REDUNDANT MULTIPLE

AUDIO CLOCK PROCESSOR

VERSION 1.00

SAFETY INSTRUCTIONS

General instructions

To reduce the risk of fire or electrical shock, do not expose this appliance to rain or moisture, direct

sunlight or excessive heat from sources such as radiators or spotlights. No user serviceable parts are in-

side. Repair and maintenance must be carried out by qualified personnel authorized by MUTEC GmbH!

The unit has been designed for operation in a standard domestic environment. Do NOT expose the unit

and its accessories to rain, moisture, direct sunlight or excessive heat produced by such heat sources as

radiators or spotlights! The free flow of air inside and around the unit must always be ensured.

Initial operation

Prior to the initial operation of the unit, the appliance, its accessories and packaging must be

inspected for any signs of physical damage that may have occurred during transit. If the unit has

been damaged mechanically or if liquids have been spilled inside the enclosure, the appliance may

not be connected to the mains or must be disconnected from the mains immediately! If the unit is

damaged, please do NOT return it to MUTEC GmbH, but notify your dealer and the shipping com-

pany immediately, otherwise claims for damage or replacement may not be granted.

If the device is left in a low-temperature environment for a long time and then is moved to a room-

temperature environment, condensation may occur on the inside and the exterior. To avoid short-

circuits and flashovers, be sure to wait one or two hours before putting the device into operation.

Power supply

The device contains a self-adapting wide-range power supply supporting the majority of global stan-

dard line voltages within a range of 90…250 V, with no need for making adjustments. Make sure that

your line-voltage source provides a supply voltage within the specified range. In addition, make sure

that the device is properly grounded via the local electric installation.

Please use the enclosed power cord (see packaging) to connect the unit to the mains. Switch the

unit off before you attempt to connect it to the mains. Connect the power cord to the unit, then

to a standard 3-pin mains outlet. To draw the power cord, never pull on the cable but on the mains

plug!

The unit must be grounded during operation!

For information on the power-inlet wiring, refer to the »Wiring of connectors« section in the

appendix. Disconnect the device from the mains when not using it for an extended period!

This symbol, an exclamation mark inside a triangle,

alerts you to important operating or safety instructions

in this manual.

This symbol, a flash of lightning inside a triangle, alerts

you to the presence of uninsulated dangerous voltage

inside the enclosure - voltage that may be sufficient to

constitute a risk of shock.

Declaration of Conformity

We herewith confirm that the product complies with the European

Commission’s standards on electromagnetic compatibility.

Interference emission: EN 50081-1, 1992

Resistance to interference: EN 50082-1, 1992

Presupposed as operation condition is that all clock outputs are con-

nected with high-quality and good shielded BNC 75 ohms cable.

RISK OF

ELECTRICAL SHOCK!

CAUTION

WARRANTY REGULATIONS

§1 Warranty

MUTEC GmbH warrants the flawless performance of this product to the original buyer for a period of two (2) years from the date of purchase. If any failure occurs within

the specified warranty period that is caused by defects in material and/or workmanship, MUTEC GmbH shall either repair or replace the product free of charge within 90

days. The purchaser is not entitled to claim an inspection of the device free of charge during the warranty period. If the warranty claim proves to be justified, the product

will be returned freight prepaid by MUTEC GmbH within Germany. Outside Germany, the product will be returned with the additional international freight charges payable

by the customer. Warranty claims other than those indicated above are expressly excluded.

§2 Warranty transferability

This warranty is extended exclusively to the original buyer who bought the product from a MUTEC GmbH specialized dealer or distributor, and is not transferable to anyone

who may subsequently purchase this product. No other person (retail dealer, distributor, etc.) shall be entitled to give any warranty promise on behalf of MUTEC GmbH.

§3 Waranty regulations

The return of the completed registration card, or online registration on one of the websites specified below, is a condition of warranty. Failing to register the device before

returning it for repair will void the extended warranty.

The serial number on the returned device must match the one stated on the registration card or entered during online registration. Otherwise, the device will be

returned to the sender at the sender’s expense.

Any returned device must be accompanied by a detailed error description and a copy of the original sales receipt issued by a MUTEC dealer or distributor.

The device must be returned free of shipping expenses and in the original package, if possible; otherwise, the sender has to provide comparably protective packaging.

The sender is fully responsible for any damage or loss of the product when shipping it to MUTEC GmbH.

§4 Limitation of warranty

Damages caused by the following conditions are not covered by this warranty:

Damages caused by every kind of normal wear and tear (e.g. displays, LEDs, potentiometers, faders, switches, buttons, connecting elements, printed labels, cover

glasses, cover prints, and similar parts).

