NEC Versa Tools:™Accessories and Solutions
USER’S GUIDE
USER’S GUIDE
VERSA DOCK
819-200470-002
VERSA®DOCK
VersaDOCKManCover-02 10/14/99 1:20 PM Page 1
Third Printing — March 2000
Copyright 2000
NEC Computers Inc.
15 Business Park Way
Sacramento, CA 95828
All Rights Reserved
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related materials, is
the valuable property of NEC Computers Inc. (hereinafter NECC) and/or its licensors.
NECC and/or its licensors, as appropriate, reserve all patent, copyright and other
proprietary rights to this document, including all design, manufacturing, reproduction, use,
and sales rights thereto, except to the extent said rights are expressly granted to others.
The NECC product(s) discussed in this document are warranted in accordance with the
terms of the Warranty Statement accompanying each product. However, actual performance
of each such product is dependent upon factors such as system configuration, customer
data, and operator control. Since implementation by customers of each product may vary,
the suitability of specific product configurations and applications must be determined by the
customer and is not warranted by NECC.
To allow for design and specification improvements, the information in this document is
subject to change at any time, without notice. Reproduction of this document or portions
thereof without prior written approval of NECC is prohibited.
As an ENERGY STAR partner, NEC Computer Systems Division has determined that this product meets the
ENERGY STAR guidelines for energy efficiency.
NEC is a registered trademark, Versa is a U.S. registered trademark, VersaBay, VersaGlide and PortBar are
trademarks, and UltraCare is a U.S. registered service mark of NEC Corporation, and/or one or more of its
subsidiaries, used under license.
ENERGY STAR is a U.S. registered mark.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of
their respective trademark owners.
Table of Contents iii
Contents
Using This Guide
Text Setup.............................................................................................vii
Related Documents............................................................................. viii
1 Introducing the NEC Versa Dock
Carton Contents...................................................................................1-2
NEC Versa Dock Features...................................................................1-3
Front and Top.................................................................................1-4
Left Side.........................................................................................1-7
Right Side.......................................................................................1-8
Back..............................................................................................1-10
The Right Environment.....................................................................1-11
Operating Environment................................................................1-12
Storage Environment....................................................................1-12
NEC Versa Dock Care.......................................................................1-12
Precautions...................................................................................1-12
Routine Care.................................................................................1-13
Battery Charging ...............................................................................1-14
2 Docking and Undocking
Connecting the Power Cable ...............................................................2-2
Preparing the NEC Versa for Docking................................................2-4
Docking the NEC Versa......................................................................2-6
Dual Booting................................................................................2-11
Locking the NEC Versa.....................................................................2-12
Undocking the NEC Versa................................................................2-15
Emergency Undocking......................................................................2-17
3 Setting Up the Software
Updating the BIOS ..............................................................................3-2
Preparing the BIOS Update Diskette..............................................3-2
Performing the BIOS Update.........................................................3-3
Installing Drivers.................................................................................3-5
Installing the Online User’s Guide......................................................3-6
Uninstalling the Online User’s Guide............................................3-7
iv Table of Contents
4 Installing Options and Connecting Devices
Installing Devices in the File Bays......................................................4-3
Removing Trays, Panels, and Covers.............................................4-3
Disconnecting the Cables from the Motherboard...........................4-6
Connecting IDE Device Cables......................................................4-8
Installing an IDE Hard Drive .......................................................4-10
Connecting VersaBay III Adapter Kit Cables..............................4-10
File Bay Installation.....................................................................4-11
Reconnecting the Cables to the Motherboard ..............................4-15
Replacing Covers, Panels, and Trays...........................................4-17
Installing PC (PCMCIA) Cards.........................................................4-21
Installing PCI Cards ..........................................................................4-21
Using PCI Cards...........................................................................4-24
Connecting External Devices ............................................................4-24
Serial Device................................................................................4-24
External Keyboard and Mouse.....................................................4-26
External Monitor ..........................................................................4-27
Parallel Devices............................................................................4-29
USB Devices................................................................................4-30
MIDI/Game Devices ....................................................................4-31
External Audio Options................................................................4-32
Connecting External Speakers......................................................4-33
5 Solving Problems
Problem Checklist ...............................................................................5-2
Troubleshooting...................................................................................5-2
Replacing the Battery ..........................................................................5-4
Battery Precautions ........................................................................5-6
Battery Disposal.............................................................................5-7
If You Need Help ................................................................................5-8
6 Getting Services and Support
Quick Reference Chart ........................................................................6-2
NECC Web Site...................................................................................6-3
NECC FTP Site ...................................................................................6-3
NECC Support Services......................................................................6-4
E-mail/Fax Support Services...............................................................6-4
Table of Contents v
A Specifications
Features ..............................................................................................A-2
Input/Output Facilities........................................................................A-2
Expansion Capabilities.......................................................................A-3
Indicator LEDs ...................................................................................A-3
Power Supply......................................................................................A-3
Power Cables......................................................................................A-4
Dimensions.........................................................................................A-4
Environmental Requirements.............................................................A-4
Index
Using This Guide vii
Using This Guide
The NEC Versa Dock User’s Guide gives you the information you need
to maximize the use of your docking station. Read this guide to become
familiar with the NEC Versa Dock and its features. For specific
information, see the following chapters.
