MSI 645 Combo Bedienungsanleitung

Version 1.0

G52-M6737X1-G22

MS-6737 (v1.X) ATX Mainboard

645Combo

Manual Rev: 1.0

Release Date: Dec. 2002

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-StarInternational MS-6737

Testedtocomply

withFCCStandard

ForHomeor OfficeUse

iii

CopyrightNotice

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Windows®95/98/2000/NT/XP are registered trademarks of Microsoft

Corporation.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Revision History

Revision Revision History Date

V1.0 First release for PCB 1.X Dec. 2002

TechnicalSupport

If a problem arises with your system and no solution can be obtained from the

user’s manual, please contact your place of purchase or local distributor.

Alternatively, please try the following help resources for further guidance.

Visit the MSI website for FAQ, technical guide, BIOS updates, driver

updates, and other information: http://www.msi.com.tw/

Contact our technical staff at: [email protected]

1. Always read the safety instructions carefully.

2. Keep this User’s Manual for future reference.

3. Keep this equipment away from humidity.

4. Lay this equipment on a reliable flat surface before setting it up.

5. The openings on the enclosure are for air convection hence protects the

equipmentfrom overheating. DO NOTCOVER THEOPENINGS.

6. Make sure the voltage of the power source and adjust properly 110/220V

before connecting the equipment to the power inlet.

7. Place the power cord such a way that people can not step on it. Do not

place anything over the power cord.

8. Always UnplugthePower Cord beforeinsertingany add-on cardormodule.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage or cause electri-

cal shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zThe power cord or plug is damaged.

zLiquid has penetrated into the equipment.

zThe equipment has been exposed to moisture.

zThe equipment has not work well or you can not get it work according

to User’s Manual.

zThe equipment has dropped and damaged.

zThe equipment has obvious sign of breakage.

12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

UNCONDITIONED,STORAGETEMPERATUREABOVE600C(1400F),IT

MAYDAMAGETHEEQUIPMENT.

Safety Instructions

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

CONTENTS

FCC-B Radio Frequency Interference Statement ..........................................iii

Revision History ...........................................................................................iii

Technical Support ......................................................................................... iii

Safety Instructions .......................................................................................iv

Chapter1.GettingStarted ........................................................................ 1-1

Mainboard Specifications ....................................................................1-2

Mainboard Layout ...............................................................................1-4

MSI Special Features ...........................................................................1-5

FuzzyLogic™ 4 .............................................................................1-5

LiveBIOS™/LiveDriver™ ............................................................1-7

Live Monitor™ ..............................................................................1-7

D-Bracket™2 (Optional) ............................................................... 1-8

PCAlert™4 ................................................................................. 1-10

Chapter2.HardwareSetup ....................................................................... 2-1

Quick Components Guide ....................................................................2-2

Central Processing Unit: CPU ..............................................................2-3

CPU Core Speed Derivation Procedure .........................................2-3

CPU Installation Procedures for Socket 478 ..................................2-4

Installing the CPU Fan ..................................................................2-5

Memory................................................................................................2-7

DDR Module Combination ............................................................ 2-8

Installing DDR Modules ...............................................................2-8

Installing SDR Modules ................................................................2-9

SDR Module Combination ............................................................2-9

Power Supply ..................................................................................... 2-10

ATX 20-Pin Power Connector: CONN1 ....................................... 2-10

ATX 12V Power Connector: JPW1 .............................................. 2-11

ATX 5V/12V Power Connector: JPW2 ......................................... 2-11

BackPanel .......................................................................................... 2-12

Mouse Connector ....................................................................... 2-12

Keyboard Connector ................................................................... 2-13

USB Connectors.......................................................................... 2-13

Serial Port Connectors: COM A & COM B.................................. 2-14

RJ-45LANJack (Optional) .......................................................... 2-14

Parallel Port Connector: LPT1...................................................... 2-15

Joystick/Midi Connector ............................................................. 2-16

Audio Port Connectors ............................................................... 2-16

Connectors......................................................................................... 2-17

Floppy Disk Drive Connector: FDD1........................................... 2-17

CD-InConnector:JCD1 ............................................................... 2-17

Hard Disk Connectors: IDE1/IDE2 .............................................. 2-18

Fan Power Connectors: CPUFA/SYSFA...................................... 2-19

Front Panel Connectors: JFP1/JFP2............................................. 2-20

Front Panel Audio Connector: JAUD1 ........................................ 2-21

Front USB Connectors: JUSB1/JUSB2 ........................................ 2-22

D-Bracket™2Connector: JDB1 .................................................. 2-23

Jumpers .............................................................................................. 2-24

Clear CMOS Jumper:JBAT1 ........................................................ 2-24

Slots ................................................................................................... 2-25

AGP (Accelerated Graphics Port) Slot......................................... 2-25

PCI (Peripheral Component Interconnect) Slots.......................... 2-25

PCI Interrupt Request Routing .................................................... 2-26

Chapter3.BIOS Setup.............................................................................. 3-1

Entering Setup......................................................................................3-2

Selecting the First Boot Device .....................................................3-2

Control Keys .................................................................................3-3

Getting Help .................................................................................. 3-3

The Main Menu ................................................................................... 3-4

vii

Standard CMOS Features ....................................................................3-6

Advanced BIOS Features .................................................................... 3-8

Advanced Chipset Features............................................................... 3-12

Power Management Features............................................................. 3-14

PNP/PCI Configurations..................................................................... 3-18

Integrated Peripherals ........................................................................ 3-21

PC Health Status ................................................................................ 3-25

Frequency/Voltage Control ................................................................ 3-26

