Nautilus Lifeline DIVER Bedienungsanleitung
1. Lifeline button is not functional until registered (see reverse).
2. Lifeline must be fully charged before rst use.
Green charging light will extinguish when fully charged.
3. Splash proof in all sea conditions, when upper cap is open.
4. Avoid submerging your Lifeline with upper cap open.
Speaker performance will be temporarily affected.
Press Chat Button to turn Lifeline on. Press and hold until “T” appears on
LCD screen, then talk into mic. Release Chat Button to receive.
Changing Chat Button Channel
1. Press chat button 3 times quickly to enter channel change mode
2. Scroll through channels using chat button
3. Hold down chat button to select and conrm channel
Chat Button- Use to communicate
between your Lifeline and any VHF radio
on the same channel. Default CH 08.
number of satellites in viewgps coordinates
battery meter
signal lock
channel name and number
LCD Screen View
transmitting
Press and hold button until “T” appears on LCD screen, then talk into mic.
Release button to receive.
Changing the Hail+Distress Button Channel
1. Press hail+distress button 7 times quickly to enter channel change mode
2. Scroll through channels using hail+distress button
3. Hold down hail+distress button to select and conrm channel
Hail+Distress Button - Use to
communicate on the International Hail
and Distress channel, CH 16.
Non-emergency functions will automatically shut off after 5 minutes of inactivity.
Top View
speaker
safety tab
mic
chat button / on button
usb port
lifeline button
hail+distress button
antenna
3 ft.
3 ft.
3 ft.
green charging light
QUICK START GUIDE
for Nautilus Lifeline DIVER
Lifeline Button - Use to automatically
transmit your GPS position and alert
message to any modern VHF radio,
CH 70. EMERGENCY USE ONLY.
Maintenance & Storage - Always store Lifeline in a dry
place, out of direct sunlight, with cap open and antenna
fully extended. Gently rinse your Lifeline in fresh water
after each use. Do not pressure blow-dry.
Do not remove antenna. Removal of
antenna will void warranty and may
result in damage to your Lifeline.
3 ft.
exclusion of liability - the nautilus lifeline diver is intended to be used as atool to aid
in your safety. it may not save your life. nautilus lifeline ltd. does not specify, warrant
or guarantee the performance of the unit in any particular circumstance. nautilus
lifeline ltd., its employees, agents or authorized dealers, shall not be liable for any
loss, damage or expense you may incur or suffer, including personal injury or loss of
life which may be caused or be associated with any defect in design or manufacturing
of the unit or any negligent act or omission (including gross negligence) or neglect of
nautilus lifeline ltd., its employees, agents or authorized dealers.
for the purposes of these conditions, nautilus lifeline ltd., is, or shall be deemed to
be, acting as agent or trustee on behalf of and for the benefit of all who are or might
be their employees, agents or authorized dealers and all such shall, to this extent, be
deemed to be parties to this exclusion of liability.
questions or concerns should be directed to info@nautiluslifeline.com
Press and hold until “DISTRESS ON” appears on the LCD screen and the
strobe ashes. To turn off, press and hold until “DISTRESS OFF” appears.
For maximum range hold Lifeline as high above the water line as possible.
NOTE: Many countries (but not all) allow use of MMSI numbers. You must
apply to your local authorities to obtain an MMSI number.
1. Visit www.nautiluslifeline.com/downloads and download
“Nautilus Lifeline DIVER software”
2. Plug Lifeline into computer using the
supplied USB cable.
3. Fill in the Nautilus Lifeline Registration form and submit by internet or
print and mail. Your MMSI can not be activated until registration
is complete.
4. Click on the “Advanced” tab.
5. Type in User Name and Lifeline MMSI
6. Click “Sync Setting to Lifeline”
Download full Operations Manual from www.nautiluslifeline.com/downloads
CHECK WWW.NAUTILUSLIFELINE.COM FOR REGULAR SOFTWARE UPGRADES
IMPORTANT! Lifeline button emergency mode is not
functional until lifeline is registered and MMSI is set.
To activate this feature visit: www.nautiluslifeline.com
3 ft.
LIFELINE BUTTON
Registration + Activation
3 ft.
