MultiSync 75F

MultiSync 95F

User’s Manual

English-1

English

Declaration of the Manufacturer

We hereby certify that the colour monitors

MultiSync 75F (N0701)

MultiSync 95F (N9902)

are in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 61000-3-2

- EN 61000-3-3

- EN 50082-1

(IEC 801-2)

(IEC 801-3)

(IEC 801-4)

and marked with

NEC-Mitsubishi Electric Visual Systems Corporation

686-1, NISHIOI OI-MACHI

ASHIGARAKAMI-GUN

KANAGAWA 258-8533, JAPAN

English-2

Safety Instruction

Caution:

When operating the MultiSync 75F/95F with a 220-240V AC power

source in Europe except UK, use the power cord provided with the

monitor.

In UK, a BS approved power cord with moulded plug has a Black (five

Amps) fuse installed for use with this equipment. If a power cord is not

supplied with this equipment please contact your supplier.

When operating the MultiSync 75F/95F with a 220-240V AC power

source in Australia, use the power cord provided with the monitor.

For all other cases, use a power cord that matches the AC voltage of the

power outlet and has been approved by and complies with the safety

standard of your particular country.

ENERGY STAR®Product

As an ENERGY STAR Partner, NEC-Mitsubishi Electronics Display has

determined that this product meets the ENERGY STAR guidelines for

energy efficiency. The ENERGY STAR emblem does not represent EPA

endorsement of any product or service.

CSA

This Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulation.

Cet appareil numerique de la class B respecte toutes les exigences du

Reglement sur le materiel brouilleur du Canada.

IBM is registered trademark of International Business Machines Corporation Apple and

Macintosh are registered trademarks of Apple Computer Inc.

Microsoft and Windows are registered trademarks of the Microsoft Corporation.

ENERGY STAR is a U.S. registered mark.

NEC is a registered trademark of NEC Corporation.

English-3

English

FCC Information

1. Use the attached specified cables with the N9705 and N9902 color

monitor so as not to interfere with radio and television reception.

(1)Please use the supplied power cable or equivalent to ensure

FCC compliance.

(2)Shielded captive type signal cable.

Use of other cables may cause interference with radio and

television reception.

2. This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy, and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

•Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/

television technician for additional suggestions. The user may find the

following booklet, prepared by the Federal Communications Commission,

helpful: “How to Identify and Resolve Radio-TV Interference Problems”.

This booklet is available from the U.S. Government Printing Office,

Washington, D.C., 20402, Stock No. 004-000-00345-4.

English-4

TCO‘99

Congratulation! You have just purchased a TCO‘99

approved and labeled product! Your choice has

provided you with a product developed for

professional use. Your purchase has also contributed

to reducing the burden on the environment and also

to the further development of environmentally

adapted electronics products.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established

method for encouraging the adaptation of goods and services to the

environment. The main problem, as far as computers and other

electronics equipment are concerned, is that environmentally harmful

substances are used both in the products and during the manufacturing.

Since it has not been possible for the majority of electronics equipment

to be recycled in a satisfactory way, most of these potentiall y damaging

substances sooner or later enter Nature.

There are also other characteristics of a computer, such as energy

consumption levels, that are important from the viewpoints of both the

work (Internal) and natural (external) environments. Since all methods of

conventional electricity generation have a negative effect on the

environment (acidic and climate-influencing emissions, radioactive

waste, etc.), it is vital to conserve energy.

Electronics equipment in offices consume an enormous amount of

energy since they are often left running continuously.

What does labelling involve?

This product meets the requirements for the TCO‘99 scheme which

provides for international and environmental labelling of personal

computers. The labelling scheme was developed as a joint effort by the

TCO (The Swedish Confederation of Professional Employees), Svenska

Naturskyddsforeningen (The Swedish Society for Nature Conservation)

and statens Energimyndighet (The Swedish National Energy

Administration).

The requirements cover a wide range of issues: environment,

ergonomics, usability, emission of electrical and magnetic fields, energy

consumption and electrical and fire safety.

