USER MANUAL
With CE Mark Statement
DECLARATION OF CONFORMITY
The manufacturer
Neatech.it
4/A, A. De Curtis St. 80040 Cercola (NA) Italy
under its responsibility, states that
the wheelchair Levia Basculante Kid
satisfies the conditions laid down by European Directive 93/42;
according to the criteria for classification of annex IX of this Directive, the Levia
Basculante Kid is classified as
class I medical device
It also complies with the requirements of the harmonized standards:
UNI EN 12182 Ausili tecnici per persone disabili
UNI EN 12183 Sedie a rotelle a propulsione manuale
TABLE OF CONTENTS
WHEELCHAIR PRESENTATION........................................................................... 1
STARTING UP..................................................................................................... 2
ADJUSTMENTS .................................................................................................. 9
ACCESSORIES................................................................................................... 20
MAINTENANCE AND ASSISTANCE................................................................... 29
TIPPING HAZARD
Any transport on a slope greater than the maximum
security slope can be dangerous.
TEMPERATURE
The temperature of some surfaces may increase
when the chair is exposed to external heat sources
as sunlight
DISPOSING
This product and all its components cannot be treated
as household waste. For more detailed information
on how recycle this product contact your local waste
disposal service
1.WHEELCHAIR PRESENTATION
www.neatech.it
1
Thank you for choosing our product.
The aeronautical technology, used to manufacture all Neatech.it
products, made possible to create rigid and foldable frame highly
customizable and reliable.
Frame and canvas are available in different colors.
Features
Aluminum alloy structure
Folding frame
Opening and closing of the wheelchair are performed with a
crossbar patented system
Adjustable brakes
Brakes are adjustable according to wheel’s diameter
Adjustable armrests
Removable footrests
Dynamic tilting
The angle between the seat and the backrest remains fixed while
tilting
Customizable colors
WARNING: It is prohibited to use the wheelchair or its parts for any
purpose other than that indicated; for a correct use please follow
the instructions given in this manual. NEATECH.IT disclaims any
responsibility for damages caused by improper use of aids.
WARNING: The information contained in this manual may be
subject to change and without prior notice.
2. STARTING UP
www.neatech.it
2
Checks to be made on delivery
Check for the integrity of the original packaging
INSIDE THE BOX THERE IS:
Wheelchair Levia Basculante Kid
Footrest
N. 2 armrests
Documentation
Check for any anomalies on the shipping documents.
Check the functionality and integrity of the device in all of its
parts, at the time of or immediately thereafter, to ensure that no
damage is caused by a careless transport.
Make sure the surface of the device is not damaged, scratched,
bended, etc.
Any fault or damage found must be immediately reported on the
shipping documents and promptly communicated to the carrier.
For any other questions, please contact the manufacturer.
If you don’t want to use the Levia Basculante Kid for a long time,
store it in a safe place free from dust and moisture
2. STARTING UP
www.neatech.it
3
The wheelchair is shipped already assembled with closed frame.
For the opening it will be sufficient to remove the sides of seat and
apply a slight pressure on the handle placed on the element that joins
the cruises as shown in Figure 1.
The wheelchair has reached the maximum opening when you can
hear a snap.
Figure 1
WARNING: A wrong grip of the handle can cause injury to hands
2. STARTING UP
www.neatech.it
4
Once opened, the frame you need to assemble the tube for the
headrest and the footrest. Regarding the tube for the headrest it is
necessary to introduce it in the tubular as shown in Figure 2. To
facilitate the operation slightly dilate the tubes of the seat.
Then tighten the locking levers saddle (L1).
Figure 2
To assemble the footrest introduce the extension in the housing as
shown in Figure 2 and tighten the locking levers saddle (L2).
L1
L2
