Instruction Manual
SETTING TIME, 12/24HR TIME
AND THE SNOOZE DURATION
1. Press SET once, the hour digits flash. Press or to set the current hour
(hold to advance rapidly).
2. Press SET again, the minute digits flash. Press or to set minutes.
3. Press SET again, the display shows “24Hr” and flashes, Press or to select
“12Hr” or “24Hr” time format.
4. Press SET again, the display shows “05” and flashes, Press or to select
your snooze time from 5 to 60 minutes.
5. Press SET again or if no key pressed for approx. 10 seconds to exit the setting
mode.
Note: when 12-hour time format is selected, the P (PM) icon will appear on the
lower middle time display to indicate the afternoon time; there is no AM indicator.
SETTING THE ALARMS
1. Press AL 1.2 once, the A1 icon and the hour digits flash. Press or to set
the alarm 1 hour.
2. Press AL 1.2 again to adjust minutes. Press or to set the alarm 1 minutes.
3. Press AL 1.2 again, LED displays “OFF” (alarm off). To select wake to sound
sources, press or to select :-
rd = wake-by-radio
bu = wake-by-buzzer
OFF = alarm off
4. Press AL 1.2 again, the A2 icon and the hour digits flash. Press or to set
the alarm 2 hour. Repeat step 2) and 3) to set alarm 2.
5. Press AL1.2 again or no button around 10 seconds to exit alarm setting mode.
When wake-to-radio or wake-to-buzzer is selected, the related alarm is turned on,
indicated by apperance of the A1 and / or the A2 icon on the left side of the display.
6. Press AL1.2 again or if no key pressed for approx. 10 seconds to exit the alarm
setting mode.
STOPPING AND RESETTING THE ALARM
TO COME ON THE NEXT DAY
When alarm 1 or 2 is sounding, the related A1 or A2 icon flashes. Press the AL 1.2
once to stop the alarm and reset it to come on the following day. After that A1 or
A2 icon keep lighting up on the display.
Note: When alarm is sounding, press thes / NAP or RADIO / SLEEP will activate
the nap timer or the radio and stop the alarm for the day.
SNOOZE OPERATION (default snooze duration is 5 minutes)
When alarm is sounding, presses once, the alarm will be silenced and
come on again after the set snooze duration.
Note: if your second alarm activates while the first alarm is sounding or it is in the
snooze mode, the second alarm overrides the first alarm (the first alarm is reset to
come on the next day).
USING THE HI-LO DIMMER
Press to adjust the brightness of the LED time display. This can only be
done when the radio is off or the unit is not sounding.
USING THE NAP TIMER
The NAP Timer allows you to rest and automatically wake up in 5, 15, 30, 45, 60,75
or 90 minutes.
1. Press / NAP once, the display shows the nap icon and the default naptime
“05” (5 minutes).
2. Press / NAP again to select your desired naptime. It will exit to time display
if no button pressed for around 5 seconds.
3. The nap icon lights up when the nap timer is counting. When the nap timer
reaches 0, the alarm will sound and the nap icon will flash. Press / NAP
once to stop the nap alarm , the nap icon will go off.