English-5

English

The environmental demands concern restrictions on the presence and

use of heavy metals, brominated and chlorinated flame retardants, CFCs

(freons) and chlorinated solvents, among other things. The product must

be prepared for recycling and the manufacturer is obliged to have an

environmental plan which must be adhered to in each country where the

company impl ements i ts operational policy. The energy requirements

include a demand that the computer and/or display, after a certain period

of inactivity, shall reduce its power consumption to a lower level in one or

more stages. The length of time to reactivate the computer shall be

reasonable for the user.

Labelled products must meet strict environmental demands, for example,

in respect of the reduction of electric and magnetic fields, physical and

visual ergonomics and good usability.

Environmental Requirements

Flame retardants

Flame retardants are present in printed circuit boards, cables, wires,

casings and housings. In turn, they delay the spread of fire. Up to thirty

percent of the plastic in a computer casing can consist of flame retar ant

substances. Most flame retardants contain bromine or chloride and these

are related to another group of environmental toxins, PCB‘s, which are

suspected to give rise to severe health effects, including reproductive

damage in fisheating birds and mammals, due to the bio-accumulative*

processes. Flame re t a rdants have been found in human blood and

researchers fear that disturbances in foetus development may occur.

TCO‘99 demand requires that plastic components weighing more than

25 grams must not contain flame retardants with organically bound

chlorine and bromine.

Flame retardants are allowed in the printed circuit boards since no

substitutes are available.

Lead**

Lead can be found in picture tubes, display screens, solders and

capacitors. Lead damages the nervous system and in higher doses,

causes lead poisoning.

TCO‘99 requirement permits the inclusion of lead since no replacement

has yet been developed.

English-6

Cadmium**

Cadmium is present in rechargeable batteries and in the

colourgenerating layers of certain computer displays. Cadmium damages

the nervous system and is toxic in high doses.

TCO‘99 requirement states that batteries, the colourgenerating layers of

display screens and the electrical or electronics components must not

contain any cadmium.

Mercury**

Mercury is sometimes found in batteries, relays and switches, Mercury

damages the nervous system and is toxic in high doses.

TCO‘99 requirement states that batteries may not contain any Mercury. It

also demands that no mercury is present in any of the electrical or

electronics components associated with the display unit.

CFCs (freons)

CFCs (freons) are sometimes used for washing printed circuit boards.

CFCs break down ozone and thereby damage the ozone layer in the

stratosphere, causing increased reception on Earth of ultraviolet light

with consequent increased risks of skin cancer (malignant melanoma).

The relevant TCO‘99 requirement; Neither CFCs nor HCFCs may be

used during the manufacturing and assembly of the product or its

packaging.

*Bio-accumulative is defined as substances which accumul ate within living organisms.

**Lead, Cadmium and Merc u ry are heavy metals which are Bio-accumulative.

To obtain complete information on the environmental criteria document,

ord e r from:

TCO Development Unit

SE-114 94 Stockholm

SWEDEN

FAX Number: +46 8 782 92 07

E-mail (Internet): development@tco.se

You may also obtain current information on TCO‘99 approved and

labeled products by visiting their website at:

http: //www.tco-info.com/

English-7

English

Contents

MultiSync monitor box* should contain the following:

•MultiSync Monitor

MultiSync 75F or MultiSync 95F

•Power cord

•Captive Signal Cable

•User‘s manual

•CD-ROM includes complete User‘s Manual in PDF format and

Windows related files (Inf file and color profile). To see the complete

User‘s Manual, Acrobat Reader 4.0 must be installed on your PC.

* Remember to save your original box and packing material to transport

or ship the monitor.

User’s Manual

Power Cord

Captive Signal Cable

English-8

Quick Start

To attach the MultiSync monitor to your system,

follow these instruction:

1. Turn off the power to your computer and MultiSync monitor.

2. If necessary, install the display card. For more information, refer to the

display card manual.

3. For the PC: Connect the 15-pin mini D-SUB of the captive signal

cable to the connector of the display card in your system (Figure A.1)

Tighten all screws.

