MSI KT4M-L Bedienungsanleitung

Version 1.0

G52-M6596X1

KT4M/KT4M-L

MS-6596 (v1.X) M-ATX Mainboard

Manual Rev: 1.0

Release Date: Sept. 2002

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-StarInternational MS-6596

Testedtocomply

withFCCStandard

ForHomeor OfficeUse

iii

CopyrightNotice

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

AMD, Athlon™, Athlon™ XP, Thoroughbred™, and Duron™ are registered

trademarks of AMD Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Windows®95/98/2000/NT/XP are registered trademarks of Microsoft

Corporation.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Revision History

Revision Revision History Date

V1.0 First release Sept. 2002

TechnicalSupport

If a problem arises with your system and no solution can be obtained from the

user’s manual, please contact your place of purchase or local distributor.

Alternatively, please try the following help resources for further guidance.

Visit the MSI website for FAQ, technical guide, BIOS updates, driver

updates, and other information: http://www.msi.com.tw/

Contact our technical staff at: [email protected]

1. Always read the safety instructions carefully.

2. Keep this User’s Manual for future reference.

3. Keep this equipment away from humidity.

4. Lay this equipment on a reliable flat surface before setting it up.

5. The openings on the enclosure are for air convection hence protects the

equipmentfromoverheating. DO NOTCOVER THEOPENINGS.

6. Make sure the voltage of the power source and adjust properly 110/220V

before connecting the equipment to the power inlet.

7. Place the power cord such a way that people can not step on it. Do not

place anything over the power cord.

8. Always UnplugthePower Cord beforeinsertingany add-on cardormodule.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage or cause electri-

cal shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zThe power cord or plug is damaged.

zLiquid has penetrated into the equipment.

zThe equipment has been exposed to moisture.

zThe equipment has not work well or you can not get it work according

to User’s Manual.

zThe equipment has dropped and damaged.

zThe equipment has obvious sign of breakage.

12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

UNCONDITIONED,STORAGETEMPERATUREABOVE600C(1400F),IT

MAYDAMAGETHEEQUIPMENT.

Safety Instructions

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

CONTENTS

FCC-B Radio Frequency Interference Statement ..........................................iii

Revision History ...........................................................................................iii

Technical Support ......................................................................................... iii

Safety Instructions .......................................................................................iv

Chapter1.GettingStarted ........................................................................ 1-1

Mainboard Specifications ....................................................................1-2

Mainboard Layout ...............................................................................1-4

Chapter2.HardwareSetup ....................................................................... 2-1

Quick Components Guide ....................................................................2-2

Central Processing Unit: CPU ..............................................................2-3

CPU Core Speed Derivation Procedure .........................................2-3

CPU Installation Procedures for Socket 462 ..................................2-4

Installing AMD Athlon CPU (Socket 462) Cooler Set ...................2-5

Setting CPU Clock Frequency through Jumper .............................2-6

Memory................................................................................................2-7

Memory Speed/CPU FSB Support Matrix .....................................2-7

DIMM Module Combination......................................................... 2-8

Installing DDR Modules ............................................................... 2-8

Power Supply .......................................................................................2-9

ATX 20-Pin Power Connector: CONN1 .........................................2-9

BackPanel .......................................................................................... 2-10

Mouse Connector ....................................................................... 2-10

Keyboard Connector ................................................................... 2-11

USB Connectors .......................................................................... 2-11

Serial Port Connectors: COM A & COM B.................................. 2-12

RJ-45LANJack (Optional) .......................................................... 2-12

Parallel Port Connector: LPT1...................................................... 2-13

Audio Port Connectors ............................................................... 2-14

Connectors......................................................................................... 2-15

Floppy Disk Drive Connector: FDD1........................................... 2-15

Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-16

Fan Power Connectors: CPUFA1/SYSFA1 .................................. 2-17

CD-InConnector:JCD1 ............................................................... 2-18

Chassis Intrusion Switch Connector: JCI1 .................................. 2-18

Power Saving Switch Connector: JSLP1...................................... 2-19

IrDA Infrared Module Header: JIR1 ............................................ 2-19

Front Panel Connectors: JFP1, JFP2 ............................................ 2-20

Front Panel Audio Connector: JAUD1 ........................................ 2-21

SPDIF Connector: JSP1 (Optional) .............................................. 2-22

S-Bracket Connector: JSB1 (Optional) ......................................... 2-23

Front USB Connector: JUSB1...................................................... 2-24

Jumpers .............................................................................................. 2-25

Clear CMOS Jumper:JBAT1 ........................................................ 2-25

FSBClockJumper:SW1,SW2 .................................................... 2-26

Slots ................................................................................................... 2-27

AGP (Accelerated Graphics Port) Slot......................................... 2-27

PCI (Peripheral Component Interconnect) Slots.......................... 2-27

CNR(CommunicationNetwork Riser) Slot .................................. 2-27

PCI Interrupt Request Routing .................................................... 2-28

Chapter3.BIOS Setup.............................................................................. 3-1

Entering Setup......................................................................................3-2

Control Keys .................................................................................3-2

Getting Help .................................................................................. 3-3

The Main Menu ................................................................................... 3-4

Standard CMOS Features .................................................................... 3-6

Advanced BIOS Features ....................................................................3-8

Advanced Chipset Features............................................................... 3-12

vii

Integrated Peripherals ........................................................................ 3-16

Power Management Features............................................................. 3-21

PNP/PCI Configurations..................................................................... 3-25

PC Health Status ................................................................................ 3-27

Frequency/Voltage Control ................................................................ 3-28

LoadFail-Safe/OptimizedDefaults ..................................................... 3-29

Set Supervisor/User Password........................................................... 3-30

