MSI PRO Series Bedienungsanleitung

Pro Series

Portable Monitor

PRO MP161(3PB7)

Table of Contents

Preparation for use ..........................................3

Packing contents .............................................3

Installation of Monitor Stand ..........................3

Overview of Monitor ......................................5

Connecting to be the monitor of various devices ..........................6

OSD setting ...................................................................................7

OSD keys ......................................................................................7

OSD menu ....................................................................................8

Professional ..................................................................................8

Image ............................................................................................9

Input source..................................................................................10

Navi key.........................................................................................11

Setting ...........................................................................................12

Specification ....................................................................................13

Preset display mode .........................................................................14

Troubleshooting ...............................................................................15

Safety precautions ............................................................................16

German Rheinland TUV certifications .............................................18

Energy Star certifications ..................................................................18

Regulatory information .....................................................................19

Amendment V1.0, 2022/12

Preparation for use

The information for hardware installation programs is provided in this chapter. Before connecting

to devices, be careful to fix the devices and use grounding wrist strap to avoid static electricity.

Packaging contents

Monitor PRO MP161(3PB7)

Document Quick Start Guide

Signal cable Mini HDMI TM transmission cable

Power cable/signal cable

Type-C transmission cable

Caution

If the consumer uses a power adapter for charging, he/she should purchase a matching power

adapter that has obtained CCC certification and meets the standard.

If any item is damaged or missing, please contact the seller or local dealer.

Packaging contents may vary by country.

The attached power cable is dedicated to this monitor and should not be used with other

products.

Applicable models (including but not limited to)

Apple

iPad Pro 11” (A1980)

iPad Pro 12.9"(3 Gen) (A1876)

Macbook 12"

Macbook Pro 13"(2016 -2020)

Macbook Pro 15"(2017/2018)

Macbook Pro 16"(2019/2020)

EliteBook Folio G1 12.5

Spectre 13-af001

Spectre x360 13-w021TU 13.3

Google

Razer

DELL

Samsung

Pixel Book

Blade Stealth 17

XPS132in1

XPS 13

Tab S4 SM-T835C 10.5"

Adjusting monitor stand

Caution

Place the monitor on a soft, protected surface to avoid scratching the display panel.

Do not use any sharp objects on the panel.

This product has no protective film, so the user does not need to remove it! Any mechanical

damage to the product, including removal of the polarizing film, may affect the warranty

repair!

PRO MP161(3PB7)

1. Adjust the stand vertically by 180 °.

2. Adjust the stand horizontally by 360 °.

3. Adjust the stand to an appropriate position and place it horizontally on the table.

4. Adjust the stand to an appropriate position and place it vertically on the table.

5. Before placing the monitor, make sure that the stand is properly adjusted to stabilize the

monitor.

Overview of the monitor

PRO MP161(3PB7)

①Power button

②Up/down key

③Type-C interface

④Type-C interface

⑤Mini HDMI interface

Connecting to be the monitor of various devices

This product is a Type-C power supplying product and it meets LPS requirements.

PC’s HDMI as the signal source

Note: Supplied power shall be larger than 15W

Signal transmission

Supply power

Signal transmission

Supply power

Note: Supplied power shall be larger than 15W

Laptop’s Type-C as the signal source

Mobile phone’s Type-C as the signal source

Signal transmission

Supply power

Note: Supplied power shall be larger than 15W

Mobile power supply

OSD setting

The basic information for OSD setting is provided in this chapter.

Caution

Any change of the information is not subject to prior notice.

OSD key

A group of OSD keys are provided for this monitor, which help to control on screen display (OSD)

menu.

①LED indicator: [Normally on: normal power-on state; Flickering: Power-saving standby state]

②Power on/off key/OK key

[2-1 Power off state-hold for 1 second to turn on the power]

[2-2 Non-OSD state-hold for 1 second to turn off the power]

[2-3 Non-OSD state- press to display OSD]

[2-4 OSD state-press to enter the sub-menu]

[2-5 OSD state- Hold for 1 second to return, and hold for 1 second again to turn off the power]

③Up key: [OSD: move upward or increase the progress bar/non-OSD state: set as a hotkey of

designated shortcut mode]

④Down key: [OSD: move downward or decrease the progress bar/non-OSD state: set as a hotkey

of designated shortcut mode]

Power on/off key/OK key

LED indicator

Up key

Down key

OSD menu

Professional

Level-1 menu Level 2/3 menu Description

Mode ECO Use [Up] or [Down] key to select and

preview mode and effect.

Press OK key to apply your type of

mode.

USER

Anti-Blue light

Movie

Office

Black-white

Response time

Normal

Adjust [Response time].

Fast

Fastest

Refresh rate Location Left top The default location of [Refresh Rate]

is [Left Top]. The [Location] can be

adjusted on OSD menu. Press OK key

to confirm and apply your location of

[Refresh Rate].

The monitor will run as per the preset

[Refresh Rate] of the screen of the

operating system.

Right top

Left bottom

Right bottom

Off

Level-1 menu Level 2/3 menu Description

Alarm Clock Location Left Top

After setting time, press OK key to

activate the timer.

The default location of [Alarm Clock]

is [Left Top]. The user can select the

[Location] by himself.

Right Top

Left Bottom

Right Bottom

Off

15:00

00:01~99:59

30:00

45:00

60:00

Screen assistance Eye-Q

check

Off Select [Off] to disable [Eye-Q Check]

function.

Select [Amsler Grid] to check central

vision state.

Select [Astigmatism] to check

Astigmatic vision state.

Select [Posture correction] to correct

the posture.

Amsler Grid

Astigmatism

Posture correction

Screen Size

Auto

Adjust [Screen Size].

The default is [Auto].

4:3

16:9

Adaptive-Sync

Off

Adaptve-Sync can prevent screen

tearing.


Level-1 menu

Level 2/3 menu

Description

Brightness

0-100

Adjust[Brightness] properly according

to the surrounding light.

After HDCR is enabled, [Brightness]

will turn gray and cannot be used.

Contrast

0-100

Adjust [Contrast] properly to relax your

eyes

Sharpness 0-5

[Sharpness] can improve the sharpness

and details of images.

Level-1 menu

Level 2/3 menu

Description

Image enhancement

Off

[Image enhancement] can improve the

sharpness on the edge of the image.

Weak

Medium

Strong

Strongest

Low Blue light Off [Low Blue Light] can protect your eyes

against blue light. After it is enabled,

[Low Blue Light] can adjust color

temperature of the screen to a more

yellowish tint.

After [Mode] is set as [Anti-Blue

Light], [Low Blue Light] will be forced

to be enabled.

HDCR

Off

HDCR can enhance image quality by

improving the contrast of the image.

After HDCR is enabled, [Brightness]

will turn gray and cannot be used.

Color temperature

Cool

The default setting of [Color

temperature] is [Normal].

Use [Up] or [Down] key to select and

preview mode and effect.

Press OK key to confirm and apply

your type of mode.

Normal

Warm

Customization

R(0-100)

G(0-100)

B(0-100)

Input Source

Level-1 menu

Description

HDMI

Select an input source from the list.

Type-C

1) Max transmission rate of data supported: 5Gbps (USB3.1).

Support Power Delivery input function of different voltage, input:

5V/3A, 9V/3A, 12V/3A, 15V/3A.

3) Support image output function, max resolution: 1920*1080@60Hz.

Max normal load:

Type-C load 5V/0.6A;

Type-C load 9V/1A;

Type-C load 12V/1A;

Type-C load 15V/2.6A;

Type-C1

Type-C2