For the Mac: Connect the MultiSync 75F or 95F Macintosh Cable

Adapter (not included) to the monitor connector on the Macintosh

(Figure B.1). Attach the 15-pin mini D-SUB end of the captive signal

cable to the Macintosh cable adapter on the computer (Figure B.1).

Tighten all screws.

4. Connect one end of the power cord to the MultiSync monitor and the

other end to the power outlet (Figure C.1).

5. Turn on the monitor (Figure D.1) and the computer.

6. This completes the installation.

NOTE: If you have any problems, please refer to the

Troubleshooting section of this User‘s Manual.

Captive Signal Cable

15-pin-mini-D-SUB

Figure A.1

English-9

English

Captive Signal Cable

Mac Adapter

(not included)

15-pin mini D-SUB

Figure B.1

Power Outlet

Power cord

Figure C.1

Figure D.1

Andere Handbücher für MultiSync 75F

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere NEC Monitor Handbücher

NEC

NEC LCD71V - AccuSync TFT LCD Flat Panel Monitor Bedienungsanleitung

NEC

NEC FP1350 - MultiSync - 22" CRT Display Bedienungsanleitung

NEC

NEC AccuSync LCD3000 Bedienungsanleitung

NEC

NEC LCD1525M - MultiSync - 15" LCD Monitor Leitfaden

NEC

NEC P221W-BK - MultiSync - 22" LCD Monitor Bedienungsanleitung

NEC

NEC X754HB Bedienungsanleitung

NEC

NEC MultiSync X551UN Bedienungsanleitung

NEC

NEC MultiSync V654Q Bedienungsanleitung

NEC

NEC PlasmaSync 50XM3 Bedienungsanleitung

NEC

NEC V462-AVT Leitfaden

NEC

NEC LCD Monitor Bedienungsanleitung

NEC

NEC MultiSync LCD2490WUXi2 Stücklistenhandbuch

NEC

NEC AccuSync LCD203WXM Bedienungsanleitung

NEC

NEC PlasmaSync 61XM1A Bedienungsanleitung

NEC

NEC LCD1570NX - MultiSync - 15" LCD Monitor Bedienungsanleitung

NEC

NEC LCD8205 - MultiSync - 82" LCD Flat Panel... Bedienungsanleitung

NEC

NEC MultiSync JC-1941UMA Bedienungsanleitung

NEC

NEC 60XM5 - PlasmaSync - 60" Plasma Panel Bedienungsanleitung

NEC

NEC M40B-AV - 40" LCD Flat Panel Display Montage- und Bedienungsanleitung

NEC

NEC P401 - MultiSync - 40" LCD Flat Panel... Bedienungsanleitung

NEC

NEC MultiSync LCD2060NX Bedienungsanleitung

NEC

NEC FA3435K series Bedienungsanleitung

NEC

NEC PX-42VM3A Bedienungsanleitung

NEC

NEC MultiSync X464UNV-3 Bedienungsanleitung

Beliebte Monitor Handbücher anderer Marken

Linear Acoustic

Linear Acoustic LQ-1000 Bedienungsanleitung

AOC

AOC I2579V Bedienungsanleitung

Gateway

Gateway FPD1520 Bedienungsanleitung

Furuno

Furuno Mu 120c Bedienungsanleitung

Asus

Asus VB171D - 17" LCD Monitor Bedienungsanleitung

Dell

Dell S2230MX Gebrauchsanweisung

Philips

Philips 107C64 Bedienungsanleitung

Dell

Dell S2409WFP Bedienungsanleitung

EverFocus

EverFocus EN-7517E Bedienungsanleitung

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Bedienungsanleitung

Dell

Dell Precision 7680 Bedienungsanleitung

LG 50PM1M - - 50" Plasma Panel Bedienungsanleitung

Bosch

Bosch DDU 9 Bedienungsanleitung

Acer

Acer A231HL Bedienungsanleitung

Philips

Philips 86BDL4152T Bedienungsanleitung

Emay

Emay SleepO2 Bedienungsanleitung

IBM

IBM 6360 Montageanleitung

LG M1950D-PZ Bedienungsanleitung
