NakiRadio Solo Bedienungsanleitung
Instruction Manual
NakiRadio
®
Solo
MN300
NakiRadio
®
Duo
MN350
Table of Contents
Introduction
1 Quick Setup – Start Here!
1.1 Safety
1.2 Features
1.3 Carton contents
1.4 External resources
2 Controls, connectors and display
2.1 Main controls
2.2 Connectors
2.4 Screens
2.5 Operation
2.6 Menu Navigation
3 Startup and setup
3.1 Setup wizard
3.2 Other settings
4 Internet radio mode
4.1 Presets
4.2 Now playing information
5 Alarms and sleep
5.1 Alarms
5.2 Sleep
6 Software upgrade and factory reset
6.1 Software upgrade
6.2 Factory reset
7 Troubleshooting and error messages
7.1 Error messages
7.2 Troubleshooting
Introduction
Thank you for purchasing a NakiRadio. The
NakiRadio will provide you and your family with
hours of education and entertainment from
approved radio stations throughout the world. We
understand that in today’s media driven
environment, families need to filter and choose
the proper media they wish to be exposed to.
NakiRadio hopes that with Siyata D’shmaya we
can help you and your family limit your exposure
to inappropriate media and enjoy the rich world
radio has to offer to the discerning listener.
For more options and choices of content available
to hear on NakiRadio, be sure to visit the Portal at
nakiradio.com. Once you create an account and
connect it to your NakiRadio, you can add/remove
content, use parental controls to limit usage, and
more.
For more information, and for technical support,
please email support@nakiradio.com.
1. NakiRadio Quick Setup
Unbox, Wizard Setup & Listen
YOU MUST HAVE A WIFI NETWORK WITH INTERNET
ACCESS FOR THE NAKIRADIO TO ACCESS CONTENT
Unbox your NakiRadio within range of a WiFi
Network
Plug included power adapter into a 110/220v
power source.
Press Power / Volume dial on the left side of
the unit to start the Setup Wizard, which will
display on the screen. Click through the
following settings and set to your choice:
Select a time format. Click Select dial on the
unit’s right side to accept.
Update from Network. Click Select dial to
accept.
Scroll through Set Timezone. Locate timezone
of your location. Click Select dial to accept.
Select setting for Daylight Savings. Click
Select Dial to accept.
WLAN Region USA. Click Select dial to
accept.
Locate & Select the WiFi SSID/network of your
choice, click Select dial to accept.
If WPS Menu appears, recommended choice
is Skip WPS
Enter your WiFi password/key by scrolling and
clicking on the Select dial.
Uppercase/lowercase letters, numbers and
symbols are located by scrolling your with the
Select dial. Press the INFO keypad button at
any time to BKSP [correct], cancel or accept
your entry. Click Select Dial to accept. If
successful, Setup Wizard will display a
completed message. Click Select Dial to exit
Wizard.
Highlight Station List and click the Select dial.
Rotate the Seelct dial to highlight the station of
your choice, and click Select dial to select
listening.
Press and hold down Power dial for 2 seconds
to place the device in Standby Mode. If device
is connected to power supply, clock will
display.
1.1. Safety
Safety Instructions
Please store this instruction manual for future reference.
• WARNING: To reduce the risk of fire or electric shock, do not
expose this device to rain or moisture. The apparatus should not be
exposed to dripping or splashing. Objects filled with liquids, such as
vases, should not be placed on device.
• WARNING: The direct plug-in adapter is used to disconnect device
from power source, please assure the wall adapter remains
accessible at all times.
• The symbol is intended to alert the user to the presence of
non-insulated dangerous voltage within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of electric shock.
• Warning: To reduce the risk of electric shock, do not remove cover
(or back), as there are no user-serviceable parts inside. Refer
servicing to qualified personnel.
• The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance instructions in the literature accompanying the
appliance.
• Correct disposal of this product: This marking indicates that
this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources.
To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased.
They can take this product for environmentally safe recycling.
• No open flames, such as lighted candles, should be placed on the
apparatus.
• CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• WARNING: The battery (battery or batteries or battery pack) should
not be exposed to excessive heat such as sunshine, fire or the like.
• Do not use this product near water or moisture.
• Clean only with a dry cloth.
• Unplug this product from the wall outlet before cleaning.
• Place the unit on a solid surface.
• Do not put it in a closed bookcase or a cabinet that may keep air from
flowing through its ventilation openings.
• Do not install near any heat sources, such as radiators, heat registers,
stoves or other appliances that produce heat.
• Protect the power cord from being walked on or pinched, particularly
at plugs and at the point where it exits from the product.
• Servicing is required when the product has been damaged. Do not
attempt to service this product yourself. Opening or removing covers
may expose you to dangerous voltages or other hazards.
• To prevent risk of fire or electric shock, avoid overloading wall outlets,
extension cords.
• Do not let objects or liquids enter the product.
• Use proper power sources. Plug the product into a proper power
source as described in the operating instructions or as marked on the
product.
FCC Warning
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation. Any
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment. This equipment has
been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
-Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician
for help.
1.2 Features
This manual describes how to use the NakiRadio Solo / Duo, an
advanced but easy-to-use Wi-Fi connected audio system with the
following modes:
• Internet Radio plays pre-approved radio stations from
around the world.
• Bluetooth
®
-In for external music sources, such as from
iPod/iPad or other media players.
NakiRadio Solo / Duo also provides the following features:
• TFT color display for easy control and clear information
display.
• Clock with auto-update capability and dual independent
alarms with Sleep/Snooze.
• Multiple network profiles for easy setup and portability.
• Multiple language options.
1.3 Carton contents
After you unpack the box, you will find the following items:
• 1 NakiRadio Solo or Duo unit
• 1 Micro-USB power adaptor
• 1 Owner’s Instruction Manual
