NEC MultiSync LCD300 Bedienungsanleitung

MultiSync LCD300

User’s Manual

Declaration of the Importer

We hereby certify that the

Color monitor LA-1332JSW

MultiSync LCD300

is in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 60555-2

- EN 60555-3

- EN 50082-1

(IEC 801-2)

(IEC 801-3)

(IEC 801-4)

and marked with

NEC Europe Ltd. Ismaning Office

Steinheilstraße 4-6

D-85737 Ismaning, Germany

Safety Instruction

Caution:

When operating the LA-1332JSW with a 220-240V AC power source in

Europe except UK, use the power cord provided with the monitor.

In UK, a BS approved power cord with moulded plug has a Black (five

Amps) fuse installed for use with this equipment. If a power cord is not

supplied with this equipment please contact your supplier.

When operating the LA-1332JSW with a 220-240V AC Power source

in Australia, use the power cord provided with the monitor.

For all other cases, use a power cord that matches the AC voltage of the

power outlet and has been approved by and complies with the safety

standard of your particular country.

IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of

International Business Machines Corporation.

Apple and Macintosh are registered trademarks of Apple Computer Inc.

Microsoft and Windows are registered trademarks of the Microsoft Corporation.

NEC is a registered trademark of NEC Corporation. ErgoDesign, IPM, OSM, ColorControl,

OptiClear, CROMACLEAR and Advanced Digital Control System are trademarks of NEC Home

Electronics, Ltd.

MultiSync is a registered trademark of NEC Technologies, Inc in U.S., and of NEC Home

Electronics, Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux,

Switzerland, Denmark, Finland, Norway and Saudi Arabia.

All other trademarks or registered trademarks are property of their respective owners.

English

Deutsch

Français

Italiano

Español

Appendix

English

Introduction to the NEC MultiSync LCD300

Congratulations on your purchase of the NEC MultiSync LCD300 true

color monitor!

True Color Monitor

The MultiSync LCD300 monitor incorporates NEC’s own l3" true color

active matrix thin-film-transistor (TFT) liquid crystal display to provide

superior display performance and a reduced footprint. Less than seven

inches in depth, the MultiSync LCD300 monitor is ideal for

environments with space and weight constraints that require superior

image quality. A high resolution of 1280 x 1024 and a fine dot pitch of

0.20mm are ideal for displaying complex graphics and high definition

images. The MultiSync LCD300 monitor also supports VGA graphics

and text modes. The MultiSync LCD300 monitor incorporates

easy-to-use digital controls to adjust positioning and image lock. This

LCD monitor also carries the MultiSync brand name, ensuring greater

compatibility with today’s sophisticated computer platforms.

Analog Advantage

Because NEC incorporates only its own patented analog LCD modules

into its MultiSync LCD monitors, the MultiSync LCD300 monitor is

capable of displaying over 16.7 million colors in a continuous spectrum,

providing a truer repesentation of color. Like its analog predecessors

based on CRT technology, the MultiSync LCD300 monitor displays a

continuous gray scale and does not require the use of dithering

techniques, a mainstay of digital LCD panels, to approximate

intermediate shades of gray. In addition, the monitor’s high contrast

LCD enhances color vibrancy and improves focus with no geometric

distortion.

Wider Compatibility

Adapting the latest advances in satellite technology to the circuitry

employed within the MultiSync LCD300 monitor, NEC provides wide

range compatibility with today’s graphics driver technology. Because

Introduction to the NEC MultiSync LCD300 E-1

the MultiSync LCD300 monitor is analog through and through, it does

not require special analog to digital display or interface cards but can

accept RGB input directly. Consequently, the same display cards that

are used to drive the Multisync LCD300 monitor can also be used to

drive standard CRT monitors. NEC’s MultiSync LCD300 monitor can

be used with a wide range of systems such as IBM PC compatible

computers, Macintosh and Power Macintosh, Sun workstations, Silicon

Graphics workstations and other workstations and x-terminals.

FullScan Capability

Using NEC’s own FullScan Capability, all of the resolutions supported

on the MultiSyn LCD300 monitor are displayed full screen, utilizing the

most of the monitor’s large display area. Rather than displaying

640 x 480 resolution as a small box in the center of the MultiSync

LCD300 monitor’s display, this VGA resolution is displayed full screen,

allowing for greater visibility.