Functional failure of the product caused by improper installation (please observe CMOS components handling instructions!), neglect or misuse of

the product, e.g. failure to operate the unit in compliance with the instructions given in the user or service manuals.

Damage caused by any form of external mechanical impact or modification.

Damage caused by the user’s failure to connect and operate the unit in compliance with local safety regulations.

Damage caused by force majeure (fire, explosion, flood, lightning, war, vandalism, etc.).

Any consequential damages or defects in products from other manufacturers and any arising costs from impairment or loss of productions or any other forms of events.

Repairs carried out by personnel which is not authorized from MUTEC GmbH will void the warranty. Adaptations and modifications to the device made with regard to

national, technical, or safety regulations in a country or of the customer do not constitute a warranty claim and must be set with MUTEC GmbH in advance.

§5 Repairs

To obtain warranty service, the buyer must call or write to MUTEC GmbH before returning the unit. All inquiries must be accompanied by a description of the problem and

the original buyer’s invoice. Devices shipped to MUTEC GmbH for repair without prior notice will be returned to the sender at the sender’s expense. In case of a functional

failure please contact:

MUTEC Gesellschaft fuer Systementwicklung und Komponentenvertrieb mbH

Siekeweg 6/8 • 12309 Berlin • Germany • Fon 030-746880-0 • Fax 030-746880-99 • tecsuppor[email protected] • www.MUTEC-net.de

MUTEC GmbH assumes no liability for any incorrect information given in this manual. Please note that

all software/hardware product names are registered trademarks of their respective owners. No part of

this manual may be reproduced, copied or converted to a machine-readable form or electronical media

without a written permission of MUTEC GmbH. We reserve the right to change or improve our products

without notice. © MUTEC GmbH 2005 – 2007

CONTENT

INTRODUCTION

About this Manual . . . . . . . . . . . . . . . . . . . . . . . 7

General Function Description . . . . . . . . . . . . . . . . . 7

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Extensions . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

CONTROL ELEMENTS

iD Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . 9

iD + iD dp Rear Panels . . . . . . . . . . . . . . . . . . . . . 9

INSTALLATION

Content of the Box . . . . . . . . . . . . . . . . . . . . . . . 11

Placing the Device . . . . . . . . . . . . . . . . . . . . . . . 11

Wiring the Word Clock Interfaces . . . . . . . . . . . . . . . 11

Wiring the AES/EBU and S/PDIF Interfaces . . . . . . . . . . 12

OPERATION

Display Menu Structure . . . . . . . . . . . . . . . . . . . . 13

Selecting Menu Pages and setting Functions . . . . . . . . 14

Main Menu Page . . . . . . . . . . . . . . . . . . . . . . . . 15

Selecting the Mode of Operation . . . . . . . . . . . . . . . 16

Selecting and activating Clock Sources . . . . . . . . . . . 16

Configuring the Word Clock Outputs . . . . . . . . . . . . . 18

Configuring the AES/EBU Outputs . . . . . . . . . . . . . . 19

Configuring the S/PDIF Outputs . . . . . . . . . . . . . . . . 20

Setting System Functions . . . . . . . . . . . . . . . . . . . 21

(Varispeed, LockTime, Input Termination, Display, Reset, etc.)

iD TECHNOLOGY

Functional Principle . . . . . . . . . . . . . . . . . . . . . . . 24

SoftReLock . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Sequence Synchronization . . . . . . . . . . . . . . . . . . . 25

Cycle Synchronization . . . . . . . . . . . . . . . . . . . . . 25

iD EXTENSIONS

iC-ALARM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

APPENDIX

Synchronizable and generatable Clock Rates . . . . . . . . . 27

Pin Assignment of the Connectors . . . . . . . . . . . . . . 28

Connecting the universal Clock Inputs to Ground . . . . . . 29

Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . 30

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>> 88

\BEDIENELEMENTE

BEDIENELEMENTE

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>

Manual SDs-01 D 3.2.2003 17:45 Uhr Seite 3

INTRODUCTION

Thank you very much for purchasing iD or iD dp, Redundant

Multiple Audio Clock Processor, from MUTEC!

About this Manual

The whole manual is related to both versions in general, iD and iD dp.

The individual differences are mentioned in the according sections and

chapters.

The structure of this manual refers to the normal process of installing

id in a standard audio/video studio environment. Thus the chapters are

ergonomically sorted to provide a fast set-up. Before first power-on we

recommend to read the chapters INTRODUCTION and BRIEF INSTRUCTIONS

to get to know the general functionality of id and to reach a fast system

integration.

The following chapters OPERATION and id TECHNOLOGY describe

individual functions which enable the adaption of iD to every studio

environment. The chapters APPLICATION EXAMPLE and APPENDIX include

descriptions of favorable studio set-ups as well as all technical information.