Appendix:Using4-or6-ChannelAudioFunction ....................................A-1

Installing the Audio Driver .................................................................A-2

Installation for Windows 98SE/ME/2000/XP ................................A-2

Using 4- or 6-Channel Audio Function ...............................................A-4

Using the Optional S-Bracket .......................................................A-4

Using the Back Panel only ......................................................... A-10

Testing the Connected Speakers.......................................................A-14

Testing Each Speaker ................................................................. A-14

PlayingKaraOK ................................................................................A-16

PlayingKaraOK..........................................................................A-16

Troubleshooting ........................................................................................ T-1

Glossary ....................................................................................................G-1

1-1

Getting Started

Chapter 1. Getting

Started

Getting Started

Thank you for purchasing the KT4M (MS-6596 v1.X) se-

ries Micro ATX mainboard. The KT4M is based on VIA®Apollo

KT400 & VT8235 chipsets for optimal system efficiency. De-

signed to fit the advanced AMD®Athlon™,Athlon™ XPor

Duron™ processors, the KT4M delivers a high performance

and professional desktop platform solution.

1-2

MS-6596 M-ATX Mainboard

Mainboard Specifications

CPU

hSupports Socket A (Socket-462) for AMD®Athlon™/Athlon™ XP /Duron™

processors.

hSupports up to 2600+ or higher speed.

Chipset

hVIA®KT400 North Bridge

- Supports 200/266/333 MHz front side bus

-Supports DDR333/266/200memory.

- Supports AGP 4X and AGP 8X.

hVIA®VT8235 South Bridge

- Integrated Direct Sound AC97 audio.

- Dual channel Ultra DMA 33/66/100/133 master mode EIDE controller.

- ACPI & PC2001 compliant enhanced power management.

- Integrated USB 2.0 controller.

MainMemory

hSupports four memory banks using two 184-pin DDR DIMMs.

hSupports up to 2GB PC2700/2100/1600 DDR SDRAMs.

hSupports 2.5v DDR SDRAM.

Slots

hOne AGP (Accelerated Graphics Port) slot.

- Supports AGP 3.0 4x/8x.

hThree 32-bit PCI bus slots (support 3.3v/5v PCI bus interface).

hOne CNR (Communication Network Riser) slot.

On-BoardIDE

hAn IDE controller on the VT8235 chipset provides IDE HDD/CD-ROM with

PIO, Bus Master and Ultra DMA133/100/66/33 operation modes.

MSIRemindsYou...

1. To support CPU with 333MHz FSB, the onboard memory mod-

ules have to be DDR333 SDRAMs.

2. Support for DDR400 technology will be available later after

validation of DDR400 specifications.

1-3

Getting Started

hCan connect up to four IDE devices.

On-BoardPeripherals

hOn-Board Peripherals include:

- One floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and

2.88Mbytes

- Two serial ports (COM A + COM B)

- One parallel port supports SPP/EPP/ECP mode

- One RJ-45 LAN port

- Vertical audio ports

- One 3-pin SPDIF connector (Optional)

- One 12-pin S-Bracket connector (Optional)

- Six USB 2.0 ports (Rear * 4/ Front * 2)

Audio

hRealTek ALC650 6-channel audio.

LAN(Optional)

h10/100Mbps Ethernet onboard.

BIOS

hThe mainboard BIOS provides “Plug & Play” BIOS which detects the pe-

ripheral devices and expansion cards of the board automatically.

hThe mainboard provides a Desktop Management Interface (DMI) function

which records your mainboard specifications.

Dimension

hMicro ATX Form Factor: 24.5 cm x 22 cm.

Mounting

h6 mounting holes.

Others

hWake Up from S1/S3 (Power/Sleep Button, PS/2 Keyboard + Mouse, PME,

USBDevice,COM,RTCAlarm,CNR).

hWake Up from S4 (Power/Sleep Button, PME, COM, RTC Alarm, CNR).

hWake Up from S5 (Power Button, PME, COM, RTC Alarm).

hPC2001Compliance.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere MSI Hauptplatine Handbücher

MSI

MSI ATX BX7 Bedienungsanleitung

MSI

MSI MS-6199VA Bedienungsanleitung

MSI

MSI MS-6533E Bedienungsanleitung

MSI

MSI MAG B460 TORPEDO Bedienungsanleitung

MSI

MSI 3200 Master Series Bedienungsanleitung

MSI

MSI 848P NEO-V - Motherboard - ATX Bedienungsanleitung

MSI

MSI MS-6367 Bedienungsanleitung

MSI

MSI B450M MORTAR MAX Bedienungsanleitung

MSI

MSI X99A GAMING 7 Bedienungsanleitung

MSI

MSI P45T-C53 Series Bedienungsanleitung

MSI

MSI A75MA-G55 Series Bedienungsanleitung

MSI

MSI H6Ma-P35 (B3) Bedienungsanleitung

MSI

MSI 865PE Neo2-P Platinum Edition Bedienungsanleitung

MSI

MSI MS-6339 Bedienungsanleitung

MSI

MSI PRO B550-P GEN3 Bedienungsanleitung

MSI

MSI MS-7512 Bedienungsanleitung

MSI

MSI 890FXA-GD70 series Bedienungsanleitung

MSI

MSI A320M PRO-VD/S Bedienungsanleitung

MSI

MSI K8NGM-V Series Bedienungsanleitung

MSI

MSI MPG Z490 GAMING PLUS Bedienungsanleitung

MSI

MSI X99A SLI KRAIT EDITION Bedienungsanleitung

MSI

MSI NF720DT-C43 Series Bedienungsanleitung

MSI

MSI Z77A-G45 GAMING series Bedienungsanleitung

MSI

MSI MAG B660 TOMAHAWK WIFI Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
