Nabco Multi-Module
Multifunction Module
for the Control of
Swing, Slide, and Fold Doors
WARNING
Do not install or service this product unless you have read and understood the Safety Practices,
Warnings, Installation and Operating Instructions contained in this manual.
Failure to do so may result in property damage or bodily injury.
P/N 15-12241
REV 5-7-10
Page 2 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
Interactive Parts Diagrams,
Installation Manuals,
Service Bulletins,
AutoCAD Drawings,
Specifications,
Sales Literature,
Unit Pricing,
Online Ordering,
News Releases,
Promotional Materials,
and much more.
Just log in with your distributor account number
and password to access all of the above or call 1-877-622-2694 for
more information.
Page 3 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
Topic Page Number
Introduction .................................................................................................................................................4
To The Installer .................................................................................................................4
Overview..................................................................................................................................4
Modes of Operation.................................................................................................................4
Specifications .................................................................................................................................................5
Programming instructions ................................................................................................................................6
Mode 1 - Electric Strike Sequence Diagram - Magnum 4 Control ..................................................................7
Mode 1 - Electric Strike Sequence Diagram - Analog Control ........................................................................8
Mode 1 - Bi-directional Door Sequencer Diagram - Magnum 4 Control..........................................................9
Mode 1 - Bi-directional Door Sequencer Diagram - Analog Control .............................................................10
Mode 2 - Apartment or Access Control Diagram - Magnum 4 Control..........................................................11
Mode 2 - Apartment or Access Control Diagram - Analog Control ...............................................................12
Mode 3 - Ratchet or Latching Operation Diagram - Analog Control .............................................................13
Mode 4 - Smoke Evacuation Diagram - Magnum 4 Control..........................................................................14
Mode 4 - Smoke Evacuation Diagram - Analog Control................................................................................15
Mode 5 - Acugard Lock-out Relay Diagram - Magnum 4 Control .................................................................16
Mode 5 - Acugard Lock-out Relay Diagram - Analog Control .......................................................................17
Mode 6 - Washroom Control Relay Diagram - Magnum 4 Control ...............................................................18
Mode 6 - Washroom Control Relay Diagram - Analog Control .....................................................................19
NABCO ENTRANCES Return Policy ............................................................................................................14
Page 4 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
To The Installer
The purpose of this manual is to familiarize the installer with the proper installation and operation of this module.
It is essential that this equipment be properly installed and operational before the door is used by the public. It is
the installer’s responsibility to inspect the operation of the entrance system to be sure it complies with any appli-
cable standards. In the United States, ANSI Standard 156.10 may be applicable for this type of door. Other local
standards or codes may apply.
Overview .
The Multi-Module is a programmable relay module that can be used for many applications. Very user friendly, the
module provides a single mode select push button to select the different modes of operation. (No dip switches)
Modes of Operation
Mode 1 - Electric Strike Sequencer
Typical momentary timed operation. Used for interfacing electric locks with automatic door operators. Refer to
diagram labeled “Mode 1 - Electric Strike Sequence Diagram” on page 7 & 8.
In this mode, the Multi-Module can also be used as a fully functional bi-directional door sequencer, no need to
use a second relay. Refer to diagram labeled “Mode 1 - Bi-directional Door Sequencer Diagram” on page 9 & 10.
Mode 2 - Apartment or access control
Used to interface automatic door operators directly to apartment interphone panels. Isolates interphone panel
voltages from automatic door operator. Also can be used to interface with access control systems that have timed
lock functions Refer to diagram labeled: “Mode 2 - Apartment or Access Control Diagram” on page 11 & 12.
Mode 3 - Ratchet or latching operation
Push button activates strike relay for the timed period then latches operator relay 2 indefinitely, until switch is acti-
vated a second time. Refer to diagram labeled: “Mode 3 - Ratchet or Latching Operation Diagram” on page 13.
Mode 4 - Smoke Evacuation
For wiring a door operator to a fire alarm panel for smoke evacuation purposes. In this mode the strike relay will
energize momentarily, the operator relay will stay energized for as long as the input is maintained. Refer to dia-
gram labeled: “Mode 4 - Smoke Evacuation Diagram” on page 14 & 15.
Mode 5 - Acugard Lock-out relay
Sensor inhibit, inhibiting of a door mounted sensor preventing sensor from acting like a motion sensor.
Sensor only active once push button has been activated Refer to diagram labeled: “Mode 5 - Acugard
Lock-out Relay Diagram” on page 16 & 17.
