MS-6580 (v1.X) ATX Mainboard
845G Max
845G Max-L
MICRO-STAR INTERNATIONAL
ii
Manual Rev: 1.0
Release Date: Apr. 2002
FCC-BRadioFrequencyInterferenceStatement
This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference when the equip-
ment is operated in a commercial environment. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct
the interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party respon-
sible for compliance could void the user’s authority to operate the equipment.
Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in order to
comply with the emission limits.
VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU
RESEAU.
Micro-StarInternational MS-6580
Testedtocomply
withFCCStandard
ForHome orOfficeUse
iii
Edition
Apr.2002
Copyright Notice
The material in this document is the intellectual property of MICRO-STAR
INTERNATIONAL. We take every care in the preparation of this document,
but no guarantee is given as to the correctness of its contents. Our products
are under continual improvement and we reserve the right to make changes
without notice.
Trademarks
All trademarks are the properties of their respective owners.
Intel®and Pentium®are registered trademarks of Intel Corporation.
PS/2 and OS®/2 are registered trademarks of International Business Machines
Corporation.
Windows®95/98/2000/NT/ME/XP are registered trademarks of Microsoft
Corporation.
Netware®is a registered trademark of Novell, Inc.
Award®is a registered trademark of Phoenix Technologies Ltd.
AMI®is a registered trademark of American Megatrends Inc.
Revision History
Revision RevisionHistory Date
1.0 First Release Apr.2002
iv
1. Always read the safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Keep this equipment away from humidity.
4. Lay this equipment on a reliable flat surface before setting it up.
5. The openings on the enclosure are for air convection hence protects the
equipmentfrom overheating. DONOT COVERTHEOPENINGS.
6. Make sure the voltage of the power source and adjust properly 110/220V
before connecting the equipment to the power inlet.
7. Place the power cord such a way that people can not step on it. Do not
place anything over the power cord.
8. AlwaysUnplug the PowerCord before inserting anyadd-on card ormodule.
9. All cautions and warnings on the equipment should be noted.
10. Never pour any liquid into the opening that could damage or cause electri-
cal shock.
11. If any of the following situations arises, get the equipment checked by a
service personnel:
zThe power cord or plug is damaged
zLiquid has penetrated into the equipment
zThe equipment has been exposed to moisture
zThe equipment has not work well or you can not get it work according
to User’s Manual.
zThe equipment has dropped and damaged
zIf the equipment has obvious sign of breakage
12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
UNCONDITIONED,STORAGETEMPERATUREABOVE600C(1400F),IT
MAYDAMAGETHEEQUIPMENT.
Safety Instructions
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
v
CONTENTS
Chapter1.GettingStarted ........................................................................ 1-1
Mainboard Specification ......................................................................1-2
Mainboard Layout ...............................................................................1-4
Quick Components Guide ....................................................................1-6
MSI Special Features ...........................................................................1-7
FuzzyLogic™4 .............................................................................1-7
LiveBIOS™/LiveDriver™ ............................................................ 1-8
Live Monitor™ ..............................................................................1-9
D-Bracket™2 (Optional) ............................................................. 1-10
Chapter2.HardwareSetup ....................................................................... 2-1
Central Processing Unit: CPU ..............................................................2-2
CPU Installation Procedures ......................................................... 2-2
Installing the CPU Fan ..................................................................2-3
CPU Core Speed Derivation Procedure .........................................2-4
Memory................................................................................................2-5
Introduction to DDR SDRAM....................................................... 2-5
DIMM Module Combination.........................................................2-6
Installing DIMM Modules ............................................................2-6
Power Supply .......................................................................................2-7
ATX 20-Pin Power Connector: PWR1 ........................................... 2-7
ATX 12V Power Connector: JPW1 ................................................2-7
BackPanel ............................................................................................2-8
