Using Your

XP-600

Security System

NAPCO

Introduction

Congratulations on your purchase of an advanced NAPCO EXPRESS XP-600 Security System. Meticulously developed by

a leading manufacturer of state-of-the-art security products, this system will provide you with unprecedented peace-of-mind and

incorporates some of the most sophisticated features available today. Above all, it has been designed with an extra step, to pro-

vide all those operating it with very easy, intuitive use. Please review the information contained in this manual, so that you and

all potential users of the system familiarize yourselves with its operation, and can therefore take full advantage of EXPRESS’

many convenience features and amenities.

Your system consists of a control panel (a computer housed within a white metal panel enclosure), one or more EXPRESS

Decorator Keypads for controlling the system, and various security detection devices. These detection devices are divided

among separate areas known as “zones”, set up throughout your premises. Each zone number corresponds to a zone light on

your Keypad’s black display area.

When a zone’s red light is ON (or lit), it indicates that one or more detection device(s) assigned to that area are active or open.

For example, if zone 1 is the front door, and it is open, the zone 1 light will be on. If zone 2 is a motion detector, and there is

movement in that area, zone light 2 will turn ON. Depending upon the actual layout your security professional has chosen to

properly protect your premises, each zone may function a little differently: The zone protecting your front door may be pro-

grammed as an Exit/Entry zone to allow you time to enter the premises and disarm the system, without inadvertently sounding

the alarm. Alternatively, a zone protecting a window could be designated as an “instant” zone, so that if it is entered or opened

while the system is on/armed, there will be an immediate alarm.

Your easy NAPCO EXPRESS Keypad puts super-simple system control at your fingertips. Most keypad commands

involve entering your four digit User Code. This includes Arming (or activating) and Disarming (or deactivating) the system. Sim-

ply put, ARMED means the system is ON; DISARMED means the system is OFF. If the system is OFF and you want to turn it

ON, just enter your Code. To turn the system back OFF, enter your code again. It’s easy, just always remember, in the event

of an alarm, entering your User Code will silence all Sirens. Your keypad is your command and status center, it keeps you

informed visibly, using its zone and status lights (in the gray display area) and audibly, using its built-in keypad sounder.

For more information, please see Keypad Controls and Indicators on page 4.

Introduction

SYSTEM INFORMATION

Central Station Phone Number: ____________________

Central Station Account Number: ____________________

For Service Call: ____________________

Entry Delay: ____________________

Exit Delay: ____________________

Alarm Time-out: ____________________

TABLE OF CONTENTS

Keypad Controls and Indicators ........................................ 4

Arming your System (When Leaving)................................ 5

Protecting Yourself While Home........................................ 6

Emergency Keys ............................................................... 7

Disarming the System ....................................................... 8

Silencing an Alarm............................................................. 8

Resetting a Fire Alarm....................................................... 8

Fire Protection ................................................................... 9

Special Functions ............................................................ 11

System Troubles.............................................................. 12

Programming User Codes ............................................... 14

Glossary .......................................................................... 15

1 Bell / Battery Test

Test your bell or siren by pressing Gfollowed by 1.

This will cause the bell, or siren to sound for 2 seconds

and also initiate a test of the battery.

2Central Station Communication Test

(This test should only be performed on weekends or at a

time designated by your alarm company)

1. Notify Central Station of the impending test.

2. Secure all zones to light the WLight on your keypad.

3. Enter your user code to Arm the system.

4. Violate your alarm by opening a window / door etc.

5. The siren or bell should sound and the system will send

the alarm signals to the Central Station.

6. Enter your user code to silence the bell or sounder.

7. Call Central Station to insure that the alarm signals were

received properly.

Important - Test Your System Weekly !

Keypad Controls and Indicators

*Key Used to enable

special functions and

options. Press *and

then the corresponding

Special Function num-

ber Option (See Special

Functions, Page 11)

Bypass Key Used to

bypass zones. Press

Bypass and the corre-

sponding zone number,

and then Arm system.

Numerical Keys 1-9, 0. Used to enter

User Codes, Zone numbers, etc.

Key Press to display any present

System troubles. Only available when

System Light is lit.

(See System Troubles, Page 12)

Armed Light will light when system is Armed,

and will flash when system is in Alarm.

Zone Lights (1 through 6) will light to indicate

that the corresponding Zone is open, and will

flash to indicate a zone in alarm.

Ready Light will light when all zones are se-

cure and system is ready to be Armed.

#Key - (Reset) used to clear miss-entered

codes, reset Alarm Memory, etc..

System Light will light and the Keypad

sounder will pulse to indicate that a system trou-

ble is present. (See System troubles, Page 12)

Fire Light will light and the Keypad sounder

will pulse to indicate that a fire has been de-

tected in the system.

Power Failure will light and the Keypad

sounder will pulse to indicate the absence of AC

power at the control panel. Call for service.

Emergency Keys Press

simultaneously to signal

an emergency condition.