Set Supervisor/User Password........................................................... 3-28

Load Optimal/High Performance Defaults .......................................... 3-29

Appendix:Using4-or6-ChannelAudioFunction ....................................A-1

Using 4- or 6-Channel Audio Function ...............................................A-2

Installing the Audio Driver...........................................................A-2

Using 4- or 6-Channel Audio Function ........................................A-2

Testing the Connected Speakers.........................................................A-6

Testing Each Speaker ...................................................................A-6

PlayingKaraOK ..................................................................................A-8

PlayingKaraOK............................................................................A-8

Troubleshooting ........................................................................................ T-1

Glossary ....................................................................................................G-1

1-1

Getting Started

Chapter 1. Getting

Started

Thank you for choosing the 645 Combo (MS-6737 v1.X)

ATX mainboard. The 645 Combo is based on SiS®645 & 962L

chipsets for optimal system efficiency. Designed to fit the ad-

vanced Intel®Pentium®4 processors in 478 pin package, the

645 Combo delivers a high performance and professional desk-

top platform solution.

Getting Started

1-2

MS-6737 ATX Mainboard

Mainboard Specifications

CPU

hSupportsIntel®Pentium®4/Celeron®(Williamette478/Northwood478) proc-

essors in the 478 pin package.

hFSB @ 400MHz, can be auto negotiated to 533MHz through BIOS for better

system efficiency.

hSupports up to 2.8GHz or higher speed.

Chipset

hSiS®645Chipset (702BGA)

- High performance host interface 400MHz.

- 64-bit high performance DDR 333/266 memory controller.

- Support AGP 4X/2X interface with fast write transaction.

- High throughput SiS MuTIOL connect to SiS962L MuTIOL Media I/O.

hSiS®962LMuTIOLMediaI/O (371BGA)

- Dual IDE ATA 66/100/133 controllers.

- Integrated USB 2.0/1.1 host controller and Fast Ethernet MAC controller.

- Integrated audio controller with AC97 interface.

- Advanced power management and PC2001 compliance.

- Integrated PCI to LPCC bridge.

MainMemory

hSupports two 184-pin unbuffered PC2700/PC2100/PC1600 DDR SDRAM or

two 168-pin unbuffered PC100/133 SDRAM.

hSupports up to 2GB memory size.

Slots

hOne AGP (Accelerated Graphics Port) slot.

- Supports AGP v2.0 2x/4x.

hSix 32-bit Master PCI bus slots (support 3.3v/5v PCI bus interface).

On-BoardIDE

hDual IDE controllers on the SiS962L chipset provides IDE HDD/CD-ROM

with PIO, Bus Master and Ultra DMA133/100/66 operation modes.

hCan connect up to four IDE devices.

On-BoardPeripherals

hOn-Board Peripherals include:

1-3

Getting Started

- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and

2.88Mbytes

- 2 serial ports (COM A + COM B)

- 1 parallel port supports SPP/EPP/ECP mode

- 1 audio/game port

- 6 USB 2.0 ports (Rear * 2/ Front * 4)

- 1 RJ45 LAN jack (Optional)

Audio

hAC’97 link controller integrated in SiS962L.

hRealTek ALC650 6-channel audio.

- Compliance with AC’97 v2.2 spec.

- Meets PC2001 audio performance requirement.

LAN (Optional)

hSiS962LintegratedMAC + RealTek8201BLPHY.

- Supports 10Mbps and 100Mbps auto-negotiation operation.

- Supports ACPI power management.

BIOS

hThe mainboard BIOS provides “Plug & Play” BIOS which detects the pe-

ripheral devices and expansion cards of the board automatically.

hThe mainboard provides a Desktop Management Interface (DMI) function

which records your mainboard specifications.

Dimension

hATX Form Factor: 29.5 cm (L) x 23 cm (W).

Mounting

h6 mounting holes.

Inhaltsverzeichnis

Andere MSI Hauptplatine Handbücher

MSI

MSI MS-6555 Bedienungsanleitung

MSI

MSI MS-7204 Bedienungsanleitung

MSI

MSI B350M MORTAR ARCTIC Bedienungsanleitung

MSI

MSI X370 XPOWER GAMING TITANIUM Bedienungsanleitung

MSI

MSI Z68MA-G43 (G3) Series Bedienungsanleitung

MSI

MSI H6M-P30 (B3) Bedienungsanleitung

MSI

MSI MS-7502 Series Bedienungsanleitung

MSI

MSI MICRO ATX AL12 Bedienungsanleitung

MSI

MSI z170a GAMING M9 ACK Bedienungsanleitung

MSI

MSI Z77A-G43 GAMING Bedienungsanleitung

MSI

MSI PRO B760M-A WIFI DDR4 Bedienungsanleitung

MSI

MSI MS-6137 Bedienungsanleitung

MSI

MSI MS-7520 ECLIPSE Series Bedienungsanleitung

MSI

MSI K7 Master MS-6341 Bedienungsanleitung

MSI

MSI MS-9804 Bedienungsanleitung

MSI

MSI Creator X299 Bedienungsanleitung

MSI

MSI H81M-E35 Bedienungsanleitung

MSI

MSI P7N SLI PLATINUM - Motherboard - ATX Bedienungsanleitung

MSI

MSI DKA790GX Series Bedienungsanleitung

MSI

MSI K7N2GM2-ILSR Bedienungsanleitung

MSI

MSI MS-7173 Bedienungsanleitung

MSI

MSI PRO B550-P GEN3 Bedienungsanleitung

MSI

MSI MS-7380 Bedienungsanleitung

MSI

MSI 870S-G54 Series Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
