MP-Man MID7C Bedienungsanleitung
For Model No.
MID7C EN User Manual
Page 1
This manual contains important safety precautions and information of correct use.
Please be sure to read this manual carefully before use so as to avoid any accidents.
Do not place the product in hot, wet or dusty environment, especially in summer, do not leave the product
inside a car with all windows closed.
Avoid dropping, impacting or shaking the product violently, otherwise it may cause damages or malfunctions.
Select a proper volume to avoid ear problem when using earphones.
Do not cross the road or drive vehicles, using headphones to avoid trac accidents.
Be sure to use the provided chargers and accessories in the package.
Be sure to charge the product when the following situations take place,
- The battery icon shows lower or empty.
- System automatically shut down and it turns o soon after restart.
- Operation keys do not respond properly.
- The device shows on the top right corner.
Hardware
7.0” High Denition TFT LCD Touch Screen (800x480 pixel)
Capacitive multi-touch (2 touch) point function
CPU: Telechips TCC8902 ARM processor
RAM : DDR2 256MB (3D accelerator possible for 3D games)
Wi-Fi (IEEE802.11 b/g/n) for internet connection
HDMI port for TV-out (1080p output support)
USB host for OTG function
G-sensor
Micro SD card slot recognizing up to 32GB
Built-in speaker & Built-in MIC
5V DC power adapter
Compatible with keyboard, mouse
Dimension : 124 x 192 x 12.8mm
Andriod 2.3 Ginger Bread
Google browser
Wi-Fi connection
e-Book function (all e-book formats supported by application)
1080p HD le playback
VoIP phone function with Wi-Fi connection
Possible to view/edit MS oce les by application
Video: AVI, RM/ RMVB, FLV, MPG4 – 1, MPEG – 2 etc.
Audio: MP3, WMA, AAC, WAV ect.
Photo: JPEG, BMP, GIF, PNG, TIFF
Page 2
specification
Software
Page 3
Name
Important Notice
- If the device is freezing or stuck, press the
reset button(a small hole).
- When the performance is slow after using
some applications, it is recommended to
close running application in setting menu.
Caution
- For charging, be sure to use the power
adapter(DC5V) that is provided in the package,
otherwise, the device may be damaged
and does not work.
- The device is equipped with high performance
processor. It may heat in case of using long or
while charging.
MID7C
Menu Home Back
Charger Reset MicroSD slot
Speaker
Camera
Volume+
Volume-
Power
USB HDMI Earphone
Long press power button to turn on/o the device. It may take a minute to boot the device.
Short press power button to turn on/o the screen.(Standby mode. Refer to 3. below)
Page 4
1. Power On/Off
After turning on the device, desktop displays with shortcut icons and arrow panel at the right side
2. Desktop
Short press the power button to turn on/o the screen (standby mode on/o).
After standby mode o, slide the lock icon to the speaker icon in order to unlock the screen.
Page 5
3. Standby mode(Screen off mode) /
Unlock the screen
On the desktop, press menu button and select Settings.
4. System settings
Page 6
Press Settings
1.Wireless & networks
Page 7
Wi-Fi – Press Wi-Fi to turn on/o
Wi-Fi settings - Press Wi-Fi settings, press Network
notication, then the device will automatically
search the available Wi-Fi signals.
Select the network you want to connect with.
2. Sound & display
Set up each setting as you like.
Page 8
3. Location & security
Use wireless networks – Location determined by Wi-Fi and/or mobile networks
Set up screen lock – Protect your device from unauthorized use by creating a personal screen unlock pattern.
Visible passwords – Show password as you type.
Install from TF card – Install encrypted certicates from TF card.
Set password – Set or change the credential storage password.
4. Applications
Unknown sources
If you want to allow installation of non-Market Applications, Press Unknown sources and presses OK.
Manage applications
All installed application are listing.
Running services
View and control currently running services.
Storage use
View storage used by applications
Development
Set options for application development
Keep pressing an application to manage.
Press Uninstall to uninstall the selected application.
Page 9