Press F+Ffor Fire

Emergency, press

A+Afor Auxiliary

Emergency or P+P

for Police Emergency.

(Programmable)

Arming Your System When Leaving

1 Before arming your system, make sure the Green XReady light is ON. This indicates that all of your

protective zones are secure. If any zones are open, the corresponding Zone light will be ON. Secure

these zones before proceeding. If any zones cannot be secured, see Bypassing Zones below.

2 Enter your user code. The Green XReady light will go out, the Red WArmed light will light.

xIf you make a mistake entering your code, press Band re-enter the code.

xIf the FIRE light is on, the Fire zone has not been properly reset. Press Band enter the code.

(See Silencing a Fire Alarm, page 8)

3 Leave the premises through the Exit/Entry door. If the keypad gives a steady tone you have taken too

long. Enter your code again to disarm system and then re-enter code and leave.

Easy Arm

The Easy Arm feature allows the system to be armed by simply pressing Afollowed by 0.

This will allow the easy arming of the system by someone who is not a regular system user.

Bypassing Zones

If an open zone cannot be immediately fixed it can be left unprotected, or Bypassed, while the rest of the

system is Armed. To Bypass a zone:

1 Press Cfollowed by the zone number to be Bypassed. The Bypassed Zone’s light will flash slowly.

2 Enter your user code. The Green XReady light will go out and the Red WArmed light will light.

3 Leave the premises through the Exit/Entry door.

When the system is subsequently disarmed, all bypassed zones will be reset, ready to be armed again.

If it is necessary to bypass any inoperative zone(s), it is important to have the zone(s) repaired as soon as

possible. A bypassed zone does not provide any protection, compromising system security.

Arming Your System

Protecting Yourself While at Home

1 Before arming your system, make sure the Green XReady light is ON. This indicates that all of your

protective zones are secure. If any zones are open, the corresponding Zone light will be ON. Secure

those zones before proceeding.

2 Enter your user code. The Green XReady light will go out, and the Red WArmed light will light.

3 Before your exit delay expires, press Cto bypass any interior zones, deactivating devices such as motion

sensors (allowing free movement within the premises). The Zone light of any bypassed zones will flash slowly.

xYour system may have been programmed for Automatic Interior Bypass, in which case it will recognize

that you have not left the premises and will automatically bypass any interior zones.

Instant Mode

Pressing Afollowed by 4will cancel the Entry delay, activating the “Instant” mode. This is typically

done in the evening when all family members are home for the night. Instant Mode can be activated at any

time after the system has been armed. The Red WArmed light will flash rapidly while in the Instant Mode.

Easy Exit (optional)

Your System may have been programmed to allow Easy Exit, which allows a user to exit the premises with

the system armed. By pressing Bfollowed by 0, the protection is removed from the Exit/ Entry zone

for 3 minutes. This will allow, for example, an early morning commuter to exit the house in the morning,

without having to disarm and rearm the system, waking the family.

Arming With a System Trouble Present (the HSystem Light is Lit)

If the XP600 has a system trouble present, the HSYSTEM light will be lit and the keypad sounder pulsing.

If you cannot immediately clear the system trouble, the system can still be armed. Simply press Dto

view the trouble, press Dagain to reset the trouble and then arm the system.

For more information, refer to page 12. Note: System troubles should be repaired as soon as possible.

Arming Your System

Emergency Buttons

The three sets of emergency buttons, if programmed, are always active whether the system is armed

or disarmed. Discuss these Buttons with your installer. The emergency signal will only be activated

when the two respective buttons are pressed at the same time.

Fire Alarm: Simultaneously press E+Eto sound a fire alarm, and to alert the central station of a

fire emergency, if so programmed.

Auxiliary Alarm: Simultaneously press F+Fto alert the central station of an auxiliary emergency,

if so programmed. (The nature of this emergency alarm is to be determined by the installer)

Police Emergency: Simultaneously press G+Gto sound a police emergency alarm, and to alert

the central station of a fire emergency, if so programmed.

Emergency Conditions

E F G

EFire

eEmergency

Enabled?

Yes

FAuxiliary

FEmergency

Enabled?

Yes

Ambush Alarm

In the event that you are forced by an intruder to disarm your system, the "ambush alarm" can be acti-

vated. Disarming the system with the Ambush Code will cause the system to appear to disarm nor-

mally--however, a silent ambush alarm signal will be sent to the Central Station. If your system has

the Ambush feature enabled, the code assigned as the User 6 code will function as your Ambush

Code.

GPolice

GEmergency

Enabled?

Yes

Ambush

Alarm

Enabled?

Yes

Disarming Your System when Returning

1 Enter your premises through the Entry/Exit door. The keypad will sound a steady tone to remind you to dis-

arm the system before your Entry Delay time expires.

2 Enter your user code. The Red WArmed light will go out, indicating that the system has been disarmed.

Note: If you make a mistake entering your code, press the Bkey and re-enter the code.