Mode 6 - Washroom control relay
Single occupant barrier free washroom control. Allows the door to be electronically locked from the inside while
removing the exterior button from the circuit. Door position switch or interior push button resets system. Installer
should recommend that a “store room” function passage set be used. Handle always locked from the exterior,
and free on the interior. Refer to diagram labeled: “Mode 6 - Washroom Control Relay Diagram” on page 18 & 19.
Page 5 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
Size 3 1/4" x 2 1/4" x 3/4"
Mounting Double sided foam tape
Operating voltage 12/24 volts Ac or Dc
Current Draw 18 mA Standby, 40 mA Max.
Inputs
2 - dry contacts
3 - wet inputs
12-24 VAC or DC, optically isolated, non-polarity sensitive
Outputs 2 - form C (SPDT)
Relay contact rating 4 amps @ 30VDC
Time delays
Relay 1 on time - 0.5-30 sec.
Delay on operate Relay 2 - 1-30 sec
Relay 2 on time - 0.5-30 sec.
To protect the Multi-Module from voltage spikes, please use
the provided transient voltage suppressor
P/N 11-12242 Multi-Module Assembly
QTY PART NO. DESCRIPTION
1 14-12240 Multi-Module & Voltage Suppressor
1 15-12241 Multi-Module Installation Manual
1 14-11313 Magnetic Switch Assembly
1 14-6284-03 Plastic Bag
1 14-2243 Label
Page 6 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
RL1 RL2
LEDLED
24V 12V N.O. COM N.C. N.C.COMN.O. WET1
WET
COM COM
DRY
DRY1 DRY2
WET2 WET3
RELAY1 RELAY2
iti-200S
DN 0302
SW 1
MODE
SWITCH
RELAY 2
ON TIME
DOO
(DELAY
ON
OPERATE)
RELAY 2
RELAY 1
ON TIME
Refer to the Figure 1 below:
To enter the program mode, push and hold SW1 Mode Switch for 2 seconds. The mode that is presently
selected will be “flashed”.
Example: if the Multi-Module is in mode 3, the relays will click and the Indicator LEDs will flash 3 times. The user
now has 3 seconds to press the mode select button again to select the next mode. Pressing the button again
within 3 seconds will advance programming to the next mode. This newly selected mode will be flashed by the
relays and LEDs.
Example: the board is in mode 3 and the button is pressed for more than 2 seconds. The LEDs will flash 3 times.
To advance to the next mode the switch is again pressed within 3 seconds. The relays and LEDs flash 4 times
and mode 4 is now selected. Repeat this action until the desired mode is reached. When the desired mode is
reached and the mode select button remains off for 3 seconds the last mode that was “flashed” will be the mode
that is now selected. Power outages will not delete the selected mode.
The installer must ensure that all codes and standards are adhered to. Instruct the owner on door system opera-
tion and how to test it. Doors should be checked on a daily basis to ensure safe operation. Strongly
recommend that system be inspected on a yearly basis by an AAADAM certified technician.
Figure 1 - Multi-Module
SW1 Mode Switch
Indicator LEDs
Potentiometers
Terminal Strip
Page 7 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
MODE 1 - ELECTRIC STRIKE SEQUENCER DIAGRAM - MAGNUM 4 CONTROL
DN 0302
SW 1
MODE
SWITCH
RELAY 2
ON TIME
DOO
(DELAY
ON
OPERATE)
RELAY 2
RELAY 1
ON TIME
Terminal Strip on Magnum Control
BROWN
BLACK
RED
WHITE
VIOLET
ORANGE
1
2
3
4
5
6
RL1 RL2
LEDLED
24V 12V N.O. COM N.C. N.C.COMN.O. WET1
WET
COM COM
DRY
DRY1 DRY2
WET2 WET3
RELAY1 RELAY2
RADIO
RECEIVER
4-TERM
Power
COM
N.O.
STRIKE
ELECTRIC
TVS
Connect Transient
(supplied)
directly to strike.
Voltage Suppressor
Not polarity sensitive.
iti-200S
If magnetic
lock or fail safe
strike used,
connect lock
wires to COM
and N.C.
terminals of
Multi-Module
Note:
1. A black circle indicates
a wire connection.
2. Power supply inputs not
polarity sensitive.
3. Multi-Module must be
set to Mode 1
STRIKE POWER
(To match strike
voltage)
Power
(IF USED)
Normally Open - Dry Contacts
INTERIOR PUSH SWITCH
EXTERIOR KEY SWITCH
Normally Open - Dry Contacts
MULTI MODULE PN 14-12240
Page 8 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
MODE 1 - ELECTRIC STRIKE SEQUENCER DIAGRAM - ANALOG CONTROL
Normally Open - Dry Contacts
EXTERIOR KEY SWITCH
INTERIOR PUSH SWITCH
Normally Open - Dry Contacts
Transformer
P/N 14-2101
24 VAC
24 VAC120 VAC
(IF USED)
Power
STRIKE POWER
(To match strike
voltage)
Note:
1. A black circle indicates
a wire connection.