!Chapter 1, “Introducing the NEC Versa Dock,” introduces you to
docking station capabilities and features. This chapter also describes
the correct operating and storage environment for the docking station
and how to care for the unit.
!Chapter 2, “Docking and Undocking,” provides instructions for
docking and undocking an NEC Versa LX or SX notebook computer
on the NEC Versa Dock..
!Chapter 3, “Setting Up the Software,” explains setting up the software
to use your docking station and NEC Versa notebook computer
together.
!Chapter 4, “Installing Options and Connecting Devices,” details how
to connect external devices and add options to the docking station.
!Chapter 5, “Solving Problems,” directs you through basic
troubleshooting procedures to help you solve problems that may arise.
!Chapter 6, “Getting Services and Support,” provides details for
getting technical support from NEC Computers Inc.
!Appendix A, “Specifications,” provides docking station
specifications.
This document, the NEC Versa Dock Quick Setup sheet, your NEC
Versa User’s Guide, and Windows documentation provide all the
information you need to effectively use the NEC Versa Dock.
Text Setup
To make this guide as easy to use as possible, text is set up as follows.
viii Using This Guide
!Warnings, cautions, and notes are set up in the following format.
WARNING
Warnings alert you to situations that can cause
personal injury or harm.
CAUTION
Cautions indicate situations that can cause damage
to system hardware or software.
Note: Notes give particularly important
information about the topic being discussed.
!Names of keys are printed as they appear on the keyboard, for
example, Ctrl, Alt, or Enter.
!Text that you must type or keys that you must press are presented in
bold type. For example, type dir and press Enter.
Related Documents
See the following documents for information related to the NEC Versa
Dock and NEC Versa operation:
!The NEC Versa Dock Quick Setup sheet.
!Your NEC Versa User’s Guide.
!The Microsoft Windows and other operating system documentation
that came with your NEC Versa.
!Manuals and setup instructions for any devices that you are
connecting to the NEC Versa Dock.
1
Introducing the NEC Versa
Dock
!Carton Contents
!NEC Versa Dock Features
!The Right Environment
!NEC Versa Dock Care
!Battery Charging
1-2 Introducing the NEC Versa Dock
The NEC Versa Dock lets you maximize your NEC Versa LX and SX
capabilities without minimizing portability. Connect an external monitor
and keyboard to the ports on the back of the NEC Versa Dock, install
your CD-ROM reader in the optional NEC Versa Dock VersaBay III,
attach your joystick to the MIDI/Game port, and you're ready to work
hard or play! Undock the NEC Versa from the NEC Versa Dock and
you're ready for the road.
This chapter introduces NEC Versa Dock features, guides you to
choosing the correct environment, and describes how to take care of the
unit.
Carton Contents
Unpack and check the contents of the NEC Versa Dock carton.
Be sure you have the hardware components shown in the following
figure and that they are in good condition. If anything is damaged or
missing, contact your dealer immediately.
Carton Contents
A- NEC Versa Dock B- CRT base C- BIOS update diskette
D - Software Setup CD E- IDE power cables F- User documentation
G - AC power cable H- NEC Versa Dock keys
Introducing the NEC Versa Dock 1-3
!NEC Versa Dock — provides many features to expand your NEC
Versa capabilities. These features are described in detail in this
chapter.
!CRT Base — supports an external monitor that weighs up to 55 lb (25
kg).
!BIOS update diskettes.
!NEC Versa Dock Software Setup CD.
!Two extra power cables for the installation of optional IDE devices.
!User Documentation — introduces you to the NEC Versa Dock and
guides you through initial docking and setup.
!AC Power Cable — allows you to connect your NEC Versa Dock to
AC power.
Always use the power cable that ships with the NEC Versa Dock. If
you need to replace the cable, follow these standards:
In North America, the cable should be rated for 120 volts (V), 7
amps(A). The plug is a NEMA 5-15P. Use an SVT or SJT 18/3
AWG cable that is less than 15 feet (4.5 m) long. Use connector
type IEC320.
In Europe, the cable should be rated for 230 V (220-240 V), 10A.
The plug is country-specific. Use an H05VV-F or H05VVH2-F
cable that is less than 15 feet (4.5 m) long. Use connector type
EN60320.
!NEC Versa Dock Keys.
NEC Versa Dock Features
NEC Versa Dock features are found on all sides of the unit. To become
familiar with these features, read each of the following sections.
Andere Handbücher für VERSA DOCK - SERVICE
3
Inhaltsverzeichnis
Andere NEC Computerzubehör Handbücher
NEC
NEC VERSA MEDIADOCK - SERVICE Bedienungsanleitung
NEC
NEC VERSA DOCK - SERVICE Bedienungsanleitung
NEC
NEC POWERMATE DESKTOP - INSTALLATION ZIP DRIVE Bedienungsanleitung
NEC
NEC VERSA DOCKING STATION 6000 Bedienungsanleitung
NEC
NEC IE-703217-G1-EM1 Bedienungsanleitung
NEC
NEC N8101-616F Bedienungsanleitung
NEC
NEC VERSA MINIDOCK 6000 Bedienungsanleitung
NEC
NEC VERSA MINIDOCK 6000 Bedienungsanleitung
NEC
NEC VERSA DOCK - SERVICE Betriebsanleitung
