MultiSync FP1375X

User’s Manual

English-1

English

Declaration

Declaration of the Manufacturer

We hereby certify that the colour monitor

MultiSync FP1375X (NSZ3101STTUW) is in

compliance with Council Directive 73/23/EEC:

-EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 61000-3-2

- EN 61000-3-3

- EN 55024

and marked with

NEC-Mitsubishi Electric Visual Systems Corporation

4-13-23, Shibaura,

Minato-Ku

Tokyo 108-0023, JAPAN

English-2

ENERGY STAR ®is a U.S. registered trademark. All other brands and product names are trademarks or

registered trademarks of their respective owners.

As an ENERGY STA R Partner, NEC-Mitsubishi Electric Visual Systems Corporation has determined that

this product meets the ENERGY STA R guidelines for energy efficiency.

The ENERGY STA R emblem does not represent EPA endorsement of any product or service.

All other trademarks mentioned in this manual are the property of their respective owners.

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO

RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT’S POLARIZED PLUG

WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS

THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE

COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,DO NOT

REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may

have sufficient magnitude to cause electric shock. Therefore, it is

dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the

operation and maintenance of this unit has been included. Therefore, it

should be read carefully in order to avoid any problems.

CAUTION

WARNING

RISK OF ELECTRIC SHOCK •DO NOT OPEN

Safety Instruction

VCCI Statement

English-3

English

Canadian Department of Communications

Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CSA

C22.2 #950.

FCC Information

1. Use the attached specified cables with the MultiSync FP1375X colour monitor so as not to

interfere with radio and television reception.

(1) Please use the supplied power cable or equivalent to ensure FCC compliance.

(2) Shielded video type signal cable.

Use of other cables and adapters may cause interference with radio and television reception.

2. This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy, and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

- Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/television technician for

additional suggestions. The user may find the following booklet, prepared by the Federal

Communications Commission, helpful: “How to Identify and Resolve Radio-TV Interference

Problems.”This booklet is available from the U.S. Government Printing Office, Washington, D.C.,

20402, Stock No. 004-000-00345-4.

No user serviceable parts inside. Do not attempt to modify this equipment. If modified, your authority

to operate this equipment might be voided by FCC.

English-4

Contents

Your new MultiSync FP1375X monitor box* should contain the following:

•MultiSync FP1375X Monitor with tilt/swivel base

•Power cord for E.U.

•Power cord for U.K.

•Video Signal Cable (VGA to DVI-A)

•Video Signal Cable (DVI-D to DVI-D)

•User’s Manual

•USB cable

•CD-ROM:

Includes complete User’s Manual in PDF format and Windows related

files (INF file and colour profile). To see the complete User’s Manual,

Acrobat Reader 4.0 must be installed at your PC.

* Remember to save your original box and packing material to transport

or ship the monitor.

Power Cord for E.U.

Video Signal Cable

VGA to DVI-A

User’s Manual

CD-ROM

USB cable

Video Signal Cable

DVI-D to DVI-D

Power cord for U.K.

English-5

English

Quick Start

To attach the MultiSync FP1375X monitor to your system, follow these

instructions:

1. Turn off the power to your computer.

2. If necessary, install the display card into your system. For more

information, refer to the display card manual.

3. For the PC Analog output: Connect the VGA to DVI-A signal cable

to the connector of the display card in your system (Figure A.1).

Tighten all screws.

For the PC with DVI digital output: Connect the DVI-D to DVI-D

signal cable to the connector of the display card in your system

(Figure A.2). Tighten all screws.

For the Mac: Connect the Macintosh cable adapter (not included)to

the monitor connector on the Macintosh (Figure B.1). Attach the VGA

end of the captive signal cable to the Macintosh cable adapter on the

computer (Figure B.1). Tighten all screws.

NOTE: Incorrect cable connections may result in irregular

operation, damage display quality/components of CRT

monitor.

Figure A.1 Figure A.2

USB Cable

Detachable

Signal Cable

(VGA to DVI-A)

DVI-A

VGA

USB Cable

Detachable

Signal Cable

(DVI-D to DVI-D)

DVI-D

English-6

4. The Windows®95/98/2000/Me INF file for your MultiSync monitor can

be found on the CD-ROM, delivered with the monitor.

