Mpio DMB Plus Bedienungsanleitung

Better and new Encoding MP3 player

Digital Sound

The MPIO maintains high

quality sound at all time.

What is MP3?

MP3 stands for MPEG 1/2 layer 3.

MP3 files can be compressed up to 1/20 size of

the original wave files.

What is the MPIO?

The MPIO stands for Multi-Play Internet AudiO,

is a new generation digital audio player.

You can purchase MP3 files on the internet

and download them directly to your MPIO for

CD quality sound without the need of casette

tapes or CDs.

Encoding Digital

Player!

Download files directly

to your MPIO and

enjoy the CD sound

quality now!.

CONTENTS

• This equipment has been tested and found to comply with the limits for a Class B digital device.

Player Features and Controls

Accessories

Inserting the battery

Display LCD Panel

Listening to the music

Installing Software on PC

Installing the MPIO Manager

Connecting the MPIO to PC

Functions of Jog button

Listening to the FM Radio

Listening to the Voice Record on PC

REP(Repeat) Mode

EQ(Equalizer) Mode

Repeat Segmentation Mode

Back Light Mode

Making MP3 files from an Audio Player

Formatting Internal Memory

Downloading Files to the MPIO

Listening to the MP3 file on PC

Erasing Files on the MPIO

Erasing Files on PC

Arranging the Playback Order

Downloading Additional Font to the MPIO

Inserting the SMC(Smart Media Card)

Troubleshooting

Safety Precautions

Technical Specifications

Warranty

PLAYER FEATURES AND CONTROLS

Front Panel

USB Connector

Line-in Jack connecting the

MPIO to Audio (Stereo

Cable)

LCD

Forward

Rewind

Volume Control

Power on/ Play

Stop/ Power off

Earphone Jack

Mode button

(MP3/ FM Radio/ MP3 Record/ Erasing Files)

Repeat Segmentation/Record/

Back light Mode

Equalizer/ Record Selection

Repeat/ FM Channel Mode

Hold

(For the prevention of malfunction of player,

locate the Hold switch to the Hold position

( ). when this button is kept on, all buttons

will not operate.)

Note : Press and release to display next 3 tracks.

: Press and release to display previous 3 tracks.

Microphone

(INTRO/ NORMAL/ REPEAT ALL/ REPEAT1/

SHUFFLE)

(FLAT/POP/ROCK/CLASSIC/X-BASS)

Battery Case

SMC(Smart Media

Card) Slot

Eject button(SMC)

Rear Panel

Power On/ Play/ Pause

Stop/ Power Off

Volume Control (+/-)

Equalizer/ FM Mode

Earphone Jack

Rewind

Forward

Hold

(MP3 Mode: Forward

FM Radio Mode: Frequency DOWN)

(MP3 Mode: Rewind

FM Radio Mode: Frequency UP)

(Changing the FM Radio Channel)

Optional Remote Control

•Press and Hold button to enter FM Radio Mode.

ACCESSORIES

USB CableUser's Guide Installation CD

Remote Control 1.5V AA type Battery

(1EA)

Stereo Cable

PocketEarphone

INSERTING THE BATTERY

1. Slide the battery cover in the

direction of the arrow. 2. Insert "AA" type battery with the

correct polarity. 3. Close the cover and slide it as

indicated until the battery cover

latches.

• You need one 1.5V AA type battery for your MPIO.

DISPLAY(LCD) PANEL

The indicator shows the amount of battery

remaining as belows:

If the battery icon shows empty and starts blinking,

it indicates the battery is almost gone.

(About 3 minutes left before the battery needs to be

replaced.)

Battery

Playback Icon

EQ (Equalizer Mode) Icon

→By selecting Equalizer

menu, you will see 5

different Equalizer

modes ( )

displayed. (see page

25)

MP3 Record Icon

REP (Repeat

Mode) Icon

(see page 24)

Battery Icon

※You can spend more electricity than usual while

listening to the radio or recording files.

LISTENING TO THE MUSIC

2. Select the file what you

wish to listen to with

Jog button.

: Forward

: Rewind

3. Adjust the volume by

pressing the volume

(+/-) to your desired

level.

1. Turn the MPIO on by

pressing the PLAY

button.

Press the PLAY /STOP

button( ) again to play the

first selection.

4. Press the PLAY/STOP( )

button to stop playing.

To turn your MPIO off, press

and hold the ( ) button for

about 2 seconds.

• To select the files during the selection state

+ : Press and hold to move backward within the

current track.

- : Press and hold to move forward within the

current track.

: Press and release to display next 3 tracks.

: Press and release to display previous 3

tracks.

• If you do not press any buttons during in the

selection state, MPIO will automatically turn off

after 3 minutes.

• The level of volume is 00-40/MAX.

• Only during the playback state, you can

adjust the volume.

INSTALLING SOFTWARE ON PC

First, place the Installation CD into our CD-ROM drive. The

installation will start with the initial page as ou can see on the

left side of this page.

• MPIO Manager

MPIO Manager is for transferring files between PC and the MPIO.

You can download MP3 files and others to your MPIO.

You can also upload any other files (except MP3 and WMA files) to your

PC using this software.

• Sample MP3

You can enjoy 5 sample songs in MP3.

• WWW

You can get updated information and MPIO Manager from our website.

S stem Requirements

•

Pentium 133MHz or faster

•

CD-ROM drive

•

USB port

•

20MB free hard disk space

•

Windows 98/SE/ME/2000(PRO)/MAC OS (ver8.61~9.1)

Insert the Installation CD into the CD-ROM drive. The picture below will appear.

INSTALLING THE MPIO MANAGER

By pressing the 'Next' button you can install the MPIO Manager in order.

Welcome to the Install Shield Wizard for MPIO

Manager. The Install Shield wizard will install

MPIO Manager on your computer. To continue,

click NEXT.

Set up will install MPIO Manager in the following

folder (C:/ Program File/ Digitalway). To install to

the folder, click NEXT!

To install to a different folder, click Browse and

select another folder.

Click!Click!