Mouse Connector ......................................................................... 2-8
Keyboard Connector .....................................................................2-9
USB Connectors ............................................................................2-9
Serial Port Connectors: COM A & COM B.................................. 2-10
VGADB 15-Pin Connector .......................................................... 2-10
Parallel Port Connector: LPT1...................................................... 2-11
LAN(RJ-45)Jack(845GMax-Lonly)........................................... 2-12
vi
Joystick/Midi Connector ............................................................. 2-12
Audio Port Connectors ............................................................... 2-12
Connectors......................................................................................... 2-13
Floppy Disk Drive Connector: FDD1........................................... 2-13
Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-14
Fan Power Connectors: CPUFAN1/SYS_FAN1/PWR_FAN1...... 2-15
IrDA Infrared Module Header: IR1 .............................................. 2-16
Bluetooth Connector: JBT1 ......................................................... 2-16
Front Panel Connectors: JFP1 & JFP2 ......................................... 2-17
Front Panel Audio Connector: JAUDIO1 .................................... 2-18
Front USB Connectors: JUSB1/2 ................................................. 2-19
CD-InConnector:CD_IN1 .......................................................... 2-21
D-Bracket™2 Connector: JDB1 .................................................. 2-22
Chassis Intrusion Switch Connector: JCASE1 ............................ 2-23
Power Saving Switch Connector: JGS1........................................ 2-23
Jumpers .............................................................................................. 2-24
Clear CMOS Jumper:JBAT1 ........................................................ 2-24
Slots ................................................................................................... 2-25
AGP (Accelerated Graphics Port) Slot......................................... 2-25
PCI Slots ...................................................................................... 2-26
CNR(CommunicationNetwork Riser) Slot .................................. 2-26
PCI Interrupt Request Routing .................................................... 2-27
Chapter3. BIOSSetup.............................................................................. 3-1
Entering Setup......................................................................................3-2
Control Keys ................................................................................. 3-2
Getting Help .................................................................................. 3-3
The Main Menu ................................................................................... 3-4
Standard CMOS Features .................................................................... 3-6
Advanced BIOS Features .................................................................... 3-8
Advanced Chipset Features............................................................... 3-13
vii
Power Management Features............................................................. 3-16
PNP/PCI Configurations..................................................................... 3-20
Integrated Peripherals ........................................................................ 3-23
PC Health Status ................................................................................ 3-26
Frequency/Voltage Control ................................................................ 3-27
Set Supervisor/User Password........................................................... 3-29
Load High Performance/BIOS Setup Defaults.................................... 3-30
Glossary ....................................................................................................G-1
Getting Started
1-1
Chapter 1. Getting Started
TOPICS
Mainboard Specification 1-2
Mainboard Layout 1-4
Quick Components Guide 1-6
MSI Special Features 1-7
Thank you for purchasing 845G Max (MS-6580) series ATX
motherboard. The 845G Max (MS-6580) series is a superior computer
mainboard based on Intel 845G & ICH4 chipsets for optimal system
efficiency. Designed to fit the advanced Intel®Pentium®4 processors in the
478 pin package, the motherboard provides a high performance and profes-
sional desktop platform solution.
There are two models available for 845G Max series mainboards: 845G
Max and 845G Max-L. 845G Max does not support the LAN function while
845G Max-L is implemented with the LAN function and offers an onboard
LAN RJ-45 jack.
1
Getting Started
Chapter 1
1-2
CPU
Supports Socket 478 for Intel®Pentium 4 processor
Supports1.3GHz,1.4GHz, 1.5GHz,1.6GHz,1.7GHz, 1.8GHz, 1.9GHz,2GHz, 2.
