mundoclima CL23362 Betriebsanleitung
www.mundoclima.com
Thank you very much for purchasing our product.
Before using your unit, please read this manual carefully and keep it for
future reference.
CL23362_CL23369
Español
BLUETOOTH MODULE
Installation & owner's manual
This manual gives detailed description of the precautions
that should be brought to your attention during operation.
In order to ensure correct service of the bluetooth module
please read this manual carefully before using the unit.
For convenience of future reference, keep this manual after
reading it.
CONTENTS
OPERATING INSTRUCTIONS
1
3
4
5
7
8
6
2
PRODUCT FEATURES .......................................... 01
PACKAGE CONTENTS .......................................... 01
SPECIFICATIONS ................................................... 02
PRODUCT STRUCTURE ........................................ 02
DESCRIPTION OF LED INDICATORS ................. 04
CONNECTION OF BLUETOOTH MODULE ........ 09
EXPORT OF FAULT RECORD AND TEST RUN
REPORT ......................................................................10
UPGRADING THROUGH USB FLASH
DRIVE ...........................................................................12
INSTALLATION INSTRUCTIONS
1
3
4
5
6
2
PRECAUTIONS ........................................................ 14
DANGER WARNING ............................................... 16
TOP AIR OUTLET INSTALLATION GUIDE ......... 18
DECLARATION ........................................................ 37
7BLUETOOTH INFORMATION ............................... 37
8PRODUCT PARAMETER .................................. 38
SIDE AIR OUTLET INSTALLATION GUIDE ........ 25
MINI SIDE AIR OUTLET INSTALLATION GUIDE
.....................................................................31
OPERATING INSTRUCTIONS
1 PRODUCT FEATURES
2 PACKAGE CONTENTS
Name OutlineQty.
01
Data
Collection
Program
Upgrading
Fault
Record Saving
Engineering
Parameter
Backup
Bluetooth Module 1
1Manual
1
ST3.9×14 Screw
02
3 SPECIFICATIONS
Name Model Transmission
Mode Dimensions
Bluetooth
Module MA3-BK Bluetooth (237x86x35)mm
4 PRODUCT STRUCTURE
LED indicator
Fig.1
03
LED1~LED6
Debug port
SW1
SW2
Communication port
USB flash drive port
Fig.2
04
LED1 LED2 LED3 LED4 LED5 LED6
Bluetooth
communi
cation
Device
commun
ication
Data
sending
Data
export
Reserved USB flash
drive
connection
Blue Green Red Red Red Red
5 DESCRIPTION OF LED INDICATORS
1) Functions of LED indicators
Bluetooth communication LED indicator: LED1 (blue)
This indicates a connection between the Bluetooth module
and the mobile phone.
Description State of LED Indicator
To be connected. Slow blinking at 0.5Hz (once
every second)
The Bluetooth module is
connected to the mobile phone. Remains on
Not powered on. Off
05
Description State of LED Indicator
● Device communication LED indicator: LED2 (green)
It indicates the communication between the Bluetooth module and
the IDU/ODU.
Failure to communicate with the
connected device (IDU or ODU)
within 60s.
Slow blinking at 0.5Hz (once
every second)
The communication with the
device is normal (but the model
is not identified).
Fast blinking at 2.5Hz
(once every 0.2s)
The communication with the
ODU is normal. Remains on
Not powered on. Off
05
Off
Description State of LED Indicator
The Bluetooth module is
receiving firmware from a USB
flash drive or an app.
Slow blinking at 0.5Hz
(once every second)
● Data sending LED indicator: LED3 (red)
It indicates that the Bluetooth module is in the command & data
sending state.
● The process of sending
firmware to the device.
● The process of rewriting the SN
to the device.
● Press and hold SW1 for 15s.
Fast blinking at 2.5Hz
(once every 0.2s)
Press and hold SW1 for 5s
(within 15s). Remains on
Not powered on and not sending
data.
● Data export LED indicator: LED4 (red)
It indicates that the Bluetooth module is in the data export state.
