INSTALLATION GUIDE

TBX-96 TERMINAL BLOCK

This guide describes how to install and use the TBX-96 terminal block with

the SCXI-1100, SCXI-1102B/C, SCXI-1104/C, and SCXI-1581 modules.

The TBX-96 is a shielded, DIN-rail mountable terminal block with

96 screw terminals for easy connection to the SCXI-1100, SCXI-1102B/C,

SCXI-1104/C, and SCXI-1581 front connector. The TBX-96 mounts on

most European standard DIN EN mounting rails.

What You Need to Get Started

To set up and use the TBX-96, you need the following:

❑TBX-96 terminal block

❑TBX-96 Terminal Block Installation Guide

❑SCXI chassis and its documentation

❑One of the following modules and its documentation

– SCXI-1100

– SCXI-1102B/C

– SCXI-1104/C

– SCXI-1581

❑SH96-96 shielded cable or R96-96 ribbon cable assembly that includes

the TBX cable adapter

❑Wire strippers

❑Combination flathead/Phillips screwdriver (included in kit)

TBX-96 Terminal Block 2 ni.com

Conventions

The following conventions are used in this guide

This icon denotes a note, which alerts you to important information.

This icon denotes a caution, which advises you of precautions to take to

avoid injury, data loss, or a system crash.

bold Bold text denotes items that you must select or click on in the software,

such as menu items and dialog box options. Bold text also denotes

parameter names.

italic Italic text denotes variables, emphasis, a cross reference, or an introduction

to a key concept. This font also denotes text that is a placeholder for a word

or value that you must supply.

monospace Text in this font denotes text or characters that you should enter from the

keyboard, sections of code, programming examples, and syntax examples.

This font is also used for the proper names of disk drives, paths, directories,

programs, subprograms, subroutines, device names, functions, operations,

variables, filenames and extensions, and code excerpts.

Safety Information

Cautions Do not operate the terminal block in an explosive atmosphere or where there

may be flammable gases or fumes.

Do not operate damaged equipment. The safety protection features built into this terminal

block can become impaired if the device becomes damaged in any way. If the terminal

block is damaged, turn the terminal block off and do not use it until service-trained

personnel can check its safety. If necessary, return the terminal block to National

Instruments for service and repair to ensure that its safety is not compromised.

Do not operate this equipment in a manner that contradicts the information specified in this

document. Misuse of this equipment could result in a shock hazard.

Do not substitute parts or modify equipment. Because of the danger of introducing

additional hazards, do not install unauthorized parts or modify the device. Return the

device to National Instruments for service and repair to ensure that its safety features are

not compromised.

Yo u must insulate all of your signal connections to the highest voltage with which the

TBX-96 can come in contact.

©National Instruments Corporation 3 TBX-96 Terminal Block

Connections, including power signals to ground and vice versa, that exceed any of the

maximum signal ratings on the TBX terminal block can create a shock or fire hazard, or

can damage any or all of the boards connected to the SCXI chassis, the host computer, and

the TBX terminal block. National Instruments is not liable for any injuries or damage

resulting from incorrect signal connections.

Clean the TBX-96 by brushing off light dust with a soft non-metallic brush. Remove other

contaminants with a stiff non-metallic brush. The unit must be completely dry and free

from contaminants before returning it to service.

Connecting the Signals

Note Refer to the Safety Information section before removing equipment covers or

connecting or disconnecting any signal wires.

Figure 1 shows the layout of the TBX-96 terminal block circuit board.

To connect a signal to the terminal block, perform the following steps while

referring to Figure 1:

1. Prepare your signal wire by stripping the insulation no more

than 7 mm.

2. Connect the signal wires to the screw terminals by inserting the

stripped end of the wire fully into the terminals. Refer to your SCXI

module user manual for examples of how to connect to field signals

and loads.

3. Tighten the terminals to a torque of 5-7 in.-lb (56-79 N-cm).

The signal connection is now complete.

TBX-96 Terminal Block 4 ni.com

Figure 1. TBX-96 Parts Locator Diagram

Installing the Cable and Terminal Block

Perform the following steps to mount the SH96-96 or R96-96 cable

assembly and to connect the TBX-96 to your SCXI module. Refer to

Figures 2 through 4 as needed.

1. Turn off your SCXI chassis.

2. Turn off the computer that contains your data acquisition (DAQ)

device or disconnect the DAQ device from your SCXI chassis.

3. Connect the TBX cable adapter to the appropriate SCXI module and

secure it by tightening both thumb screws.

4. If you are using an SH96-96, verify that the two backshell mounting

ears on each end of the cable assembly are in the position shown in

Figure 2 and 3. If the backshell mounting ears are not in the position

shown, remove the backshell mounting ears and install them in the

position shown. If you are using an R96-96, the mounting screws are

built into the backshell.

1 96-Pin Male DIN Connector 2 Screw Terminals

TBX-96

A32

C32

S/N

1 2 3 4 5 6 7 8 9 10111213141516171819 2021222324 2526272829303132

AJ1 J2 J3 J4 J5 J6 J7 J8 J9 J10 J11

P1 ASSY183280 01

©National Instruments Corporation 5 TBX-96 Terminal Block

Figure 2. Connecting the SH96-96 or R96-96 Cable to the SCXI Module

1 R96-96 Cable Assembly

2 SH96-96 Cable Assembly

3 Backshell Mounting Screws and Ears

4 TBX Cable Adapter

5 Thumb Screws

6 SCXI Chassis

TBX-96 Terminal Block 6 ni.com

Figure 3. Connecting the SH96-96 or R96-96 Cable to the TBX-96 Terminal Block

5. Connect one end of the cable assembly to your TBX cable adapter and

secure the cable by tightening both backshell mounting screws.

6. Connect the other end of the cable assembly to your TBX-96 terminal

block connector and secure the cable by tightening both backshell

mounting screws.

7. Reconnect the DAQ device to your SCXI chassis.

1 Backshell Mounting Screws and Ears 2 SH96-96 Cable Assembly 3 R96-96 Cable Assembly

Note: The SH96-96 and R96-96 cables are not shown in the exact position for proper connection to the terminal

block connector. See Figure 4 for the completed connection.

NATIONAL

INSTRUMENTS

©National Instruments Corporation 7 TBX-96 Terminal Block

Figure 4. The Completed Installation

Mounting on and Removing from a DIN-Rail

To mount the TBX-96 terminal block onto the DIN rail, snap it into the DIN

rail with a firm push. To remove the TBX-96 terminal block from the DIN

rail, place a flathead screwdriver into the slot above the terminal block base

and pry it from the rail.

NATIONAL

INSTRUMENTS

TBX-96 Terminal Block 8 ni.com

Specifications

All specifications are typical at 25 °C unless otherwise specified.

Electrical

Maximum working voltage ....................30 Vrms,42.4V

peak, or 60 VDC

Maximum wire gauge .............................14 AWG

Mechanical

Dimensions .............................................19.76 by 12.55 by 6.27 cm

(7.78by4.94by2.47in.)

Weight ....................................................315 gm

(11.2 oz.)

Compatible DIN rails..............................DIN EN 50 022

DINEN50035

Environmental

Operating temperature ............................0 to 50 °C

Storage temperature ................................–20 to 70 °C

Relative humidity ...................................10 to 90% noncondensing

Safety

Designed in accordance with IEC 61010-1, EN 61010-1, UL 3111-1, and

CAN/CSA C22.2 No. 1010.1 for electrical measuring and test equipment.

For use at altitudes up to 2,000 meters.

Installation category I1

Pollution degree 2

1Category I is a signal level such as voltages on a printed wire board (PWB) on the secondary of an isolation transformer.

©National Instruments Corporation 9 TBX-96 Terminal Block

Electromagnetic Compatibility

EMC/EMI............................................... CE, C-Tick, and FCC Part 15

(Class A) Compliant

Electrical emissions................................ EN 55011 Class A at 10 m

FCC Part 15A above 1 GHz

Electrical immunity................................ Evaluated to EN 61326-1:1997

A1:1998, Table 1

Note For full EMC and EMI compliance, you must operate this device with shielded

cabling. See the Declaration of Conformity (DoC) for this product for any additional

regulatory compliance information. To obtain the DoC for this product, click

Declaration of Conformity at ni.com/hardref.nsf/. This Web site lists the DoCs by

product family. Select the appropriate product family, followed by your product, and a link

to the DoC (in Adobe Acrobat format) appears. Click the Acrobat icon to download or read

the DoC.

PWB Layout Dimensions

In the event your application requires individualized mounting, see

Figure 5 for the circuit board layout dimensions of the TBX-96.