5. Connect one end of the power cord to the MultiSync FP1375X monitor

and the other end to the power outlet (Figure C.1).

6. Turn on the monitor (Figure D.1).

7. Turn on the Computer.

NOTE: If you have any problems, please refer to the

Troubleshooting section of this User’s Manual.

Figure B.1

VGA

Detachable Signal Cable

(VGA to DVI-A)

Computer Mac Adapter

(not included)

Figure C.1

Power Outlet

Power Cord

Figure D.1

Power Button

DVI-A

DVI-I/D-SUB

Reset

English-7

English

Controls

OSM (On-Screen Manager) control buttons on the front of the monitor

function as follows:

When OSM controls are activated, icons are displayed at the top of the

menu. If an arrow (→) is displayed in a sub-menu, it indicates further

choices are available. To enter a sub-menu, press PROCEED.

Brightness/Contrast Controls

Brightness: Adjusts the overall image and background screen

brightness.

Contrast: Adjusts the image brightness in relation to the background.

Sub-Menu

Exits to the OSM main menu.

Moves the highlighted area

up/down to select one of the

controls.

Moves the bar in the - or +

direction to decrease or

increase the adjustment.

Only executes control or

enters sub-menu.

Resets all the controls within

the highlighted menu to the

factory setting.

EXIT

CONTROL ▲/▼

CONTROL -/+

PROCEED

RESET

Main Menu

Exits the OSM menu.

Moves the highlighted

area up/down to select

one of the controls.

Moves highlighted area

left/right to select one of

the controls.

Has no function.

With OSM menu screen,

reset.

D-SUB/DVI-I Without OSM menu screen, push to select the signal input

connector, D-SUB (VGA) or DVI-I.

NOTE: When the DVI input has been changed,

you must restart your computer.

NOTE: When RESET is pressed in the main and

sub-menu, a warning window will appear

allowing you to cancel the reset function.

English-8

Degauss: Eliminates the build-up of stray magnetic fields which alter the

correct scan of the electron beams and affect the purity of the screen

colours, focus, and convergence. When activated, your screen image will

jump and waver a bit as the screen is demagnetised.

Caution: Please allow a minimum of 20 minutes to elapse between

uses of the Degauss function.

Size and Position Controls

Auto Adjust: Automatically adjust the horizontal and vertical size and

position settings for applicable timings.

Left/Right: Moves the image horizontally (left or right).

Down/Up: Moves the image vertically (up or down).

Narrow/Wide: Decreases or increases the horizontal size of the image.

Short/Tall: Decreases or increases the vertical size of the image.

Colour Control/Colour Control System

Colour presets 1 through 5 selects the desired colour setting. The bar is

replaced by the colour setting choice from 1 to 5. Each colour setting is

adjusted at the factory to the stated Kelvin. If a setting is adjusted, the

name of the setting will change from Kelvin to Custom.

Red, Green, Blue: Colour Control System decreases or increases the

monitor’s red, green or blue colour guns depending upon which is

selected. The change in colour will appear on screen and the direction

(decrease or increase) will be shown by the bars.

sRGB Mode: sRGB mode provides the suitable colour managed picture

image.You can not change Red, Green and Blue colours individually.

NOTE: In this mode, Brightness and Contrast are not adjustable.

Geometry Controls

Geometry Controls Menu

The Geometry controls allow you to adjust the curvature or angle of the

sides of your display.

Sides In/Out (pincushion): Decreases or increases the curvature of the

sides either inward or outward.

English-9

English

Sides Left/Right (pincushion balance): Decreases or increases the

curvature of the sides either to the left or right.

Sides Tilt (parallelogram): Decreases or increases the tilt of the sides

either to the left or right.

Sides Align (trapezoidal): Decreases or increases the bottom of the

screen to be the same as the top.

Rotate (raster rotation): Rotates the entire display clockwise or

counterclockwise.

Tools 1

Moiré Canceler: Moiréis a wavy pattern which can sometimes appear

on the screen. The pattern is repetitive and superimposed as rippled

images. When running certain applications, the wavy pattern is more

evident than in others. To reduce moiré, adjust the level by using

-/+ control buttons.