If there are any uncertainties when operating the units which can not be

cleared up by the content of this manual, please feel free to contact your

local dealer or MUTEC directly. All contact details are included in chapter

WARRANTY REGULATIONS located at the beginning of the manual.

General Function Description

Conventional audio clock distributors only distribute and amplify the

incoming reference through different outputs, but the distributed signal

itself will not be further processed. In result, the connected devices

receive jitter-disturbed and unstable clock signals which causes uncertain

synchronization and degraded sound quatlity!

iD works as a clock distributor in an entirely different way. Based on latest

DDS-technology, iD decouples the incoming reference completely to the

output signals. Due to this, the connected devices will receive most stable

and jitter-free clock signals possible at any time – no matter if the incoming

reference consists of high jitter, is instable or partly interrupted. Thus, iD

offers a highly convenient solution to upgrade your studio set-up and

improve your produced sound quality overall!

iD is not only a signal-regenerating distribution amplifier but can also be

used as a master clock reference. In both operation modes iD supports the

industry’s widest range of 36 different audio-related Word Clock rates from

8.0kHz to 24.576MHz. The 3 inputs accept various clock references which

can be distributed through 16 Word Clock (expandable to 20!), 2 AES/EBU

and 2 S/PDIF outputs. Every output pair can transmit a different clock rate

at the same time and a digital varispeed function can be added regardless

of the operation mode. A lot of more special features ensure the use of iD

in every studio environment.

Due to security demands of broadcast houses and professional studios, iD‘s

internal DDS process is designed to supply highest possible failure safety for

all outgoing clock signals in every state of operation. Even in cases of drop

outs or total absence of the reference clock signal, all outgoing signals are

straightforward available without any influences based on the unlimited

freewheel protection mode. Recurring reference signals will be gently re-

synchronized through iD’s efficient SoftRelock functionality without any

phase jumps in the output signals.

The phase relationships of all input and output signals will be observed and

adjusted in real-time automatically, aligned to AES11–1997/2003 und EBU

R83–1996. This process reaches a control accuracy in the nanosecond range.

Boxes which contain a triangle

with an exclamation mark should

be read carefully! These include

additional information which are of major

importance for the functional descriptions in

the text column.

The grey boxes contain supplementary

information for the corresponding sections

in the text columns. The content of the

individual box refers to the description in

the text column beside the box.

Synchronizable references

Word Clock + Word Clock x 256 (so called

Super Clock for ProToolsTM systems)

DSD 64, DSD 128 + DXD

AES/EBU3 + AES/EBU11

AES/EBU3 id + AES/EBU11 id

S/PDIF

Internal reference clock generator

Further references through option cards

or custom designed-programming

Generatable references

Word Clock + Word Clock x 256 (so called

Super Clock for ProToolsTM systems)

DSD64, DSD128 + DXD

AES/EBU11

S/PDIF

Further clock signals through option cards

\\\\\\\\\\\\

INTRODUCTION

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>

Manual SDs-01 E 3.2.2003 18:26 Uhr Seite 5

Features

Works as distributor and generator for Word Clock, Word Clock x 256,

AES/EBU, AES/EBUid and S/PDIF.

Based on iCLOCK’s lowest-jitter DDS technology.

Clock accuracy aligned to AES11, Grade 1.

Entirely jitter elimination and drop out compensation of incoming

reference signals.

Synchronizes and generates 36 Word Clock rates.

Synchronizes and generates all AES/EBU and S/PDIF clock rates up to

192.0kHz.

Synchronizes and generates DSD and DXD clock rates.

Redundant (fail-safe) operation for broadcast use and centralized clock

distribution.

SoftRelock functionality for recurring reference signals.

CYCLESYNC functionality for automatically re-synchronization.

Multiples and divisibles of the reference clock simultaneously available.

Digital varispeed of ± 20%, available during internal and external

synchronization.

Follows external references up to ± 20%.

Intelligent high-precision signal management aligned to AES11-1997

and EBU R83-1996.

Easy and convenient operation through large display with brightness

control.

Software and hardware upgradability and recalibratability.

Applications

Reliable audio clock distribution and generation.

Jitter attenuation in clock signals.

Centralized and redundant audio clock distribution.

Conversion between Word Clock, Word Clock x 256, DSD, DXD, AES/EBU,

AES/EBUid, S/PDIF and optional standards.

Increasing failure safety in clock distribution systems.

Extensions

iDdp

iD basis unit with two redundant power supplies

iD-WCO-4

4 x Word Clock output expansion

iC-ALARM

3-way relais-coupled alarm signal interface

A functional description of all options is

contained in the chapter titled EXTENSIONS.

