MUDIX MX-1 Bedienungsanleitung
MUDIX 1080P Video Projector
Model: MX-1
Shenzhen Hifun Technology Co.,Ltd
Address: No.12, Longshan Road, Luotian Community, Yanluo Street, Baoan District,
Shenzhen China
IMPORTANT SAFETY INSTRUCTIONS ....................................................................................02
SAFETY NOTICE........................................................................................................................04
PACKAGE CONTENTS ..............................................................................................................04
PROJECTOR COMPONENTS & FUNCTIONS..........................................................................05
REMOTE CONTROL BUTTONS ................................................................................................06
EQUIPMENT CONNECTION......................................................................................................07
INSTALLATION & ADJUSTING .................................................................................................08
1. Placement. ..........................................................................................................................08
2. Adjust The Focus. ...............................................................................................................08
3. Projection Distance Reference............................................................................................09
4. Power On/Off.......................................................................................................................10
HOME PAGE...............................................................................................................................11
Wi-Fi CONNECTION...................................................................................................................15
WIRELESS MIRRORING............................................................................................................16
1. For IOS device ---- mobile phone .......................................................................................16
2. For IOS device ----MacBook or ipad ...................................................................................16
3. For Android device--- Mobil phone ......................................................................................18
4. For computer device mirror cast..........................................................................................19
PROJECTION SETTINGS...........................................................................................................20
TO PLAY FROM EXTERNAL DEVICES.....................................................................................22
CLEANING..................................................................................................................................23
REPAIR .......................................................................................................................................23
SPECIFICATIONS.......................................................................................................................23
FAQ .............................................................................................................................................24
CONTENTS
- 01 -
Before using this product, please read the user
manual carefully and keep it for future reference.
Scan the QR code for more details.
●Please scan the QR code via phone or visit https://mudix.afterservice.vip to REGISTER and
EXTEND warranty.
●Defective item received or issues with product, please scan the QR code via phone or visit
https://mudix.afterservice.vip to contact our 7/24 after service team.
●Any questions, advice or product issues, please send e-mail to [email protected].
Get 24/7 Assistance at
Use camera or QR scanner to scan
Or visit: https://mudix.afterservice.vip
- 02 -
IMPORTANT SAFETY INSTRUCTIONS
●Please read and understand all instructions before using this device.
●Don't change any settings that are not described in this manual.
●Warranty does not apply if personal injury, data loss, or damage occurs as a result of failure to
follow instructions.
Warnings
●To reduce the risk of fire or electric shock, do not expose the device to rain or moisture.
Objects filled with liquids, such as vases, should not be placed on the device.
●To prevent overheating, do not block or clog the ventilation openings.
●To avoid device damage or fire explosions, the air inlet/outlet/lens should be well ventilated
when the projector is working.
●Never place the device in a confined space. Always leave enough space around the device for
ventilation.
●Keep minimum (19.68 inch) space around the appliance for optimal ventilation.
●Do not place the device in areas susceptible to excessive dust and dirt or near any appliance
generating a strong magnetic field.
●Protect the device against direct sunlight heat, large temperature fluctuations, and moisture.
●When the device runs for a long time and the surface becomes hot, shut it down and unplug
the power cord. Resume operation only after the device has cooled.
●Always handle the device with care. Avoid touching the lens.
●Never place heavy or sharp objects on the device or the power cord.
●To avoid electric shock, do not disassemble the projector by yourself.
●Only use attachments or accessories specified by the manufacturer.
●Avoid extreme vibration. It may damage the internal components.
- 03 -
●Do not put any hazards into the accessories.
●Do not use the projector in the following cases or it may pollute optical elements, reduce
product life, and the projection image will be dark:
- Wet, dusty, smoky places.
- Places where the temperature is above 104°F.
●A layer of moisture will form inside the device to cause a malfunction in the following cases:
- If the device is moved from a cold place to a warm place.
- After a cold room is heated.
- When the device is placed in a damp room, please seal the device in a plastic bag to avoid
moisture.
●To avoid hearing damage, do not listen for extended periods at high volume. Set the volume at
a safe level.
●Do not allow children to handle the device without supervision.
Power Supply
●Power off the device before removing the power supply from the socket.
●Protect the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where they exit from this device.
●Unplug this device if there are lightning storms or when unused for a long time.
●Where the mains plug or an appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable. Before you make or change any connections,
ensure that all devices are disconnected from the power outlet.
●Never touch the power cable or the power connection with wet hands.
- 04 -
SAFETY NOTICE
Do not install in
unventilated places.
Do not install in high
temperature or humid places.
Do not block the ventilation
holes (intake or exhaust)
Do not install in dusty or
smoky places.
PACKAGE CONTENTS
●Projector
●User Manual
●Remote Control
●Power Adapter
●Power Cord
●HD Cable
●Tripod Stand
- 05 -
PROJECTOR COMPONENTS & FUNCTIONS
Buttons and indicators
Lens
IR
USB
Power connector
HD Input
Audio Output
IR
USB
- 06 -
PROJECTOR COMPONENTS & FUNCTIONS
Power on/off
REMOTE CONTROL BUTTONS
Power
HD
OK
Volume -
Mute Volume +
Up Home
Down Return
Focus-
Focus+
Left
Right
Menu
F- F+
F-
F+
- 07 -
EQUIPMENT CONNECTION
Signal flow direction
Notebook/set-top box
HD cable
USB Disk
Audio Earphone
- 08 -
INSTALLATION & ADJUSTING
1Placement
Place projector on a flat, stable foundation squarely in front of the projection surface.
For best results, the projection surface shall be white and flat.
The distance between this projector and the projection surface must be a minimum of 1.2
meters (47 inches).
2Adjust The Focus
USing remote control to adjust the focus of image.
ABCD
Blurry image
F-F+
F- F+
