trigger is disengaged and it is set up from 0 to 9 seconds from 0 to 9 seconds by Volume -
/+ Keys.
*Factory Default : 3 seconds
•CA3 TRIGGER
–Press the SCAN and/or CA.SEL Key, adjust the displaying time of the camera 3 after the
trigger is disengaged and it is set up from 0 to 9 seconds from 0 to 9 seconds by Volume
-/+ Keys.
*Factory Default : 3 seconds
*If the value is set at “0”, the display is promptly changed to the image of the camera
displaying prior to the trigger on after the trigger is disengaged.
4) Camera
•CAMERA 1
–Press the SCAN and/or CA.SEL Key, select the Normal or Mirror Image of Camera 1 by the
Volume -/+ Key.
- NOR : Normal Image (Factory Default)
MIR : Mirror Image
•CAMERA 2
–Press the SCAN and/or CA.SEL Key, select the Normal or Mirror Image of Camera 2 by the
Volume -/+ Key.
–Normal Image (Factory Default)
•CAMERA 3
–Press the SCAN and/or CA.SEL Key, select the Normal or Mirror Image of Camera 3 by the
Volume -/+ Key.
–Normal Image (Factory Default)
•Adjustable Guide Line (Parking Guide Line)
- Locate the cursor at DISTANCE by the SCAN and/or CA.SEL Key.
- Select ON or OFF by the VOLUME -/+ Key.
- ON : Displayed the Adjustable Guide Line (Factory Default)
- OFF : No displayed the Guide Line.
–When the Camera 1 turns “ON”by the Trigger (“R”gear) in the Standby Mode, displays
the Guide Line for the adjustment.