2. Power supply inputs not
polarity sensitive.
If magnetic
lock or fail safe
strike used,
connect lock
wires to COM
and N.C.
terminals of
Multi-Module
iti-200S
TVS
ELECTRIC
STRIKE
N.O.
COM
Power
4-TERM
RECEIVER
RADIO
RELAY2RELAY1
WET3WET2
DRY2DRY1
DRY
COMCOM
WET
WET1N.O. COM N.C.N.C.COMN.O.
12V24V
LED LED
RL2RL1
RED
BLACK
Activation Connector on Analog Control
RELAY 1
ON TIME
DOO
(DELAY
ON
OPERATE)
RELAY 2
RELAY 2
ON TIME SW 1
MODE
SWITCH
DN 0302
Connect Transient
(supplied)
directly to strike.
Voltage Suppressor
Not polarity sensitive.
Page 9 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
MODE 1 - BI-DIRECTIONAL DOOR SEQUENCER DIAGRAM - MAGNUM 4 CONTROL
NOTE:
1. When the module is triggered
by push switch (DRY1)
Relay # 1 will activate
first, then after an adjustable
delay, Relay # 2 will activate.
When the module is triggered
by the push switch (DRY2)
Relay # 2 will activate
first, then after an adjustable
delay, Relay # 1 will activate.
2. A black circle indicates a
wire connection.
3. Power supply inputs not
polarity sensitive.
Normally Open - Dry Contacts
OPTIONAL VESTIBULE PUSH SWITCH
BROWN
BLACK
RED
WHITE
VIOLET
ORANGE
Normally Open - Dry Contacts
EXTERIOR PUSH SWITCH
INTERIOR PUSH SWITCH
Normally Open - Dry Contacts
6
5
4
3
2
1
ORANGE
VIOLET
WHITE
RED
BLACK
BROWN
DN 0302
SW 1
MODE
SWITCH
RELAY 2
ON TIME
DOO
(DELAY
ON
OPERATE)
RELAY 2
RELAY 1
ON TIME
RL1 RL2
LEDLED
24V 12V N.O. COM N.C. N.C.COMN.O. WET1
WET
COM COM
DRY
DRY1 DRY2
WET2 WET3
RELAY1 RELAY2
iti-200S
Terminal Strip on
Interior Magnum
Control
Terminal Strip on
Exterior Magnum
Control
Page 10 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
MODE 1 - BI-DIRECTIONAL DOOR SEQUENCER DIAGRAM - ANALOG CONTROL
iti-200S
RELAY2RELAY1
WET3WET2
DRY2DRY1
DRY
COMCOM
WET
WET1N.O. COM N.C.N.C.COMN.O.
12V24V
LED LED
RL2RL1
RELAY 1
ON TIME
DOO
(DELAY
ON
OPERATE)
RELAY 2
RELAY 2
ON TIME SW 1
MODE
SWITCH
DN 0302
Normally Open - Dry Contacts
INTERIOR PUSH SWITCH
EXTERIOR PUSH SWITCH
Normally Open - Dry Contacts
OPTIONAL VESTIBULE PUSH SWITCH
Normally Open - Dry Contacts
NOTE:
1. When the module is triggered
by push switch (DRY1)
Relay # 1 will activate
first, then after an adjustable
delay, Relay # 2 will activate.
When the module is triggered
by the push switch (DRY2)
Relay # 2 will activate
first, then after an adjustable
delay, Relay # 1 will activate.
2. A black circle indicates a
wire connection.
3. Power supply inputs not
polarity sensitive.
BLACK
RED
RED
BLACK
Activation Connector
on Exterior Analog
Control
Activation Connector
on Interior Analog
Control
Transformer
P/N 14-2101
24 VAC
24 VAC120 VAC
Inhaltsverzeichnis
Andere Nabco Steuereinheit Handbücher
Beliebte Steuereinheit Handbücher anderer Marken
Festo
Festo Compact Performance CP-FB6-E Stücklistenhandbuch
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung
JS Automation
JS Automation MPC3034A Bedienungsanleitung
JAUDT
JAUDT SW GII 6406 Series Kurzanleitung
Spektrum
Spektrum Air Module System Bedienungsanleitung
BOC Edwards
BOC Edwards Q Series Bedienungsanleitung