1GHz, 2.2GHz, 2.26GHz, 2.4GHz and up
Chipset
Intel® 845G chipset (788 FC-BGA)
- AGP 4x slot (1.5V only)
- Integrated graphic controller
- Supports 100/133MHz FSB
- Supports 400/533MHz Intel NetBurst micro-architecture bus
Intel® ICH4 chipset (421 BGA)
- AC’97 2.2 interface
- 6 USB 2.0/1.1 ports
- 2 channel Ultra ATA/100 Bus Master IDE controller
- SMBus 2.0 support
- Integrated LAN controller
MainMemory
Three 184-pin DDR DIMM sockets
Supports 64 to 512MB technologies for x8 and x16 devices
Slots
One AGP (Accelerated Graphics Port) 4x slot (1.5V only)
Six PCI 2.2 32-bit Master PCI Bus slots (supports 3.3V/5V PCI bus interface)
One CNR (Communication Network Riser) slot
On-BoardIDE
An IDE controller on the ICH4 chipset provides IDE HDD/CD-ROM with
PIO, Bus Master and Ultra DMA 66/100 operation modes.
Can connect up to 4 IDE devices
On-Board Peripherals
On-board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes
- 2 serial ports (COM A + COM B pin header), 1 VGA port
- 1 parallel port supports SPP/EPP/ECP mode
Mainboard Specification
Getting Started
1-3
- 6 USB 2.0/1.1 ports (Rear * 2 / Front * 4)
- 1 Line-In/Line-Out/Mic-In/Game port
- 1 RJ45 connector (optional)
Network (845G Max-L only)
ICH4 Integrated LAN controller
Intel 82562ET
- ACPI and APM supported
- Wake-On-LAN and WFM 2.0 supported
Audio
ICH4 chip integrated
AC’97 2.2 compliant
BIOS
The mainboard BIOS provides “Plug & Play” BIOS which detects the pe-
ripheral devices and expansion cards of the board automatically.
The mainboard provides a Desktop Management Interface (DMI) function
which records your mainboard specifications.
Dimension
ATX Form Factor: 30.5 cm (L) x 21.5 cm (W)
Mounting
6 mounting holes
Others
AC’97 Audio onboard
Vcore/Vio adjustable
STR/STD support
PC2001 compliant
Dieses Handbuch passt für folgende Modelle
2
Inhaltsverzeichnis
Andere MSI Hauptplatine Handbücher
MSI
MSI MS-7338 Bedienungsanleitung
MSI
MSI MS-9641 Bedienungsanleitung
MSI
MSI H170M PRO-VDH Bedienungsanleitung
MSI
MSI 945GM2-FR Bedienungsanleitung
MSI
MSI Z87-G45 GAMING Bedienungsanleitung
MSI
MSI X370 SLI PLUS Bedienungsanleitung
MSI
MSI K8N Neo Platinum Bedienungsanleitung
MSI
MSI 790XT-G45 series Bedienungsanleitung
MSI
MSI MS-7021 Bedienungsanleitung
MSI
MSI Z270 XPOWER GAMING TITANIUM Bedienungsanleitung
MSI
MSI 7C56-002R Bedienungsanleitung
MSI
MSI G52-72221X3 Bedienungsanleitung
MSI
MSI A520M PRO-VDH Bedienungsanleitung
MSI
MSI MPG Z690 CARBON WIFI Bedienungsanleitung
MSI
MSI P35 Platinum Combo series Bedienungsanleitung
MSI
MSI A320M GRENADE Bedienungsanleitung
MSI
MSI GAMING Series Bedienungsanleitung
MSI
MSI MPG Z490 GAMING EDGE WIFI Bedienungsanleitung
MSI
MSI X299 PRO Bedienungsanleitung
MSI
MSI 760GA-P43 FX Bedienungsanleitung
Beliebte Hauptplatine Handbücher anderer Marken
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Bedienungsanleitung
Gigabyte
Gigabyte GA-9IVDT Bedienungsanleitung
Texas Instruments
Texas Instruments ADS8372EVM Bedienungsanleitung
Commell
Commell MS-C73 Bedienungsanleitung
IBT Technologies
IBT Technologies MB860 Bedienungsanleitung
Nvidia
Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung
