Mustek DV316L Bedienungsanleitung
1
I. Getting to know your camera
1. Configuration and installation
1 Display button
2 LED On / Off button
3 Mode button (DV / DSC)
4 Shutter button
5 Up button
6 OK button
7 AV / USB jack
8 Right button
9 MENU button
10 Down button
11 Power button
12 Left button
13 LCD screen
14 Tripod socket
15 SD card slot
16 Wrist strap
17 Battery cover
18 Lens
2
2. On-screen display
A. When shooting movies
B. When shooting still images
T
W
12/1511
EV+ 0 . 0
White balance indicator
Qua lity ind ic ato r
Auto
Da y Lig ht
Tu n g s t e n
Flu o re sc e n t
Cloudy
Super
Fin e
No rm a l
Se lf-tim e r ind ic ato r
10 Sec ond
20 Sec ond
Ba tte ry level ind ic a to
r
Em p t y
Ha lf
Fu l l
Digital zoom bar
Reso lut ion ind ic a to r
2592x1944
2048x1536
1600x1200
1280x960
640x480
Me m o ry c a rd insid e
Capture mode
EV Va l u l e
Ph o t o t a ke n
/
photo capacit
y
Da te st am p
3
C. When playing back
3. Preparation before capture
3.1 Battery
Open the battery cover and load the batteries according to the polarity
indicated inside the battery room.
3.2 Insert the memory card
Insert the memory card to the card slot carefully
with the label facing the battery cover. Check the
right direction before inserting the memory card.
4. Turn on / off the camera
Battery level indicator
Empty
Half
Full
6/20
Playback mode
Video file
Audio file
Still image
Protecting indicator
The sequence of the current file/ The
number of the recorded files
4
a) Open the LCD panel.
b) Press the power button to turn on / off the camera.
5. Shooting
a) Press the power button to enter default capture mode. If the camera is
in other mode, press the mode button till the icon appears on the
upper left corner of the screen.
b) Press the shutter button to take pictures.
6. Video recording
a) Press the mode button till the icon ” “ appears on the upper left
corner of screen.
b) Press the shutter button to start recording.
c) Press the shutter button again to stop recording the video.
When the light is insufficient you can press the LED on / off button to light
the LED.
7. Audio recording
a) Press the mode button to enter Audio record Mode ( ).
5
b) Press the shutter button to start recording.
c) Press the shutter button again to stop recording.
8. Playback mode
8.1 Still image review
a) Press the Mode button till the icon or the information “AVI” or
“WAV” appears on the upper left corner of the screen to enter the
playback mode.
b) Press the left / right button to show previous or next image or
video file.
c) When previewing the still image, press the down button to display the
index screen.
8.2 Play video and audio files
this camera does not have the speaker; the volume is only available when
connecting with TV or PC to playback.
a) Power on and press the mode to playback mode.
b) Press the left / right button to select video file (AVI) or audio
6
file (WAV).
c) Press the shutter button to play video or audio file and press shutter
again to end playing.
d) Press the left / right button to show previous file or next file.
e) Press the ok button to have a pause and then press it again to
continue.
8.3 Delete files
a) In playback mode, press the menu button to enter the menu interface,
press the up / down button to select “delete current” or “delete
all”.
b) Select “Delete Current” to delete the current file. Press the right
button to confirm and exit.
c) Select “Delete All” to delete all the files. Press the right button to
confirm and exit.
.ⅡImage download
Set the USB mode to “mass storage” and then the camera becomes a
removable storage device.
7
a) Connect the camera with a PC by a USB cable
b) Double click the icon “my computer” on the desktop of PC
c) Double click “ ” icon.
d) Double click “DCIM” file folder.
e) Copy all the files to your PC.
Note: Do not take out the SD card or the batteries when you are copying
the files to PC; otherwise the files would be destroyed or lost.
Ⅲ. Specifications & system requirements
1. Specifications
Sensor 3 Mega pixel CMOS
resolution
2592 x 1944, 2048 x 1536, 1600 x 1200,
1280 x 960, 640 x 480
Storage media Internal 32MB Flash, External SD card（8MB to 2GB）
File format JPEG, WAV, MJPEG(AVI)
Capture Single / Burst
Video quality VGA 640x480 ,QVGA 320X240
8
Shutter speed Electronic shutter：1/2 ~ 1/1024 sec
Self timer 10 sec / 20 sec
Zoom 4 x digital zoom
White balance Auto / Daylight / Tungsten / Fluorescent / Cloudy
Exposure -2.0 ~ +2.0
Illumination Auto
PC-camera 640 x 480
interface USB1.1
TV output NTSC / PAL
Screen 1.5” TFT LCD
Power source 3 AAA alkaline batteries
OSD language
English / French / German / Spanish / Italian /
Portuguese / Dutch/Greek
Focal range f=6.4mm
Aperture F=2.8
Auto power off 60sec / 120sec
System WIN98SE / 2000 / ME / XP / Vista
9
Weight 0.14 kg (without batteries and SD card)
Dimension 102 mm x 30 mm x 54 mm
Note: The product design and the specifications are subject to change
without notice.
2. System requirements：
Windows 98SE/2000/ME/XP/Vista
CPU: Pentium III 800MHz or above
Memory：64 MB memory or above
Disk space：Min. 128 MB space available
Note: This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the end of its life
separately from your household waste. There are separate collection
systems for recycling in the EU. For more information, please contact the
local authority or your retailer where you purchased the product.