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>> 88

\BEDIENELEMENTE

BEDIENELEMENTE

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>

Manual SDs-01 D 3.2.2003 17:45 Uhr Seite 3

CONTROL ELEMENTS

iD + iDdp Front Panel

1 DISPLAY

All parameter and function settings are controlled using the display and

the four cursor buttons.

2 + 3 STATUS Indicators

The three blue indicators show the lock status of the currently active clock

source. The five red indicators show important system statuses of iD.

4 CURSOR Buttons

All parameter and function settings are controlled using the four cursor

buttons and the display.

iD Rear Panel

1 + 2 INPUT1, INPUT2

These universal input terminals allow for applying various external clock

signals for synchronizing the internal clock synthesizer. All clock formats

supported by the system can be received at any of these inputs. These two

inputs and INPUT 3 can be synchronized by the synthesizer in a freely confi-

gurable sequence. The impedance of each input is 75 Ω and can be switched

off internally for chaining devices, see the »Switching-off the Termination

of the universal Clock Inputs« section in the APPENDIX.

3 ALARM OUT

The iC-ALARM output is optionally available (item no. 8005-065). Refer to

the EXTENSIONS chapter for a short overview.

4 INPUT3 (AES/EBU)

A balanced digital AES/EBU signal can be applied to this input for synchro-

nizing the internal clock synthesizer. The signal must comply with

AES3 – 1992 (R1997) or AES11 – 1997.

Refer to the OPERATIONS chapter for more

information.

Both input terminals are isolated to ground

to avoid interference from the connected

clock line.

If this does not comply with the electrical

studio purposes, the ground connections of

both inputs could be linked permanently by

setting jumpers on the mainboard. Refer to

the »Connecting the universal Clock Inputs

to Ground« section in the APPENDIX for a

short instruction.

iD and iDdp front panels look equal

iDdp Rear Panel

\\\\\\\\\\\\\

CONTROL ELEMENTS

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>

Manual SDs-01 E 3.2.2003 18:26 Uhr Seite 6

5 WORD CLOCK OUT

These outputs send Word Clock and Word Clock x 256 clock rates. Each of

the output pairs can be assigned with a separate clock rate based on the

incoming or internal generated basis clock rate. Associated output pairs are

arranged on top of each other. The individual BNC terminals of an output

pair are marked as A and B; this allows, for example, for a simple documenta-

tion of the connected devices.

6 AES/EBU OUT

These outputs send a balanced digital AES/EBU audio or blank frame signal

compliant with AES3 – 1992 (R1997) and AES11 – 1997. A couple of channel

status bits can be edited. The individual output terminals are marked as

»A« and »B«; this allows, for example, for a simple documentation of the

connected devices.

7 S/PDIF OUT

These outputs send an unbalanced digital S/PDIF audio or blank frame

signal compliant with IEC 60958. A couple of channel status bits can be

edited. The individual output terminals are marked as A and B; this allows,

for example, for a simple documentation of the connected devices.

8 RS 485

This interface port is provided for programming the iD and updating the

device firmware. A software for remotely controlling the device over LANs

(Local-Area Networks) will be available in future.

9 OPTION

This slot is provided for installing optional iD terminals. Refer to the iD

EXTENSIONS chapter for a short description of extensions available cur-

rently or in the future.

10 MAINS IN 90 – 260V, Power Switch

This is the main switch for switching the device on and off. Be sure to

make all connections (especially the supplied power cable) properly before

turning on the switch. Heed the SAFETY INSTRUCTIONS at the beginning of

this manual.

11 MAINS IN 90 – 260V, Power Inlet

Connect the supplied power cable here. Make sure that the power switch

is turned off before connecting the power cable to this inlet and to the

power outlet. Line voltages within the range of 90…260 V with a frequency

of 50 or 60 Hz can be applied. The internal power supply will automatically

make all necessary adjustments.

12 iCLOCK dp MAINS IN 90 – 260V, Power Inlets

Connect the supplied power cables here. It does not matter which power

inlet is used when only one power cable will be connected. In general ope-

ration two power cables containing mains voltage can be connected simul-

taneously. Line voltages within the range of 90…260 V with a frequency of

50 or 60 Hz can be applied. The internal power supplies will automatically

make all necessary adjustments.

iDdp does not consist of a power switch!

Refer to the »Synchronizable and gene-

ratable Clock Rates« section in the APPENDIX

for a full list of all Word Clock, AES/EBU and

S/PDIF clock rates that can be generated.

For detailed specifications on all terminals,

refer to the »Pin assignment of the

Connectors« and »Technical Data« sections

in the APPENDIX.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Mutec Computerhardware Handbücher

Mutec

Mutec FMC05 Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung

Mutec iD Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken
