Native Instruments VC 2A Bedienungsanleitung
Manual
The information in this document is subject to change without notice and does not represent a
commitment on the part of Native Instruments GmbH. The software described by this docu-
ment is subject to a License Agreement and may not be copied to other media. No part of this
publication may be copied, reproduced or otherwise transmitted or recorded, for any purpose,
without prior written permission by Native Instruments GmbH, hereinafter referred to as Native
Instruments.
“Native Instruments”, “NI” and associated logos are (registered) trademarks of Native Instru-
ments GmbH.
Mac, Mac OS, GarageBand, Logic, iTunes and iPod are registered trademarks of Apple Inc.,
registered in the U.S. and other countries.
Windows, Windows Vista and DirectSound are registered trademarks of Microsoft Corporation
in the United States and/or other countries.
All other trade marks are the property of their respective owners and use of them does not im-
ply any affiliation with or endorsement by them.
LA-2A and 1176 LN are registered trademarks of Universal Audio, Inc.
Vintage Compressors is manufactured and developed by Native Instruments and Softube,
based on its own modeling techniques.
Universal Audio has not endorsed nor sponsored the Vintage Compressors in any manner, nor
licensed any intellectual property for use in this product.
Document authored by: Nicolas Sidi, Adam Hanley, Gustav Sto. Tomas
Software version: 1.0 (10/2012)
Special thanks to the Beta Test Team, who were invaluable not just in tracking down bugs, but
in making this a better product.
Disclaimer
Table of Contents
1 Welcome to VC 2A ....................................................................................................5
1.1 What Is a Compressor? ............................................................................................................... 5
1.1.1 Main Compression Parameters .................................................................................. 6
1.1.2 Other Compression Parameters and Features ............................................................ 6
1.2 The VC 2A ................................................................................................................................... 7
2 Using the VC 2A ........................................................................................................9
2.1 The Menu Bar ............................................................................................................................. 9
2.2 The Main Interface ...................................................................................................................... 11
3 Credits ......................................................................................................................14
Table of Contents
VC 2A - Manual - 4
1 Welcome to VC 2A
The VC 2A brings one of the most renowned compressor units of music history into your studio
by way of the FX Framework. The VC 2A perfectly re-creates the smooth and warm sound of its
ancestor. This compressor notably achieves outstanding results on guitars, bass, and vocals,
whose quieter parts can be softly pushed in a very natural way.
1.1 What Is a Compressor?
Technically speaking, a compressor is an audio processing unit that reduces the dynamic range
of an incoming signal, i.e. reduces the level difference between the signal's quiet and loud
sections. This way, it can help to increase the perceived loudness of a signal and attract the
listener's attention.
For many studio and live music applications, the usage of compressors is inevitable: they let
you "glue" the individual instruments of an instrument group together and make them "sit" in
the mix more naturally, which is particularly helpful when mixing drum recordings. Compres-
sion can also stretch the decay phase of instruments, mostly drums, and add sustain to the
tone of electric guitars.
However, compression can be used for a wide range of applications. Here are a just few exam-
ples:
▪Electric guitars and basses: Compression is applied to picked string instruments in order to
smooth the varying intensity of the individual strokes, thus increasing the perceived over-
all level. At extreme settings, you can get a “wall-of-sound” effect!
▪Drums: Adding compression to a bass drum or snare track will add punch and help define
its sound in your mix.
▪Vocals: Adding compression to vocals can make them sound more balanced by leveling
the soft and loud sounds in the voice.
▪Mixing/pre-mastering: A slight compression applied to the overall mix (or some specific
subgroups) can add cohesion between the various instruments.
Welcome to VC 2A
What Is a Compressor?
VC 2A - Manual - 5
▪Using compression is a fine art: You can easily destroy your sound if you don’t carefully set
the compression parameters! For each purpose, specific settings are required. A good un-
derstanding of each parameter’s effect, together with the experience gained by using the
compressor, will allow you to achieve great results!
In addition to the above listed common applications there is room for your own experiments, so
feel free to use your compressor in a way not listed here.
1.1.1 Main Compression Parameters
Compression can be controlled by several parameters. The most important parameters are the
following:
▪A threshold defines the audio level above which compression takes place. Below this
threshold level, the incoming signal is left untouched; above this threshold level, the gain
of the incoming signal is attenuated.
▪You can choose how much attenuation is applied to the signal by defining an input/output
ratio. For example, when you select a ratio of 2:1, an input level that is 2 dB above the
threshold will create an output level that is only 1 dB above the threshold.
By setting an extreme compression ratio, you can practically prevent the signal from ex-
ceeding the threshold level. The compressor then acts as a limiter.
