Ripwave CPE Quick Installation Guide Navini Networks, Inc.

RipwaveTM CPE Quick Installation Guide

The following instructions are for the experienced user as a quick setup

guide for the Ripwave unit. For more details on installation of the Ripwave

unit and software, see the Ripwave Unit Installation and User Guide.

Hardware Installation

1. Turn the computer off before installation. Connect the USB or Ethernet

cable to the Ripwave unit and to the corresponding port on the PC.

USB Cable Ethernet Cable

2. Connect the AC power adapter to the Ripwave unit and to a 110 VAC

outlet.

3. Rotate the antenna clockwise to the UP position.

4. Push the On/Off switch on the Ripwave unit to turn the unit ON. The

lower indicator light on the Ripwave unit illuminates green.

5. Set the power switch on the computer to the ON position. When the

system is up, log in to the computer.

Note: For Windows NT® and Windows®2000, you must be logged into

an account having administrative privileges to install the Ripwave unit

and its software.

6. For an Ethernet connection, go to the Ripwave Monitor Software

Installation section. For a USB connection, Plug and Play will detect the

new hardware – click Next in the Add New Hardware Wizard dialog box,

and continue on with the hardware installation.

7. Insert the Navini Networks Ripwave Installation CD in the CD-ROM

drive.

8. Follow the instructions for the ‘Add New Hardware Wizard’ to install the

device driver for the Ripwave unit.

9. Select the ‘CD-ROM drive’ checkbox. Click Next to continue.

10. Restart the computer, and proceed to the Ripwave Monitor Software

Installation.

AC power adapter

Ethernet Port

(

2600E

)

USB Port

Power adapter

cable jack

On/Off Switch

Power adapter

cable

USB Port

Ethernet Port

(

2400E

)

Ripwave Monitor Software Installation

1. Shut down all programs before installing the Ripwave Monitor software.

This includes all anti-virus software.

2. Insert the Navini Networks Ripwave Installation CD in the CD-ROM

drive.

3. Click Start > Run from the menu at the bottom left corner of your

screen. In the Run window, enter e:\setup (where “e” represents the CD

drive; use the letter representing your specific CD drive) in the Open

field. Click OK.

4. Follow the instructions for the ‘Ripwave Monitor Installation Wizard’ to

install the Ripwave Monitor software.

5. Restart the computer. When the system is up, log in to the computer and

open the Web browser.

6. LET IT RIP…BEGIN SURFING THE INTERNET!

at the Speed of Thought, Zero-Install, Ripwave, and Unwired by Navini are trademarks of Navini Networks, Inc.

Other product and company names mentioned herein may be trademarks and/or service marks of their respective

owners.

Ripwave



CPE

Quick Installation Guide

Product Release 1.16

Parent Number 95-00116-00

Part number 40-00112-00

Sub-part number 40-00098-00

Revision C Version 1.0

July 31, 2002