Alarm Indication

If the Red WArmed light is flashing rapidly, an alarm occurred while you were away. Proceed with caution!

For your own protection, leave immediately and call authorities from a neighbor’s phone .

Silencing an Alarm

In the event that the system goes into alarm due to a violated burglary zone, the bell or siren will sound and the

keypad sounder will also activate. To silence the system, enter your User code. The zone light of the zone

which went into alarm will continue to flash until Bis pressed to reset the alarm memory.

Silencing a Fire Alarm

In the event that the Fire alarm activates due to an violated smoke or fire detector, the bell or siren will sound a

distinct pulsating tone. The Red IFIRE light on the keypad will be flashing, and the keypad sounder will emit

a pulsing tone. If a Fire Alarm does occur:

1 If a fire is in progress, evacuate the premises immediately! Call the Fire Department from an outside phone.

2 If there is no evidence of a fire, enter your User Code. The bell or siren will silence, and the IFIRE light on

the keypad will stop flashing but will still be lit.

3 Determine which device went into alarm. If you are protected by smoke detectors, the light on the active

detector will be lit. Once it is determined which smoke detector is in alarm, press Bto reset the fire zone.

4 If the Fire zone has reset properly, the FIRE light on the keypad should go out in approx. 30 seconds If it

does not go out, press Bagain in a few minutes. If the FIRE light still does not go out, call for service.

Disarming Your System / Silencing an Alarm

Preparing a Fire Escape Plan

Even with the most advanced fire alarm system, adequate protection requires an escape plan. To prepare your plan,

draw floor plans of your building (space is provided on the next page). Show two exits - a front or back door and a win-

dow from each room. (Make sure each window opens. You may need a special fire-escape ladder if the window is high

up). Write down your outside meeting place.

Family Rehearsal

Rehearse each of the following activities:

1 Everyone in his room with the doors closed.

2 One person sounds the alarm.

3 Each person tests his door.

4 Pretend that the door is hot and use the alternate escape exit.

5 Everyone meets outdoors at the assigned spot.

Important! - Read Carefully

Discuss each of these escape procedures with all those who

use the building.

1 In a residence, sleep with the bedroom door closed.

2 When the fire alarm signals, escape quickly. Do not stop to pack.

3 Test the door. If it is hot, use your alternate route through the window.

If the door is cool, brace your shoulder against it and open it cautiously. Be ready to slam the door if smoke or heat

rushes in. Crawl through the smoke, holding your breath. Close the doors again on leaving to help prevent the fire

from spreading.

4 Go to your specific outdoor meeting place so you can see that everyone is safe.

5 Call the Fire Department from a neighbor’s telephone.

Fire Protection

Would You Like More Safety Information?

For more information on home fire detection,

burn safety, and home fire safety, write to:

National Fire Protection Association,

Public Affairs Dept. 05A,

Batterymarch Plaza,

Quincy, MA 02269

Fire Protection

Floor Plan

Draw a plan of your premises below.

Andere Handbücher für EXPRESS XP-600

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere NAPCO Sicherheitssystem Handbücher

NAPCO

NAPCO FREEDOM F-64TP Bedienungsanleitung

NAPCO

NAPCO FREEDOM - Bedienungsanleitung

NAPCO

NAPCO EXPRESS XP-600 Installationshandbuch

NAPCO

NAPCO MAGNUM ALERT 1008e Bedienungsanleitung

NAPCO

NAPCO EXPRESS XP-600 Bedienungsanleitung

NAPCO

NAPCO XP-400 Datenblatt

NAPCO

NAPCO MAGNUM ALERT-725 Bedienungsanleitung

NAPCO

NAPCO MAGNUM ALERT 3000 FIRE ALARM Bedienungsanleitung

NAPCO

NAPCO Freedom F-64 Bedienungsanleitung

NAPCO

NAPCO Magnum Alert-700 Bedienungsanleitung

NAPCO

NAPCO Magnum Alert-700 Bedienungsanleitung

NAPCO

NAPCO XP-400 Installationshandbuch

NAPCO

NAPCO MAGNUM ALERT-850 Bedienungsanleitung

NAPCO

NAPCO XP-600 - 9-16-1997 Bedienungsanleitung

NAPCO

NAPCO MAGNUM ALERT 900 SYSTEM Bedienungsanleitung

NAPCO

NAPCO FREEDOM - Bedienungsanleitung

NAPCO

NAPCO Gemini GEM-X255 Bedienungsanleitung

NAPCO

NAPCO PRO410 Bedienungsanleitung

NAPCO

NAPCO F-TPBR Bedienungsanleitung

NAPCO

NAPCO Magnum Alert 800 Bedienungsanleitung

NAPCO

NAPCO Magnum Alert-854 Bedienungsanleitung

NAPCO

NAPCO MVA-1000 Bedienungsanleitung

NAPCO

NAPCO MAGNUM ALERT 850 SYSTEM Bedienungsanleitung

NAPCO

NAPCO FREEDOM - Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