▪Since the compression attenuates the higher levels of your input signal, most compressors
allow you to add a fixed make-up gain to the output in order to counterbalance the loss of
level.
1.1.2 Other Compression Parameters and Features
The compression process can be further tuned by using additional parameters and features.
Attack and Release
The attack time can define how long it takes for the compressor to come into full effect when
the threshold level is reached. For example, a longer attack time can be useful to retain the
attack transients on a percussive or plucked string instrument in order to only compress the
instrument sound coming after the transients. For this, you could also make use of parallel
compression (see below).
Welcome to VC 2A
What Is a Compressor?
VC 2A - Manual - 6
Similarly, the release time can define how long it takes for the active compressor to return to
its standby state after the signal level has fallen below the threshold level.
The right settings for attack and release time strongly depend on both the current purpose of
the compression and the kind of instrument that you are working on!
Side-Chain Input
Every compressor uses a detector to decide when to kick in. This detector listens to a control
signal and activates the compressor when needed.
Usually, the detector listens to the input signal itself and activates the compressor whenever
the level of the input signal exceeds the selected threshold.
A side-chain input, on the contrary, allows you to feed the detector with another signal (e.g. an-
other track in your mix). In this setup, compression is applied according to the level of the oth-
er signal. This greatly widens the versatility of your compressor.
Typically the side-chain input is fed by the bass drum track as a control signal to trigger
the compressor on the bass guitar track. Another example is the “auto talk over” feature
found on several mixers, which automatically attenuates the level of the music as soon as
you talk in the microphone.
Parallel Compression
Sometimes you may want to keep the original signal and blend it with the compressed signal.
Setting up a signal path for parallel compression can help retain some of the sonic characteris-
tics of your original instrument (mainly the transients) when a signal is heavily compressed and
in need of some top-end sparkle.
1.2 The VC 2A
The VC 2A is inspired by one of the most sought-after compression units ever made. Originally
produced in the early 1960s, this tube-based compressor is still being used in the best record-
ing studios worldwide. Its revolutionary design, making use of an electro-luminescent optical
gain reduction system, played an important role in its transparent compression characteristics.
This, along with the analog circuitry, helped coin the unit’s trademark character whose soft
coloring is still treasured among musicians and sound engineers.
Welcome to VC 2A
The VC 2A
VC 2A - Manual - 7
The VC 2A faithfully reproduces the characteristics and features of its highly prestigious hard-
ware ancestor. Notably, it provides you with the same incredibly simple interface, which mainly
relies on two knobs. You won’t find any Attack nor Release control here, since these were de-
termined by the analog hardware components used in the unit.
Nevertheless, bringing vintage hardware into the software world allowed us to add a few great
features. For example, unlike its ancestor, the VC 2A offers both a side-chain input and paral-
lel compression. And, of course, as with any effect available through FX Framework, you can
save and recall presets for your favorite settings.
Welcome to VC 2A
The VC 2A
VC 2A - Manual - 8
2 Using the VC 2A
This section describes how to use the VC 2A.
2.1 The Menu Bar
At the very top of the VC 2A interface, you will see the Menu bar. This is primarily used for
saving and loading presets, but also has a few other functions.
The Menu bar is located at the top of the interface.
Saving and Deleting Presets
To save a preset:
1. Click the drop-down arrow to the very left of the Menu bar to open the File menu.
2. Select Save as… from the menu:
3. Enter the name of your preset in the area under the label New Preset Name.
4. Click the SAVE button to finish the process and close the dialog box.
Using the VC 2A
The Menu Bar
VC 2A - Manual - 9
If you wish to remove a preset you no longer want, you can delete it by selecting Delete
from the File menu. Please note: you are not able to delete factory content.
Loading Presets
In the center part of the Menu bar, you will see the Preset menu. To navigate through presets,
either:
►Click the left and right arrows to cycle through and load the presets one at a time, or
►Click the drop-down menu to view a list of all available presets.
When using the second option, a preset is loaded when you click its name.
The Preset Menu
When you save a preset, the Preset menu is automatically split in two submenus, one contain-
ing factory presets and one containing user presets. By selecting a preset from the User sub-
menu, the list of presets you have saved is brought to the front of the Preset menu and dis-
played below the Factory and User options.
►By loading one of the presets from the Factory submenu, the factory presets are brought
back to the front.
A/B Comparisons
VC 2A offers an A/B comparison system to help you fine tune your settings.
Basically, this feature gives you two slots into which you can enter different parameter set-
tings. You can then quickly switch between the two slots to quickly compare the settings and
use whichever sounds better.
By default, you edit the parameters of slot A. To switch to slot B:
►Click the A/B switch located beside the preset menu.
Using the VC 2A
The Menu Bar
VC 2A - Manual - 10