Reduced Footprint

The MultiSync LCD300 monitor offers nearly the same viewable image

size as conventional 14-inch and 15-inch CRTs at 40% of the depth and

30% of the weight. With a depth of about 17cm and a weight of 4 kg,

the reduced footprint of NEC’s MultiSync LCD monitor provides the

ideal solution for environments requiring superior image quality but

with size and weight limitations. And the monitor’s small footprint and

low weight allow it to be moved or transported easily from one location

to another.

Low Power Consumption

The MultiSync LCD300 monitor has been designed with NEC’s IPM

(Intelligent Power Manager) System. When utilized with an Energy Star

system or display card, the MultiSync LCD300’s IPM System is an

innovative power saving utilily that complies with both the EPA’s

Energy Star requirements and Europe’s NUTEK power management

requirements. With a maximum power consumption of 40 watts, the

MultiSync LCD300 monitor consumes over 50% less power than

conventional CRTs and emits less heat. In its power saving mode, the

MultiSync LCD300 monitor consumes less than 8 watts. All this

E - 2 Introduction to the NEC MultiSync LCD300

translates into energy savings, environmental protection, reduced

emissions and reduced air conditioning costs of the work environment.

The MultiSync LCD300 monitor follows the Video Electronics Standard

Association (VESA) approved power-down signaling method. Endorsed

by the EPA, VESA’s Display Power Management Signaling (DPMS)

method is the power-down process a system should use to communicate

to the monitor to save power. Power-down functions can be utilized

only with an Energy Star system or display card which adheres to the

VESA DPMS standard. By using the monitor’s horizontal and vertical

SYNC signals, the monitor can be prompted into the different IPM

modes. The following is the description of the LED indicator for the

IPM power-saving modes:

Mode LED Indicator Power Consumption

ON Green Typical: 40 watts

Standby & Suspend Amber Typical: less than 8 watts

Power Switch OFF No Light No Power Used

ErgoDesign Features

The MultiSync LCD300 monitor utilizes NEC’s ErgoDesign features

philosophy that adapts technology to the way you work, increasing

productivity through enhancements in comfort and ease of use.

ErgoDesign features include a low glare screen treatment, power and

brightness controls that are positioned within easy reach, easy-to-use

digital controls and a tilt base that easily adjusts to each individual’s

preferred angle of vision.

Reduced Emissions

Incorporating NEC’s own Reduced Magnetic Field technology, the

MultiSync LCD300 monitor has minimal field emissions and follows the

strictest international magnetic field, alternating electric field and

electrostatic guidelines.

Introduction to the NEC MultiSync LCD300 E-3

Contents of Package

Included with your MultiSync LCD300 monitor are the following items:

–NEC MultiSync LCD300 (Model LA-1332JSW) true color

monitor.

–AC power cable.

–Video signal cable (15 pin mini D-sub male to 5 branched BNC

male).

–User’s manual.

Remember to save the original box and packing materials to transport or

ship this monitor.

E - 4 Contents of Package

Recommended Use

For optimum performance, please note the following when setting up

and using the MultiSync LCD300 color monitor:

•The optimum monitor position is facing away from direct

sunlight.

•Allow adequate ventilation around the monitor so that heat

can properly dissipate.

•Do not place any heavy objects on the power cord. Damage

to the cord may cause shock or fire.

•Use the monitor in a clean and dry area.

•Handle with care when transporting. Save packaging for

transporting.

•When operating the MultiSync LCD300 with its AC125-

240V worldwide power supply, use a power supply cord

that matches the power supply voltage of the AC power

outlet being used. The power supply cord you use shall be

employed one of the type H05VV-F with the earth pin,

which must have been approved by and comply with the

safety standards of your country.

•The power cable connector is the primary means of detaching

the system from the power supply. The monitor should be in-

stalled close to a power outlet which is easily accessible.

•Clean the LCD monitor surface with a lint-free, non-abrasive

cloth. Avoid using any cleaning solution, glass cleaner or tissue

paper.

•For optimum performance, allow 20 minutes for warm-up.

•Avoid displaying fixed patterns on the monitor for extremely

long periods of the time to avoid after-image effects.

•Avoid applying pressure to the LCD monitor surface.

Recommended Use E - 5