Basic Convergence: Aligns all three colours (R,G,B) to form a single

colour (white). The purpose of this control is to ensure that a white line

drawn on the screen is as crisp and clear as possible.

•Use the Horizontal control to adjust the alignment of the white lines in

the up/down direction.

•Use the Vertical control to adjust the alignment of the white lines in

the left/ right direction.

Corner Correction: Allows you to adjust the geometry of the corners of

your display –Top, Top Balance, Bottom or Bottom Balance.

Linearity: This selection allows you to adjust the spacing of the area on

the screen. The purpose of this control is to ensure that a one-inch circle

is a true one-inch circle wherever it is on the screen. The best way to

determine the vertical linearity is as follows:

•Draw equally spaced horizontal lines using a drawing application that

has a ruler.

•Use the Vertical Balance control to adjust the lines near the top and

bottom of your screen.

•Use the Vertical control to adjust the spacing between the lines near

the center and top of your screen.

Andere Handbücher für MultiSync FP1375X

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere NEC Monitor Handbücher

NEC

NEC MDview 193 Bedienungsanleitung

NEC

NEC 60XP10 - PlasmaSync - 60" Plasma Panel Bedienungsanleitung

NEC

NEC LCD2070NX - MultiSync - 20" LCD Monitor Bedienungsanleitung

NEC

NEC NEC MultiSync LCD1550V LCD1550V LCD1550V Bedienungsanleitung

NEC

NEC MultiSync LCD1990FX Bedienungsanleitung

NEC

NEC MultiSync V554 Bedienungsanleitung

NEC

NEC MultiSync FP1355 FP1355 FP1355 Bedienungsanleitung

NEC

NEC MultiSync X551 UHD IGT Bedienungsanleitung

NEC

NEC MultiSync JC-1941UMA Bedienungsanleitung

NEC

NEC LCD175VX - MultiSync - 17" LCD Monitor Bedienungsanleitung

NEC

NEC MultiSync P702 Bedienungsanleitung

NEC

NEC FP1350 - MultiSync - 22" CRT Display Bedienungsanleitung

NEC

NEC MULTISYNC LCD1510+ Firmware-Update

NEC

NEC MultiSync LCD175M Bedienungsanleitung

NEC

NEC MultiSync X464UN Bedienungsanleitung

NEC

NEC LCD2190UXI - MultiSync - 21.3" LCD Monitor Bedienungsanleitung

NEC

NEC PlasmaSync 42VP4 Bedienungsanleitung

NEC

NEC MultiSync LCD1760NX Bedienungsanleitung

NEC

NEC AccuSync LCD3000 Bedienungsanleitung

NEC

NEC LCD2070NX - MultiSync - 20" LCD Monitor Leitfaden

NEC

NEC PX-42VM3A Bedienungsanleitung

NEC

NEC MultiSync SC40 Bedienungsanleitung

NEC

NEC MultiSync XV17 Bedienungsanleitung

NEC

NEC P402-TMX4P Beilage

Beliebte Monitor Handbücher anderer Marken

Linear Acoustic

Linear Acoustic LQ-1000 Bedienungsanleitung

AOC

AOC I2579V Bedienungsanleitung

Gateway

Gateway FPD1520 Bedienungsanleitung

Furuno

Furuno Mu 120c Bedienungsanleitung

Asus

Asus VB171D - 17" LCD Monitor Bedienungsanleitung

Dell

Dell S2230MX Gebrauchsanweisung

Philips

Philips 107C64 Bedienungsanleitung

Dell

Dell S2409WFP Bedienungsanleitung

EverFocus

EverFocus EN-7517E Bedienungsanleitung

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Bedienungsanleitung

Dell

Dell Precision 7680 Bedienungsanleitung

LG 50PM1M - - 50" Plasma Panel Bedienungsanleitung

Bosch

Bosch DDU 9 Bedienungsanleitung

Acer

Acer A231HL Bedienungsanleitung

Philips

Philips 86BDL4152T Bedienungsanleitung

Emay

Emay SleepO2 Bedienungsanleitung

IBM

IBM 6360 Montageanleitung

LG M1950D-PZ Bedienungsanleitung
