1&2)

—Stored

Menu Mode

—Accessed

Radio Call — Enabled

Scan List Edit — Enabled

Speed Dial — Enabled

English

RADIO OVERVIEW

PROGRAMMABLE BUTTONS

Your radio has four programmable buttons.

Your dealer/programmer can program these

buttons as shortcuts to various radio features.

Check with your dealer/programmer for a

complete list of functions your radio supports.

Programmable buttons include:

• The four front buttons (C, D, E, and

F).

• The three buttons (A, B, and C) of the

optional DTMF microphone.

Some buttons can access up to two features,

depending on the type of button press:

•Short Press — quickly pressing and

releasing the programmable buttons,

–

•Long Press — pressing and holding the

programmable buttons for a

preprogrammed period of time,

–

•Hold Down — pressing and holding down

the programmable buttons while checking

status or making adjustments.

The table on page 13 summarizes the

programmable features available and shows

the page number where the feature is

explained.

In the “Button” column, have your dealer/

programmer record the name of the

programmable button next to the feature that

has been programmed to it.

The dealer/programmer can use the

abbreviations (P1, P2, P3, or P4) shown in the

radio illustration on page 7.

Also, where appropriate, have your dealer/

programmer indicate whether the button press

requires a short press, a long press, or needs

to be held down.

Phone Mode — Enabled

Option Board Enabled Disabled

Escalert Enabled Disabled

Programmable

Buttons

Positive

Indicator Tone

Negative

Indicator Tone

English

RADIO OVERVIEW

Programmable Features

Function Indicator Short Press Long Press Hold Down Page Button

Menu Mode —

Dbutton enters Menu Mode and selects

menu options. Cbutton is automatically

re-assigned to exit Menu Mode.†

—15

Volume Set — — —

Sounds a tone

for adjusting

your radio’s

volume level.

Monitor C

Toggle silent

monitor operation

(also turn off open

squelch monitor

when it has been

activated).

Turn on open

squelch monitor. —18

Repeater/

Talkaround JToggle between using a repeater or

transmitting directly to another radio.†—19

Home Revert

Memory

Channel (1&2)

—Provides direct

channel access. ——20

Store Memory

Channel (1&2) ——Stores current chan-

nel. —20

Local/Distance — Toggle between local mode and distance

mode.†—20

†This function is activated by EITHER a short OR a long press, but not both.

English

RADIO OVERVIEW

Voice Operated

Transmission

(VOX)

— Toggle VOX on and off.†—21

Radio Call — Directly access the radio call menu.†—23,

Scan/Nuisance

Channel Delete GToggle scan on and

off.

Delete a nuisance

channel while

scanning.

—27,

Edit Scan List —Directly access the Scan Edit menu to add,

delete, or prioritize channels.†—29

Phone DDirectly access Phone mode.†—33,34

Speed Dial DDirectly Access Phone mode to quickly

access phone list for speed dial.†—35

Escalert On/Off —Toggles escalert on and off.†—44

Squelch — Toggles squelch level between tight and

normal squelch.†—49

Power Level BToggle transmit power level between High

and Low.†—49

Option Board AToggle the option board on and off.†—50

†This function is activated by EITHER a short OR a long press, but not both.

Programmable Features (Continued)

Function Indicator Short Press Long Press Hold Down Page Button

English

RADIO OVERVIEW

MENU BUTTONS

Menu Button

If preprogrammed by your dealer/programmer,

the two front buttons (Cand D) can be

used, in conjunction with other programmable

features, to access and select menu options

(D); and exit menu mode (C).

The Dbutton can be preprogrammed by

your dealer/programmer to either a short or

long press to access Menu Mode.

Menu Scroll Buttons

Used to scroll while in Menu Mode.

Refer to the menu navigation chart for

menu selectable features at the back of

this manual.

Navigate the Menu

Gor Hto scroll through the menu options. If

you scroll past the last option, the selection

wraps around and starts again.

When you reach the required option, a short

press of the Dbutton selects that option and

enters the Sub-menu.

Gor Hto scroll through the sub-menu

options. Select the option with a short press of

the Dbutton.

Exit the Menu

While in Menu Mode, the Cbutton is

automatically assigned to completely exit the

Menu Mode by a long press or by a series of

short presses to exit from a sub-level of the

menu hierarchy.

The radio also exits the menu mode if there

has been no inputs via the navigation buttons

for the “Inactivity Time” or after a selection has

been made.

Once you have exited Menu Mode, the C

and Dbuttons return to normal

programmable condition.
